Adjusting the range of TRAVEL and resistance FORCE of the brake pedal (with
no BRAKE MOD installed)
- Install the metal stop (23) at the rear of the brake pedal arm.
- Select your choice of position (Long, Medium or Short range of travel), and then tighten the 4 M3-
type Allen screws (8) using the included 2.5 mm Allen key (20).
Long travel and strong
resistance (default)
- Long travel with resistance of approximately 22 lbs / 10 kg
- Medium travel with resistance of approximately 18.7 lbs / 8.5 kg
- Short travel with resistance of approximately 15.4 lbs / 7 kg
Note: the longer the travel, the stronger the pedal's resistance (and vice versa)
Medium travel and
medium resistance
Long travel and strong
resistance (default)

Number of possible travel or resistance positions:

9/17
Short travel and
weak resistance
Short travel and
weak resistance
.
