Management
BMC Controller
ASPEED AST2400
IPMI Dedicated
- 1 x Realtek RTL8211E for dedicated management GLAN
GLAN
Features
- Watch Dog
- NMI
Graphics
Controller
ASPEED AST2400
VRAM
DDR3 16MB
Rear Panel I/O
VGA Port
1 x D-Sub
USB 3.0 Port
2
USB 2.0 Port
2
LAN Port
EP2C612D24:
2 + 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
EP2C612D24-4L:
4 + 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
Serial Port
1 (COM1)
UID Button/
1
LED
Internal Connector
Auxiliary Panel
1 (includes chassis intrusion, location button & LED, front
Header
LAN LED, and system event LED)
TPM Header
1
IPMB Header
1
Fan Header
2 x CPU Fans, 6 x system Fans (4-pin)
ATX Power
1 (24-pin) + 2 (8-pin)
USB 3.0 Header
1 (supports 2 USB 3.0 ports)
USB 2.0 Header
1 (supports 2 USB 2.0 ports)
Type A USB 3.0
1
Port
System BIOS
BIOS Type
128 Mb AMI UEFI Legal BIOS
BIOS Features
- Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
EP2C612D24 / EP2C612D24-4L
3
