DIAGNOSTICS AND STREAM STATISTICS
lost(2)}
off(2)}
The Zephyr iPort PLUS SNMP extension agent requires Windows SNMP feature to be installed. To install this
feature, navigate to Start, Control Panel, Programs and Features and select Turn Windows features on or off. Select
"Simple Network Management Protocol (SNMP)" and press OK to install it.
Once the Windows SNMP feature is installed, it needs to be configured. Open Windows Services control panel by
navigating to Start, Control Panel, Administrative Tools and with administrative privileges open Services item:
Locate the "SNMP Service" item, right-click and select Properties.
♦
Enter Contact and Location information in the Agent tab and select the SNMP Service type.
♦
Configure the access information in the Security tab. Use community "public" and READ_ONLY rights to
♦
set up a public access.
If needed, set up an IP address which will receive the generated traps in the Traps tab.
♦
Press Apply. You may also need to restart the SNMP Service for these changes to take effect.
♦
SNMP Security
SNMP 'Communities' serve as passwords for this function. Go into the Read: and Write: boxes to enter text that is
specified for the read/write strings on the SNMP Manager monitoring device. As with similar text-entry screens,
execute a Save after entering.
SNMP Traps
When Zephyr iPort PLUS initiates an alarm as opposed to being queried or polled for one, the alarm is known as a
'trap.'
SNMP Ports
The default SNMP Ports, General Port 161 and Trap Port 162, are the default for most SNMP operations. These
may be changed as needed in the usual way.
-32- Decoder LW audio OK (var: index)
-33- Decoder LW audio lost (var: index)
-34- Decoder WAN jitter alarm (var: index)
-35- Decoder WAN sequence alarm (var: index)
-37- Decoder general alarm (var: index)
-10- encoder
-10- operational state: Integer {on(1), off(2)}
-11- LW receive state: Integer {ok(1),
-12- LW audio state: Integer {ok(1), lost(2)}
-11- decoder
-10- operational state: Integer {on(1),
-11- WAN receive state: Integer {ok(1),
-12- LW audio state: Integer {ok(1), lost(2)}
SECTION 7 |
42
lost(2)
