Range covered by each camera

The illustration shown here is an example. As such, the actual visible area
may be different. See P. 302 for information about the visual range of each
camera.
2-4. Using other driving systems
*
Front monitor
Side-front simultaneous dis-
*
play monitor
Side-rear simultaneous dis-
*
play monitor
Rear monitor
*
: Range of wide view front & side
monitor display (The monitor for
side displays left side only.)
2
289
