OUTLINE DIMENSIONS

0° MIN
1.05
1.00
0.95
0.15
SEATING
0.05 0.08 MAX
PLANE
COPLANARITY
VIEW A
ROTATED 90 ° CCW
1.40 MAX
16.00 BSC SQ
1.20
0.75
MAX
0.60
0.45
100
1
PIN 1
TOP VIEW
(PINS DOWN)
0.20
0.09
25
7°
26
3.5°
VIEW A
0°
COMPLIANT TO JEDEC STANDARDS MS-026-AED-HD
Figure 71. 100-Lead Thin Quad Flat Package, Exposed Pad [TQFP_EP]
Dimensions shown in millimeters
10.10
10.00
9.90
BALL A1
INDICATOR
TOP VIEW
DETAIL A
COMPLIANT WITH JEDEC STANDARDS MO-205-AC.
Figure 72. 144-Ball Chip Scale Package, Ball Grid Array [CSP_BGA]
Dimensions shown in millimeters
14.00 BSC SQ
76
76
75 75
51 51
50 50
0.50 BSC
LEAD PITCH
(SV-100-3)
9 7
12 11 10
8
8.80
BSC SQ
BOTTOM VIEW
0.80 BSC
DETAIL A
0.43 MAX
0.25 MIN
0.55
0.50
0.45
BALL DIAMETER
(BC-144-1)
Rev. B | Page 44 of 48
100
1
EXPOSED
9.50 SQ
PAD
BOTTOM VIEW
(PINS UP)
25
26
0.27
0.22
FOR PROPER CONNECTION OF
THE EXPOSED PAD, REFER TO
0.17
THE PIN CONFIGURATION AND
FUNCTION DESCRIPTIONS
SECTION OF THIS DATA SHEET.
A1 CORNER
INDEX AREA
5 3 1
6 4 2
A
B
C
D
E
F
G
H
J
K
L
M
1.00
0.85
COPLANARITY
SEATING 0.12 MAX
PLANE
