Appendix D: BACnet PICS
D BACnet PICS
BACnet Protocol Implementation Conformance Statement (PICS)
Date: 2016-11-22
Vendor Name: HMS Industrial Networks AB
Product Name: Anybus Modbus to BACnet Gateway
Product Model Number: AB9900
Application Software Version: 1.0
Firmware Revision: 1.0.0.0
BACnet Protocol Revision: 12
Product Description:
Modbus – BACnet MS/TP & BACnet IP Gateway
Abstraction of Modbus Registers as BACnet Objects.
BACnet Standardized Device Profile (Annex L):
BACnet Operator Workstation (B-OWS)
BACnet Building Controller (B-BC)
BACnet Advanced Application Controller (B-AAC)
BACnet Application Specific Controller (B-ASC)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
Additional BACnet Interoperability Building Blocks Supported (Annex K):
Reference of BIBBs List
Segmentation Capability:
Segmented request supported
Segmented responses supported
Data Link Layer Options:
BACnet IP, (Annex J)
BACnet IP, (Annex J), Foreign Device
ISO 8802-3, Ethernet (Clause 7)
ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 57600, 76800, 115200
MS/TP slave (Clause 9), baud rate(s):
Point-To-Point, EIA 232 (Clause 10), baud rate(s):
Point-To-Point, modem, (Clause 10), baud rate(s):
LonTalk, (Clause 11), medium: _____
Other:
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with
MS/TP slaves and certain other devices.)
Networking Options:
Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
Annex H, BACnet Tunneling Router over IP
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices?
Character Sets Supported
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
ISO 10646 (UTF-8)
ISO 10646 (UCS-2)
Gateway
If this product is a communication gateway, describe the types of non-BACnet equipment/network(s) that the gateway supports:
Modbus RTU (EIA485) and TCP networks.
Modbus to BACnet Gateway User Manual
No Yes
No Yes
Yes No
Yes
IBM /Microsoft DBCS
ISO 10646 (UCS-4)
Window Size · 16 ·
Window Size · 16 ·
No
ISO 8859-1
JIS X 0208
54 (56)
SCM-1202-049 1.0
