Installation Guide v.1.2 WARNING: SmartWitness installations should be performed by a qualified individual or installation professional only. Working with a vehicle's power system can be dangerous to both you and your vehicle. This installation is intended only to be a guide since vehicle designs and power/input sources can vary significantly from vehicle to vehicle.
1. Overview: The SVC1080-LCS is a 1080P Full HD accident camera for commercial vehicles. SVC1080-LCS features an integrated 3-Axis G-sensor, microphone, integrated GPS receiver, permanent power cable, and a tamper-resistant design. SDHC storage, up to 64GB. Mac and PC analysis software included.
Page 3
Benefits The SVC1080-LCS features a full HD (1080P), 170° lens to provide a comprehensive view of any incident. The LCS will record exactly what happened before, during and after an incident. It does this by recording the following information: drivers view of the road, vehicle location, impact force of accident, audio, and driving style such as the following: speed, acceleration, braking, and steering.
Page 4
2. SVC1080-LCS Overview Windshield mount a. Front + Adhesive tape Camera Lens Tamper Resistant Power Cable Locking Cover b. Rear Panic Button Status LEDs G-sensor calibration button www.smartwitness.com...
(use the windshield as a guide to determine the angle (see the image at step #4 ). Push the bracket back into the body and secure it first with the bracket lock and then the bracket lock screw, as seen below www.smartwitness.com...
Page 6
4. Attach the provided 3M adhesive pad to the SVC1080-LCS bracket and press firmly. 5. Secure the SVC1080-LCS to the windscreen behind the rear view mirror, below the A1 line. The camera lens should be as high on the windshield as possible, but still within the windshield wiper zone.
Page 7
Optional (verify with customer if white, Alarm Out 1 blue, green, or yellow wires will be used) Alarm Out 2 3. OPTIONAL remote switch installation (your SVC1080-LCS may not include this accessory) Remote SW+ Remote SW- Model # SW-PB www.smartwitness.com...
5. Final Steps After installation of the SVC1080-LCS into the vehicle, you can turn on vehicle ignition and the camera will power on. There will be a sequence of BLUE/RED LED lights cycling during boot process. Once boot up is complete. There will be a solid blue light. This means proper operation and recording.
Use a multimeter to ensure the camera is receiving proper voltage o If connecting to fuse panel, check the vehicle fuse o Check the in-line fuse located on the red power cable of the SVC1080-LCS o *If none of these work, please contact SmartWitness The Blue LED is off and the Red light is blinking ...
