Setting the Time

Zephyr iPort PLUS maintains a very accurate clock by connecting to an NTP time server. Once the network
connections are established, you can set it up.
From the main menu, go to the Options page. Under NTP Synchronization, enter the IP address for primary and
secondary NTP servers. Click the Synchronize clock with NTP server box and click Apply. You should see the NTP
status change to 'Reached, SYNC'.
Under Time zone configuration, set your GMT offset and click Apply.
For web addresses and status information about time servers maintained in the United States by NIST, visit
<http://tf.nist.gov/tf-cgi/servers.cgi>.
To find out more about NTP time servers globally, visit <http://www.pool.ntp.org/en/>.

Changing Passcodes

User passcodes may be changed from their default settings on the System page. You can do this for both the front
panel OLED/knob and Web access.
Default for the OLED/knob is <blank>, meaning no password is needed.
Default for the Web interface is also <blank>.

Backing-up and Restoring Configuration

Backup and Restore of the iPort PLUS system configuration is done on the System page.
It can be time-consuming to enter all the needed Zephyr iPort PLUS configuration values. So we give you a way to
save them all in a file on your local PC. This can also be used to "clone" additional Zephyr iPort PLUS units after you
have configured the first in a multiple Zephyr iPort PLUS installation. (Don't forget to change the Host name, IP
numbers, etc. before connecting to your network...).
You can also reset Zephyr iPort PLUS to the factory defaults by using the Reset cfg button.

Restart

This is on the System page.
Clicking the Restart button causes Zephyr iPort PLUS to restart, while retaining all the current configuration
values.
