- Page 1 USER MANUAL Phoenix Charger 12/30 12/50 24/16 24/25 victron energy...
- Page 2 Victron Energy B.V. Victron Energy B.V. reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication and may not reflect the product at all times in the future.
-
Page 3: Safety And Regulatory Information
An additional grounding point is located at the outside of the product. Whenever it is likely that the grounding protection has been impaired, the product must be made inoperative and secured against any unintended operation; refer to qualified service personnel. victron energy... -
Page 4: Operation
Phoenix Charger will reduce its float voltage. By doing this we reduce the gassing in your battery so they will not run dry after a longer period of not using your battery. victron energy... -
Page 5: Remote Control
> 60 seconds the charger switches to The ambient Consult your electrician and temperature of the let him connect a Bulk mode and continues charging according battery is too high temperature sensor normal charging characteristic. victron energy... -
Page 6: Installation
• Socketdriver & socket 10 mm. • Screwdriver no. 2. • Crosshead screwdriver no. 2 phillips. • Battery cables and external fuse: Model Length 0 - 6 m Fuse 12/30 16 mm² 40 AT 12/50 25 mm² 60 AT 24/16 10 mm²... - Page 7 PHOENIX CHARGER CONTROL PHOENIX CHARGER CONTROL PHOENIX CHARGER CONTROL DOUBLE POLE SWITCH & CIRCUIT BREA KER 12/50: 60AT 25AT 12/50: 60AT 12/30: 40AT 12/30: 40AT 24/25: 30AT 24/25: 30AT 24/16: 20AT 24/16: 20AT STARTER BA T TERY BATTERY 2 BATTERY 1...
- Page 8 • Keep the pushbutton ⇑ and/ or ⇓ pushed while 20AT 20AT 20AT 20AT switching off. • The factory settings are restored. Restoring defaults When ready • Connect battery and if applicable Voltage sense and Temperature sense. • Replace the frontplate. victron energy...
- Page 9 The optimum absorption voltage of flat plate lead acid batteries depends on mechanical and chemical properties. Batteries with high antimony doping can general be charged with a lower absorption voltage than batteries with low antimony doping, like the Victory carbon fibre battery. (See the book "Electricity on board" at www.victronenergy.com victron energy...
- Page 10 ‘dead’ battery. Return to factory defaults • Switch the charger on. • Keep the pushbutton ⇑ and/ or ⇓ pushed while switching off. • The factory defaults are restored. • Replace the frontplate. victron energy...
-
Page 11: Specifications
SPECIFICATIONS Model 12/50 12/30 24/25 24/16 Nominal input voltage range 120 - 240 Vac Absolute minimum working voltage 90 Vac Absolute maximum working voltage 265 Vac Frequency range 45 - 65 Hz Maximum input current 4A/230 Vac 10A/120 Vac Powerfactor (cos ϕ ) ≈1... - Page 12 (for 12V and 24V charger, temperature compensated). This will limit water loss to a minimum when the battery is stored for the winter season. After an adjustable time (default = 7 days) the charger will enter Repeated Absorption-mode for an adjustable time (default = 4 quarters ). victron energy...
- Page 13 1 1 0 1 2 0 1 3 2 1 5 0 1 7 0 1 8 7 2 3 0 U i n Figure 3: Maximum output current vs. input voltage: Output voltage = 12.0V / 24.0V victron energy...
-
Page 14: Default Factory Settings
29.6 V 14.0 V / 13.0V 28.0 V / 26.0V 5 hrs model model model model Factory defaults can always be restored by your authorized Victron Energy dealer. Acting sequence is described in the installation part of the manual. victron energy... - Page 15 energy...
- Page 16 Serialnumber: Dealer: Victron Energy B.V. The Netherlands Phone ** 31 36 535 97 00 ** 31 36 531 16 66 Customer support desk ** 31 36 535 97 77 E-mail sales@victronenergy.com Internet site http://www.victronenergy.com Article Number ISM010001000 Revision rev01 Date...
