GENUINE PARKING SENSOR, REAR
INSTALLATION INSTRUCTIONS
Thank you for purchasing a genuine Mazda accessory.
Before removal and installation, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly install and use the Parking sensor,
rear. Your safety depends on it.
Keep these instructions with your vehicle records for future reference.
•
There are several
installing or removing the Parking sensor, rear. Always read and follow them in order to prevent injuries,
accidents, and possible damage to the vehicle.
WARNING:
Indicates a situation in which serious injury or death could result if the warning
is ignored.
CAUTION:
Indicates a situation in which bodily injury or damage to the vehicle could result if the
caution is ignored.
•
For areas indicating the tightening torque in this instruction manual, tighten to the specified torque using
a torque wrench.
• Do not modify the Parking sensor, rear.
• Do not install the Parking sensor, rear in any way other than described in the following instructions.
• If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in
installation.
• If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice
before using it.
• Mazda and its suppliers are not responsible for injuries, accidents, and damage to persons and property
that arise from the failure of the dealer or installer to follow these instructions.
• To ensure safety and reliability of the work, installation, removal and disposal work must be carried out
by an Authorized Mazda Dealership.
• Be careful not to lose removed parts, and be sure that they are kept free from scratches, grease or
other dirt.
PART NAME:
VEHICLE:
PART NUMBER:
NOTE
To the dealer
• Please turn over these instructions to the customer after installation.
To the customer
• Keep these instructions after installation. The instructions may be necessary
for installing other optional parts or removal of this accessory.
• Should the vehicle or this accessory be resold, always leave these instructions
with vehicle for the next owner.
WARNING
WARNING and
CAUTION sections in this booklet concerning safety when
PARKING SENSOR, REAR
MAZDA6
C853 V7 290
C844 V7 281 (4 pc. SENSOR)
1
