INTRODUCTION

1
Introduction

Welcome to Zephyr iPort PLUS

Welcome to Zephyr iPort PLUS, a Livewire
transport of multiple channels of mono and stereo audio across any QoS-enabled IP network, including T1 and T3
connections, as well as private WANs with MPLS (MultiProtocol Label Switching). It is the perfect solution for
large-scale distribution of audio to single or multiple locations.
Zephyr iPort PLUS represents the natural evolution of the original Zephyr iPort, with several additions and
enhancements, including:
Sixteen bi-directional IP-audio codecs, each capable of compressed or linear audio transport at bit rates
♦
ranging from 24 kbps to 2.4 Mbps.
Up to eight IP stream destinations per encoder.
♦
UDP, TCP and Multicast stream types independently configurable per WAN stream.
♦
SHOUTcast interface support.
♦
Associated data transmission via three uni-directional (RS-232 style) user data channels per each audio
♦
direction per codec.
Optional SSD (Solid State Drive) Content Delay with dynamic storage space allocation, configurable per
♦
codec with synchronized delay of GPIO and user data channels.
NTP synchronization for content delay on absolute time.
♦
Increased GPIO capacity to 20 independent uni-directional contact closures per codec per transmit
♦
direction.
Virtual endpoints, with all the same logic as attached to hardware circuits.
¸
Cut-in logic for snake between hardware GPIO nodes.
¸
Cut-in logic for Element to hardware GPIO link.
¸
Element console emulation logic.
¸
GPIO node emulation logic.
¸
Remote status signaling and control using virtual GPIO pins.
¸
-to-MPEG/-aptX Enhanced/-linear PCM gateway that enables the
® ®
