Page 1 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove compartment as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 2: How To Use This Manual
Illustrations complement the words of caution is ignored. the manual to best explain how to enjoy your Mazda. By reading your manual, you can nd out about the features, important safety information, and driving under NOTE various road conditions.
Page 3: Table Of Contents
Table of Contents Pictorial Index Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 5: Pictorial Index
Pictorial Index Interior, exterior views and part identi cation of your Mazda. Interior Overview (Left-Hand Drive Model)........1-2 Interior Equipment (View A) ............1-2 Interior Equipment (View B) ............1-4 Interior Equipment (View C) ............1-5 Interior Overview (Right-Hand Drive Model) ........ 1-6 Interior Equipment (View A) ............
Page 6 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View A) Lighting control..................... page 4-70 Turn and lane-change signal ................. page 4-80 Wiper and washer lever ..................page 4-81 Tyre pressure monitoring system set switch ............page 4-230 DSC OFF switch ....................page 4-99 i-stop OFF switch ....................
Page 7 Hazard warning asher switch ................page 4-88 Steering shift switches ..................page 4-64 Lock release lever ....................page 3-38 Bonnet release handle ................... page 6-20 Remote fuel- ller ap release ................page 3-36 1–3 The equipment and installation position varies by vehicle...
Page 8 Electric parking brake switch ................page 4-90 Drive selection switch ..................page 4-109 CD/DVD player ...................page 5-56 , 5-60 Fuse block (Left side) ................... page 6-66 Storage pocket ..................... page 5-155 1–4 The equipment and installation position varies by vehicle...
Page 9 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View C) Seat belts ....................... page 2-17 SRS air bag......................page 2-43 Bottle holder ......................page 5-154 Sunvisor ......................page 5-148 Vanity mirror ....................... page 5-148 Overhead lights ....................page 5-148 Sunroof switch ......................
Page 10 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF switch ........................page 4-173 Parking sensor switch..................page 4-248 Headlight levelling switch ..................page 4-76 Rear sunshade switch ..................page 5-159 1–6 The equipment and installation position varies by vehicle...
Page 11 Instrument panel illumination knob ..............page 4-28 Cruise control switch ................page 4-159 , 4-222 Remote fuel- ller ap release ................page 3-36 Bonnet release handle ................... page 6-20 Steering shift switches ..................page 4-64 Lock release lever ....................page 3-38 1–7...
Page 12 Electric parking brake switch ................page 4-90 Commander switch ....................page 5-40 Shift lever/Selector lever ................page 4-55 , 4-58 CD/DVD player ...................page 5-56 , 5-60 Glove compartment ..................... page 5-156 Fuse block ......................page 6-66 1–8 The equipment and installation position varies by vehicle...
Page 13 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View C) Rearview mirror ....................page 3-42 Sunvisor ......................page 5-148 Vanity mirror ....................... page 5-148 Overhead lights ....................page 5-148 Sunroof switch ...................... page 3-47 Bottle holder ......................page 5-154 SRS air bag......................
Page 14: Exterior Overview
Pictorial Index Exterior Overview (Saloon) Bonnet ........................page 6-20 Windscreen wiper blades ..................page 6-32 Sunroof ........................page 3-47 Doors and keys ...................... page 3-13 Fuel- ller ap ......................page 3-36 Wheels and Tyres ....................page 6-42 Exterior lights ......................page 6-46 Boot lid ........................
Page 15 Doors and keys ...................... page 3-13 Fuel- ller ap ......................page 3-36 Wheels and Tyres ....................page 6-42 Exterior lights ......................page 6-46 Rear window wiper blade ..................page 6-34 Liftgate ........................page 3-21 Child safety locks ....................page 3-21 Outside mirror ....................... page 3-39 1–11...
Page 16 MEMO 1–12...
Page 17: Essential Safety Equipment
Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ..................... 2-2 Seat Precautions ................2-2 Front Seat ..................2-5 Rear Seat ..................2-11 Head Restraints ................2-15 Seat Belt Systems ................2-17 Seat Belt Precautions ..............
Page 18 The front seats contain air bag components essential to the supplementary restraint system. Such modi cations could damage the supplementary restraint system and result in serious injury. Consult an Authorised Mazda Repairer if there is any need to remove or reinstall the front seats.
Page 19: Before Driving
Essential Safety Equipment Seats WARNING Do not drive with either front seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 20 Essential Safety Equipment Seats WARNING Always leave your car locked and keep the car keys safely away from children (Saloon): Leaving your car unlocked or the keys in reach of children is dangerous. Children who nd their way into the boot through an unlocked rear seatback or an open boot can become accidentally locked in the boot.
Page 21 Essential Safety Equipment Seats Front Seat Seat Operation Power operation Seat Slide (Manual Seat) To move a seat forward or backward, raise the lever and slide the seat to the desired position and release the lever. Make sure the lever returns to its original position and the seat is locked in place by attempting to push it forward and backward.
Page 22 To increase the seat rmness, move the lever forward. Move the lever backward to decrease rmness. (Power Operation) To increase the seat rmness, press and hold the front part of the switch to the desired position, then release it. Press the rear part of the switch to decrease rmness. 2–6...
Page 23 Essential Safety Equipment Seats Seat Warmer WARNING The front seats are electrically heated. The ignition must be switched ON. Be careful when using the seat Press the seat warmer switch while the warmer: ignition is switched ON to operate the seat The heat from the seat warmer may be warmer.
Page 24 Essential Safety Equipment Seats NOTE CAUTION Use the seat warmer when the engine Before folding a rear seatback, is running. Leaving the seat warmer make sure that the rear seat warmer on for long periods with the engine switch is off. If a rear seatback is not running could cause the battery folded while the rear seat warmer power to be depleted.
Page 25: Driving Position Memory
5. Press the SET button on the seat until a ngers or hands could get pinched and beep sound is heard one time. injured. 6. Perform one of the following settings within 5 seconds of completing step 5 above: SET button...
Page 26 (button 1 or 2). 5. Start the engine. 5. A beep sound is heard when the driving 6. The active driving display adjustment position adjustment is completed. begins. NOTE NOTE If the driving position movement is If there is no driving position not changed, only the beep sounds.
Page 27 Essential Safety Equipment Seats Erasing programmed driving positions Rear Seat (Erasing the driving positions Split Folding programmed to the key) By lowering the rear seatbacks the luggage 1. Switch the ignition OFF. compartment space can be expanded. 2. Press the SET button on the side of the seat until a beep sound is heard one WARNING time.
Page 28 Essential Safety Equipment Seats WARNING CAUTION When transporting cargo, do not allow (Wagon) the cargo to exceed the height of the When folding the seatback forward, seatbacks. always support the seatback with your Transporting cargo stacked higher hand. If it is not supported by a hand, than the seatbacks is dangerous ngers or the hand pressing the push as visibility to the rear and sides of...
Page 29 Essential Safety Equipment Seats (Saloon) 3. Using remote handle Open the liftgate and lower the 1. (With rear seat warmer) seatback you want to fold down using Turn the rear seat warmer switch off. the remote handle. Refer to Seat Warmer on page 2-7 . Using push knob 2.
Page 30 Essential Safety Equipment Seats To return the seatback to its upright 1. Insert the 3-point seat belt into the belt position: clip. 2. Press the seatback rearward and lock it in place. After returning the seatback WARNING to its upright position, make sure it is securely locked.
Page 31: Height Adjustment
Essential Safety Equipment Seats Head Restraints Front outboard seat Your vehicle is equipped with head restraints on all outboard seats and the rear centre seat. The head restraints are intended to help protect you and the passengers from neck injury. WARNING Always drive with the head restraints installed when seats are being used and...
Page 32 Essential Safety Equipment Seats Removal/Installation CAUTION To remove the head restraint, pull it up while pressing the stop-catch. When installing a head restraint, To install the head restraint, insert the legs make sure that it is installed into the holes while pressing the stop- correctly with the front of the head catch.
Page 33: Seat Belt Systems
Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. All the seats have lap/shoulder belts. These belts also have retractors with inertia locks that keep them out of the way when not in use.
Page 34 Essential Safety Equipment Seat Belt Systems WARNING Positioning the Shoulder Portion of the Seat Belt: Improper positioning of the shoulder portion of the seat belt is dangerous. Always make sure the shoulder portion of the seat belt is positioned across your shoulder and near your neck, but never under your arm, on your neck, or on your upper arm.
Page 35 Belt retraction may become dif cult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to "Seat Belt Maintenance" (page 6-78 ). Ring Pregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts.
Page 36 If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an expert repairer, we recommend an Take up slack Authorised Mazda Repairer. Keep low on hip bone Front Shoulder Belt Adjuster Too high...
Page 37 Essential Safety Equipment Seat Belt Systems Seat Belt Warning Systems Front Seat Belt Pretensioner and Load If it detects that the occupant seat belt is unfastened, the warning light or beep Limiting Systems alerts the occupant. Refer to Taking Action on page 7-45 . For optimum protection, the driver and Refer to Seat Belt Warning Beep on page front passenger seat belts are equipped...
Page 38 Have systems cannot provide adequate an expert repairer, we recommend an protection in an accident and this Authorised Mazda Repairer safely could result in serious injury. For more dispose of the pretensioner system or details about wearing seat belts, refer scrap a pretensioner system equipped to "Fastening the seat belts"...
Page 39 Essential Safety Equipment Seat Belt Systems NOTE The pretensioner system may not operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2-57 ). Some smoke (non-toxic gas) will be released when the air bags and pretensioners deploy.
Page 40: Child Restraint
Essential Safety Equipment Child Restraint Child-Restraint Precautions Mazda strongly urges the use of child-restraint systems for children small enough to use them. Mazda recommends use of a Mazda genuine child-restraint system or one that complies with the UNECE 44 regulation. If you would like to purchase a Mazda genuine child-restraint system, please contact an Authorised Mazda Dealer.
Page 41 Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident.
Page 42 Essential Safety Equipment Child Restraint WARNING Extreme Hazard! Never use a rear-facing child-restraint system on the front passenger seat with an air bag that could deploy: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 43 Essential Safety Equipment Child Restraint WARNING Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child.
Page 44 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with ISOFIX anchors for attachment of ISOFIX child-restraint systems in the rear. When using these anchors to secure a child-restraint system, refer to “ISOFIX Anchor-Secured Child-Restraint Systems” (page 2-39 ).
Page 45 9 kg — 18 kg (20 lb — 40 lb) 3 to 7 years old 15 kg — 25 kg (33 lb — 55 lb) 6 to 12 years old 22 kg — 36 kg (48 lb — 79 lb) (Other countries) Please comply with the legal regulations concerning the use of child-restraint systems in your country.
Page 46 Essential Safety Equipment Child Restraint Child-Restraint System Types Child seat Equal to Group 1 of the UNECE 44 (Europe and countries conforming to regulation. the UNECE 44 regulation) In this owner's manual, explanation of child-restraint systems secured with seat belts is provided for the following three types of popular child-restraint systems: baby seat, child seat, junior seat.
Page 47 Essential Safety Equipment Child Restraint Baby Seat Installation Position WARNING A baby seat is used in the rear-facing position only. Always install a baby seat in the correct seat position: Installing a baby seat without rst consulting the table “Child-Restraint System Suitability for Various Seat Positions”...
Page 48 Essential Safety Equipment Child Restraint Child Seat Installation Position Rear-facing type A child seat is used in front-facing and WARNING rear-facing positions depending on the age and size of the child. When installing, follow the manufacturer's instructions in Always install a rear-facing child seat accordance with the appropriate age and in the correct seat position: size of the child as well as the directions...
Page 49 Essential Safety Equipment Child Restraint Front-facing type Junior Seat Installation Position A junior seat is used in the front-facing WARNING position only. Never install a front-facing child seat in the wrong seat position: Installing a front-facing child seat without rst consulting the table “Child-Restraint System Suitability for Various Seat Positions”...
Page 50 Essential Safety Equipment Child Restraint WARNING Always install a junior seat in the correct seat position: Installing a junior seat without rst consulting the table “Child-Restraint System Suitability for Various Seat Positions” is dangerous. A junior seat installed on the wrong seat position cannot be properly secured.
Page 51 IL = suitable for particular ISOFIX child-restraint systems (CRS). These ISOFIX CRS are those of the “speci c vehicle”, “restricted” or “semi-universal” categories. A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog.
Page 52 Child Restraint (Except Europe) Regarding child-restraint systems which can be installed to your Mazda, consult an expert repairer, we recommend an Authorised Mazda Repairer. X = ISOFIX position not suitable for ISOFIX child-restraint systems in this mass group and/or this size class.
Page 53 Essential Safety Equipment Child Restraint NOTE When installing a child-restraint system, the following points must be observed: Always remove the head restraint before installing a child-restraint system. In addition, always use a tether strap and attach it securely. Refer to Head Restraints on page 2-15 .
Page 54 Essential Safety Equipment Child Restraint Installing Child-Restraint WARNING Systems Always attach the tether strap to the Anchor Bracket correct tether anchor position: Attaching the tether strap to the Anchor brackets for securing child- incorrect tether anchor position is restraint systems are equipped in the dangerous.
Page 55 Essential Safety Equipment Child Restraint WARNING WARNING Always remove the head restraint and Always install the head restraint and set the tether strap: adjust it to the appropriate position Routing the tether strap on top of after removing the child-restraint the head restraint is dangerous.
Page 56 6. If your child-restraint system came near or around the ISOFIX anchors. equipped with a tether, that probably Always follow the child-restraint system means it is very important to properly manufacturer's instructions.
Page 57 Essential Safety Equipment Child Restraint WARNING WARNING Always attach the tether strap to the Always remove the head restraint and correct tether anchor position: set the tether strap: Attaching the tether strap to the Routing the tether strap on top of incorrect tether anchor position is the head restraint is dangerous.
Page 58 Essential Safety Equipment Child Restraint WARNING Always install the head restraint and adjust it to the appropriate position after removing the child-restraint system: Driving with the head restraint removed is dangerous as impact to the occupant's head cannot be prevented during emergency braking or in a collision, which could result in a serious accident, injury or death.
Page 59: Srs Air Bags
Essential Safety Equipment SRS Air Bags Supplementary Restraint System (SRS) Precautions The front and side supplementary restraint systems (SRS) include different types of air bags. Please verify the different types of air bags which are equipped on your vehicle by locating the “SRS AIRBAG”...
Page 60 Essential Safety Equipment SRS Air Bags WARNING Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to in ate only in the rst accident, such as frontal, near frontal or side collisions that are at least moderate.
Page 61 Essential Safety Equipment SRS Air Bags WARNING Sit in the centre of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them, or sleeping up against the door or hanging out the windows is extremely dangerous. The side and curtain air bags in ate with great force and speed directly expanding along the door on the side the car is hit.
Page 62 An expert repairer, we recommend an Authorised Mazda Repairer can provide the special care needed in the removal and installation of front seats. It is important to protect the air bag wiring and connections to assure that the bags do not accidentally deploy and the seats retain an undamaged air bag connection.
Page 63 Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury could result. Have an expert repairer, we recommend an Authorised Mazda Repairer safely dispose of the air bag system or scrap an air bag equipped vehicle.
Page 64 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 65 Essential Safety Equipment SRS Air Bags Front Passenger Air Bag Deactivation Switch WARNING Do not deactivate the front passenger air bag unnecessarily: Unnecessary deactivation of the front passenger air bag is dangerous. If turned off unnecessarily, the front passenger will not receive the added protection of the air bag. Serious injuries or even death could occur.
Page 66 NOTE Have the front passenger air bag deactivation switch inspected by an expert repairer, we recommend an Authorised Mazda Repairer if any of these conditions occur: The front passenger air bag deactivation indicator light does not illuminate for a speci ed period of time when the ignition is switched ON.
Page 67 Essential Safety Equipment SRS Air Bags Switch Positions Before driving, always con rm that the front passenger air bag deactivation switch is in the appropriate position using the auxiliary key according to your requirements. WARNING Do not leave the key in the front passenger air bag deactivation switch: Unintentional deactivation of the front passenger air bag is dangerous.
Page 68 Essential Safety Equipment SRS Air Bags Front passenger front air bag, side air bag, and front passenger seat belt pretensioner operate. Activate the system only when a child-restraint system is not installed on the front passenger seat. Switching to ON position 1.
Page 69 Essential Safety Equipment SRS Air Bags Supplementary Restraint System Components Driver/Front passenger in ators and air bags Crash sensors, and diagnostic module (SAS unit) Seat belt pretensioners (page 2-21 ) Front air bag sensors Side crash sensors Air bag/seat belt pretensioner system warning light (page 4-47 ) Side and curtain in ators and air bags Front passenger air bag deactivation indicator light (page 2-49 )
Page 70 SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 71 Essential Safety Equipment SRS Air Bags Front Passenger Air Bag The front passenger air bag is mounted in the front passenger instrument panel. The in ation mechanism for the front passenger air bag is the same as the driver's air bag. For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"...
Page 72 Essential Safety Equipment SRS Air Bags Curtain Air Bags The curtain air bags are mounted in the front and rear window pillars, and the roof edge along both sides. When the air bag crash sensors detect a side impact of greater than moderate force, the curtain air bag in ates quickly and helps to reduce injury mainly to the rear outboard passenger's head caused by directly hitting interior parts such as a door or window.
Page 73 Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal collision A severe side collision A rear collision equipment...
Page 74 Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity. Limitations to front/near front collision detection: The following illustrations are examples of front/near front collisions that may not be detected as severe enough to deploy the SRS air bag equipment.
Page 75 Essential Safety Equipment SRS Air Bags Limitations to side collision detection: The following illustrations are examples of side collisions that may not be detected as severe enough to deploy the SRS air bag equipment. Side impacts with two-wheeled vehicles Side impacts involving trees or poles Roll-over 2–59...
Page 76 MEMO 2–60...
Page 77 Before Driving Use of various features, including keys, doors, mirrors and windows. Keys ............3-2 Security System ......... 3-50 Keys ..........3-2 Modi cation and Add-On Keyless Entry System ....3-3 Equipment ........3-50 Immobilizer System ..... 3-50 Advanced Keyless Entry System ..3-9 Theft-Deterrent System Advanced Keyless Entry (With the Intrusion Sensor)
Page 78 The key is near electronic devices to be an interesting toy to play with such as personal computers. and could cause the power windows or Non-Mazda genuine electronic other controls to operate, or even make equipment is installed in the the vehicle move.
Page 79 Operating the theft-deterrent system is also possible on theft-deterrent system- If your key (auxiliary key) is lost, consult equipped vehicles. your Authorised Mazda Repairer and have your code number ready. System malfunctions or warnings are indicated by the following warning lights NOTE or beeps.
Page 80 Additional keys can be obtained at an Authorised Mazda Repairer. Up to 6 keys can be used with the keyless functions per vehicle. Bring all keys to an Authorised Mazda Repairer when additional keys are required.
Page 81 Before Driving Keys Transmitter NOTE Operation indicator light (European models) The headlights turn on/off by Operation buttons operating the transmitter. Refer to Leaving Home Light on page 4-75 . (With theft-deterrent system) The hazard warning lights ash when the theft-deterrent system is armed or turned off.
Page 82 (With theft-deterrent system) When the doors are locked by pressing the lock button on the key while the theft-deterrent system is armed, the hazard warning lights will ash once to indicate that the system is armed. 3–6...
Page 83 Before Driving Keys Unlock button Boot button (Saloon) To unlock the doors and the liftgate/boot To open the boot lid, press and hold the lid, press the unlock button and the hazard boot button until the boot lid opens. warning lights will ash twice. Type A Type B (With the advanced keyless function...
Page 84 Before Driving Keys Operational Range Without the advanced keyless function The system operates only when the driver is in the vehicle or within operational Interior aerial range while the key is being carried. Starting the Engine NOTE Starting the engine may be possible even if the key is outside of the vehicle and extremely close to a door Operational range...
Page 85 Before using the key near people who repairer, we recommend an Authorised use medical devices, ask the medical Mazda Repairer for details. If the device manufacturer or your physician advanced keyless entry system has been if radio waves from the key will affect deactivated, you can start the engine by the device.
Page 86 Before Driving Advanced Keyless Entry System Operational Range NOTE The system operates only when the driver The system may not operate if you is in the vehicle or within operational are too close to the windows or door range while the key is being carried. handles, or liftgate/boot lid.
Page 87: Doors And Locks
Before Driving Doors and Locks Door Locks WARNING WARNING After closing the doors and the liftgate/ boot lid, always verify that they are securely closed: Always take all children and pets with Doors and the liftgate/boot lid not you or leave a responsible person with securely closed are dangerous, if the them: vehicle is driven with a door and the...
Page 88 6 seconds have On the rear parcel shelf (saloon) elapsed from the time of the accident. Next to a communication device...
Page 89 3 seconds. your vehicle from opening the door from the inside. If you have any problems with the double locking system, consult an expert repairer, we recommend an Authorised Mazda Repairer. Centre position Lock position 3–13...
Page 90 Before Driving Doors and Locks Locking, Unlocking with Request NOTE Switch (With the advanced keyless function) You can also activate the system by pressing the lock button on the All doors and the liftgate/boot lid can be transmitter twice within 3 seconds. locked/unlocked by pressing the request (With the advanced keyless switch on the front doors while the key is...
Page 91 Before Driving Doors and Locks To unlock NOTE To unlock the doors and the liftgate/boot Use the following procedure to lid, press the request switch on a front change the setting. door and the hazard warning lights will ash twice. 1.
Page 92 Before Driving Doors and Locks NOTE NOTE (With double locking system) Auto re-lock function The double locking system can After unlocking with the request be activated/deactivated using the switch, all doors and the liftgate/boot request switch. lid will automatically lock if any Refer to Double Locking System on of the following operations are not page 3-13 .
Page 93 Before Driving Doors and Locks Locking, Unlocking with Door- Auto Lock/Unlock Function Lock Switch All doors and the liftgate/boot lid lock WARNING automatically when the lock side is pressed with all doors and the liftgate Do not pull the inner handle on a front closed.
Page 94 Authorised Mazda Repairer. For details consult an expert repairer, we recommend an Authorised transaxle, the procedure will be Mazda Repairer. Refer to Personalisation Features cancelled.
Page 95 Current Function Number Function Number 5 the selected function Press unlock side of Press 6 times number) lock switch once Function Number 6 Press lock side of Function Number 1 Press 7 times...
Page 96 Before Driving Doors and Locks Locking, Unlocking with Door- Operation from outside Lock Knob To lock the rear and front passenger doors with the door-lock knob from the Operation from inside outside, press the door-lock knob to the lock position and close the door (holding (With door-lock switch) the door handle in the open position is not To lock any door from the inside, press the...
Page 97 Before Driving Doors and Locks Rear Door Child Safety Locks Liftgate/Boot Lid These locks are intended to help prevent children from accidentally opening the WARNING rear doors. Use them on both rear doors whenever a child rides in the rear seat of Never allow a person to ride in the the vehicle.
Page 98: Boot Lid
Consult an accumulation on it. Otherwise, the expert repairer, we recommend an liftgate/boot lid could close under the Authorised Mazda Repairer if a weight of the snow and ice resulting liftgate damper stay is deformed in injury.
Page 99 Before Driving Doors and Locks Opening the liftgate/boot lid with NOTE Electric liftgate/boot lid opener (With the advanced keyless function) Unlock the doors and liftgate/boot lid, then press the electric liftgate/boot lid A locked liftgate/boot lid can also opener on the liftgate/boot lid and raise the be opened while the key is being liftgate/boot lid when the latch releases.
Page 100 Before Driving Doors and Locks Closing the liftgate/boot lid NOTE Lower the liftgate/boot lid slowly using If the liftgate is not fully closed, the liftgate/boot lid grip recess, then push the driver is noti ed by a warning the liftgate/boot lid closed using both indicated in the instrument cluster.
Page 101: Luggage Compartment
Before Driving Doors and Locks Luggage Compartment Place the third golf bag with its top pointed to the right, and then set the bottom of the bag so that it is pointed to Loading golf bags the left. Golf bags can be carried in the luggage compartment.
Page 102: Luggage Compartment Cover
Before Driving Doors and Locks Place each of the three golf bags into the NOTE luggage compartment with the bottom of each bag pointed to the left, and then set Some golf bags cannot t depending on the top of each bag so that it is pointed to their size.
Page 103 Before Driving Doors and Locks Using the rear luggage compartment NOTE cover If you attempt to open the liftgate Pull out the luggage compartment cover under cold weather conditions with and insert it into the clips of the liftgate. the luggage compartment cover attached, the damper function may not operate normally and the liftgate may be dif cult to raise.
Page 104 Before Driving Doors and Locks Storing the cover 3. Remove the partitions on both sides of the luggage compartment. 1. Open the luggage board. Luggage board 4. Store the luggage compartment cover 2. Rotate the shopping bag hook out of with the tabs pointed down.
Page 105 Before Driving Doors and Locks Luggage Compartment Net CAUTION (Wagon) The luggage compartment net can be used Make sure the net is rmly secured. as a compartment separator or to keep If it is not rmly secured, it could animals in the back. unexpectedly disengage resulting in injury.
Page 106 Before Driving Doors and Locks 2. Retract the spring holder on the right To remove the net: end of the retractor bar to insert it into 1. Lift the net slightly and disengage the the installation groove. anchors from the ceiling retainers. 2.
Page 107 Fuel Requirements (SKYACTIV-G 2.0, SKYACTIV-G 2.5) Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL, which will reduce exhaust emissions and keep spark plug fouling to a minimum. Your Mazda will perform best with fuel listed in the table. Research Octane Fuel...
Page 108 Never add fuel system additives. Otherwise, the emission control system could be damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. NOTE When refuelling, always add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel. 3–32...
Page 109 USE ONLY UNLEADED FUEL. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 110 Either condition will damage the converter and cause poor performance. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 111 When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact an expert repairer, we recommend an Authorised Mazda Repairer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 112 Before Driving Fuel and Emission Fuel-Filler Flap and Cap CAUTION WARNING Always use only a designated Mazda fuel- ller cap or an approved equivalent, available at an expert repairer, we When removing the fuel- ller cap, recommend an Authorised Mazda loosen the cap slightly and wait for any Repairer.
Page 113 Before Driving Fuel and Emission Fuel-Filler Cap To remove the fuel- ller cap, turn it anticlockwise. Attach the removed cap to the inner side of the fuel ap. To close the fuel- ller cap, turn it clockwise until a click is heard. Open Close 3–37...
Page 114: Steering Wheel
Before Driving Steering Wheel Steering Wheel Heated Steering Wheel The grips on the left and right of the steering wheel can be warmed up. WARNING Heated steering Heating area Never adjust the steering wheel while wheel switch the vehicle is moving: Adjusting the steering wheel while the vehicle is moving is dangerous.
Page 115: Outside Mirrors
Before Driving Mirrors Mirrors NOTE Before driving, adjust the inside and (Driver's Side Wide Angle Mirror outside mirrors. The wide angle mirror has two Outside Mirrors curvatures on its surface separated by a region line into outer and inner regions. The inner region is WARNING a standard convex mirror whereas the outer region allows for a wider...
Page 116 Before Driving Mirrors Power mirror adjustment Manual folding mirror The ignition must be switched to ACC or Fold the outside mirror rearward until it is ON position. ush with the vehicle. To adjust: 1. Rotate the mirror switch to the left or right to choose the left or right side mirror.
Page 117 Before Driving Mirrors The ignition must be switched to ACC or Automatic folding mechanism ON position. The automatic folding mechanism operates Type A when the ignition is switched to ACC or To fold, rotate the switch. OFF. To return the mirror to the driving When the outer mirror automatic folding position, rotate the switch to the centre switch is pressed to the AUTO position...
Page 118: Rearview Mirror
Before Driving Mirrors Rearview Mirror Reducing glare from headlights Manual antidazzle mirror WARNING Push the antidazzle lever forward for day driving. Pull it back to reduce glare of Do not stack cargo or objects higher headlights from vehicles at the rear. than the seatbacks: Cargo stacked higher than the seatbacks is dangerous.
Page 119 Before Driving Mirrors NOTE Do not use glass cleaner or suspend objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor The auto-dimming function is cancelled when the ignition is switched ON and the shift/selector lever is in reverse (R).
Page 120 Before Driving Windows Power Windows NOTE The ignition must be switched ON for the A power window may no longer open/ power windows to operate. close if you continue to press the switch after fully opening/closing the power WARNING window. If the power window does not open/close, wait a moment and then operate the switch again.
Page 121 5. Repeat Steps 3-4 for the front passenger power window while seated in the front passenger seat. Auto-opening/closing 6. Repeat Steps 3-4 for both the left and right rear power windows while seated To fully open the window automatically, in the rear seat.
Page 122 Before Driving Windows Jam-safe window Engine-off power window operation If a person's hands, head or an object The power window can be operated for blocks the window during the manual about 40 seconds after the ignition is closing operation or the auto-closing switched from ON to off with all doors operation, the window will stop and open closed.
Page 123 Before Driving Windows (Without outer mirror folding switch) Sunroof The sunroof can be opened or closed Locked position electrically only when the ignition is switched ON. Tilt/Slide switch Unlocked position NOTE When the power window lock switch WARNING is in the locked position, the light on each power window switch, except for the driver's power window switch, Do not let passengers stand up or...
Page 124: Tilt Operation
To fully close automatically, momentarily After washing your Mazda or after it press the tilt/slide switch in the forward rains, wipe the water off the sunroof direction.
Page 125 Before Driving Windows Jam-safe Sunroof Sunshade If a person's hands, head or an object The sunshade can be opened and closed blocks the sunroof while it is closing, the by hand. sunroof will stop and move in the reverse direction. The sunshade opens automatically when the sunroof is opened, but must be closed WARNING...
Page 126: Security System
Immobilizer System Equipment The immobilizer system allows the engine to start only with a key the system Mazda cannot guarantee the immobilizer recognises. and the theft-deterrent systems' operation if the system has been modi ed or if any If someone attempts to start the engine add-on equipment has been installed.
Page 127 They are only available through an Authorised Mazda Repairer. Always keep a spare key in case one is lost. If a key is lost, consult an Authorised Mazda Repairer as soon as possible. Disarming If you lose a key, an Authorised...
Page 128 Do not install seats that are not Intrusion sensor Mazda genuine products. To prevent obstruction of intrusion The intrusion sensor uses ultrasonic waves sensor, do not place objects or cargo to detect movement inside the vehicle and...
Page 129 Before Driving Security System Operation How to Arm the System 1. Close the windows and the sunroof Siren triggering conditions securely. The siren sounds intermittently and the NOTE hazard warning lights ash for about 30 seconds when the system is triggered by Even with a window or the sunroof any one of the following: open, the system can be armed,...
Page 130 Before Driving Security System 5. After 20 seconds, the system is fully Cancelling the Intrusion Sensor armed. If the theft deterrent system has been armed while any of the following NOTE conditions are present, cancel the intrusion sensor to prevent the alarm from triggering The theft-deterrent system can also unnecessarily.
Page 131 Before Driving Security System To cancel the intrusion sensor, press To Stop the Alarm the intrusion sensor cancel button on A triggered alarm can be turned off using the transmitter within 20 seconds after any one of the following methods: pressing the lock button.
Page 132 Before Driving Security System Theft-Deterrent System NOTE (Without the Intrusion If the battery goes dead while the Sensor) theft-deterrent system is armed, the horn will activate and the hazard If the theft deterrent system detects an warning lights will ash when the inappropriate entry into the vehicle, battery is charged or replaced.
Page 133 Before Driving Security System NOTE NOTE The theft deterrent system can also When the doors are unlocked by be armed by activating the auto pressing the unlock button on the relock function with all the doors, transmitter while the theft-deterrent the liftgate/boot lid and the bonnet system is turned off, the hazard warning closed.
Page 134: When Driving
(avoid sudden braking). Avoid unnecessary hard stops. Follow the maintenance schedule (page Avoid full-throttle starts. 6-3 ) and have an expert repairer, Do not tow a trailer. we recommend an Authorised Mazda Repairer perform inspections and servicing. Use the air conditioner only when necessary.
Page 135: Driving Tips
Driving Tips Hazardous Driving Floor Mat We recommend the use of Genuine WARNING Mazda oor mats. WARNING Be extremely careful if it is necessary to downshift on slippery surfaces: Downshifting into lower gear while Make sure the oor mats are secured...
Page 136 Before Driving Driving Tips Rocking the Vehicle WARNING WARNING Do not install two oor mats, one on top of the other, on the driver's side: Installing two oor mats, one on top Do not spin the wheels at high speed, of the other, on the driver's side is and do not allow anyone to stand dangerous as the retention pins can...
Page 137 Use an engine oil appropriate for the components. If this situation occurs, lowest ambient temperatures that the drive the vehicle slowly, releasing vehicle will be driven in (page 6-23 ). the accelerator pedal and lightly Inspect the ignition system for damage applying the brakes several times and loose connections.
Page 138 Driving Tips Use snow tyres on all four wheels Tyre chain selection (Europe) Do not exceed the maximum permissible Mazda recommends hexagon type speed for your snow tyres or legal speed steel ring chains. Select the proper type limits. according to your tyre size.
Page 139 Always follow the absorption. If the vehicle has been chain manufacturer's instructions. immersed in water, consult an expert 2. Retighten the chains after driving repairer, we recommend an Authorised 1/2—1 km (1/4—1/2 mile). Mazda Repairer. 3–63...
Page 140 To get the most from it, observe the following. 1. Change engine oil and lter according to Scheduled Maintenance (page 6-3 ). 2. Use only recommended engine oil (page 6-23 ). Extra additives are NOT recommended.
Page 141 Never overload vehicle or trailer. Consult an Authorised Mazda Dealer if you need further details. CAUTION Do not tow a trailer during the rst 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components.
Page 142 Before Driving Towing CAUTION Be aware of the towing load weight differences when towing at high altitudes. For altitudes exceeding 1,000 meter (3,280 ft 10 in), always reduce the towing load by 10% for every 1,000 meter (3,280 ft 10 in) increase in altitude from the load indicated under the gross combination weight heading in the maximum trailer towing-load table.
Page 143 Before Driving Towing GROSS MODEL TOTAL TRAILER WEIGHT COMBINATION WEIGHT i-stop i-ELOOP Trailer without Trailer with Trailer with Body Engine Transaxle system system brake brake brake SKYACTIV-D Automatic 730 kg 1,600 kg 3,670 kg Saloon × × STANDARD transaxle (1,609.3 lb) (3,527.3 lb) (8,090.8 lb) POWER...
Page 144 Before Driving Towing GROSS MODEL TOTAL TRAILER WEIGHT COMBINATION WEIGHT i-stop i-ELOOP Trailer without Trailer with Trailer with Body Engine Transaxle system system brake brake brake SKYACTIV-D Manual 730 kg 1,600 kg 3,690 kg Wagon 2.2 HIGH × × transaxle (1,609.3 lb) (3,527.3 lb) (8,134.9 lb)
Page 145 Before Driving Towing Germany and Austria/Gradient up to 8% GROSS MODEL TOTAL TRAILER WEIGHT COMBINATION WEIGHT i-stop i-ELOOP Trailer without Trailer with Trailer with Body Engine Transaxle system system brake brake brake SKYACTIV-G Manual 680 kg 1,700 kg 3,635 kg Saloon ×...
Page 146 Before Driving Towing GROSS MODEL TOTAL TRAILER WEIGHT COMBINATION WEIGHT i-stop i-ELOOP Trailer without Trailer with Trailer with Body Engine Transaxle system system brake brake brake SKYACTIV-G Automatic 680 kg 1,700 kg 3,720 kg Wagon 2.0 HIGH × — transaxle (1,499.1 lb) (3,747.8 lb) (8,201.1 lb)
Page 147 Before Driving Towing Russia/Gradient up to 12% GROSS MODEL TOTAL TRAILER WEIGHT COMBINATION WEIGHT i-stop i-ELOOP Trailer without Trailer with Trailer with Body Engine Transaxle system system brake brake brake SKYACTIV-G Manual 680 kg 1,300 kg 3,235 kg Saloon — —...
Page 148 SKYACTIV-G Manual 680 kg 1,250 kg 3,150 kg Saloon × — transaxle (1,499.1 lb) (2,755.7 lb) (6,944.4 lb) SKYACTIV-G Automatic 680 kg 1,250 kg 3,185 kg Saloon × — transaxle (1,499.1 lb) (2,755.7 lb) (7,021.6 lb) SKYACTIV-G...
Page 149 Before Driving Towing WARNING Always keep tow loads within speci ed limits as indicated in the Trailer Towing-Load Table: Attempting to tow loads greater than those speci ed is dangerous as it may cause serious handling and performance problems that could result in personal injury or vehicle damage, or both.
Page 150: Trailer Hitch
Trailer Hitch When towing a trailer, use an appropriate trailer hitch. We recommend using a genuine Mazda trailer hitch. Use the original holes drilled by the vehicle manufacture for securing the trailer hitch. Contact your Authorised Mazda Dealer for more information.
Page 151 Before Driving Towing Trailer hitch installation area (Wagon) Unit: mm (in) A: 350—420 (13.8—16.5) B: 1178.5 (46.398) C: 1046.9 (41.217) MAX. 75 Kg (165 lb) Hitch coupling point Tyres When towing a trailer, make sure all tyres are in ated to the recommended cold-tyre pressure, as indicated on the tyre pressure chart on the driver's door frame.
Page 152: Trailer Lights
Trailer Lights CAUTION Do not connect a trailer lighting system directly to the lighting system of your Mazda. This may damage your vehicle's electrical system and lighting systems. To connect the lighting system, consult an Authorised Mazda Dealer.
Page 153 Stop and re-inspect all lights and connections after driving a short distance. Driving Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and stopping in a traf c-free area. Take time to get accustomed to the extra weight and length.
Page 154 Before Driving Towing Parking Avoid parking on an incline with a trailer. If this must be done, follow these instructions. Parking on an Incline 1. Set the parking brake and the brakes. 2. Have someone block the wheels of the vehicle and trailer while you apply the brakes. 3.
Page 155 When Driving Information concerning safe driving and stopping. Start/Stop Engine ........ 4-4 Switches and Controls ...... 4-70 Ignition Switch ....... 4-4 Lighting Control ......4-70 Starting the Engine ......4-5 Front Fog Lights ......4-77 Turning the Engine Off ....4-11 Rear Fog Light ......
Page 156 Distance Recognition Support System (DRSS) ........4-144 Driver Attention Alert (DAA) ... 4-148 Rear Cross Traf c Alert (RCTA) ........4-151 Mazda Radar Cruise Control (MRCC) ........4-155 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) ........4-169 Adjustable Speed Limiter ..
Page 157 Cruise Control ......... 4-222 Cruise Control ......4-222 Tyre Pressure Monitoring System ..........4-227 Tyre Pressure Monitoring System ........4-227 Diesel Particulate Filter ....4-231 Diesel Particulate Filter (SKYACTIV-D 2.2) ....4-231 Rear View Monitor ......4-232 Rear View Monitor ....
Page 158 When Driving Start/Stop Engine Ignition Switch The power supply to electrical devices turns off and the push button start indicator Push Button Start Positions light (amber) also turns off. The system operates only when the key is In this position the steering wheel is within operational range.
Page 159 When Driving Start/Stop Engine ACC (Accessory) Starting the Engine Some electrical accessories will operate and the indicator light (amber) illuminates. WARNING In this position the steering wheel is unlocked. Radio waves from the key may affect NOTE medical devices such as pacemakers: Before using the key near people who The keyless entry system does not use medical devices, ask the medical...
Page 160 Consult an expert repairer, we recommend an Authorised Mazda 6. Verify that the KEY indicator light Repairer for details. If the push (green) (if equipped) in the instrument button start system functions have...
Page 161 Have your expert repairer, we recommend an vehicle inspected at an expert repairer, Authorised Mazda Repairer as soon we recommend an Authorised Mazda as possible. If this occurs, the engine Repairer as soon as possible.
Page 162 When Driving Start/Stop Engine NOTE NOTE When the engine is force-started, (SKYACTIV-D 2.2) the KEY warning light (red) (if When starting the engine, do equipped) remains illuminated and not release the clutch pedal the push button start indicator light (manual transaxle) or the brake (amber) remains ashing.
Page 163 Engine under Emergency Starting. If the engine still does not start, have your vehicle inspected by an Authorised Mazda Repairer (page 7-26 ). (SKYACTIV-D 2.2) If the ambient temperature is lower than about - 10 °C (14 °F), the...
Page 164 5. Verify that the push button start indicator light (green) turns on. 6. Press the push button start to start the engine. 4–10...
Page 165 Authorised Mazda Repairer as soon as the loss of power braking, which could possible. If this occurs, the engine can cause an accident and serious injury.
Page 166 Replace with a new battery before the key becomes unusable. Refer to Key Battery Replacement on page 6-39 . (Vehicle equipped with Type A instrument cluster) A message is indicated in the display of the instrument cluster.
Page 167 When Driving Start/Stop Engine i-stop The i-stop function automatically stops the engine when the vehicle is stopped at a traf c light or stuck in traf c, and then restarts the engine automatically to resume driving. The system provides improved fuel economy, reduced exhaust gas emissions, and eliminates idling noise while the engine is stopped.
Page 168 When Driving Start/Stop Engine Automatic transaxle 1. Engine idling stops when the brake pedal is depressed while the vehicle is driven (except for driving in the R or M position second gear xed mode) and the vehicle is stopped. 2. The engine restarts automatically when the brake pedal is released with the selector lever in the D or M position (not in second gear xed mode).
Page 169 The fuel injection amount learning is being performed. (The i-stop indicator light (green) turns off when the vehicle speed before stopping is approx. 10 km/h (6.2 mph) or less and fuel injection amount learning is performed while the vehicle is stopped.)
Page 170 When Driving Start/Stop Engine NOTE Under the following conditions, a period of time is required to stop engine idling The battery power is depleted for some reasons such as the vehicle has not been driven for a long period. The ambient temperature is high or low. After the battery terminals are disconnected for some reasons such as for battery replacement.
Page 171 Battery terminals are disconnected Engine idling may not stop right after the battery terminals are disconnected. In addition, if the battery is replaced, the i-stop functions must be veri ed. Consult an expert repairer, we recommend an Authorised Mazda Repairer. 4–17...
Page 172 When Driving Start/Stop Engine i-stop OFF Switch By pressing the switch until a beep sounds, the i-stop function is turned off and the i-stop warning light (amber) in the instrument cluster turns on. By pressing the switch again until the beep sounds, the i-stop function becomes operational and the i-stop warning light (amber) turns off.
Page 173 When Driving Start/Stop Engine Vehicle Roll Prevention Function (Automatic transaxle) Vehicles with the i-stop function are equipped with a vehicle roll prevention function. This function prevents the vehicle from rolling, such as when releasing the brake pedal while on a slope under the following conditions: While engine idling is stopped (prevents the vehicle from rolling back) When the engine restarts after releasing the brake pedal (prevents the vehicle's sudden movement due to vehicle creep), sudden movement of the vehicle is prevented by...
Page 174 When Driving Start/Stop Engine WARNING Do not rely completely on the vehicle roll prevention function. The vehicle roll prevention function is a supplementary function which operates for a maximum of four seconds after releasing the brake pedal and accelerating the vehicle from an engine idling stop condition.
Page 175 When Driving Start/Stop Engine i-stop Warning Light (Amber)/i-stop Indicator Light (Green) To ensure safe and comfortable use of the vehicle, the i-stop system constantly monitors the driver's operations, the vehicle's interior and exterior environment, and the operational status of the vehicle, and uses the i-stop warning light (amber) and i-stop indicator light (green) to inform the driver of various cautions and warnings.
Page 176 NOTE A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light does not turn on when the ignition is switched ON. The light continues to remain on even though the i-stop OFF switch has been pressed while the engine is running.
Page 177 When Driving Instrument Cluster and Display Meters and Gauges Instrument Cluster Type A (With Multi-information Display) Type B (Without Multi-information Display) Steering Switch 4–23...
Page 178 When Driving Instrument Cluster and Display Speedometer ......................page 4-25 Odometer, Trip Meter and Trip Meter Selector ............ page 4-25 Tachometer ......................page 4-26 Instrument Panel Illumination ................page 4-28 Trip Computer and INFO Switch ................page 4-31 Engine Coolant Temperature Gauge ..............page 4-27 Fuel Gauge ......................
Page 179 When Driving Instrument Cluster and Display Speedometer Odometer The odometer records the total distance The speedometer indicates the speed of the the vehicle has been driven. vehicle. Trip meter Odometer, Trip Meter and Trip Meter Selector (Without Multi- The trip meter can record the total distance information Display) of two trips.
Page 180 When Driving Instrument Cluster and Display The trip meter records the total distance Tachometer the vehicle is driven until the meter The tachometer shows engine speed in is again reset. Return it to “0.0” by thousands of revolutions per minute (rpm). depressing and holding the selector for one second or more.
Page 181 When Driving Instrument Cluster and Display Engine Coolant Temperature NOTE Gauge (Without Multi-information Display) The temperature unit (Centigrade/ Fahrenheit) of the engine coolant Displays the engine coolant temperature. gauge display changes in conjunction The white gauge indicates that the engine with the temperature unit of the coolant temperature is low, and the red outside temperature display.
Page 182 When Driving Instrument Cluster and Display Fuel Gauge (Without Multi- NOTE information Display) After refuelling, it may require some The fuel gauge shows approximately time for the indicator to stabilize. In how much fuel is remaining in the tank addition, the indicator may deviate when the ignition is switched ON.
Page 183 When Driving Instrument Cluster and Display Function for cancelling illumination NOTE dimmer (With auto-light control) The illumination dimmer can be When the ignition is switched ON cancelled by rotating the instrument panel in the early evening or at dusk, the illumination knob to the right until a beep instrument panel illumination is sound is heard while the instrument cluster...
Page 184 When Driving Instrument Cluster and Display NOTE NOTE Under the following conditions, the When the temperature unit indicated outside temperature display may differ in the outside temperature display is from the actual outside temperature changed, the temperature unit indicated depending on the surroundings and in the engine coolant gauge display vehicle conditions: changes in conjunction with it.
Page 185 If you have any problems with your trip differ from the amount indicated. computer, consult an expert repairer, we recommend an Authorised Mazda Repairer. Average fuel economy mode Distance-to-empty mode This mode displays the average fuel...
Page 186 When Driving Instrument Cluster and Display (European model) (European model) (Except European model) (Except European model) To clear the data being displayed, press the Vehicle Speed Alarm INFO switch for more than 1.5 seconds. After pressing the INFO switch, - - - L/100 In this mode, the current setting for the km (- - - mpg) will be displayed for about vehicle speed alarm is displayed.
Page 187 Current fuel economy Maintenance Monitor Blind Spot Monitoring (BSM) Display Distance Recognition Support System (DRSS) Display Mazda Radar Cruise Control (MRCC) Display Lane Departure Warning System (LDWS) Display Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display Cruise Control Display...
Page 188 When Driving Instrument Cluster and Display The screen content changes each time the INFO switch is pressed. Current Fuel Economy, Warning message, Trip Meter A, Average Outside Temperature, Fuel Economy, Outside Odometer, Temperature, Odometer, Distance-to-empty, Distance-to-empty, Fuel Fuel Gauge Gauge Press the INFO switch Press the INFO switch Current Fuel Economy,...
Page 189 When Driving Instrument Cluster and Display Odometer, Trip Meter and Trip Trip meter Meter Selector The driving distance for a speci ed interval is indicated. Two types (TRIP The odometer is constantly displayed on A, TRIP B) of interval distance and the the screen when the ignition is switched average fuel economy for each can be ON, and the TRIP A or TRIP B screen...
Page 190 When Driving Instrument Cluster and Display Engine Coolant Temperature Fuel Gauge Gauge The fuel gauge shows approximately Displays the engine coolant temperature. how much fuel is remaining in the tank The blue gauge indicates that the engine when the ignition is switched ON. We coolant temperature is low, and the red recommend keeping the tank over 1/4 full.
Page 191 When Driving Instrument Cluster and Display (SKYACTIV-D 2.2) NOTE If inconsistency in engine performance or stalling occurs due to low fuel level When the temperature unit indicated conditions, refuel the vehicle as soon as in the outside temperature display is possible and add at least 10 L (2.7 US gal, changed, the temperature unit indicated 2.2 Imp gal) of fuel.
Page 192 When Driving Instrument Cluster and Display Distance-to-empty This displays the approximate distance you can travel on the remaining fuel based on the fuel economy. The distance-to-empty will be calculated and displayed every second. NOTE Even though the distance-to-empty display may indicate a suf cient amount of remaining driving distance before refuelling is required, refuel as soon as possible if the fuel level...
Page 193 When Driving Instrument Cluster and Display Average Fuel Economy This mode displays the average fuel economy by calculating the total fuel consumption and the total travelled distance since purchasing the vehicle, re-connecting the battery after disconnection, or resetting the data. The average fuel economy is calculated and displayed every minute.
Page 194 NOTE Maintenance Monitor. Refer to Maintenance Monitor on page If any of the INFO switch is pressed 6-16 . while a message is displayed, it will The maintenance monitor displays the no longer be displayed the next time information when the ignition is switched the ignition is switched ON.
Page 195 Displays the currently set system status. Display The vehicle speed preset using the cruise control is displayed. Refer to Mazda Radar Cruise Control Compass Display (MRCC) on page 4-155 . The direction the vehicle is moving is displayed while the vehicle is being driven.
Page 196 When Driving Instrument Cluster and Display Vehicle Speed Alarm In this mode, the current setting for the vehicle speed alarm is displayed. You can change the vehicle speed setting at which the warning is triggered. NOTE The vehicle speed alarm display is activated at the same time the beep sound is heard. The set vehicle speed ashes several times.
Page 197 When Driving Instrument Cluster and Display Active Driving Display Mirror Combiner Optical receiver WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident. CAUTION Do not try to adjust the angle or open/close the active driving display manually.
Page 198 Refer to Traf c Sign Recognition System (TSR) on page 4-137 . Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-155 . Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Operation Conditions and Warnings Refer to Lane-keep Assist System (LAS) &...
Page 199 When Driving Instrument Cluster and Display Navigation Guidance (vehicles with navigation system) Speed limit indicator (vehicles with navigation system) Vehicle Speed Each setting/adjustment for the active driving display can be performed on the centre display. 1. Select the icon on the home screen and display the Settings screen. 2.
Page 200 When Driving Instrument Cluster and Display Warning/Indicator Lights Instrument Cluster varies depending on model and speci cations. Instrument Cluster Type A (With Multi-information Display) Type B (Without Multi-information Display) Centre of Instrument panel Warning/Indicator lights will appear in any of the highlighted areas 4–46...
Page 201 When Driving Instrument Cluster and Display Warning Indication/Warning Lights These lights turn on or ash to notify the user of the system operation status or a system malfunction. Signal Warning Page Brake System Warning Light 7-34 Electronic Brake Force Distribution ABS Warning Light System Warning 7-34 ,...
Page 202 (Amber) Adaptive LED Headlights (ALH) Warning Indication/Warning Light 7-38 (Amber) Blind Spot Monitoring (BSM) Warning Indication 7-38 Mazda Radar Cruise Control (MRCC) Warning Indication 7-38 (Amber) Lane Departure Warning System (LDWS) Warning Light 4-129 (Amber) Lane-keep Assist System (LAS) & Lane Departure Warning System...
Page 203 *1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 4–49...
Page 204 When Driving Instrument Cluster and Display Indication/Indicator Lights These lights turn on or ash to notify the user of the system operation status or a system malfunction. Signal Indicator Page Seat Belt Indicator Light (Rear seat) 2-21 (Green) Front Passenger Air Bag Deactivation Indicator Light 2-49 Security Indicator Light 3-51...
Page 205 High Beam Control System (HBC) Indicator Light 4-120 (Green) Adaptive LED Headlights (ALH) Indicator Light 4-123 (Green) Malfunction 7-38 , Blind Spot Monitoring (BSM) OFF Indicator Light Except malfunction 4-136 Mazda Radar Cruise Control (MRCC) Main Indication 4-159 (White) 4–51 *Some models.
Page 206 When Driving Instrument Cluster and Display Signal Indicator Page Mazda Radar Cruise Control (MRCC) Set Indication 4-159 (Green) Malfunction 7-38 , Lane Departure Warning System (LDWS) OFF Indicator Light Except malfunction 4-128 Lane-keep Assist System (LAS) & Lane Departure Warning System...
Page 207 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. *2 The light turns on continuously when the electric parking brake is applied.
Page 208 When ashing (SKYACTIV-D 2.2) The sedimentor separates water from the fuel. If water accumulates in this lter, the warning light will ash. When it does, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 4–54...
Page 209: Manual Transaxle Operation
When Driving Manual Transaxle Operation Manual Transaxle Shift WARNING Pattern Do not use sudden engine braking on slippery road surfaces or at high speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous.
Page 210 When Driving Manual Transaxle Operation Gear Shift Indicator (GSI) NOTE The Gear Shift Indicator (GSI) supports If shifting to R is dif cult, shift back you to obtain optimum fuel economy and into neutral, release the clutch pedal, smooth driving. It displays the selected and try again.
Page 211 When Driving Manual Transaxle Operation NOTE The Gear Shift Indicator (GSI) turns off when the following operations are performed. The vehicle is stopped. The vehicle is put in neutral. The vehicle is driven in reverse. The clutch is not fully engaged when accelerating from a stop.
Page 212: Automatic Transaxle
When Driving Automatic Transaxle Automatic Transaxle Controls Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the shift lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift.
Page 213 4. Move the selector lever. The shift-lock system prevents shifting out Take the vehicle to an expert repairer, we of P unless the brake pedal is depressed. recommend an Authorised Mazda Repairer to have the system checked. To shift from P: Type B 1.
Page 214 When Driving Automatic Transaxle Transaxle Ranges NOTE The shift position indicator light in the (With parking sensor system) instrument cluster illuminates. Refer When the selector lever is shifted to the to Warning/Indicator Lights on page R position with the ignition switched 4-46 .
Page 215 D is the normal driving position. From a D position. Depending on the road and stop, the transaxle will automatically shift driving conditions/vehicle operations, gear through a 6-gear sequence. shifting could be delayed or not occur, M (Manual) however, this does not indicate a problem because the AAS mode will maintain the M is the manual shift mode position.
Page 216 When Driving Automatic Transaxle Manual Shift Mode Indicators The manual shift mode gives you the feel Manual shift mode indication of driving a manual transaxle vehicle by In manual shift mode, the “M” of the shift allowing you to operate the selector lever position indication in the instrument panel manually.
Page 217 When Driving Automatic Transaxle Gear Shift Indicator (GSI) NOTE The gear shift indicator supports you to If the gears cannot be shifted down obtain optimum fuel economy and smooth when driving at higher speeds, the driving. It displays the selected gear gear position indication will ash position in the instrument cluster as well twice to signal that the gears cannot...
Page 218 When Driving Automatic Transaxle Using steering shift switch NOTE To shift up to a higher gear with the The gear shift indicator turns off when steering shift switches, pull the UP switch the following operations are performed. ) toward you once with your ngers.
Page 219 When Driving Automatic Transaxle Manually Shifting Down NOTE You can shift gears down by operating When driving slowly, the gears may the selector lever or the steering shift not shift up. switches Do not drive the vehicle with the tachometer needle in the RED ZONE Using selector lever while in manual shift mode.
Page 220 When the selector lever is moved back while the vehicle speed is about 10 km/h Do not use engine braking on slippery (6.2 mph) or less, the transaxle is set in the road surfaces or at high speeds: second gear xed mode. The gear is xed...
Page 221 When Driving Automatic Transaxle Shift Gear (Shifting) Speed Limit For each gear position while in the manual mode, the speed limit is set as follows: When the selector lever is operated within the range of the speed limit, the gear is shifted. Shift up The gear does not shift up while the vehicle speed is lower than the speed limit.
Page 222 When Driving Automatic Transaxle Direct Mode NOTE Direct mode can be used for temporarily Shifting up and down while in direct switching gears by operating the steering mode may not be possible depending on shift switch while the vehicle is being the vehicle speed.
Page 223 When Driving Automatic Transaxle Driving Tips Passing For extra power when passing another vehicle or climbing steep grades, depress WARNING the accelerator fully. The transaxle will shift to a lower gear, depending on vehicle Do not let the vehicle move in a speed.
Page 224 When Driving Switches and Controls Lighting Control Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless safety requires them.
Page 225 When Driving Switches and Controls Without auto-light control Switch Position ACC or ACC or ACC or Ignition Position Headlights Running lights Tail lights Position lights Number plate lights *1 The lights are turned on while the vehicle is driven. *2 The lights are turned on continuously if the ignition is switched from ON to any other position with the lights turned on.
Page 226 When Driving Switches and Controls With auto-light control Switch Position Ignition Position or OFF or OFF or OFF or OFF Headlights Auto Running lights Tail lights Position lights Auto Auto Number plate lights *1 The lights are turned on while the vehicle is driven. *2 The lights are turned on by the auto light function.
Page 227 When Driving Switches and Controls Auto-light control When the headlight switch is in the position and the ignition is switched ON, the light sensor senses the surrounding lightness or darkness and automatically turns the headlights and other exterior lights on or off. CAUTION Do not shade the light sensor by adhering a sticker or a label on the windscreen.
Page 228 When Driving Switches and Controls Headlight High-Low Beam Flashing the Headlights The headlights switch between high and Can be used when the ignition is switched low beams by moving the lever forward or backward. To ash the headlights, pull the lever fully towards you (the headlight switch does not need to be on).
Page 229 When Driving Switches and Controls Coming Home Light Leaving Home Light The coming home light turns on the The leaving home light turns on the lights headlights (low beams) when the lever is when the transmitter unlock button is operated. pressed while away from the vehicle.
Page 230: Headlight Levelling
When Driving Switches and Controls Headlight Levelling Select the proper headlight angle from the following chart. The number of passengers and weight of cargo in the luggage compartment change (European model) the angle of the headlights. Switch Front seat Rear Position Load seat...
Page 231: Running Lights
When Driving Switches and Controls Running Lights Front Fog Lights Some countries require moving vehicles to The front fog lights can be used when the have their lights on (running lights) during ignition is switched ON. the daytime. Use this switch to turn on the front fog lights.
Page 232 When Driving Switches and Controls Rear Fog Light NOTE The rear fog light can be used when the (With auto-light control) ignition is switched ON. If the fog light switch is in the The rear fog light helps your vehicle to be position or the headlight switch is in seen.
Page 233 When Driving Switches and Controls To turn the rear fog light off, do any of the Without Front Fog Lights following: The headlights must be turned on to turn Rotate the fog light switch to the on the rear fog light. position again (the fog light switch returns to the position automatically).
Page 234: Direction Indicators
When Driving Switches and Controls Turn and Lane-Change Lane-Change Signals Signals Move the lever halfway toward the direction of the lane change—until the The ignition must be switched ON to use indicator ashes— and hold it there. It will the turn and lane-change signals. return to the off position when released.
Page 235 OFF, consult an expert repairer, we recommend an Authorised Mazda Only use windscreen washer uid Repairer as soon as possible. mixed with anti-freeze protection in...
Page 236: Windscreen Wipers
When Driving Switches and Controls Windscreen Wipers With auto-wiper control Turn the wipers on by pressing the lever up or down. With intermittent wiper Switch Position Wiper operation Type Type Operation while pulling up lever Switch Position Stop Wiper operation Type Type Auto control...
Page 237 When Driving Switches and Controls Auto-wiper control CAUTION When the wiper lever is in the position, the rain sensor senses the amount Do not shade the rain sensor by of rainfall on the windscreen and turns the adhering a sticker or a label on the wipers on or off automatically (off—...
Page 238 If the washer does not work, inspect the restore the auto-wiper operation. uid level (page 6-31 ). If the uid level If the auto-wiper lever is left in the is normal, consult an expert repairer,...
Page 239 If the washer does not work, inspect the uid sprays. uid level (page 6-31 ). If the uid level is normal and the washer still does not work, consult an expert repairer, we recommend an Authorised Mazda Repairer.
Page 240 When Driving Switches and Controls Rear Window Defogger CAUTION The rear window defogger clears fog from the rear window. Do not use sharp instruments or window cleaners with abrasives to clean the The ignition must be switched ON to use inside of the rear window surface.
Page 241 When Driving Switches and Controls Mirror Defogger Horn The mirror defoggers defrost the outside To sound the horn, press the mark on mirrors. the steering wheel. The mirror defoggers operate in conjunction with the rear window defogger. To turn on the mirror defoggers, switch the ignition ON and press the rear window defogger switch (page 4-86 ).
Page 242 When Driving Switches and Controls Hazard Warning Flasher NOTE The hazard warning lights should always The direction indicators do not work be used when you stop on or near a when the hazard warning lights are roadway in an emergency. Check local regulations about the use of hazard warning lights while the vehicle is being towed to verify that...
Page 243 When Driving Brake Brake System WARNING Foot Brake Do not coast with the engine stalled or turned off, nd a safe place to stop: This vehicle has power-assisted brakes Coasting with the engine stalled or that adjust automatically through normal turned off is dangerous.
Page 244 When Driving Brake Electric Parking Brake CAUTION The electric parking brake equipment applies the parking brake using an electric Do not drive with your foot held motor. When the electric parking brake is on the clutch pedal or brake pedal, applied, the electric parking brake switch or hold the clutch pedal depressed indicator light turns on.
Page 245 When Driving Brake When applying the electric parking NOTE brake If the electric parking brake is not The electric parking brake can be applied used for long periods, an automatic regardless of the ignition switch position. inspection of the system is performed Securely depress the brake pedal and pull while the vehicle is parked.
Page 246: Warning Light
When Driving Brake Electric parking brake manual release Electric parking brake automatic release Securely depress the brake pedal and press down the electric parking brake switch. If the accelerator pedal is depressed with the electric parking brake applied and all of the following conditions met, the parking brake is released automatically.
Page 247 When you hear this noise, consult an brakes will apply more rmly. This expert repairer, we recommend an is a normal effect of the brake assist Authorised Mazda Repairer as soon as operation and does not indicate a possible. malfunction.
Page 248 System Hill Launch Assist (HLA) is a function which assists the driver in accelerating Your Mazda is equipped with an from a stop while on a slope. When emergency stop signal system that is the driver releases the brake pedal and...
Page 249 When Driving Brake NOTE WARNING Hill Launch Assist (HLA) does not Do not rely completely on Hill Launch operate on a gentle slope. In addition, Assist (HLA): the gradient of the slope on which Hill Launch Assist (HLA) is an the system will operate changes auxiliary device for accelerating from depending on the vehicle's load.
Page 250 When Driving ABS/TCS/DSC Antilock Brake System NOTE (ABS) Braking distances may be longer on loose surfaces (snow or gravel, The ABS control unit continuously for example) which usually have a monitors the speed of each wheel. If hard foundation. A vehicle with a one wheel is about to lock up, the ABS normal braking system may require responds by automatically releasing and...
Page 251 WARNING correctly. Take your vehicle to an expert repairer, we recommend an Authorised Do not rely on the Traction Control Mazda Repairer. System (TCS) as a substitute for safe driving: NOTE The Traction Control System (TCS)
Page 252 Use tyres of the correct size as ABS and TCS to help control side slip speci ed for your Mazda on all when driving on slippery surfaces, or four wheels. during sudden or evasive manoeuvring, Use tyres of the same enhancing vehicle safety.
Page 253 If the DSC OFF switch is pressed your vehicle to an expert repairer, we and held for 10 seconds or more, recommend an Authorised Mazda the DSC OFF switch malfunction Repairer. The DSC may have a detection function operates and the malfunction.
Page 254 When Driving i-ELOOP i-ELOOP i-ELOOP is a regenerative braking system. When you depress the brake pedal or use engine braking, the kinetic energy that occurs is converted to electrical energy by the power generator and the converted electrical energy is stored in the rechargeable battery (capacitor and battery).
Page 255 A difference in the fuel economy may occur depending on how the vehicle's electrical devices are used. If the capacitor is to be disposed of, always consult an expert repairer, we recommend an Authorised Mazda Repairer. For details, go to the following URL. http://www.mazda.com/csr/environment/recycling...
Page 256 When Driving i-ELOOP i-ELOOP Control Status Display The driver is noti ed of the i-ELOOP power generating status and the vehicle conditions by the control status display. The i-ELOOP power generating status is displayed in the centre display. Refer to Control Status Display on page 4-104 .
Page 257 3. Operate the commander switch or touch the screen and display the menu. NOTE When the menu is displayed by touching the screen, the display is hidden automatically after 6 seconds. 4. Select the icon in the menu and perform the operation. Each icon operates as follows: Indication on display Control status Hides the menu display.
Page 258 When Driving Fuel Economy Monitor Fuel Consumption Display Information regarding the fuel economy is displayed. Indication on display Control status Displays the fuel economy for the past 60 minutes. Displays the fuel economy every minute for the past 1 to 10 minutes. Displays the fuel economy every 10 minutes for the past 10 to 60 minutes.
Page 259 When Driving Fuel Economy Monitor Indication on display Control status With i-ELOOP system Displays the status of the electricity stored in the rechargeable battery and being supplied to the electrical devices (whole vehicle in display is illuminated simultaneously). Displays the accumulated fuel economy. With i-ELOOP system Displays the readiness status as to whether operation of the i-stop function is available.
Page 260 When Driving Fuel Economy Monitor Indication on display Control status With i-ELOOP system Displays the i-stop function status while the vehicle is stopped. Indicates the operations required by the driver to operate the i-stop function while it is not operating. Without i-ELOOP system Displays the current amount of time that the i-stop function has been operating and the accumulated...
Page 261 When Driving Fuel Economy Monitor Effectiveness Display The actual performance of the energy ef ciency is displayed. Indication on display Control status The leaf graphic grows according to the amount of emissions reduced by the system effects. The cumulative total amount of leaf growth is indicated in terms of the number of tree graphics.
Page 262 It may cause tyre slipping. NOTE When the sport mode is selected, driving at higher engine speeds increases and it may increase fuel consumption. Mazda recommends that you cancel the sport mode on normal driving. Drive mode cannot be switched in the following conditions: ABS/TCS/DSC is operating The Mazda Radar Cruise Control (MRCC) system/cruise control is operating.
Page 263 When Driving Drive Selection Drive Selection Switch Press the drive selection switch forward (“ ”) to select the sport mode. Pull the drive selection switch back (“ ”) to cancel the sport mode. NOTE When the ignition is switched off, the sport mode is cancelled.
Page 264 When Driving i-ACTIV AWD i-ACTIV AWD Operation Tyres and Tyre Chains The condition of the tyres plays a large 4WD provides excellent drivability on role in the performance of the vehicle. snow-covered and ice-packed roads, sand Moreover, to prevent adverse effects to the and mud, as well as on steep slopes and drive assembly, please note the following: other slippery surfaces.
Page 265 When Driving i-ACTIV AWD Tyre chains Install tyre chains to the front tyres. Do not use tyre chains on the rear wheels. Do not drive the vehicle faster than 30 km/h (19 mph) with the tyre chains installed. Do not drive the vehicle with tyre chains on road conditions other than snow or ice.
Page 266: Power Steering
If the steering feels stiffer than usual during normal driving or the steering vibrates, consult an expert repairer, we recommend an Authorised Mazda Repairer. The warning indication/warning light noti es the driver of system abnormalities and operation conditions.
Page 267 When Driving i-ACTIVSENSE i-ACTIVSENSE i-ACTIVSENSE is a collective term covering a series of advanced safety and driver support systems which make use of a Forward Sensing Camera (FSC) and radar sensors. These systems consist of active safety and pre-crash safety systems. These systems are designed to assist the driver in safer driving by reducing the load on the driver and helping to avert collisions or reduce their severity.
Page 268 When Driving i-ACTIVSENSE Driver support systems Inter-vehicle distance Mazda Radar Cruise Control (MRCC) ................4-155 Lane departure Lane-keep Assist System (LAS) ..................4-169 Speed control Adjustable Speed Limiter ....................4-183 Pre-Crash Safety Technology Pre-crash safety technology is designed to assist the driver in averting collisions or reduce their severity in situations where they cannot be avoided.
Page 269 The radar sensor (front) functions by detecting the radio waves re ected off a vehicle ahead sent from the radar sensor. The following systems also use the radar sensor (front). Mazda Radar Cruise Control (MRCC) Distance Recognition Support System (DRSS) Smart Brake Support (SBS) The radar sensor (front) is mounted behind the radiator grille.
Page 270 When Driving i-ACTIVSENSE Ultrasonic sensors (rear) The ultrasonic sensors (rear) function by detecting the ultrasonic waves re ected off obstructions at the rear sent from the ultrasonic sensors. The following systems also use the ultrasonic sensors (rear). Smart City Brake Support [Reverse] (SCBS R) The ultrasonic sensors (rear) are mounted in the rear bumper.
Page 271 When Driving i-ACTIVSENSE Adaptive Front Lighting System (AFS) The adaptive front lighting system (AFS) automatically adjusts the headlight beams to the left or right in conjunction with the operation of the steering wheel after the headlights have been turned on. NOTE Headlights do not blind drivers approaching in the opposite direction...
Page 272 When Driving i-ACTIVSENSE High Beam Control System (HBC) The High Beam Control System (HBC) determines the conditions in front of the vehicle using the Forward Sensing Camera (FSC) while driving in darkness to automatically switch the headlights between high and low beams. Refer to Warning/Indicator Lights on page 4-46 .
Page 273 When Driving i-ACTIVSENSE NOTE The timing in which the system switches the headlights changes under the following conditions. If the system does not switch the headlights appropriately, manually switch between high and low beams according to the visibility as well as road and traf c conditions.
Page 274 When Driving i-ACTIVSENSE To Operate the System Manual Switching The High Beam Control System (HBC) Switching to low beams operates to switch the headlights automatically between high and low Shift the lever to the low beam position. beams after the ignition is switched ON The High Beam Control System (HBC) and the headlight switch is in the AUTO indicator light (green) turns off.
Page 275 When Driving i-ACTIVSENSE Adaptive LED Headlights (ALH) The Adaptive LED Headlights (ALH) are a system which uses the Forward Sensing Camera (FSC) to determine the situation of a vehicle ahead or a vehicle approaching in the opposite direction while driving at night to automatically switch the illumination range of the headlights, the illuminated area, or the illumination brightness.
Page 276 When Driving i-ACTIVSENSE Wide-Range Low Beam This feature extends the illumination range of the light cast by the low beams while driving at a speed less than about 40 km/h (25 mph). Highway Mode This feature shifts the illumination angle of the light cast by the headlights upward while driving on highways.
Page 277 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Adaptive LED Headlights (ALH) may not operate normally. Manually switch between the high and low beams according to the visibility, and the road and traf c conditions. When there are other sources of light in the area such as street lamps, illuminated signboards, and traf c signals.
Page 278 When Driving i-ACTIVSENSE Lane Departure Warning System (LDWS) The LDWS alerts the driver that the vehicle may be deviating from its lane. If the white (yellow) lines on the traf c lane are detected using the Forward Sensing Camera (FSC) and the system determines that the vehicle may be deviating from its lane, it noti es the driver by ashing the LDWS warning light and activating the LDWS warning beep, and by the multi-information display (vehicles with multi-information display) and the active driving...
Page 279 When Driving i-ACTIVSENSE WARNING Do not use the LDWS under the following conditions: The system may not operate adequately according to the actual driving conditions, resulting in an accident. Driving on roads with tight curves. Driving under bad weather conditions (rain, fog, and snow). The functions of the LDWS have limitations: Always stay on course using the steering wheel and drive with care.
Page 280 When Driving i-ACTIVSENSE NOTE Under the following conditions, the LDWS may not be able to detect white or yellow lines correctly and the LDWS may not operate correctly. If an object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 281 When Driving i-ACTIVSENSE When the System Operates The LDWS does not operate in the following cases: If the LDWS OFF indicator light in the The system cannot detect white or instrument cluster turns off when the yellow lines. ignition is switched ON, the system goes The vehicle speed is less than about 60 on standby.
Page 282 When Driving i-ACTIVSENSE Vehicle lane display (vehicles with Auto cancel warning multi-information display) When the following operations are The vehicle lane lines (stand-by) are performed, the LDWS determines that indicated in the multi-information display the driver intends to make a lane change when the LDWS goes on standby.
Page 283 When Driving i-ACTIVSENSE NOTE NOTE When the ignition is switched OFF, the If the LDWS warning sound is set LDWS becomes operational the next to rumble , the sound will be heard time the ignition switched ON. from the vehicle speaker on the side which the system determined the vehicle may be deviating from its lane.
Page 284 When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) The Blind Spot Monitoring (BSM) is designed to assist the driver in checking the area to the rear of the vehicle on both sides during lane changes by notifying the driver of the presence of vehicles approaching from the rear in an adjacent lane.
Page 285 In the following cases, the Blind Spot Monitoring (BSM) OFF indicator light turns on and operation of the system is stopped. If the Blind Spot Monitoring (BSM) OFF indicator light remains illuminated, have the vehicle inspected at an Authorised Mazda Repairer as soon as possible.
Page 286 When Driving i-ACTIVSENSE NOTE In the following case, the ashing of the Blind Spot Monitoring (BSM) warning indicator light, and the activation of the warning sound and the warning screen indicator display may not occur or they may be delayed. A vehicle makes a lane change from a driving lane two lanes over to an adjacent lane.
Page 287 When Driving i-ACTIVSENSE NOTE A Blind Spot Monitoring (BSM) warning indicator light may ash or the warning beep may be activated several times when making a turn at a city intersection. Turn off the Blind Spot Monitoring (BSM) while pulling a trailer or while an accessory such as a bicycle carrier is installed to the rear of the vehicle.
Page 288 When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) Warning Indicator Lights/Blind Spot Monitoring (BSM) Warning Beep The Blind Spot Monitoring (BSM) or Rear Cross Traf c Alert (RCTA) system noti es the driver of the presence of vehicles in adjacent lanes or at the rear of the vehicle using the Blind Spot Monitoring (BSM) warning indicator light, the warning sound and the display indicator (vehicles with multi-information display and active driving display) while the systems are operational.
Page 289 When Driving i-ACTIVSENSE Function for cancelling illumination dimmer If the Blind Spot Monitoring (BSM) warning indicator lights turn on when the position lights are turned on, the brightness of the Blind Spot Monitoring (BSM) warning indicator lights is dimmed. If the Blind Spot Monitoring (BSM) warning indicator lights are dif cult to see due to glare from surrounding brightness when travelling on snow-covered roads or under foggy conditions, press the dimmer cancellation button to cancel the dimmer and increase the brightness of Blind Spot Monitoring (BSM) warning indicator lights when they turn on.
Page 290 When Driving i-ACTIVSENSE Cancelling Operation of Blind Spot Monitoring (BSM) The Blind Spot Monitoring (BSM) system can be set to inoperable. Refer to Personalisation Features on page 9-13 . When the Blind Spot Monitoring (BSM) is set to inoperable, the Blind Spot Monitoring (BSM) and Rear Cross Traf c Alert (RCTA) systems are turned off and the Blind Spot Monitoring (BSM) OFF...
Page 291 Authorised Mazda Repairer. The Traf c Sign Recognition System (TSR) operates only if the navigation system SD card (Mazda genuine) is inserted in the SD card slot. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details.
Page 292 When Driving i-ACTIVSENSE WARNING Always check the traf c signs visually while driving. The Traf c Sign Recognition System (TSR) helps prevent the driver from overlooking traf c signs and provides support for safer driving. Depending on the weather conditions or problems with traf c signs, a traf c sign may not be recognised or a traf c sign different from the actual traf c sign may be displayed.
Page 293 When Driving i-ACTIVSENSE NOTE The Traf c Sign Recognition System (TSR) does not operate if there is a malfunction in the Forward Sensing Camera (FSC). Under the following conditions, the Traf c Sign Recognition System (TSR) may not operate normally. An object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 294 When Driving i-ACTIVSENSE Traf c Sign Display Indication The following traf c signs are displayed on the active driving display. Speed limit signs (including auxiliary signs) Inclement weather speed limit sign Do not enter signs The above indications are some examples. If the Forward Sensing Camera (FSC) cannot classify an auxiliary sign (such as time restrictions, turning restrictions, end of section) correctly, the following screen is displayed.
Page 295 NOTE Speed limit signs (including auxiliary signs) When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is displayed when any one of the following conditions are met. The Forward Sensing Camera (FSC) recognises a speed limit sign as a sign targeted for your vehicle and the vehicle passes it.
Page 296 When Driving i-ACTIVSENSE NOTE Do not enter signs A do not enter sign is displayed when all of the following conditions are met. The vehicle speed is about 80 km/h (50 mph) or slower. The Forward Sensing Camera (FSC) recognises a do not enter sign as a sign targeted for your vehicle and the vehicle passes it.
Page 297 When Driving i-ACTIVSENSE NOTE The excessive speed warning is initially set to inoperable. If you want to activate the excessive speed warning, change the setting in the personalisation features. Off: The excessive speed warning is not activated. Warning display only: The area around the speed limit sign ashes 3 times in amber, and if the vehicle speed continues to exceed the displayed speed limit sign, the indication stops ashing and remains on.
Page 298 When Driving i-ACTIVSENSE Distance Recognition Support System (DRSS) The Distance Recognition Support System (DRSS) measures the distance between your vehicle and a vehicle ahead using a radar sensor (front) while the vehicle speed is about 30 km/h (19 mph) or faster, and if your vehicle approaches a vehicle ahead more closely than what is appropriate for maintaining distance between the vehicles according to the vehicle speed, a noti cation in the active driving display is indicated to advise you to keep a safe distance from the vehicle ahead.
Page 299 The Distance Recognition Support System (DRSS) operation status is indicated in the active driving display or multi-information display. Regarding malfunctions, check the vehicle conditions or have it inspected by an expert repairer, we recommend an Authorised Mazda Repairer according to the content of the displayed message.
Page 300 When Driving i-ACTIVSENSE Distance-between-vehicles guidelines Indication on display Distance between Distance between vehicles guidelines vehicles guidelines (During travel at about (During travel at about Multi-information display Active driving display 40 km/h (25 mph) 80 km/h (50 mph) — About 25 m (82 ft) About 50 m (164 ft) —...
Page 301 When Driving i-ACTIVSENSE Indication on display Distance between Distance between vehicles guidelines vehicles guidelines (During travel at about (During travel at about Multi-information display Active driving display 40 km/h (25 mph) 80 km/h (50 mph) Illuminated in About 10 m (32 ft) or About 20 m (65 ft) or amber less...
Page 302 When Driving i-ACTIVSENSE Driver Attention Alert (DAA) The Driver Attention Alert (DAA) is a system which detects driver fatigue and decreased attentiveness, and encourages the driver to take a rest. When the vehicle is driven inside traf c lane lines at about 65 to 140 km/h (41 to 86 mph), the Driver Attention Alert (DAA) estimates the amount of accumulated fatigue and decreased attentiveness of the driver based on the information from the Forward Sensing Camera (FSC) and other vehicle information, and encourages the driver to take a...
Page 303 When Driving i-ACTIVSENSE NOTE The Driver Attention Alert (DAA) operates when all of the following conditions are met. The vehicle speed is about 65 to 140 km/h (41 to 86 mph). The system detects white (yellow) lane lines. The system has completed learning of the driver’s driving data. The Driver Attention Alert (DAA) does not operate under the following conditions.
Page 304 When Driving i-ACTIVSENSE Driver Attention Alert (DAA) Display When the system detects driver fatigue or decreased attentiveness, it activates the warning sound and displays an alert in the multi-information display. Cancelling Driver Attention Alert (DAA) The Driver Attention Alert (DAA) can be set to not activate.
Page 305 When Driving i-ACTIVSENSE Rear Cross Traf c Alert (RCTA) The Rear Cross Traf c Alert (RCTA) system is designed to assist the driver in checking the area to the rear of the vehicle on both sides while the vehicle is reversing by alerting the driver to the presence of vehicles approaching the rear of the vehicle.
Page 306 When Driving i-ACTIVSENSE Rear Cross Traf c Alert (RCTA) operation 1. The Rear Cross Traf c Alert (RCTA) system operates when the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted to the reverse (R) position. 2. If there is the possibility of a collision with an approaching vehicle, the Blind Spot Monitoring (BSM) warning indicator lights ashes and the warning beep is activated simultaneously.
Page 307 In the following cases, the BSM OFF Indicator Light turns on and operation of the system is stopped. If the BSM OFF Indicator Light remains illuminated, have the vehicle inspected at an Authorised Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning indicator lights has occurred.
Page 308 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensors (rear) cannot detect target objects or it may be dif cult to detect them. The vehicle speed when reversing is about 15 km/h (9 mph) or faster. The radar sensor (rear) detection area is obstructed by a nearby wall or parked vehicle.
Page 309 Mazda Radar Cruise Control (MRCC) The Mazda Radar Cruise Control (MRCC) system is designed to maintain headway control according to the vehicle speed using a radar sensor (front) to detect the distance to a vehicle ahead, which frees the driver from having to constantly use the accelerator or brake pedals.
Page 310 For the purposes of safety, switch the Mazda Radar Cruise Control (MRCC) system off when it is not being used. CAUTION If the vehicle is towed or you are towing something, switch the Mazda Radar Cruise Control (MRCC) system off to prevent an incorrect operation. 4–156...
Page 311 When Driving i-ACTIVSENSE NOTE The Mazda Radar Cruise Control (MRCC) system operates when all of the following conditions are met. The vehicle speed is as follows: (European models) About 30 km/h (19 mph) to 200 km/h (124 mph) (Except European models) About 30 km/h (19 mph) to 145 km/h (90 mph) The Mazda Radar Cruise Control (MRCC) system is turned on.
Page 312 While the Mazda Radar Cruise Control (MRCC) system is in use, it does not cancel even if the selector lever (automatic transaxle)/shift lever (manual transaxle) is operated and any intended engine braking will not occur.
Page 313 NOTE When the ignition is switched to ACC or OFF while the Mazda Radar Cruise Control (MRCC) is ON, the Mazda Radar Cruise Control (MRCC) remains ON automatically. When the MODE switch is pressed while the Mazda Radar Cruise Control (MRCC) system is turned on, the system switches to the cruise control function.
Page 314 1. Adjust the vehicle speed to the desired setting using the accelerator pedal. 2. Headway control begins when the SET or SET switch is pressed. The set speed and the inter-vehicle distance display lled with white lines are displayed. The Mazda Radar Cruise Control (MRCC) set indication (green) is indicated simultaneously.
Page 315 When Driving i-ACTIVSENSE How to Set the Distance Between Vehicles During Headway Control The distance between vehicles is set to a shorter distance each time the switch is pressed. The distance between vehicles is set to a longer distance by pressing the switch.
Page 316 When Driving i-ACTIVSENSE NOTE The distance between vehicles differs depending on the vehicle speed, and the slower the vehicle speed, the shorter the distance. When the ignition is switched to ACC or OFF and then the engine is started again, the system automatically sets the distance between vehicles to the previous setting.
Page 317 When Driving i-ACTIVSENSE When the system is temporarily cancelled NOTE In the following cases, the Mazda Radar Cruise Control (MRCC) is temporarily When accelerating using the SET cancelled, the Mazda Radar Cruise Control switch while in headway control, the (MRCC) set indication (green) is turned...
Page 318 RES switch and after all of the operation conditions have been met. If the Mazda Radar Cruise Control (MRCC) system is deactivated, the system does not return to the previously set speed even if the RES switch is pressed.
Page 319 NOTE If the gears are not shifted up even though the shift-up request indication is displayed, load will be applied to the engine and the Mazda Radar Cruise Control (MRCC) system may be automatically cancelled or engine damage could occur.
Page 320 Switching to cruise control function When the MODE switch is pressed while While this function is operating, the the Mazda Radar Cruise Control (MRCC) headway control operation is cancelled system is turned on, the system switches to and only the cruise control function the cruise control function.
Page 321 When Driving i-ACTIVSENSE How to set the speed How to Decrease the Set Speed Adjust the system to the desired vehicle Press the SET switch continuously and speed using the accelerator pedal. release the switch at the desired speed. When the SET or SET switch is The set speed can be adjusted pressed, the cruise set indication (green) is incrementally (1 km/h (1 mph) increments)
Page 322 When Driving i-ACTIVSENSE NOTE If the vehicle speed decreases by about 15 km/h (9.4 mph) or more than the set speed, the cruise control function may be cancelled. When the vehicle speed is less than 21 km/h (13 mph), the cruise control function is cancelled.
Page 323 When Driving i-ACTIVSENSE Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) alerts the driver that the vehicle may be deviating from its lane and it provides steering assistance to help the driver stay within the vehicle lanes.
Page 324 Departure Warning System (LDWS) can operate normally. Do not modify the suspensions. Always use wheels of the speci ed type and size for the front and rear wheels. Consult an expert repairer, we recommend an Authorised Mazda Repairer for tyre replacement. 4–170...
Page 325 When Driving i-ACTIVSENSE NOTE When the direction indicator lever is operated for a lane change, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) is automatically disabled. The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) becomes operational again when the direction indicator lever is returned and the system detects white (yellow) lane lines while the vehicle is being driven normally within its vehicle lane.
Page 326 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) may not be able to detect white (yellow) lane lines correctly and it may not operate normally. If an object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 327 When Driving i-ACTIVSENSE System Operation Drive the vehicle in the centre of the vehicle lane while the system is on Make sure that the Lane-keep Assist standby. When all of the following System (LAS) & Lane Departure Warning conditions are met, the Lane-keep Assist System (LDWS) OFF indicator light in System (LAS) &...
Page 328 When Driving i-ACTIVSENSE The Lane-keep Assist System (LAS) & NOTE Lane Departure Warning System (LDWS) goes on stand-by status in the following (When the timing of the steering cases: assist is set to “Late”) The system cannot detect white (yellow) The Lane-keep Assist System lane lines.
Page 329 When Driving i-ACTIVSENSE NOTE NOTE If the driver takes his or her hands off The following settings for the the steering wheel (not holding the Lane-keep Assist System (LAS) & steering wheel), the warning sound is Lane Departure Warning System activated and an alert is indicated in (LDWS) can be changed.
Page 330 When Driving i-ACTIVSENSE (Operational status) Auto cancel of warning/steering assist When the following operations are Multi-information Display performed, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) determines that the driver intends to make a lane change and the system operation is cancelled automatically.
Page 331 When Driving i-ACTIVSENSE Steering operation assist OFF (non- NOTE operational) After the operation, the Lane-keep The steering operation assist for the Assist System (LAS) & Lane Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Departure Warning System (LDWS) can operation may not operate for a be changed to non-operational (OFF).
Page 332 When Driving i-ACTIVSENSE Drive the vehicle in the centre of the NOTE driving lane while the Lane-keep Assist System (LAS) & Lane Departure Warning The Lane-keep Assist System (LAS) System (LDWS) OFF indicator light in the & Lane Departure Warning System instrument cluster is turned off.
Page 333 When Driving i-ACTIVSENSE (Stand-by status) (Auto cancel of warnings) When the following operations are Multi-information Display performed, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) determines that the driver intends to make a lane change and the system operation is cancelled automatically.
Page 334 (LDWS) OFF indication is displayed in the multi-information display. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. There is a malfunction in the power steering. There is a malfunction in the DSC. There is a malfunction in the Forward Sensing Camera (FSC).
Page 335 When Driving i-ACTIVSENSE Lane Departure Warning If the system determines that the vehicle may deviate from its lane, the lane departure warning (beep sound, rumble sound , or steering wheel vibration) is activated and the direction in which the system determines that the vehicle may deviate is indicated in the multi-information display or the active driving display.
Page 336 When Driving i-ACTIVSENSE NOTE If you have set the lane departure warning sound to the beep sound/rumble sound setting, the warning sound may not be heard depending on the surrounding noise conditions. If you have set the lane departure warning system to the steering wheel vibrations setting, the vibration may not be felt depending on the road surface conditions.
Page 337 Instrument Cluster Type A Instrument Cluster Type B Without multi- With multi- Active driving display information display information display Mazda Radar Cruise Control (MRCC) Cruise control system MODE switch SET+ switch RES/+ switch RES switch SET- switch SET- switch...
Page 338 Setting display With cruise control Displays when the SET switch is operated and the speed is set. With Mazda Rader Cruise Control (MRCC) Displays when the SET or SET switch is operated and the speed is set. Active Driving Display...
Page 339 When Driving i-ACTIVSENSE Adjustable Speed Limiter Main Indication (White)/Adjustable Speed Limiter Set Indication (Green) The indication has two colours. Adjustable speed limiter main indication (white) The indication display in white when the MODE switch is pressed and the adjustable speed limiter is activated.
Page 340 3 km/h (2 mph). Be careful not to drive over the set speed. (With Mazda Radar Cruise Control (MRCC)) If the set speed is set lower than the current vehicle speed by pressing the SET or RES switch, the warning beep is not activated for about 30 seconds even if the vehicle speed is faster than the newly set speed by 3 km/h (2 mph).
Page 341 Press the OFF/CAN switch. The adjustable speed limiter screen is no longer displayed and the adjustable speed limiter main indication (white) does not display. NOTE When the MODE switch is pressed while the adjustable speed limiter is operating, the system switches to the cruise control or Mazda Radar Cruise Control (MRCC) system. 4–187...
Page 342 When the current vehicle speed is less than 30 km/h (20 mph), the speed is set to 30 km/h (20 mph). (With Mazda Radar Cruise Control (MRCC)) Press the SET or SET to set the speed. When the current vehicle speed is 30 km/h (20 mph) or more, the speed is set to the current vehicle speed.
Page 343 When the vehicle set speed is displayed in the instrument cluster, press the RES / switch to set the displayed vehicle speed. (With Mazda Radar Cruise Control (MRCC)) When the vehicle set speed is displayed in the instrument cluster, press the RES switch to set the displayed vehicle speed.
Page 344 4 to 80 km/h (2 to 50 mph) if the object is a vehicle ahead and about 10 to 80 km/h (6.2 to 50 mph) if the object is a pedestrian.
Page 345 The vehicle speed is between about 4 to 80 km/h (2 to 50 mph). (Object is a pedestrian) The vehicle speed is between about 10 to 80 km/h (6.2 to 50 mph). The Advanced Smart City Brake Support (Advanced SCBS) system is not turned off.
Page 346 The operation distance and volume of the collision warning can be changed. Refer to Personalisation Features on page 9-13 . (With SCBS OFF switch) The operation distance and volume of the collision warning can be changed. Consult an Authorised Mazda Repairer. 4–192...
Page 347 When Driving i-ACTIVSENSE Automatic Brake Operation Stopping the Advanced Smart City Display Brake Support (Advanced SCBS) System Operation “SCBS Automatic Brake” is indicated in the multi-information display or the active The Advanced Smart City Brake Support driving display after the Advanced SCBS (Advanced SCBS) system can be brakes or the brake assist (Advanced temporarily deactivated.
Page 348 When Driving i-ACTIVSENSE With SCBS OFF switch Press the SCBS OFF switch to turn off the system. The Smart City Brake Support (SCBS) OFF indicator light in the instrument cluster will illuminate. Press the switch again to turn the system back on.
Page 349 When Driving i-ACTIVSENSE Smart City Brake Support [Forward] (SCBS F) (Indonesia, Malaysia, and Taiwan) The Smart City Brake Support [Forward] (SCBS F) system alerts the driver of a possible collision using an indication in the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead and determines that a collision with a vehicle ahead is unavoidable while the vehicle is being driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph).
Page 350 When Driving i-ACTIVSENSE CAUTION When driving off-road in areas where there is dense grass, it is recommended that the Smart City Brake Support [Forward] (SCBS F) system be turned off. In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle.
Page 351 When Driving i-ACTIVSENSE NOTE The Smart City Brake Support [Forward] (SCBS F) system will operate under the following conditions. The engine is running. The Smart Brake Support/Smart City Brake Support (SBS/SCBS) system warning indication/warning light (amber) does not illuminate. (Rear-end collision warning) The vehicle speed is about 4 to 80 km/h (2 to 50 mph).
Page 352 SCBS brake is automatically changed. released. Refer to Personalisation Features on page 9-13 . (With SCBS OFF switch) The operation distance and volume of the collision warning can be changed. Consult an Authorised Mazda Repairer. 4–198...
Page 353 When Driving i-ACTIVSENSE Stopping the Smart City Brake With SCBS OFF switch Support [Forward] (SCBS F) Press the SCBS OFF switch to turn System Operation off the system. The Smart City Brake Support (SCBS) OFF indicator light in the The Smart City Brake Support [Forward] instrument cluster will illuminate.
Page 354 When Driving i-ACTIVSENSE Smart City Brake Support [Reverse] (SCBS R) The Smart City Brake Support [Reverse] (SCBS R) is a system which is designed to reduce damage in the event of a collision by operating the brake control (SCBS brake) when the system’s ultrasonic sensors detect an obstruction at the rear of the vehicle while driving at a speed of about 2 to 8 km/h (2 to 4 mph) and the system determines that a collision is unavoidable.
Page 355 (rear), stop using the Smart City Brake Support [Reverse] (SCBS R) system immediately and have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. If the vehicle continues to be driven with cracks or scratch marks left around an ultrasonic sensor, the system may operate unnecessarily and cause an unexpected accident.
Page 356 When Driving i-ACTIVSENSE CAUTION When driving off-road in areas where there is grass or foliage, it is recommended that the Smart City Brake Support [Reverse] (SCBS R) system be turned off. Always use tyres of the speci ed size and the same manufacturer, brand, and tread pattern on all 4 wheels.
Page 357 When Driving i-ACTIVSENSE NOTE In the following cases, the ultrasonic sensors (rear) cannot detect obstructions and the Smart City Brake Support [Reverse] (SCBS R) may not operate. The height of the obstruction is low such as low walls or trucks with low loading platforms.
Page 358 When Driving i-ACTIVSENSE NOTE In the following cases, an ultrasonic sensor (rear) may detect something as a target obstruction which could cause the Smart City Brake Support [Reverse] (SCBS R) system to operate. Driving on a steep slope. Wheel blocks. Hanging curtains, gate poles such as at toll gates and railroad crossing.
Page 359 When Driving i-ACTIVSENSE Smart City Brake Support (SCBS) NOTE Indicator Light (Red) The collision warning beep sounds If the Smart City Brake Support (SCBS) is intermittently while the SCBS brake operating, the indicator light (red) ashes. is operating. If the vehicle is stopped by the SCBS operation and the brake pedal is not depressed, the warning beep sounds one time after about 2 seconds and...
Page 360 When Driving i-ACTIVSENSE With SCBS OFF switch Press the SCBS OFF switch to turn off the system. The Smart City Brake Support (SCBS) OFF indicator light in the instrument cluster will illuminate. Press the switch again to turn the system back on.
Page 361 When Driving i-ACTIVSENSE Smart Brake Support (SBS) The Smart Brake Support (SBS) system alerts the driver of a possible collision using a display and warning sound if the radar sensor (front) and the Forward Sensing Camera (FSC) determine that there is the possibility of a collision with a vehicle ahead while the vehicle is being driven at about 15 km/h or faster (10 mph or faster).
Page 362 When Driving i-ACTIVSENSE NOTE The Smart Brake Support (SBS) system operates when all of the following conditions are met: The ignition is switched ON. The Smart Brake Support (SBS) system is on. The vehicle speed is about 15 km/h or faster (10 mph or faster). The relative speed between your vehicle and the vehicle ahead is about 15 km/h or faster (10 mph or faster).
Page 363 When Driving i-ACTIVSENSE Smart Brake Support (SBS) Stopping The Smart Brake Indicator Light (Red) Support (SBS) System Operation If the Smart Brake Support (SBS) is The Smart Brake Support (SBS) system operating, the indicator light (red) ashes. can be temporarily deactivated. Refer to Personalisation Features on page 9-13 .
Page 364 When Driving i-ACTIVSENSE Forward Sensing Camera (FSC) Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing Camera (FSC) is positioned near the rearview mirror and used by the following systems. High Beam Control System (HBC) Adaptive LED Headlights (ALH) Driver Attention Alert (DAA) Lane Departure Warning System (LDWS) Lane-keep Assist System (LAS) &...
Page 365 When Driving i-ACTIVSENSE CAUTION Do not apply accessories, stickers or lm to the windscreen near the Forward Sensing Camera (FSC). If the area in front of the Forward Sensing Camera (FSC) lens is obstructed, it will cause the system to not operate correctly. Consequently, each system may not operate normally which could lead to an unexpected accident.
Page 366 Always keep the windscreen glass around the camera clean by removing dirt or fogging. Use the windscreen defroster to remove fogging on the windscreen. Consult an expert repairer, we recommend an Authorised Mazda Repairer regarding cleaning the interior side of the windscreen around the Forward Sensing Camera (FSC).
Page 367 When Driving i-ACTIVSENSE CAUTION Always use tyres for all wheels that are of the speci ed size, and the same manufacturer, brand, and tread pattern. In addition, do not use tyres with signi cantly different wear patterns on the same vehicle as the system may not operate normally. The Forward Sensing Camera (FSC) includes a function for detecting a soiled windscreen and informing the driver, however, depending on the conditions, it may not detect plastic shopping bags, ice or snow on the windscreen.
Page 368 When Driving i-ACTIVSENSE NOTE In the following cases, the Forward Sensing Camera (FSC) may not be able to detect target objects correctly. Under bad weather condition, such as rain, fog and snow. The window washer is being used or the windscreen wipers are not used when it's raining.
Page 369 When Driving i-ACTIVSENSE NOTE If the Forward Sensing Camera (FSC) cannot operate normally due to backlight or fog, the system functions related to the Forward Sensing Camera (FSC) are temporarily stopped and the following warning lights turn on. However, this does not indicate a malfunction.
Page 370 Radar Sensor (Front) Your vehicle is equipped with a radar sensor (front). The following systems also use the radar sensor (front). Mazda Radar Cruise Control (MRCC) Distance Recognition Support System (DRSS) Smart Brake Support (SBS) The radar sensor (front) functions by detecting the radio waves re ected off a vehicle ahead or an obstruction sent from the radar sensor.
Page 371 If the front part of the vehicle has been damaged in a vehicle accident, the position of the radar sensor (front) may have moved. Stop the system immediately and always have the vehicle inspected at an Authorised Mazda Repairer. Do not use the front bumper to push other vehicles or obstructions such as when pulling out of a parking space.
Page 372 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensor (front) may not be able to detect vehicles ahead or obstructions correctly and each system may not operate normally. The rear surface of a vehicle ahead does not re ect radio waves effectively, such as an unloaded trailer or an automobile with a loading platform covered by a soft top, vehicles with a hard plastic tailgate, and round-shaped vehicles.
Page 373 Always keep the surface of the rear bumper near the radar sensors (rear) clean so that the radar sensors (rear) operate normally. Also, do not apply items such as stickers. Refer to Exterior Care on page 6-71 . CAUTION If the rear bumper receives a severe impact, the system may no longer operate normally.
Page 374 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork, and replacement near the radar sensors, consult an expert repairer, we recommend an Authorised Mazda Repairer. Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier is installed to the rear of the vehicle.
Page 375 When Driving i-ACTIVSENSE Ultrasonic Sensor (Rear) The ultrasonic sensors (rear) function by emitting ultrasonic waves which are re ected off obstructions at the rear and the returning ultrasonic waves are picked up by the ultrasonic sensors (rear). Saloon Wagon Ultrasonic sensor (rear) Ultrasonic sensor (rear) The ultrasonic sensors (rear) are mounted in the rear bumper.
Page 376: Cruise Control
When Driving Cruise Control Cruise Control With cruise control, you can set and automatically maintain any speed of more than about 25 km/h (16 mph). WARNING Do not use the cruise control under the following conditions: Using the cruise control under the following conditions is dangerous and could result in loss of vehicle control.
Page 377 When Driving Cruise Control Cruise Main Indication (White)/ Without adjustable speed limiter Cruise Set Indication (Green) To activate the system, press the ON switch. The cruise main indication (white) illuminates. To deactivate the system, press the OFF/ CAN switch. The cruise main indication (white) turns off.
Page 378 When Driving Cruise Control To Set Speed NOTE 1. (With adjustable speed limiter) The cruise control speed setting Activate the cruise control system by cannot be performed under the pressing the MODE switch. The cruise following conditions: main indication (white) turns on. (Without adjustable speed limiter) (Automatic transaxle) Activate the cruise control system by...
Page 379 Increasing speed with a single RES / Type B Instrument Cluster switch operation Instrument cluster display for vehicle speed indicated in km/h: 1 km/h (0.6 mph) Instrument cluster display for vehicle speed indicated in mph: 1 mph (1.6 km/h) To increase speed using accelerator...
Page 380 Instrument cluster display for vehicle (Manual transaxle) The shift speed indicated in km/h: 1 km/h (0.6 mph) lever is in the neutral position. Instrument cluster display for vehicle When the cruise control system is speed indicated in mph: 1 mph (1.6 km/h)
Page 381: Tyre Pressure Monitoring System
When Driving Tyre Pressure Monitoring System Tyre Pressure Monitoring System The Tyre Pressure Monitoring System (TPMS) monitors the air pressure of all four tyres. If the air pressure of one or more tyres is too low, the system warns the driver by indicating the tyre pressure monitoring system warning light in the instrument cluster and operating a beep sound.
Page 382 When Driving Tyre Pressure Monitoring System CAUTION Each tyre, including the spare (if provided), should be checked monthly when cold and in ated to the in ation pressure recommended by the vehicle manufacturer on the vehicle placard or tyre in ation pressure label. (If your vehicle has tyres of a different size than the size indicated on the vehicle placard or tyre in ation pressure label, you should determine the proper tyre in ation pressure for those tyres.) As an added safety feature, your vehicle has been equipped with a tyre pressure...
Page 383 When Driving Tyre Pressure Monitoring System NOTE Because this system detects slight changes in tyre conditions, the timing of the warning may be faster or slower in the following cases: The size, manufacturer, or the type of tyres is different from the speci cation. The size, manufacturer, or the type of a tyre is different from the others, or the level of tyre wear is excessively different between them.
Page 384 When Driving Tyre Pressure Monitoring System Tyre Pressure Monitoring System CAUTION Initialization In the following cases, system If the system initialization is performed initialization must be performed so that the without adjusting the tyre pressure, the system operates normally. system cannot detect the normal tyre pressure and it may not illuminate the A tyre pressure is adjusted.
Page 385: Diesel Particulate Filter
If the vehicle is repeatedly driven for a repairer, we recommend an Authorised short period of time (10 minute or less) Mazda Repairer. If the vehicle is not or driven while the engine is cold. inspected and continues to be driven, the If the vehicle is idled for a long time.
Page 386: Rear View Monitor
When Driving Rear View Monitor Rear View Monitor The rear view monitor provides visual images of the rear of the vehicle when reversing. WARNING Always drive carefully con rming the safety of the rear and the surrounding conditions by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an accident or a collision with an object.
Page 387 When replacing the tyres, consult an expert repairer, we recommend an Authorised Mazda Repairer. Replacing the tyres could result in deviation of the guide lines which appear on the display. If the vehicle's front, side, or rear has been involved in a collision, the alignment of the rear view parking camera (location, installation angle) may have deviated.
Page 388 When Driving Rear View Monitor Switching to the Rear View Monitor Display Shift the shift lever (manual transaxle) or the selector lever (automatic transaxle) to reverse (R) with the ignition switched ON to switch the display to the rear view monitor display. NOTE When the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted from reverse (R) to another shift lever (manual transaxle) or the selector lever...
Page 389 When Driving Rear View Monitor NOTE The displayable range varies depending on the vehicle and road conditions. The displayable range is limited. Objects under the bumper or around the bumper ends cannot be displayed. The distance appearing in the displayed image is different from the actual distance because the rear view parking camera is equipped with a speci c lens.
Page 390 When Driving Rear View Monitor Viewing the Display Predicted vehicle path assist lines display type The projected path guidance mode displays the predicted path of the vehicle after you turn the steering wheel. Use this mode for parking your vehicle in a parking space or garage. a) Projected vehicle path (yellow) These lines are displayed as a reference for the projected path of the vehicle.
Page 391 When Driving Rear View Monitor CAUTION The indicated position of the guide lines on the display changes depending on the vehicle conditions (such as the number of occupants/cargo load) and the road conditions (such as a steep gradient to the rear of the vehicle). Always check the area to the vehicle's rear and the surrounding area directly with your eyes while backing up.
Page 392: Rear View Monitor Operation
When Driving Rear View Monitor Rear View Monitor Operation The operation of the rear view monitor when reversing the vehicle varies depending on the traf c, road, and vehicle conditions. The amount of steering and the timing also varies depending on conditions, so con rm the surrounding conditions directly with your eyes and steer the vehicle in accordance with the conditions.
Page 393 (Display condition) (Vehicle condition) 6. When the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted from reverse (R) to another shift lever (manual transaxle) or the selector lever (automatic transaxle) position, the screen returns to the previous display.
Page 394 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and distance guide lines may appear aligned in the monitor, but they may not actually be aligned on the ground.
Page 395 (Display condition) (Vehicle condition) 6. When the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted from reverse (R) to another shift lever (manual transaxle) or the selector lever (automatic transaxle) position, the screen returns to the previous display.
Page 396 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and distance guide lines may appear aligned in the monitor, but they may not actually be aligned on the ground.
Page 397 When Driving Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. Appears Appears farther than closer than actual...
Page 398 When Driving Rear View Monitor (Predicted vehicle path assist lines display type) When reversing near a three-dimensional object When reversing near an overhanging object, the vehicle may hit the object even if the anticipated course line does not contact the object on the screen. The position of the object displayed on the screen is different from the actual position because the anticipated course lines on the screen are displayed based on a horizontal road surface.
Page 399: Parking Sensor System
10 km/h (6 mph) or less. The system is equipped with an assist device to notify the driver of the approximate distance from the vehicle to the surrounding obstruction...
Page 400 Small, short objects Always have the system inspected at an expert repairer, we recommend an Authorised Mazda Repairer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
Page 401 Remove any foreign material from the sensor area. When installing a trailer hitch, consult an expert repairer, we recommend an Authorised Mazda Repairer. Sensor Detection Range The sensors detect obstructions within the following range.
Page 402 When Driving Parking Sensor System Park Assist Sensor System Operation When the parking sensor switch is pressed with the ignition switched ON, the buzzer sounds and the indicator light turns on. When the ignition is switched ON with the parking sensor activated, the buzzer sounds and the indicator light turns on.
Page 403 When Driving Parking Sensor System Obstruction Detection Indication The position of a sensor which has detected an obstruction is indicated. The gauge illuminates in different areas depending on the distance to an obstruction detected by the sensor. As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the vehicle illuminates.
Page 404 Solution The system may have a malfunction. Have the vehicle inspected at an expert repairer, we Disconnection recommend an Authorised Mazda Repairer as soon as possible. The system may have a malfunction. Have System the vehicle inspected at an expert repairer, we...
Page 405 Distance between vehicle and obstruction Distance Beeper sound Detection area Front Sensor Rear Sensor Approx. 100—60 cm (39.3—23.6 in) Approx. 150—60 cm (59.0—23.6 in) Slow intermittent Farthest distance sound Approx. 60—45 cm (23.6—17.7 in) Approx. 60—45 cm (23.6—17.7 in) Medium...
Page 406 *1 The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction. NOTE If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped (except for the close-distance zone). If the same obstruction is detected in another zone, the corresponding beep sound is heard.
Page 407: Indicator Light
The system may have a malfunction. Have the vehicle inspected at an expert The beep sound is not heard. repairer, we recommend an Authorised Mazda Repairer as soon as possible. Remove any foreign material from the sensor area. If the system does not...
Page 408 MEMO 4–254...
Page 409: Interior Features
Interior Features Use of various features for ride comfort, including air-conditioning and audio system. Air-Conditioning System ..............5-2 Operating Tips ................5-2 Vent Operation ................5-3 Manual Type ................. 5-5 Fully Automatic Type ..............5-9 Audio System ..................5-13 Aerial ................... 5-13 Operating Tips for Audio System ..........
Page 410 For details, consult an expert repairer, air inlet in the cowl grille to improve the we recommend an Authorised Mazda system ef ciency. Repairer. Use the air-conditioning system to defog the windows and dehumidify the air.
Page 411 Interior Features Air-Conditioning System Vent Operation Centre Vents Knob Adjusting the Vents Open Directing air ow To adjust the direction of air ow, move the Close adjustment knob. Dial NOTE Rear Vents When using the air conditioner Knob Dial under humid ambient temperature conditions, the system may blow Open fog from the vents.
Page 412 Interior Features Air-Conditioning System Selecting the Air ow Mode Instrument panel Vents Defroster and Floor Vents Defroster Vents Instrument panel and Floor Vents Floor Vents * With rear vents 5–4...
Page 413 Interior Features Air-Conditioning System Manual Type Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch Control Switches Mode selector dial Turn the mode selector dial to select Temperature control dial air ow mode (page 5-4 ).
Page 414 Using the position in cold or rainy weather is dangerous as it will cause the windows to fog up. Your vision will be hampered, which could lead to a serious accident. 5–6...
Page 415 Interior Features Air-Conditioning System Cooling (With air conditioner) NOTE 1. Set the mode selector dial to the When maximum cooling is desired, position. set the temperature control dial to 2. Set the temperature control dial to the the extreme cold position and set the cold position.
Page 416 Interior Features Air-Conditioning System Dehumidifying (With air WARNING conditioner) Operate the air conditioner in cool or cold Do not defog the windscreen using the weather to help defog the windscreen and position with the temperature side windows. control set to the cold position: Using the position with the 1.
Page 417 Interior Features Air-Conditioning System Fully Automatic Type Air-conditioning information is displayed on the display. Temperature setting display (driver’s side) Windscreen defroster switch Driver temperature control dial Air intake selector Rear window defogger switch (recirculated air position) Air intake selector A/C mode display Passenger temperature (outside air position) control dial...
Page 418 Interior Features Air-Conditioning System OFF switch Mode selector switch Pressing the OFF switch shuts off the air- The desired air ow mode can be selected conditioning system. (page 5-4 ). Temperature control dial NOTE This dial controls temperature. Turn it With the air ow mode set to the clockwise for hot and anticlockwise for position and the temperature...
Page 419 Interior Features Air-Conditioning System DUAL switch NOTE Use the DUAL switch to change the The air-conditioning operates when mode between the individual operation the A/C switch is pressed even if the (driver and passenger) and interconnection fan is off. (simultaneous) modes. The A/C ECO function is designed to economize use of the air- Individual operation mode (indicator...
Page 420 Interior Features Air-Conditioning System To turn off the system, press the OFF NOTE switch. Use the temperature control dial to NOTE increase the air ow temperature and defog the windscreen more quickly. Setting the temperature to maximum hot or cold will not provide the desired temperature at a faster rate.
Page 421 Interior Features Audio System Aerial Operating Tips for Audio System Type A The aerial is embedded into the window WARNING glass. Always adjust the audio while the CAUTION vehicle is stopped: Do not adjust the audio control When washing the inside of the window switches while driving the vehicle.
Page 422 Interior Features Audio System Radio Reception NOTE AM characteristics To prevent the battery from being discharged, do not leave the audio AM signals bend around such things as system on for a long period of time buildings or mountains and bounce off the when the engine is not running.
Page 423 Interior Features Audio System Signals from an FM transmitter are similar Flutter/Skip noise to beams of light because they do not Signals from an FM transmitter move in bend around corners, but they do re ect. straight lines and become weak in valleys Unlike AM signals, FM signals cannot between tall buildings, mountains, and travel beyond the horizon.
Page 424 Interior Features Audio System Strong signal noise Operating Tips for CD Player This occurs very close to a transmitter Condensation phenomenon tower. The broadcast signals are extremely strong, so the result is noise and sound Immediately after turning on the heater breakup at the radio receiver.
Page 425 Interior Features Audio System If the memory portion of the CD is CDs bearing the logo shown in the transparent or translucent, do not use the illustration can be played. No other discs disc. can be played. Transparent A new CD may have rough edges on its inner and outer perimeters.
Page 426 Interior Features Audio System The CD player ejects the CD if the CD Operating Tips for MP3 is inserted upside down. Also dirty and/ MP3 stands for MPEG Audio Layer 3, or defective CDs may be ejected. which is standardised voice compression Do not insert cleaning discs in the CD established by the ISO working group...
Page 427 Interior Features Audio System This audio system handles MP3 les Operating Tips for AAC that have been recorded on CD-R/CD- AAC stands for Advanced Audio Coding, RW/CD-ROMs. which is standardised voice compression When naming an MP3 le, be sure to established by the ISO working group add an MP3 le extension (.mp3) after...
Page 428 Interior Features Audio System Operating Tips for DVD Player A new DVD may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting Condensation phenomenon will not be possible and the DVD player Immediately after turning on the heater will not play the DVD.
Page 429 Interior Features Audio System Be sure never to touch the signal surface This unit may not be able to play certain when handling the DVDs. Pick up a DVD-R/DVD R/DVD-RW/DVD DVD by grasping the outer edge or the RWs made using a computer or DVD edge of the hole and the outer edge.
Page 430 Interior Features Audio System Mark Meaning NOTE Indicates the region code for which a disc can be Video data (DVD-Video/DVD-VR played. les) written to DVD/DVD-R/ ALL indicates global DVD R/DVD-RW/DVD RW can applicability, and a number be played. indicates applicability based on region.
Page 431 Interior Features Audio System Multi-language OGG les written under speci cations other than the indicated speci cation As a function of the DVD player, audio may not play normally or les or folder or subtitles for the same video images can names may not display correctly.
Page 432 If data in the iPod is lost while it is To prevent loss or damage of stored connected to the unit, Mazda cannot data, we recommend that you always guarantee recovery of any lost data. back up your data.
Page 433 Interior Features Audio System Audio Set [Type A/Type B (non-touchscreen)] Type A (RDS non-compatible) Type B (RDS compatible) Power/Volume/Sound Controls ................page 5-26 Clock ........................page 5-28 Operating the Radio (Type A) ................page 5-30 Operating the Radio (Type B) ................page 5-32 Operating the Compact Disc (CD) Player.............
Page 434: Volume Adjustment
Interior Features Audio System Power/Volume/Sound Controls Audio display Menu button Power/Volume/Audio control dial The figure is an example showing the type A unit. Power ON/OFF 2. Turn the audio control dial to adjust the selected functions as follows: Switch the ignition to ACC or ON. Press the power/volume dial to turn the audio Setting value system on.
Page 435 Interior Features Audio System BT SETUP mode NOTE Music and other audio such as voice data If not operated for several seconds, the recorded on portable audio devices and display returns to the previous display. mobile phones available on the market To reset bass, treble, fade, and balance, which are equipped with the Bluetooth ®...
Page 436 Interior Features Audio System Clock :00 button Audio control dial Audio display Clock button Menu button Hour/Minute set switch The figure is an example showing the type A unit. Setting the time Time resetting The clock can be set at any time when the 1.
Page 437 MEMO 5–29...
Page 438 Interior Features Audio System Operating the Radio (Type A) Audio display Channel preset buttons Tuning button Scan button Auto memory button Band selector button Radio ON Seek tuning Press a band selector button ( ) to Automatic search for radio stations starts turn the radio on.
Page 439 Interior Features Audio System Preset channel tuning The 6 preset channels can be used to store 6 AM and 12 FM stations. 1. To set a channel rst select AM, FM1, or FM2. Tune to the desired station. 2. Press a channel preset button for about 2 seconds until a beep is heard.
Page 440 Interior Features Audio System Operating the Radio (Type B) Audio display Channel preset buttons Tuning button Scan button Programme-type information button Band selector button Traffic announcement button Radio ON Seek tuning Press a band selector button ( ) to Automatic search for radio stations starts turn the radio on.
Page 441 Preset channel tuning If you wish to continue a regional programme, press the menu button The 6 preset channels can be used to store ) and select the REG mode to turn 6 MW/LW and 12 FM stations. it on. “ REG ON ” is displayed. To cancel 1.
Page 442 2. Operate any one of the following: USB device, AUX, or BT audio), and “ Alarm! ” is displayed. Press the pre-programmed channel preset button ( 1 to 6 ). When the emergency broadcast ends, the Press the Programme-type system will return to the previous mode.
Page 443 MEMO 5–35...
Page 444 Interior Features Audio System Operating the Compact Disc (CD) Player Repeat button Text button Play/Pause button Random button Audio display Track down/ Folder up button Media/Scan button Reverse button Folder down button Track up/ Fast-forward button CD eject button CD slot The figure is an example showing the type A unit.
Page 445 Interior Features Audio System Pause During MP3/WMA/AAC CD playback To stop playback, press the Play/Pause This function scans the titles in a folder button ( 4 ). currently being played and plays 10 Press the button again to resume playback. seconds of each song to aid you in nding a song you want to listen to.
Page 446 Interior Features Audio System (Folder repeat) (CD random) 1. Press the repeat button ( 1 ) during 1. Press the random button ( 2 ) during playback, and then press the button playback, and then press the button again within 3 seconds to play the again within 3 seconds to play the tracks in the current folder repeatedly.
Page 447 (3.5 ) stereo mini plug lead. be displayed are indicated by an Contact an expert repairer, we recommend asterisk ( ). an Authorised Mazda Repairer for details. In addition, audio can be played from the vehicle audio device by connecting a USB Display scroll device to the USB port.
Page 448 Interior Features Audio System Audio Set [Type C/Type D (touchscreen)] NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance. Additionally, depending on future software updates, the content may successively change without notice.
Page 449 Interior Features Audio System Switches around commander knob The following operations can be done by pressing the switches around the commander knob. : Displays the home screen. : Displays the Entertainment screen. : Displays the Navigation screen (Only navigation-equipped vehicles). For operation of the Navigation screen, refer to the navigation system manual.
Page 450 Interior Features Audio System Touch panel operation CAUTION Do not press the screen strongly or press it with a sharp-pointed object. Otherwise, the screen could be damaged. NOTE For safety reasons, operation of the centre display is disabled while the vehicle is being driven.
Page 451 Interior Features Audio System SLIDE 1. Touch the setting item displaying a slider bar. 2. Touch the slider with your nger and move to the desired level. SWIPE 1. Touch the screen with your nger and move up or down. 2.
Page 452 Interior Features Audio System Home screen Icon Function Applications Information such as average fuel economy, maintenance, and warnings can be veri ed. Depending on the grade and speci cation, the screen display may differ. Entertainment Operates audio such as the radio and CDs. The audio source most recently used is displayed.
Page 453 MEMO 5–45...
Page 454 Interior Features Audio System Volume/Display/Sound Controls Audio control switch Commander switch Volume dial Volume switch Volume adjustment Daytime/nighttime (Mode) screen setting Turn the commander switch volume dial. The volume switch on the steering switch The daytime or nighttime screen can be can also be pressed.
Page 455 Interior Features Audio System Audio sound adjustment Bose Centerpoint (Automatic surround ® level adjustment) Select the icon on the home screen to Centerpoint lets vehicle owners enjoy ® *3 display the Settings screen. a Bose surround sound experience from ® Select the tab to select the item you their existing CDs and MP3s.
Page 456 Interior Features Audio System Operating the Radio (Type C) Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the centre display. AM/FM Radio Icon Function...
Page 457 Interior Features Audio System Favourites Radio Changing Favourites list order Selected stations can be registered for 1. Select the icon to display the convenient operation. Up to 50 stations Favourites list. can be registered. The Favourites list is 2. Select common to AM and FM radio.
Page 458 Interior Features Audio System Operating the Radio (Type D) Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the centre display. AM/FM Radio Icon Function...
Page 459 Interior Features Audio System Deleting from Favourites NOTE 1. Select the icon to display the Favourites list. When the icon is selected while 2. Select FM is selected, each programme is 3. Select selected. 4. Select the radio frequency you want to delete.
Page 460 Interior Features Audio System Traf c announcement (TA) (Selecting Genre) Select during FM/AM reception to 1. Select the on the station list switch to the TA mode. screen to display the genre list screen. If a TA broadcast is received while in the 2.
Page 461 Interior Features Audio System Operating the Digital Audio Broadcasting (DAB) Radio (Type D) What is DAB radio? DAB radio is a digital broadcasting system for radio. DAB radio provides a high-quality radio sound source using an auto frequency switching function in boundary areas. By displaying the radio text, information such as the song name and artist name can be displayed.
Page 462 Interior Features Audio System Icon Function Goes to the next station. Touch and hold to go to the top station in the next ensemble. Displays the DAB radio setting screen. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-46 . Example of use (Update station list and DAB radio setting listen to DAB radio)
Page 463 Interior Features Audio System NOTE The radio text may not be displayed depending on the radio station. The radio text cannot be displayed in DAB-FM mode. If there is no DAB radio signal, “Signal Lost” is displayed on the screen. Change the ensemble or radio station, or perform station list updating.
Page 464 Interior Features Audio System Operating the Compact Disc (CD) Player CD eject button CD slot Inserting the CD Type Playable data Music data (CD-DA) Insert the CD into the slot, label-side up. Music/MP3/WMA/ AAC CD player MP3/WMA/AAC le The auto-loading mechanism will set the CD and begin play.
Page 465 Interior Features Audio System Playback Select the icon on the home screen with a CD inserted and display the Entertainment screen. When is selected, the following icons are indicated in the lower part of the centre display. Icon Function Displays the Entertainment menu. Use to switch to a different audio source. (Music CD) Displays the track list of the CD.
Page 466 Interior Features Audio System Icon Function Plays a CD. When selected again, playback is temporarily stopped. Advances to the beginning of the next song. Long-press to fast forward. It stops when you remove your hand from the icon or the commander knob.
Page 467 MEMO 5–59...
Page 468 Interior Features Audio System Operating the Digital Versatile Disc (DVD) Player DVD eject button DVD slot Ejecting the DVD Type Playable data DVD VIDEO/DVD- DVD VIDEO/DVD-VR Press the DVD eject button ( ) to eject the VR player DVD. Inserting the DVD Insert the DVD into the slot, label-side up.
Page 469 Interior Features Audio System Playback Select the icon on the home screen with a DVD inserted and display the Entertainment screen. When is selected, the DVD top menu screen and the controller are displayed. When starting the playback by operating the controller, the following icons are displayed at the bottom of the screen.
Page 470 Interior Features Audio System Setting image quality NOTE Brightness, contrast, tint, colour density For safety reasons, images are not can be adjusted. displayed while the vehicle is being When the icon is selected, the following driven. tabs are displayed at the bottom of the Slide the of the controller to screen.
Page 471 Interior Features Audio System Settings NOTE Depending on the grade and speci cation, the screen display may differ. Select the icon on the home screen and display the Settings screen. Switch the tab and select the setting item you want to change. You can customize settings in the setup display as follows: Item Function...
Page 472 2. Voice recognition assistance for Play Artist Music Database Update and Play Album System Gracenote can be downloaded from the Mazda Handsfree Website. Refer to Gracenote Database (Type C/Type D) on page 5-84 . Memory and settings are initialized to the factory settings.
Page 473 Hands-Free ® Scheduled Maintenance Maintenance Monitor Maintenance Tyre Rotation (Type C/Type Oil Change D audio) on Vehicle page 6-16 . Status Refer to If Monitor Warnings a Warning Warning currently Light Turns Guidance active can be On or Flashes veri ed.
Page 474 Interior Features Audio System Adjusting the Volume DAB radio (Type D) Press the Seek switch ( , ) while To increase the volume, press up the listening to DAB radio to call up a station volume switch ( ). previously stored to the favourites list. To decrease the volume, press down the With each operation of the switch, radio volume switch ( ).
Page 475 If the ignition is switched off with the Contact an expert repairer, we recommend audio muted, the mute will be cancelled. an Authorised Mazda Repairer for details. Therefore, when the engine is restarted, In addition, audio can be played from the the audio is not muted.
Page 476 Interior Features Audio System Type C/Type D CAUTION Depending on the portable audio device, noise may occur when the device is connected to the vehicle accessory socket. (If noise occurs, do not use the accessory socket.) NOTE Auxiliary jack USB port This mode may not be usable How to use AUX mode depending on the portable audio...
Page 477 Interior Features Audio System How to connect USB port/ Connecting with a connector lead Auxiliary jack 1. Open the console lid. 2. If there is a cover on the AUX jack or Type A/Type B USB port, remove the cover. 3.
Page 478 Interior Features Audio System How to use AUX mode (Type A/ Type B) 1. Switch the ignition to ACC or ON. 2. Press the power/volume dial to turn the audio system on. 3. Press the media button ( ) of the audio unit to change to the AUX mode.
Page 479 MEMO 5–71...
Page 480 Interior Features Audio System How to use USB mode (Type A/Type B) Random button Audio display Repeat button Text button Play/Pause button Folder up button Track down/Reverse button Folder down button Media/Scan button Track up/Fast-forward button The figure is an example showing the type A unit. NOTE Type Playable data...
Page 481 Interior Features Audio System Track search Repeat playback Press the track up button ( ) once to skip Track repeat forward to the beginning of the next track. Press the track down button ( ) within a 1. Press the repeat button ( 1 ) during few seconds after playback begins to track playback to play the current track down to the beginning of the previous...
Page 482 USB device has Folder number/File number MP3/WMA/AAC les and re-connect correctly. If the message reappears, have File name the unit checked by an Authorised Mazda Folder name Repairer. Album name Song name Artist name NOTE...
Page 483 MEMO 5–75...
Page 484 Interior Features Audio System How to use iPod mode (Type A/Type B) Audio display Text button Play/Pause button Random button Category down button Repeat button Category up button List up button Track down/Reverse button Track up/Fast-forward button List down button Media/Scan button The figure is an example showing the type A unit.
Page 485 Press the category down button ( 5 ) to selected. select the previous category and press the category up button ( 6 ) to select the next category. Repeat playback NOTE 1. Press the repeat button ( 1 ) during...
Page 486 Album name malfunction in the iPod. Verify that the Song name content recorded in the iPod has playable les and connect correctly. If the message reappears, have the unit checked by an Authorised Mazda Repairer. 5–78...
Page 487 Error Indications (Type A/Type B) If you see an error indication on the display, nd the cause in the chart. If you cannot clear the error indication, take the vehicle to an expert repairer, we recommend an Authorised Mazda Repairer. Indication Cause Solution...
Page 488 Interior Features Audio System How to use AUX mode (Type C/Type D) 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch to the AUX mode. The following icons are displayed in the lower part of the centre display.
Page 489 Interior Features Audio System Playback 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch the USB mode. The following icons are displayed in the lower part of the centre display. Icon Function Displays the Entertainment menu.
Page 490: Category List
Interior Features Audio System NOTE To move to the desired location on the track, move the slider indicating the playback time. The appearance of the repeat and shuf e icons changes depending on the type of operation in which the function is used. Category list Select the icon to display the following category list.
Page 491 Interior Features Audio System Example of use (to play all tracks in USB device) (Method 1) 1. Select to display the category list. 2. Select All the tracks in the USB device are displayed. 3. Select a desired track. The selected track is played. All the tracks in the USB device can be played by continuing playback.
Page 492 Gracenote music recognition service. CAUTION For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com Introduction Music recognition technology and related data are provided by Gracenote .
Page 493 Interior Features Audio System You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers for your own personal non-commercial use only. You agree not to assign, copy, transfer or transmit the Gracenote Software or any Gracenote Data to any third party. YOU AGREE NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
Page 494 4. Select . The list of the update package stored in the USB device and the version are displayed. 5. Select the package to use the update. 6. Select NOTE Gracenote can be downloaded from the Mazda Hands-free Website. 5–86...
Page 495 Interior Features Bluetooth ® Bluetooth ® * Bluetooth Hands-Free outline ® When a Bluetooth device (mobile phone) is connected to the vehicle's Bluetooth unit via ® ® radio wave transmission, a call can be made or received by pressing the talk button, pick- up button, or hang-up button on the audio remote control switch, or by operating the centre display.
Page 496 Bluetooth ® CAUTION Some Bluetooth mobile devices are not compatible with the vehicle. Consult an ® Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding Bluetooth mobile device compatibility: ® Phone: (Germany) 0800 4263 738 (8:00—18:00 Central European Time) (Except Germany) 00800 4263 7383 (8:00—18:00 Central European Time)
Page 497 Interior Features Bluetooth ® Component Parts Audio unit Type A Type C/Type D Talk button, Pick-up button and Hang-up button Talk button Pick-up button Hang-up button Microphone Microphone Microphone (hands-free) The microphone is used for speaking voice commands or when making a Hands-free call. Talk button, Pick-Up button and Hang-Up button (hands-free) The basic functions of Bluetooth Hands-Free can be used for such things as making calls or...
Page 498 Pairing options, con rmation prompts, language, password, select phone or select music player.” 4. Say: [Beep] “Pairing options” 5. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set pin Code.” 6. Say: [Beep] “Set pin code” 5–90...
Page 499 Bluetooth ® 5. Say: [Beep] “Pairing options” audio devices can be paired to one vehicle. 6. Prompt: “Select one of the following: Pair, edit, delete, list, or set pin code.” NOTE 7. Say: [Beep] “Pair” 8. Prompt: “Start the pairing process on...
Page 500 Pair, edit, delete, list, or set pin code.” or by activating Bluetooth ® Hands-Free 6. Say: [Beep] “List” rst after switching the ignition from 7. Prompt: “XXXXX..., XXXXX..., OFF to ACC, the system reads out a voice XXXXX... (Ex. Device A, device B, guidance, “XXXXXX - - - (Ex.
Page 501 XXXXX... (Ex. device C). Which 3. Prompt: “Select one of the following: device please?” Pairing options, con rmation prompts, 6. Say: [Beep] “X” (Say the number for language, password, select phone or the music player to be connected.) select music player.”...
Page 502 2. Say: [Beep] “Setup” Pair, edit, delete, list, or set pin code.” 3. Prompt: “Select one of the following: 6. Say: [Beep] “Edit” Pairing options, con rmation prompts, 7. Prompt: “Please say the name of the language, password, select phone or device you would like to edit.
Page 503 Interior Features Bluetooth ® Bluetooth Audio Preparation 2. Turn the audio control dial and select a ® desired mode. Bluetooth audio device set-up ® Bluetooth audio pairing, changes, ® deletions, and display of paired device information can be performed. 1. The mode changes as follows each time the menu button ( ) is pressed.
Page 504 Interior Features Bluetooth ® Bluetooth audio device pairing Pairing a Bluetooth audio device which ® ® has a four-digit PIN code Any Bluetooth audio device must be ® paired to the vehicle's Bluetooth unit 1. Using the audio control dial, select ®...
Page 505 0000 ” is displayed. “ PAIRING ” is ashing. “ PAIRING ” ashes on the audio 6. When the pairing is completed, “ ” and display. “ PAIR SUCCESS ” are displayed after 4. Operate the Bluetooth audio device ®...
Page 506 “ BT SETUP ” mode. (Refer to “Bluetooth audio device set-up” for ® 6. If the link to the desired device is details.) successful, the “ ” symbol is displayed 2. Press the audio control dial to again, together with “ LINK determine the mode.
Page 507 Device name 4 Device selection can also be done using voice recognition. Device name 5 Device name 6 How to con rm the device currently linked Device name 7 Switch to the link-change mode. (Refer to “Changing the link to a Bluetooth...
Page 508 Interior Features Bluetooth ® 6. Rotate the audio control dial clockwise Bluetooth audio device information ® and switch the display to “ SURE ? display YES ”. 1. Using the audio control dial, select the pair device information display mode NOTE “...
Page 509 4. Say: [Beep] “Yes” French, Spanish, Italian, German, 5. Prompt: “Please wait. Switching to Dutch, or Portuguese.” French phonebook. French selected.” 6. Say: [Beep] “French” (Speak the (Spoken in the newly selected desired language: “English”, “French”, language). “Spanish”, “Italian”, “German”, “Dutch”, or “Portuguese”)
Page 510 Interior Features Bluetooth ® Voice Recognition (Type A) Commands useable anytime during voice recognition In this section, the basic operation of the “Help” or “Go Back” are commands voice recognition is explained. which can be used at anytime during voice Activating Voice Recognition recognition.
Page 511 5. Prompt: “Password is disabled. Would noises from outside the vehicle, or turn you like to enable it?” down the air ow of the air-conditioning 6. Say: [Beep] “Yes” system while Bluetooth Hands-Free is ® 7. Prompt: “Please say a 4-digit being used.
Page 512 5. Prompt: “Password is enabled. Would with a short press. you like to disable it?” 2. Say: [Beep] “Setup” 6. Say: [Beep] “Yes” 3. Prompt: “Select one of the following: 7. Prompt: “Password is disabled.” Pairing options, con rmation prompts, language, password, select phone or select music player.”...
Page 513 Press and release the talk 6. Press the talk button with a short press. button when you are ready to begin. 7. The voice guidance reads out the voice Press the hang-up button to cancel at input command number (refer to the any time.”...
Page 514 “one, two, three, four” not “twelve, When “Enable” is spoken, the voice thirty four”.) recognition learning is turned on. Do not read out parentheses. “(” and 6. Prompt: “Speaker Enrolment is hyphens “-” are used for separating disabled/enabled.” numbers in a phone number. Bluetooth Preparation (Type C/ ®...
Page 515 Bluetooth Hands-Free rst ® operation. after switching the ignition from OFF to 6. Using your device, perform a search ACC, the device connection condition is for the Bluetooth device (Peripheral ® indicated in the centre display.
Page 516 The following functions can be used for If pairing is redone on the same the Hands-free or audio. mobile phone device, rst clear “Mazda” displayed on the Bluetooth ® Hands-free: Phone calls and E-mail/ setting screen of the mobile device.
Page 517 4. Select “Go Back” and “Cancel” are commands 5. Select which can be used at anytime during voice 6. Input the new PIN code to be set. recognition. 7. Select Returning to previous operation Available Language (Type C/Type To return to the previous operation, say, “Go Back”...
Page 518 Interior Features Bluetooth ® To prevent a deterioration in the voice recognition rate and voice quality, the following points should be observed: The voice recognition cannot be performed while voice guidance or the beep sound is operating. Wait until the voice guidance or the beep sound is nished before saying your commands.
Page 519: Voice Command
Interior Features Bluetooth ® Audio Operation Using Voice Recognition (Type C/Type D) Voice command When the talk button is pressed and the following command is spoken, the audio or navigation can be operated. The commands in the () can be omitted. The speci ed name and number are put into the {}.
Page 520 Interior Features Bluetooth ® Entertainment (audio) related command Corresponding audio Voice command Function source (Go to/Play) AM (Radio) Switches the audio source to AM radio. (Go to/Play) FM (Radio) Switches the audio source to FM radio. (Go to/Play) DAB (Radio) Switches the audio source to DAB radio.
Page 521 4. Say: [Beep] “New entry” phone”)” (Say a voice tag registered in 5. Prompt: “Name please.” the phonebook.) 6. Say: [Beep] “XXXXX... (Ex. “Mary's 5. Prompt: “Calling XXXXX... (Ex. phone”)” (Say a voice tag for the name “John's phone”) XXXX (Ex. “at registered.)
Page 522 6. Prompt: “X (Number of locations which include data) numbers have been imported. What name would you like to use for these numbers?” 7. Say: [Beep] “XXXXX... (Ex. “Mary's phone”)”...
Page 523 14. (Number Change) “List names”.” Press the pick-up button, then go to 6. Say: [Beep] “XXXXX... (Ex. “Mary's Step 15. phone”)” (Say the voice tag for the (Adding/inputting telephone registered name to be edited in the number) phonebook.)
Page 524 7. Prompt: “You are about to delete “List names”. ” everything from your Hands Free 6. Say: [Beep] “XXXXX... (Ex. “John's system phonebook. Do you want to phone”) ” (Say the registered voice tag continue?”...
Page 525 “Previous”: Returns to the previous numbers, or press the Pick-Up button to phonebook data in read-out when the execute dialing.” talk button is short-pressed. 6. Prompt: “End of list, would you like to start from the beginning?” 7. Say: [Beep] “No” 5–117...
Page 526 Interior Features Bluetooth ® 6. (Dialing) Hanging Up a Call Press the pick-up button or say “Dial”, Press the hang-up button during the call. A then go to Step 7. beep sound will con rm that call is ended. (Adding/inputting telephone...
Page 527 Is this correct?” (Voice tag and 2. Say: [Beep] “Swap calls” phone number location registered in 3. Prompt: “Swapping calls.” phonebook). 6. Say: [Beep] “Yes” Three-way call function 7. Prompt: “Dialing” 1. Press the talk button with a short press. 2. Say: [Beep] “Join calls”...
Page 528 Interior Features Bluetooth ® Redialing function Bluetooth Hands-Free ® 1. Press the talk button with a short press. (Type C/Type D) 2. Say: [Beep] “Redial” 3. Prompt: “Dialing” Making a Call Ending the current call Phonebook Usage Press the hang-up button during the call. Telephone calls can be made by saying the contact name in the downloaded DTMF (Dual Tone Multi-...
Page 529 5. If is selected, select Registering your favourites 1. Select the icon on the home screen 6. Download will be started from the to display the Communication screen. mobile phone. 2. Select to display the favourites list. 3. Select 4.
Page 530 4. Select 3. Input the telephone number using the 5. The contact can be moved after it is dial pad. selected. 4. Select to make the call. 6. Slide the contact or move it using the commander switch, then select 5–122...
Page 531 Interior Features Bluetooth ® Numeral or symbol entry Use the dial pad. Long-press the to input +. Select to delete the currently input value. Long-press to delete all input values. Redial Function Makes a call to the last person called (latest person on outgoing call record) from the mobile phone/vehicle.
Page 532: Receiving An Incoming Call
Interior Features Bluetooth ® Receiving an Incoming Call When an incoming call is received, the incoming call noti cation screen is displayed. The “Incoming Call Noti cations” setting must be on. Refer to Communication Settings on page 5-129 . To accept the call, press the pick-up button on the audio control switch or select the screen.
Page 533 Interior Features Bluetooth ® Receiving and Replying to NOTE Messages (available only with E-mail/SMS compatible phones) If the ignition is switched off during a hands-free call, the line is SMS (Short Message Service) messages, transferred to the device (Mobile and E-mail received by connected devices phone) automatically.
Page 534 Interior Features Bluetooth ® NOTE Attached data is not downloaded. Messages up to 1 kilobyte (E-mail)/140-bytes (SMS) can be downloaded. A message list is created for each device. If the connected device does not correspond to MAP 1.0, the AT command is used to download.
Page 535 Interior Features Bluetooth ® The following icons are displayed in the lower part of the details on the message. Icons which can be used differ depending on use conditions. Icon Function Displays the Communication menu. Displays the inbox. Plays back a message. When selected again, playback is temporarily stopped.
Page 536 Interior Features Bluetooth ® Example of use (verify unread E-mail) NOTE 1. Select the icon on the home screen to display the Communication screen. Select the icon to change the 2. Select to display the inbox. language. Select the icon to switch between capitalized and lower-case characters.
Page 537 Interior Features Bluetooth ® Communication Settings Select the icon on the home screen to display the Communication screen. Select to change the setting. Item Setting Function Go to Bluetooth setting menu. ® Bluetooth — ® Refer to Bluetooth Preparation (Type C/Type D) on page 5-106 . ®...
Page 538 Interior Features Bluetooth ® Bluetooth Audio ® NOTE (Type A) The battery consumption of Bluetooth audio devices increases ® Applicable Bluetooth speci cation ® while Bluetooth is connected. ® (Recommended) If a general mobile phone device Ver. 2.0 is USB connected during music playback over the Bluetooth ®...
Page 539 Interior Features Bluetooth ® Selecting a le (track) NOTE Some Bluetooth audio devices need a Selects the next le (track) ® certain amount of time before the “ ” Short-press the track up button ( symbol is displayed. Selects the beginning of the current le (track) 3.
Page 540 Interior Features Bluetooth ® Display scroll Bluetooth Audio ® Only 13 characters can be displayed at one (Type C/Type D) time. To display the rest of the characters Applicable Bluetooth speci cation ® of a long title, press and hold the text (Recommended) button (3).
Page 541 Interior Features Bluetooth ® AVRCP Function A2DP Ver. Ver. Ver. Depends Depends Scan — — device device Depends Folder up/ — — — down device X: Available —: Not available NOTE The battery consumption of Bluetooth audio devices increases ® while Bluetooth ®...
Page 542 Interior Features Bluetooth ® How to Use the Bluetooth Audio System ® Switching to Bluetooth audio mode ® To listen to music or voice audio recorded to a Bluetooth audio device, switch to the ® Bluetooth audio mode to operate the audio device using the audio system control panel. ®...
Page 543 Interior Features Bluetooth ® Playback To listen to a Bluetooth audio device over the vehicle's speaker system, switch the mode to ® Bluetooth audio mode. (Refer to “Switching to Bluetooth audio mode”) ® ® After switching to the Bluetooth audio mode, the following icons are displayed in the ®...
Page 544 Interior Features Bluetooth ® Bluetooth Audio Device ® Information Display If a Bluetooth audio device is connected, ® the following information is displayed in the centre display. AVRCP AVRCP AVRCP Ver. lower Ver. 1.4 or Ver. 1.3 than 1.3 higher Device name Remaining battery...
Page 545 Interior Features Bluetooth ® How to Use Aha ™ What is Aha ™ is an application which can be used to enjoy various Internet content such as Internet radio and podcasts. Stay connected to your friends activities by getting updates from Facebook and Twitter. Using the location-based service, nearby services and destinations can be searched or real- time local information can be obtained.
Page 546 Interior Features Bluetooth ® Icon Function Like Evaluates the current content as “Like”. Dislike Evaluates the current content as “Dislike”. Reverses for 15 seconds. Map (vehicles with navigation system) Displays the destination searched by the location based services on the navigation system. Call A call can be made to the telephone number of a shop searched using the Location Based Services.
Page 547: Main Menu
Interior Features Bluetooth ® Main menu Select the icon. Switch the tab and select the station category. Function Displays the preset station list set on the device. Presets Select the preset station name to play the station content. Select the desired station. Guidance is provided to the searched destination near the vehicle's position.
Page 548 Interior Features Bluetooth ® Example of use (Location Based Shout Services) Some social stations, such as Facebook or 1. Select the desired station from the Caraoke, support the ability to record and “Nearby” tab on the main menu. share voice messages using the “Shout” The destination name or address function.
Page 549 Interior Features Bluetooth ® How to Use Stitcher Radio ™ What is Stitcher Radio? ™ Stitcher radio is an application which can be used to listen to Internet radio or stream ™ *1 podcasts. Recommended content is automatically selected by registering content which you put into your favourites, or by pressing the Like or Dislike button.
Page 550 Interior Features Bluetooth ® Icon Function Reverses for 30 seconds. Plays the station. Select it again to pause playback. Goes to the next station. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-46 . Station list 1.
Page 551 Interior Features Bluetooth ® Add to your favourites If the current programme has not been registered to your favourites, it can be registered to your favourites. 1. Select the icon to display the favourites station which the registration can be added. 2.
Page 552 The pairing information paired to procedure. Pairing cannot be performed again the Bluetooth ® unit or device is not Clear “Mazda” stored in the device. recognised correctly. Perform pairing again. Unable to perform pairing The Bluetooth function and the ®...
Page 553 ® If you pair your phone which has already been paired to your vehicle more than once in the past, you need to delete “Mazda” on your mobile device. Then, execute the Bluetooth search on your mobile device once again, and pair to a newly detected ®...
Page 554 There is a malfunction in the Poor voice recognition occurred. Consult an expert repairer, microphone. we recommend an Authorised Mazda Repairer. If there is any malfunction after There is a problem with the Phone-related voice recognition is checking the pairing situation, check connection between the Bluetooth ®...
Page 555 Interior Features Bluetooth ® Other problems Symptom Cause Solution method The indication for the remaining The indication method is different battery is different between the — between the vehicle and the device. vehicle and the device When a call is made from the If the number has been registered vehicle, the telephone number is into the phonebook, the incoming/...
Page 556: Interior Equipment
Interior Features Interior Equipment Sunvisors Interior Lights When you need a sunvisor, lower it for use NOTE in front or swing it to the side. Sunvisor Do not leave the lights on for long periods while the engine is turned off. Otherwise the battery power could be depleted.
Page 557 Interior Features Interior Equipment Front Map Lights NOTE When the overhead light switch is in the Once the rear map lights have been door or off position, press the lens to turned off, they will turn on and off illuminate the front map lights, and then depending on the position to which press the lens again to turn them off.
Page 558 Interior Features Interior Equipment Boot Light Ambient Light The boot light is on when the lid is open An ambient light continuously turn on and off when it's closed. when the ignition is switched ON. An ambient light dim when the position lights or headlights are turned on.
Page 559: Illuminated Entry System
Interior Features Interior Equipment Illuminated Entry System Accessory Sockets When the illuminated entry system Only use genuine Mazda accessories or operates, the overhead lights, the courtesy the equivalent requiring no greater than lights, and an ambient light turn on in the 120 W (DC 12 V, 10 A).
Page 560 Do not use accessories that require more than 120 W (DC 12 V, 10 A). Do not use accessories that are not genuine Mazda accessories or the equivalent. Close the cover when the accessory socket is not in use to...
Page 561 Interior Features Interior Equipment Connecting the accessory socket Cup Holder 1. Open the lid. 2. Pass the connection plug cord through WARNING the cutout of the console and insert the plug into the accessory socket. Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot Plug...
Page 562 Interior Features Interior Equipment Rear Bottle Holder The rear cup holder is on the rear centre Bottle holders are on the inside of the armrest. doors. Bottle holder CAUTION Do not use the bottle holders for containers without caps. The contents may spill when the door is opened or closed.
Page 563 Interior Features Interior Equipment Storage Compartments Overhead Console This console box is designed to store eyeglasses or other accessories. WARNING Push and release to open. Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 564 Interior Features Interior Equipment Glove Compartment Cargo Securing Loops (Wagon) To open the glove compartment, pull the latch toward you. WARNING Make sure luggage and cargo is secured before driving: Not securing cargo while driving is dangerous as it could move or be crushed during sudden braking or a collision and cause injury.
Page 565 Interior Features Interior Equipment Cargo Sub-Compartment (Saloon) Lift the boot mat. (Wagon) Boot mat 1. Lift the luggage board. Cargo sub-compartment Shopping Bag Hook (Wagon) Luggage The shopping bag hook can be used for board hanging shopping bags. 2. Rotate the shopping bag hook out of its retainer and set the luggage board CAUTION against it.
Page 566 Interior Features Interior Equipment Rear Coat Hooks Removable Ashtray The removable ashtray can be xed and WARNING used in either of the front cup holders. WARNING Never hang heavy or sharp objects on the assist grips and coat hooks: Hanging heavy or sharp-ended objects Only use the removable ashtray in such as a coat hanger from the assist its xed position, and make sure it is...
Page 567 Interior Features Interior Equipment Rear Sunshade Operating the Rear Sunshade When the rear sunshade switch is operated with the ignition switched ON, the rear sunshade rises/lowers. The rear sunshade rises/lowers automatically when the rear sunshade WARNING switch is pressed. The rear sunshade stops automatically after rising/lowering completely.
Page 568 MEMO 5–160...
Page 569: Maintenance And Care
Maintenance and Care How to keep your Mazda in top condition. Essential Information ................ 6-2 Introduction ................... 6-2 Scheduled Maintenance ..............6-3 Scheduled Maintenance ..............6-3 Maintenance Monitor ..............6-16 Owner Maintenance ................. 6-18 Owner Maintenance Precautions ..........6-18 Bonnet ..................6-20 Engine Compartment Overview ..........
Page 570: Essential Information
If you are unsure about any procedure it describes, we strongly urge you to have a reliable and quali ed technician perform the work, we recommend an Authorised Mazda Repairer. Authorised Mazda technicians and genuine Mazda parts are dedicated to your vehicle.
Page 571: Scheduled Maintenance
Flexible 20,000 km (12,500 miles)) Engine oil & lter Other than exible *4*6 Ukraine *5*6 Replace every 12 months or 10,000 km (6,250 miles). Except Ukraine Fuel lter Ukraine Except Ukraine Fuel lines and hoses Ukraine Fuel injection system Fuel system (Drain water) Air lter 6–3...
Page 572 *15*16 Emergency at tyre repair kit (if installed) Inspect annually. Chart symbols: I : Inspect: Inspect and clean, repair, adjust, ll up, or replace if necessary. R : Replace C : Clean T : Tighten D : Drain 6–4...
Page 573 Maintenance and Care Scheduled Maintenance Remarks: *1 In the countries below, inspect the spark plugs at every 10,000 km (6,250 miles) or 12 months before replacing them at the said interval. Albania, Bosnia and Herzegovina, Bulgaria, Croatia, Latvia, Macedonia, Moldova, Montenegro, Romania,...
Page 574 *14 If this component has been submerged in water, the oil should be replaced. *15 Tyre rotation is recommended every 10,000 km (6,250 miles). *16 The Tyre Pressure Monitoring System (TPMS) initialization must be performed so that the system operates normally (if equipped).
Page 575 Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Spark plugs Replace every 120,000 km or 6 years. Fuel lter Replace every 135,000 km. Evaporative system (if installed) Fuel lines and hoses Drive belts Engine oil &...
Page 576 *5 Inspect the battery electrolyte level, speci c gravity and outer appearance. The sealed battery only requires an outer appearance inspection. *6 If the brakes are used extensively (for example, continuous hard driving or mountain driving) or if the vehicle is operated in extremely humid climates, replace the brake uid annually.
Page 577 ×1000 km 90 105 120 135 150 165 180 Drive belts Russia/ Belarus/ Engine oil Kazakhstan Azerbaijan Replace every 5,000 km or 6 months. Russia/ Belarus/ Engine oil lter Kazakhstan Azerbaijan Replace every 10,000 km or 12 months. Cooling system Replace at rst 195,000 km or 10 years;...
Page 578 *2 If the vehicle is operated primarily under any of the following conditions, replace the engine oil and oil lter at every 7,500 km or 6 months. a) Purpose of vehicle use is police car, taxi or driving school car.
Page 579 *6 If the vehicle is operated in very dusty or sandy areas, clean the air lter at every 7,500 km or 6 months. *7 Inspect the battery electrolyte level, speci c gravity and outer appearance. The sealed battery only requires an outer appearance inspection.
Page 580 ×1000 km 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 ×1000 miles 6.25 12.5 18.75 25 31.25 37.5 43.75 50 56.25 62.5 68.75 75 81.25 87.5 93.75 100 SKYACTIV-G 2.0 AND SKYACTIV-G 2.5...
Page 581 Interval ×1000 km 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 ×1000 miles 6.25 12.5 18.75 25 31.25 37.5 43.75 50 56.25 62.5 68.75 75 81.25 87.5 93.75 100 SKYACTIV-D 2.2 Except...
Page 582 Driving in extremely hot conditions f) Driving in mountainous conditions continually *2 In the countries below, inspect the spark plugs at every 10,000 km (6,250 miles) or 1 year before replacing them at the said interval. Armenia, Angola, Bolivia, Burundi, B.Virgin, Cambodia, Cameroon, Chile, Costa Rica, Curacao, El...
Page 583 *8 Inspect the battery electrolyte level, speci c gravity and outer appearance. If the vehicle is operated in extremely hot and cold areas, inspect the battery electrolyte level, speci c gravity and appearance every 10,000 km (6,250 miles) or 6 months. The sealed battery only requires an outer appearance inspection.
Page 584 Maintenance Monitor Maintenance Monitor (Type A/Type B audio) “Oil Change” with exible setting is available. Consult an Authorised Mazda Repairer for details . When the engine oil exible maintenance setting is selected, the wrench indicator light in the instrument cluster will be illuminated when remaining oil life becomes less than 1,000 km (600 mile), or remaining days are less than 15 (Whichever comes rst).
Page 585 *2 Whenever the engine oil is replaced, the vehicle engine control unit reset is necessary for SKYACTIV-D 2.2. Your Authorised Mazda Repairer will be able to reset the engine control unit or refer to the vehicle engine control unit reset procedure on page 6-26 .
Page 586: Owner Maintenance
Improper or incomplete service may result in problems. This section gives instructions only for items that are easy to perform. As explained in the Introduction (page 6-2 ), several procedures can be done only by a quali ed service technician with special tools.
Page 587 After you have nished checking or doing servicing in the engine compartment, do not forget and leave items such as tools or rags in the engine compartment. Tools or other items left in the engine compartment could cause engine damage or a re leading to an unexpected accident. 6–19...
Page 588 The lever is located a little to the left of centre when facing the vehicle. 3. Grasp the support rod in the padded area and secure it in the support rod hole indicated by the arrow to hold the bonnet open. Release handle Clip Clip Support rod 6–20...
Page 589 Verify that the support rod is secured in the clip before closing the bonnet. Clip Clip Clip 3. Lower the bonnet slowly to a height of about 20 cm (7.9 in) above its closed position and then let it drop. 6–21...
Page 590 Battery Fuse block Engine oil dipstick Cooling system cap Engine coolant reservoir Engine oil-filler cap SKYACTIV-D 2.2 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Battery Fuse block Engine oil-filler cap Cooling system cap Engine coolant reservoir Engine oil dipstick 6–22...
Page 591 Authorised Mazda Repairer. Recommended Oil In order to keep the maintenance interval (page 6-3 ) and to protect the engine from damage caused by poor lubrication, it is vitally important to make use of engine oil with the correct speci cation. Do not use oils which do not meet the following speci cations or requirements.
Page 592 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –20 –40 Recommended oils Mazda Original Oil Supra DPF 0W-30 Mazda Original Oil Ultra DPF 5W-30 Alternative Oil Quality 0W-30 ACEA C3 5W-30 (Except Europe) Temperature Range SAE Viscosity Numbers –40...
Page 593 Otherwise the wrench indicator light or engine oil warning light may turn on. To reset the engine control unit, consult an expert repairer, we recommend an Authorised Mazda Repairer or refer to the vehicle engine control unit reset procedure on page 6-26 .
Page 594 SKYACTIV-G 2.0 or SKYACTIV-G 2.5 which the engine oil exible maintenance setting is selected. After replacing the engine oil, have a repair shop such as an Authorised Mazda Repairer perform the initialization (engine oil data resetting) of the recorded value. If the value recorded by the computer is not initialized, the wrench indicator light may not turn off or it may turn on earlier than normal.
Page 595 MAX. CAUTION Do not over ll the engine oil. This may cause engine damage. 6. Make sure the O-ring on the dipstick is positioned properly before reinserting SKYACTIV-D 2.2 the dipstick. 7. Reinsert the dipstick fully.
Page 596 NOTE Changing the coolant should be done Inspecting Coolant Level by an expert repairer, we recommend an Authorised Mazda Repairer. WARNING Inspect the antifreeze protection and Do not use a match or live ame in the coolant level in the coolant reservoir at engine compartment.
Page 597 This would reduce effectiveness. If the “FL22” mark is shown on or near the cooling system cap, use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may cause serious damage to the engine and cooling system. 6–29...
Page 598 If the coolant reservoir is empty or new Brake/Clutch Fluid coolant is required frequently, consult an expert repairer, we recommend an Inspecting Brake/Clutch Fluid Authorised Mazda Repairer. Level WARNING If the brake/clutch uid level is low, have the brakes inspected: A low brake/clutch uid level is dangerous.
Page 599 Inspect uid level in the washer uid reservoir; add uid if necessary. Use plain water if washer uid is unavailable. But use only washer uid in cold weather to prevent it from freezing. NOTE Front and rear washer uid is supplied from the same reservoir. 6–31...
Page 600 If the blades are not wiping properly, clean the window and blades with a good cleaner or mild detergent; then rinse thoroughly with clean water. Repeat if necessary. 6–32...
Page 601 1. Raise the wiper arm. 2. Open the clip and slide the blade assembly in the direction of the arrow. 5. Remove the metal stiffeners from each blade rubber and install them in the new blade. 6–33...
Page 602 1. Raise the wiper arm and rotate the the old blade rubber. wiper blade to the right until it unlocks, then remove the blade. 6. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal. CAUTION To prevent damage to the rear window, do not let the wiper arm fall on it.
Page 603 Then install the blade assembly in the reverse order of removal. 3. Remove the metal stiffeners from the blade rubber and install them in the new blade. CAUTION Do not bend or discard the stiffeners. You need to use them again. 6–35...
Page 604 Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries. Keep all ames including cigarettes and sparks away from open battery cells. 6–36...
Page 605 Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries. NOTE Before performing battery maintenance, remove the battery cover. 6–37...
Page 606: Battery Maintenance
If the vehicle will not be used for an Examine the speci c gravity of the extended time, disconnect the battery electrolyte with a hydrometer, especially leads and charge the battery every six during cold weather. If it is low, recharge weeks. the battery. 6–38...
Page 607: Battery Recharging
Insulate the plus and minus terminals of the battery using Battery Replacement cellophane or equivalent tape. Contact an Authorised Mazda Repairer for Never disassemble. a battery replacement purchase. Never throw the battery into re or water. Never deform or crush.
Page 608 3. Insert the tape-wrapped athead Replacing the battery at an Authorised screwdriver into the gap and slide it in Mazda Repairer is recommended to the direction of the arrow. prevent damage to the key. If replacing the battery by yourself, follow the instruction.
Page 609 If the rubber ring detaches, reattach it before inserting a new battery. Rubber ring 6. Insert a new battery with the positive pole facing up, and then cover the battery with the battery cap. 7. Close the cover.
Page 610 Using Different Tyre Types: Refer to Tyres on page 9-10 . Driving your vehicle with different types of tyres is dangerous. It could Use only a Mazda-genuine tyre valve cause poor handling and poor braking; cap: leading to loss of control.
Page 611: Tyre Rotation
10,000 After rotation, in ate all tyre pressures to km (6,250 miles), or sooner if irregular speci cation (page 9-10 ) and inspect the wear develops. wheel nuts for tightness.
Page 612 Refer to Tyre Pressure Monitoring System Replacing just one tyre is dangerous. Initialization on page 4-230 . It could cause poor handling and poor braking resulting in loss of vehicle control. Mazda strongly recommends that you replace all four tyres at the same time. 6–44...
Page 613 Authorised Mazda Repairer. wear solid-band indicator appears, replace the tyre with the same type of temporary spare (page 6-44 ). Proper tyre balancing provides the best riding comfort and helps reduce tread wear. Out-of-balance tyres can cause vibration and uneven wear, such as cupping and at spots.
Page 614 Maintenance and Care Owner Maintenance Light Bulbs With LED Headlights (Saloon) (Wagon) With Halogen Headlights (Saloon) (Wagon) 6–46...
Page 615 (Right-hand drive model) High-mount brake light Number plate lights Overhead lights/Front map lights Vanity mirror lights Courtesy lights Rear map lights Boot light (Saloon) Luggage compartment light (Wagon) *1 With rear fog light *2 Without rear fog light 6–47 *Some models.
Page 616 The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is CAUTION necessary. Headlights (With halogen headlights) When removing the lens or lamp unit...
Page 617 Removal Installation 4. Turn the screw anticlockwise and remove it, and then partially peel back 6. Turn the socket and bulb assembly the mudguard. to remove it. Carefully remove the bulb from its socket in the re ector by gently pulling it straight backward out of the socket.
Page 618 2. Lift the bonnet. 3. Remove the clip. 6. Turn the socket and bulb assembly anticlockwise and remove it. 4. Move the air cleaner cover and create a space large enough to work in.
Page 619 Maintenance and Care Owner Maintenance 3. Disconnect the clip. 6. Turn the cover anticlockwise and remove it. Clip 4. Remove the windscreen washer uid 7. Turn the socket and bulb assembly reservoir and bolts. anticlockwise and remove it. Windscreen washer...
Page 620 2. Lift the bonnet. 3. Remove the clip. 6. Turn the socket and bulb assembly to remove it. Carefully remove the bulb from its socket in the re ector by gently pulling it straight backward out of the socket.
Page 621 Maintenance and Care Owner Maintenance 3. Disconnect the clip. 6. Disconnect the connector from the unit by pressing the tab on the connector with your nger and pulling the connector downward. Clip 4. Remove the windscreen washer uid reservoir and bolts.
Page 622 The LED bulb cannot be replaced as a single unit because it is an integrated unit. The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is necessary. Front direction indicator lights, Position lights (With halogen headlights) 1.
Page 623 Maintenance and Care Owner Maintenance 6. Disconnect the bulb from the socket. Front fog lights (With halogen Front direction indicator lights headlights) 1. Make sure the ignition is switched off, and the headlight switch is off. 2. If you are changing the right bulb, start the engine, turn the steering wheel all the way to the left, and turn off engine.
Page 624 Rear direction indicator lights Saloon 1. Make sure the ignition is switched off, and the direction indicator switch is off. 6. Turn the socket and bulb assembly 2. Lift the boot mat. to remove it. Carefully remove the 3. (Left side)
Page 625 Maintenance and Care Owner Maintenance (Right side) 6. Turn the socket and bulb assembly anticlockwise and remove it. 7. Disconnect the bulb from the socket. 4. Pull the centre of each plastic retainer and remove the retainers and the boot end trim.
Page 626 The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is 3. (Reverse light, Rear fog light ) necessary. Disconnect the electrical connector...
Page 627 2. Remove the cover with a cloth- wrapped athead screwdriver to the cover. Reverse light, Rear fog light 3. Turn the socket and bulb assembly anticlockwise and remove it. 6. Install the new bulb in the reverse order of the removal procedure. 6–59...
Page 628 The LED bulb has to be replaced with prying on the edge of the lens with a the unit. We recommend an Authorised athead screwdriver. Mazda Repairer when the replacement is necessary. 6–60...
Page 629 2. Disconnect the bulb by pulling it out. Overhead lights/Front map lights Vanity mirror lights 6–61 *Some models.
Page 630 The LED bulb cannot be replaced as a single unit because it is an integrated unit. The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is necessary. (Bulb type) 1. Wrap a small athead screwdriver with a soft cloth to prevent damage to 3.
Page 631 If the same fuse blows again, avoid using and then slide the screwdriver to detach that system and consult an expert repairer, the lens. we recommend an Authorised Mazda Repairer as soon as possible. Fuse Replacement Replacing the fuses on the vehicle's left...
Page 632 Maintenance and Care Owner Maintenance 3. Pull the fuse straight out with the 6. Reinstall the cover and make sure that fuse puller provided on the fuse block it is securely installed. located in the engine compartment. Replacing the fuses under the bonnet...
Page 633 Maintenance and Care Owner Maintenance WARNING Do not replace the main fuse and multiplex slow blow fuse by yourself. Have an Authorised Mazda Repairer perform the replacement: Replacing these fuses by yourself is dangerous because they are high current fuses. Incorrect replacement could cause an electrical shock or a short circuit resulting in a re.
Page 634: Fuse Panel Description
Electric parking brake (LH) AUDIO 40 A Audio system EPB R 20 A Electric parking brake (RH) ENG.MAIN 40 A Engine control system ABS/DSC M 50 A ABS, Dynamic stability control system 50 A For protection of various circuits 6–66 *Some models.
Page 635 Tail lights, Number plate lights FUEL PUMP2 25 A Fuel system SCR2 Hazard warning ashers, Direction indicator lights, Tail lights, HAZARD 25 A Position lights, Number plate lights 15 A Running lights R.OUTLET2 15 A Accessory sockets 6–67 *Some models.
Page 636 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING HORN 15 A Horn ROOM 15 A Overhead light 6–68...
Page 637 MIRROR 7.5 A Power control mirror R.OUTLET1 15 A Accessory sockets — — — — — — — — — — — — — — — M.DEF 7.5 A Mirror defogger R.SEAT W 20 A Seat warmer 6–69 *Some models.
Page 638 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING R.SHADE 7.5 A Rear sunshade AT IND 7.5 A AT shift indicator P.SEAT P 30 A Power seat 6–70 *Some models.
Page 639: Appearance Care
These acids can settle on a vehicle's nish. As the water evaporates, Prevention the acid becomes concentrated and can It is necessary to have your Mazda washed damage the nish. and waxed to preserve its nish according And the longer the acid remains on the to the instructions in this section.
Page 640 The rings can damage paint chipping. your vehicle's nish. Chipped paint can lead to rust forming on your Mazda. Before this Prevention happens, repair the damage by using It is necessary to wash and wax your Mazda touch-up paint according vehicle to preserve its nish according to to the instructions in this section.
Page 641 Maintenance and Care Appearance Care Maintaining the Finish To help protect the nish from rust and deterioration, wash your Mazda thoroughly and frequently, at least once a Washing month, with lukewarm or cold water. CAUTION If the vehicle is washed improperly, the paint surface could be scratched.
Page 642 Keep a suf cient space (30 cm (12 in) or more) between the nozzle and the vehicle. In addition, do not spend too much time spraying the same area of the vehicle, and be very careful when spraying between gaps in doors and around windows. 6–74...
Page 643 Always wash and dry the vehicle before etc., by using Mazda touch-up paint before waxing it. In addition to the vehicle body, rust begins to form. First, remove the dirt wax the metal trim to maintain its lustre.
Page 644 This coating is liable speed or hard brushes. to be damaged with time. Check this coating periodically. Should repairs be necessary, consult an expert repairer, we recommend an Authorised Mazda Repairer. They are well informed on how repairs should be made. 6–76...
Page 645 In addition, do not use an electrical or air tool to apply wax. Otherwise, the Beverage or fragrance frictional heat generated could result Grease or oil in deformation of plastic parts or paint Soiling damage. 6–77...
Page 646 If a seat belt appears frayed or has Leather Upholstery Maintenance abrasions, have it replaced by an Authorised Mazda Repairer: 1. Remove dust and sand using a vacuum If a seat belts is used under such a cleaner.
Page 647 If a chemical solvent gets on the combiner temperature becomes hot, the vinyl or mirror surface, wipe it off immediately. may deteriorate and adhere to the Otherwise, they could be damaged and the genuine leather. surface coating could be scratched. 6–79 *Some models.
Page 648 When washing the inside of the window glass, use a soft cloth dampened in lukewarm water, gently wiping the thermal laments and the aerial lines. Use of glass cleaning products could damage the thermal laments and the aerial lines. 6–80...
Page 649: If Trouble Arises
If Trouble Arises Helpful information on what to do if a problem arises with the vehicle. Parking in an Emergency ....7-2 Warning/Indicator Lights and Warning Parking in an Emergency ....7-2 Sounds ..........7-34 Roadside Emergency Triangle If a Warning Light Turns On or Retaining Strap ......
Page 650: Parking In An Emergency
If Trouble Arises Parking in an Emergency Parking in an Emergency Roadside Emergency Triangle Retaining Strap The hazard warning lights should always be used when you stop on or near a Saloon roadway in an emergency. Keep the roadside emergency triangle in the pocket and secure it with the strap.
Page 651: Flat Tyre
NOTE Your vehicle may or may not be equipped with a spare tyre, jack, wheel brace, and tool bag. For details, consult an Authorised Mazda Repairer. Spare tyre and tools are stored in the locations illustrated in the diagram. (With temporary spare tyre)
Page 652 If Trouble Arises Flat Tyre (Without spare tyre) Towing eyelet (Short type) Wheel brace Jack lever Emergency flat tyre repair kit Jack Screwdriver Towing eyelet (Long type) Wrench Tool bag Some models. 7–4...
Page 653 If Trouble Arises Flat Tyre (With spare tyre) Spare tyre hold-down bolt Wheel brace Jack lever Towing eyelet (Short type) Towing eyelet (Long type) Screwdriver Jack Wrench Spare tyre Tool bag (Without spare tyre) Wheel brace Emergency flat tyre repair kit Jack lever Towing eyelet (Long type)
Page 654 Lift the luggage board. (With spare tyre) 1. Lift the boot mat. Boot mat Luggage board (Without spare tyre) 2. Remove the pocket. Luggage board 3. Turn the wing bolt and jack screw anticlockwise. Wing bolt Jack screw 7–6 *Some models.
Page 655 If Trouble Arises Flat Tyre 2. (With spare tyre) 3. Remove the pocket by pulling the tab. Remove the cargo sub-compartment. (Without spare tyre) Rotate the shopping bag hook out of its retainer and set the luggage board against it. (With spare tyre) 4.
Page 656 Spare Tyre so the ground clearance is reduced. Your Mazda has a temporary spare tyre. Do not use a tyre chain on this tyre The temporary spare tyre is lighter and because it will not t properly.
Page 657 If Trouble Arises Flat Tyre To remove the spare tyre 2. Turn the spare tyre hold-down bolt anticlockwise. 1. (Saloon) Lift the boot mat. (Wagon) Spare tyre hold-down bolt Remove the luggage board. (Saloon) Boot mat To secure the spare tyre Store the spare tyre in the reverse order of removal.
Page 658 The emergency at tyre repair kit includes The emergency at tyre repair kit included the following items. with your Mazda is for a temporary repair of a slightly damaged at tyre resulting from running over nails or similar sharp objects on the road surface.
Page 659 The emergency at tyre repair kit cannot be used in the following cases. Consult an expert repairer, we recommend an Authorised Mazda Repairer. The period of effective use for the tyre sealant has expired. (The period of effectiveness is indicated Wagon on the bottle label.)
Page 660 Remove the valve core carefully. 6. Remove the cap from the bottle. Screw on the injection hose with the bottle's inner cap left on to break the inner cap.
Page 661 Return the empty hose and insert the injection hose into tyre sealant bottle to an Authorised the valve. Mazda Repairer when replacing the tyre. The empty tyre sealant bottle will need to be used to extract and dispose of the Plug used sealant from the tyre.
Page 662 If Trouble Arises Flat Tyre 14. Insert the compressor plug into the WARNING interior accessory socket and switch the ignition to ACC (page 5-151 ). Attach the speed restriction sticker in a place where it can be viewed easily by the driver: Compressor plug Applying the speed restriction...
Page 663 CAUTION Authorised Mazda Repairer. Drive carefully to an expert repairer, we recommend an Authorised Mazda NOTE Repairer and keep the vehicle speed below 80 km/h (50 mph). When checking the tyre in ation...
Page 664: Tyre Repair Kit
CAUTION use it if it has expired. Have the tyre sealant replaced at an Authorised Mazda Repairer before the period of effective For a tyre which has undergone an use has expired.
Page 665 (page 7-3 ). Stopping in traf c or on the shoulder of a 6. Block the wheel diagonally opposite busy road is dangerous. the at tyre. When blocking a wheel,...
Page 666 If Trouble Arises Flat Tyre Removing a Flat Tyre 4. Place the jack under the jack-up position closest to the tyre being 1. Loosen the wheel nuts by turning them changed with the jack head squarely anticlockwise one turn each, but do not under the jack-up point.
Page 667 If Trouble Arises Flat Tyre 6. Insert the jack lever and attach the WARNING wheel brace to tyre jack. Use only the front and rear jacking positions recommended in this manual: Attempting to jack the vehicle in positions other than those recommended in this manual is dangerous.
Page 668 If Trouble Arises Flat Tyre Mounting the Spare Tyre WARNING 1. Remove dirt and grime from the mounting surfaces of the wheel and Do not jack up the vehicle higher than hub, including the hub bolts, with a is necessary: cloth.
Page 669 If you are unsure of how tight the nuts WARNING should be, have them inspected at an expert repairer, we recommend an Authorised Mazda Repairer. Do not apply oil or grease to wheel nuts and bolts and do not tighten the wheel nuts beyond the recommended...
Page 670 5. Remove the tyre blocks and store the tools and jack. 6. Store the damaged tyre in the luggage compartment. 7. Check the in ation pressure. Refer to Tyres on page 9-10 .
Page 671 If Trouble Arises Battery Runs Out Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 672 If Trouble Arises Battery Runs Out CAUTION Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V motor generator set).
Page 673 If Trouble Arises Battery Runs Out 1. Remove the battery cover. 6. (With i-ELOOP system) “i-ELOOP charging” is displayed in the multi-display of the instrument cluster after the engine is started. The message is no longer displayed when the engine is running and the charging is completed.
Page 674: Emergency Starting
If Trouble Arises Emergency Starting Starting a Flooded Engine Push-Starting (SKYACTIV-G 2.0 and Do not push-start your Mazda. SKYACTIV-G 2.5) WARNING If the engine fails to start, it may be ooded (excessive fuel in the engine). Never tow a vehicle to start it:...
Page 675 10 seconds before trying again. If your vehicle runs out of fuel, add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel, and try to restart the engine. Because air can get into fuel lines when a vehicle runs out of fuel, your engine may take longer to start.
Page 676 Open the bonnet ONLY after steam is Repairer. no longer escaping from the engine: Steam from an overheated engine is 6. Make sure the cooling fan is operating, dangerous. The escaping steam could then turn off the engine after the seriously burn you.
Page 677 CAUTION coolant is still leaking: Stop the engine and call an expert repairer, If the engine continues to overheat or we recommend an Authorised Mazda frequently overheats, have the cooling Repairer. system inspected. The engine could SKYACTIV-G 2.0 and SKYACTIV-G be seriously damaged unless repairs are made.
Page 678: Emergency Towing
We recommend that towing be done only by an expert repairer, we recommend Always tow a 4WD vehicle with all four an Authorised Mazda Repairer or a wheels off the ground: commercial tow-truck service. Towing a 4WD vehicle with either the...
Page 679 If Trouble Arises Emergency Towing CAUTION CAUTION Do not tow the vehicle pointed Follow these instructions when towing backward with driving wheels on the vehicle with all wheels on the the ground. This may cause internal ground. damage to the transaxle. 1.
Page 680 If Trouble Arises Emergency Towing Towing Hooks Towing Hooks 1. Remove the towing eyelet and the wheel brace from the luggage CAUTION compartment (page 7-3 ). 2. Wrap a athead screwdriver or similar The towing eyelet should be used tool with a soft cloth to prevent damage in an emergency (to get the vehicle to a painted bumper, and open the cap out of a ditch or a snow bank, for...
Page 681 3. Securely install the towing eyelet using tightened, it may loosen or disengage the wheel brace or equivalent. from the bumper when towing the Consult an Authorised Mazda Repairer. vehicle. Make sure that the towing Front eyelet is securely tightened to the bumper.
Page 682 4. Select the applicable warning to view the warning details. Stop Vehicle in Safe Place Immediately If any of the following warning lights turns on, the system may have a malfunction. Stop the vehicle in a safe place immediately and contact an Authorised Mazda Repairer. Signal Warning If the brake system warning light remains illuminated the brake uid may be low or there could be a problem with the brake system.
Page 683 Have the vehicle towed to an expert repairer, we recommend an Warning Authorised Mazda Repairer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 684 2. Turn off the engine and wait 5 minutes for the oil to drain back into the sump. 3. Inspect the engine oil level 6-27 . If it's low, add the appropriate amount of engine oil while being careful not to over ll.
Page 685 If the message is displayed, stop the vehicle in a safe place and do not operate the steering wheel. There is no problem if the message in the display turns off after a while. Contact an expert repairer, we recommend an Authorised Mazda Repairer if the message is displayed continuously.
Page 686 Contact Authorised Mazda Repairer and Have Vehicle Inspected If any of the following warning lights or the indicator light turns on/ ashes, the system may have a malfunction. Contact an expert repairer, we recommend an Authorised Mazda Repairer to have your vehicle inspected.
Page 687 The fuel tank level being very low or approaching empty. If the check engine light remains on, or it ashes continuously , do not drive at high speeds and consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible.
Page 688 ON. If any of these occur, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. The system may not operate in an accident.
Page 689 Authorised Mazda Repairer or a tyre repair station.
Page 690 Light an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. Refer to Emergency Operation for Starting the Engine on page 4-11 .
Page 691 The “Front radar sensor system malfunction” is displayed if there is a malfunction in the (Amber) system while the Mazda Radar Cruise Control (MRCC) system is on. Have your vehicle Mazda Radar Cruise inspected at an expert repairer, we recommend an Authorised Mazda Repairer.
Page 692 Authorised Mazda Repairer. Driver Attention Alert (DAA) Warning Indication This light illuminates if there is a malfunction in the LED headlight. Have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. LED Headlight Warning Light 7–44 *Some models.
Page 693 1 hour or only or ashes, or the tyre pressure drive it 1.6 km (1 mile) or less warning beep sound is heard, before adjusting the tyre pressures. decrease vehicle speed immediately...
Page 694 City Brake Support (SBS/ For any other reasons, have the vehicle SCBS) Warning Light inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light turns on when the remaining fuel is about 9.0 L (2.3 US gal, 1.9 Imp gal).
Page 695 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Warning Action to be taken The seat belt warning light turns on if the driver or front passenger's seat is occupied and the seat belt is not fastened with the ignition switched ON. If the driver or front passenger's seat belt is unfastened (only when the front passenger's seat is occupied)
Page 696 Cause Action to be taken The key battery is dead. Replace the key battery (page 6-39 ). The key is not within the operation range. Bring the key into the operation range The key is placed in areas inside the (page 3-8 ).
Page 697 If Trouble Arises Warning/Indicator Lights and Warning Sounds Message Indicated in Multi-information Display If there is a noti cation from the vehicle, a message is displayed in the multi-information display. Check the information and take the necessary action. (Display example) If the warning light turns on/ ashes simultaneously or a symbol is indicated in the display, check the information regarding the warning light or symbol.
Page 698 Stop Vehicle in Safe Place Immediately If the following messages are displayed in the centre display (Type C/type D audio), a vehicle system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorised Mazda Repairer. Display Indicated Condition Displays if the engine coolant temperature has increased excessively.
Page 699 If Trouble Arises Warning/Indicator Lights and Warning Sounds Make Sure the Message is No Longer Displayed Displays in the following cases: Display Indicated Condition/Action to be taken Displays if i-ELOOP requires charging. Leave the engine idling and wait until the message disappears. NOTE If the vehicle is driven while the message is displayed, the buzzer will sound.
Page 700 Have your vehicle inspected at an expert ACC, the “Ignition Not Switched repairer, we recommend an Authorised Off (STOP) Warning Beep” (page Mazda Repairer as soon as possible. 7-53 ) overrides the lights-on reminder. WARNING A personalised function is available to change the sound volume for the lights-on reminder.
Page 701 ACC, a beep will beep sounds continuously. If the seat belt be heard 6 times in the cabin to notify remains unfastened, the beep sound stops the driver that the ignition has not been once and then continues for about 90 switched OFF (STOP).
Page 702 If the key is left in the luggage the doors are closed, a beep will be heard compartment/boot with all the doors in the cabin 6 times and the KEY warning locked and the liftgate/boot lid closed, a light (red) in the instrument cluster turns...
Page 703 If Trouble Arises Warning/Indicator Lights and Warning Sounds i-stop Warning Beep Outside Temperature Warning Beep If the driver's door is opened while engine idling is stopped, the warning Warns the driver of the possibility of icy sound operates to notify the driver that roads when the outside temperature is low.
Page 704 (MRCC) System Warnings If the power steering system has a malfunction, the power steering The Mazda Radar Cruise Control (MRCC) malfunction light turns on or ashes and system warnings notify the driver of the buzzer operates at the same time.
Page 705 If Trouble Arises Warning/Indicator Lights and Warning Sounds Lane Departure Warning Sound Excessive Speed Warning While the system is operating, if the If the vehicle speed exceeds the speed system determines that the vehicle may limit sign displayed on the active driving depart from the lane, it sounds a warning display, the warning sound is activated sound.
Page 706 If Trouble Arises When Liftgate/Boot Lid Cannot be Opened When Liftgate/Boot Lid (Saloon) 1. Open the cover. Cannot be Opened 2. (European models) If the vehicle battery is dead or there is a Open the cap. malfunction in the electrical system and the liftgate/boot lid cannot be opened, Cover perform the following procedure as an...
Page 707 4. Move the lever to the left to fold the seatback. Cover Lever 5. Move the lever to the left to open the boot lid. After performing this emergency measure, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 7–59...
Page 708 If the active driving display does not operate, switch the ignition off and then restart the engine. If the active driving display does not operate even with the engine restarted, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 7–60...
Page 709: Customer Information
Cell Phones ..................8-4 Cell Phones Warning ..............8-4 Recording of Vehicle Data ..............8-5 Recording of Vehicle Data ............8-5 Declaration of Conformity ..............8-6 Declaration of Conformity ............8-6 Electromagnetic Compatibility ............8-20 Electromagnetic Compatibility ........... 8-20 Collection/Disposal of Old Equipment/Used Battery ....8-22 Information for Users on Collection and Disposal of Old Equipment and Used Batteries ............
Page 710 Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorised Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 711 Other parts and accessories than those mentioned above have not been examined and approved by Mazda unless explicitly stated by Mazda. We cannot certify the suitability of such products. Mazda is not liable for any damage caused by the use of such products. WARNING...
Page 712: Cell Phones
Customer Information Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 713 Mazda and its subcontracting parties may obtain and use the recorded data for vehicle malfunction diagnosis, research and development, and quality improvement. Mazda will not disclose or provide any of the obtained data to a third party unless: An agreement from the vehicle owner (agreements from lessor and lessee for leased...
Page 714: Declaration Of Conformity
Customer Information Declaration of Conformity Declaration of Conformity Keyless Entry System/Immobilizer System 8–6...
Page 715 Customer Information Declaration of Conformity 8–7...
Page 716 Customer Information Declaration of Conformity 8–8...
Page 717 Customer Information Declaration of Conformity Blind Spot Monitoring (BSM) System 8–9...
Page 718 Customer Information Declaration of Conformity 8–10...
Page 719 Customer Information Declaration of Conformity Bluetooth Hands-Free ® Type A 8–11...
Page 720 Customer Information Declaration of Conformity 8–12...
Page 721 Customer Information Declaration of Conformity Type C/Type D 8–13...
Page 722 Customer Information Declaration of Conformity 8–14...
Page 723 Customer Information Declaration of Conformity 8–15...
Page 724 Customer Information Declaration of Conformity 8–16...
Page 725 Customer Information Declaration of Conformity 8–17...
Page 726 Customer Information Declaration of Conformity Distance Recognition Support System (DRSS)/Mazda Radar Cruise Control (MRCC)/Smart Brake Support (SBS) 8–18...
Page 727 Customer Information Declaration of Conformity 8–19...
Page 728: Electromagnetic Compatibility
10 regulation as related to electromagnetic compatibility. Radio Frequency (RF) transmitter equipment (e.g. cellular telephones, amateur radio transmitters, etc.) may only be tted to your Mazda if they comply with the parameters shown in the table below. *1 UNECE stands for United Nations Economic Commission for Europe.
Page 729 Customer Information Electromagnetic Compatibility Aerial positions: : front right of roof : front left of roof : centre of roof : both sides of liftgate (Wagon) : both sides of boot lid (Saloon) Frequency Band (MHz) Maximum output power (Wattage) Aerial Positions 50 —...
Page 730 Customer Information Collection/Disposal of Old Equipment/Used Battery Information for Users on Collection and Disposal of Old Equipment and Used Batteries When disposing your old battery, please refer to the information as follows. Information on Disposal in the European Union These crossed-out wheeled bin symbols on the products, packaging, and/or accompanying documents mean that used electronic products and batteries should not be mixed with general household waste.
Page 731 Customer Information Collection/Disposal of Old Equipment/Used Battery Information on Disposal in Other Countries Outside the European Union The above symbols are only valid in the European Union. If you wish to discard old products and used batteries, please contact your local authorities, your waste disposal service or the point of sales where you purchased the items, and ask for the correct method of disposal.
Page 732 MEMO 8–24...
Page 733 Speci cations Technical information about your Mazda. Identi cation Numbers ..............9-2 Vehicle Information Labels ............9-2 Speci cations ..................9-4 Speci cations ................9-4 Personalisation Features..............9-13 Personalisation Features .............. 9-13 9–1 9–1...
Page 734 Speci cations Identi cation Numbers Vehicle Information Chassis Number/Vehicle Identi cation Number (Malta, Labels Ireland, U.K.) Chassis Number Vehicle Identi cation Number Open the cover shown in the gure to (South Africa, Arab Gulf check the chassis number. Cooperation Council) The vehicle identi cation number legally identi es your vehicle.
Page 735 Speci cations Identi cation Numbers Vehicle Emission Control Engine Number Information Label (The SKYACTIV-G 2.0, SKYACTIV-G 2.5 Philippines) Forward SKYACTIV-D 2.2 Tyre Pressure Label Left-hand drive model Forward Conformity Plate (Arab Gulf Cooperation Council) Production year and month are shown on Right-hand drive model this plate.
Page 736 Saloon Wagon Saloon Manual Automatic Automatic transaxle Automatic transaxle transaxle transaxle Maximum engine power/ 114 kW/6,000 rpm 138 kW/5,700 rpm revolution Maximum engine torque/ 200 N·m/4,000 rpm 250 N·m/3,250 rpm revolution 212 km/h 205 km/h Maximum speed 202 km/h (126 mph)
Page 737: Electrical System
*1 Q-85 or T-110 is designed for i-stop system (FOR STOP & START)/i-ELOOP system. Only Q-85 or T-110 should be used to ensure correct operation of i-stop system (FOR STOP & START)/i-ELOOP system. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. *2 Not for i-stop system/i-ELOOP system.
Page 738 *2 Mazda Original Oils are specially designed/tested for the respective engine. For optimum performance we recommend to use Mazda Original Oils at all times. *3 If you are unable to nd a Mazda Original Oil, alternative oils meeting the listed speci cation may also be used. *4 Use API SM/SN in Kazakhstan.
Page 739 5.1 L (5.4 US qt, 4.5 Imp qt) SKYACTIV-D Without oil lter replacement 4.8 L (5.1 US qt, 4.2 Imp qt) Left-hand drive model 6.6 L (7.0 US qt, 5.8 Imp qt) Manual transaxle Right-hand drive model 6.5 L (6.9 US qt, 5.7 Imp qt)
Page 740 Speci cations Speci cations Dimensions Saloon Item Vehicle speci cation Without number plate 4,865 mm (191.5 in) holder Overall length With number plate holder 4,870 mm (191.7 in) Overall width 1,840 mm (72.4 in) Overall height 1,450 mm (57.1 in) 17 inch wheel vehicle 1,585 mm (62.4 in) Front tread...
Page 741: Light Bulbs
Speci cations Speci cations Light Bulbs Exterior light Category Light bulb Wattage UNECE (SAE) Without running lights HB3 (9005) High beam Halogen With running lights 55/15 H15 (—) headlights Headlights Low beam H11 (H11) High beam — (—) LED headlights Low beam —...
Page 742: Index
Speci cations Speci cations Interior light Category Light bulb Wattage UNECE Boot light (Saloon) — Bulb type — Luggage compartment light (Wagon) LED type — Bulb type — Overhead light (Front)/Map lights LED type — Bulb type — Rear map lights LED type —...
Page 743 For details, contact an expert repairer, we recommend an Authorised Mazda Repairer . Check the tyre pressure label for tyre size and in ation pressure (page 6-42 ). After adjusting the tyre pressure, initialization of the tyre pressure monitoring system is necessary to make the system operates normally.
Page 744 Brakes If you require information regarding the wear limit speci cation for the brake disc plates and the measurement method, please contact an expert repairer, we recommend an Authorised Mazda Repairer. The information is made freely available. 9–12 *Some models.
Page 745 Personalisation Features The following personalisation features can be set or changed by the customer or an Authorised Mazda Repairer. Consult an Authorised Mazda Repairer for details. Additionally, some of the personalisation features can be changed by the customer depending on the feature.
Page 746 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings The warning sound for the Lane Departure Rumble Beep/Rumble — Warning System (LDWS) can be changed. The volume of the Rumble High/Mid/Low — warning sound for the Lane Departure Warning System Lane Departure (LDWS) can be...
Page 747 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings The warning timing in which the Lane-keep Assist System (LAS) & Lane Departure Warning System Early/Medium/ Medium — (LDWS) system Late/Adaptive determines that the vehicle may be When the steering deviating from its lane wheel operation...
Page 748 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings The Traf c Sign Recognition System (TSR) can On/Off — be set to inoperable. Traf c Sign Off/ Recognition The warning pattern of the excessive speed Visual/ —...
Page 749 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings Light/ Auto-light Medium Light/ control (page Timing by which lights turn on Medium Medium/ — 4-70 ) Medium Dark/ Dark High Beam Control System Operational/non-operational On/Off — (HBC) (page 4-118 ) Adaptive LED...
Page 750 *5 If the auto-wiper control is set to Off, the wiper lever position is set to intermittent operation. *6 The operation may stop in 15 minutes due to the effect of the outside temperature even if the operation time of the rear window defogger has been changed to Continuous.
Page 751 Index 10–1 10–1...
Page 752 Collision warning ......4-192 Smart City Brake Support (SCBS) Indicator Light (Red)....4-192 Battery ..........6-36 Stopping the Advanced Smart City Inspecting electrolyte level ... 6-38 Brake Support (Advanced SCBS) Maintenance ........6-38 system operation......4-193 Recharging ........6-39 Air Bag/Seat Belt Pretensioner System Replacement ........
Page 753 Coming Home Light ......4-75 (Type C/Type D)......5-120 Control Status Display ...... 4-104 Troubleshooting ......5-144 Courtesy Lights ......... 5-148 Body Lubrication ........ 6-32 Cruise Control ........4-222 Bonnet Release ........6-20 Cruise control switch....4-222 Boot Lid ..........3-21 Cruise main indication (white)/ Luggage compartment ....
Page 754 Automatic transaxle ...... 4-69 Bonnet release ....... 6-20 Driving in ooded area....3-63 Coolant .......... 6-28 Floor mat ........3-59 Engine compartment overview ..6-22 Hazardous driving ......3-59 Exhaust gas........3-35 Rocking the vehicle ....... 3-60 Oil ..........6-23 Running-in........
Page 755 Blind Spot Monitoring (BSM) ..4-130 Fuel Consumption Display ..4-104 Camera and sensors ..... 4-115 Fuses ........... 6-63 Distance Recognition Support System Panel description ......6-66 (DRSS) ........4-144 Replacement ........6-63 Driver Attention Alert (DAA) ..4-148 Forward Sensing Camera (FSC) ... 4-210 High Beam Control System (HBC) ..........
Page 756 Low engine coolant temperature ... 4-54 the advanced keyless function) ... 7-54 Wrench .......... 4-54 Key Removed from Vehicle Warning Inspecting Brake/Clutch Fluid Level ... 6-30 Beep ............ 7-53 Inspecting Coolant Level ....6-28 Key Suspend Function ......3-8 Inspecting Engine Oil Level ....6-27 Keyless Entry System ......
Page 757 Meters and Gauges ......4-23 Owner Maintenance Mirror Defogger ........4-87 Closing the bonnet......6-21 Mirrors Engine compartment overview ..6-22 Outside mirrors......3-39 Key battery replacement ....6-39 Rearview mirror ......3-42 Opening the bonnet ....... 6-20 Owner maintenance precautions ... 6-18...
Page 758 Index Replacement Fuse ..........6-63 Parking Brake ........4-90 Key battery ........6-39 Parking Sensor System ..... 4-245 Light bulbs ........6-46 Park assist sensor system Tyres ..........6-44 operation ........4-248 Wheel ..........6-45 Sensor detection range ....4-247 Wiper ..........
Page 759 Index Smart Brake Support (SBS) ....4-207 Storage Pocket ........5-155 Collision warning ......4-209 Sunroof ..........3-47 Smart Brake Support (SBS) indicator Sunshade ..........3-49 light (red) ........4-209 Sunvisors ........... 5-148 Stopping the Smart Brake Support (SBS) system operation ....4-209 Smart City Brake Support [Forward] (SCBS F) ...........
Page 760 Temporary spare tyre ..... 6-45 Air bag/seat belt pretensioner system Tyre chains ........3-62 warning beep ......... 7-52 Tyre in ation pressure ....6-42 Blind Spot Monitoring (BSM) warning Tyre rotation ........6-43 beep ..........7-56 Collision warning ......7-57 Electric Parking Brake Warning Beep..........
Page 761 Index Warranty ..........8-2 Windows Power windows ......3-44 Windscreen Washer ......4-84 Windscreen Wipers ......4-82 Winter Driving ........3-61 Wiper Replacing Rear Window Wiper Blade (Wagon) ......... 6-34 Replacing windscreen wiper blades..........6-33 10–11...
Page 762 MEMO 10–12...

Mazda 6 Owner's Manual

Quick Links

Related Manuals for Mazda 6

Summary of Contents for Mazda 6

Table of Contents
