Manual Blue Power Charger XLR Class II
Blue Power Charger
XLR Class II
Input voltage range
Frequency
Charge voltage 'absorption'
Charge voltage 'float'
Charge voltage 'storage'
Charge current (A)
Charge characteristic
Recommended battery capacity
Protection
Operating temp. range
Humidity (non condensing)
ENCLOSURE
Material & Colour
Battery-connection
230 V AC-connection
Protection category
Weight
Dimensions (L x W x H)
STANDARDS
Safety
Emission
Immunity
24/5
90-250 VAC
45-65 Hz
28,8 V
28 V
26,4 V
5 A
4-stage adaptive
20 to 50 Ah 30 to 80 Ah
Battery reverse polarity
Output short circuit Over temperature
-20 to +60°C (full rated output up to 40°C)
Max 95 %
ABS (blue RAL 5012)
Cable of 1,5m with male XLR connector
Cable of 2m with class II "Euro"plug (CE 7/16)
IP 21, Class II
1,34 kg
232 x 94 x 64 mm
EN60335-1, EN60335-2-29, EN12184, ISO7176-14
EN60601-1-2, EN61000-3-2, EN61000-3-3,
EN61000-6-3, EN55022, EN55014-1
EN60601-1-2, EN61000-6-2, EN55024, EN55014-2
24/8
8 A
U (V)
30 28,8 V
28
26
24
I (A)
bulk
8
6
4
2
Fig. 1
0
28,8 V
28,0 V
26,4 V
float storage
(max
(1 week)
24 h)
Rev 01
storage
(1 week)
