SmartWitness KP1S + SVC400

Installation Guide

v.1.2
+
WARNING: SmartWitness installations should be performed by a qualified individual or
installation professional only. Working with a vehicle's power system can be dangerous to
both you and your vehicle. This installation is intended only to be a guide since vehicle
designs and power/input sources can vary significantly from vehicle to vehicle.
If you need to schedule a professional installation service in the USA for your SmartWitness
device(s), please visit
http://smartwitness.com/scheduleinstall
and submit the online form.
www.smartwitness.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the KP1S and is the answer not in the manual?

Questions and answers

Related Manuals for SmartWitness KP1S

Summary of Contents for SmartWitness KP1S

  • Page 1: Installation Guide

    This installation is intended only to be a guide since vehicle designs and power/input sources can vary significantly from vehicle to vehicle. If you need to schedule a professional installation service in the USA for your SmartWitness device(s), please visit http://smartwitness.com/scheduleinstall...
  • Page 2 Modem* *Depending on the order, the 3G Modem and/or SD card may or may not be included. **SD Cards, Secondary camera, Power Adaptor, and 3G modems may be in a separate package from the KP1S (common in large, bulk orders).
  • Page 3 SD Card Slot Camera 3 Input SD Door Power Input (Red = IGN+, Black = GND) & 12v Alarm Input Rear View Triggers (optional) Camera 4 Input Panic Button Camera 1 input (optional) Camera 2 input GPS Input (optional) www.smartwitness.com...
  • Page 4 KP1S connected with SVC400 “KP1- SVC400-AV” www.smartwitness.com...
  • Page 5 Video output to KP1S ch2 input. Connecting Cameras 1, 2, & 3 (5V, 2.5mm stereo) to SVC400 All SmartWitness 5V cameras can plug n play into camera channels 1, 2, & 3 on SVC400 Compatible camera models end in “-S”, such as the SVA033-S All”-S”...
  • Page 6 # 4 trigger wire to rear backup sensor. The camera will display full “RCA-Y-SPLT” screen when the trigger wire receives 12V. Link to download SmartWitness 7” LCD (to Camera) monitor data sheet (PDF) (to 12V Power and ground) (to LCD Monitor) www.smartwitness.com...
  • Page 7 Link to download SVCSPWK-BW2 datasheet (PDF www.smartwitness.com...
  • Page 8 It stretches 300% and is fully fused within 24 hours after application. It is best to stretch the tape, start from one end and overlap at an angle until you reach the other end of the connector. www.smartwitness.com...

  • Page 9: Final Steps

    & 3G modem), you can turn on vehicle ignition and the KP1S will power on. There will be a sequence of LED lights cycling during boot process. Once boot up is complete, there will be a solid blue light. This indicates proper operation and recording.

  • Page 10: Troubleshooting

    If Link LED is OFF, check the USB connection of the cable and modem  If Link LED is blinking and the KP1S Green LED is also blinking, it may be a camera  configuration issue or server issue. Please contact SmartWitness.
