Hilti SCW 22-A Operating Instruction

Hilti SCW 22-A Operating Instruction

Hide thumbs Also See for SCW 22-A:

Advertisement

Quick Links

Download this manual
SCW 22-A
English
en
Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00

Advertisement

loading
Need help?

Need help?

Do you have a question about the SCW 22-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hilti SCW 22-A

Summary of Contents for Hilti SCW 22-A

  • Page 1 SCW 22-A English Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 2 Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 3 1 Information about the documentation 1.1 About this documentation • Read this documentation before initial operation or use. This is a is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •...
  • Page 4 1.4 Product information Hilti products are designed for professional use and may be operated, serviced and maintained only by trained, authorized personnel. This personnel must be informed of any particular hazards that may be encountered. The product and its ancillary equipment may present hazards when used incorrectly by untrained personnel or when used not as directed.
  • Page 5 ▶ Store power tools out of reach of children when not in use. Do not allow persons who are not familiar with the tool or these instructions to operate it. Power tools are dangerous in the hands of untrained users. ▶...
  • Page 6 ▶ When restarting a saw in the workpiece, centre the saw blade in the kerf and check that saw teeth are not engaged into the material. If saw blade is binding, it may walk up or kickback from the workpiece as the saw is restarted. ▶...
  • Page 7 Contact Hilti Service after the battery has cooled down. Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 8 Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 9 Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 10 3 Description 3.1 Overview of the product Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 11 ▶ Do not use the product to cut tree branches or trunks. ▶ Use only Hilti Li­ion batteries from the B 18 / B 22 series with this product. ▶ Use only Hilti battery chargers of the C4/36 series with these batteries.

  • Page 12: Operation

    To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Center or online at: www.hilti.com 3.6 Accessories...
  • Page 13 5.2 Removing the saw blade WARNING Risk of burning injury. A hot accessory tool, clamping flange or clamping screw and the sharp edges of the saw blade present hazards. ▶ Wear protective gloves when changing saw blades. 1. Pull the battery out of the product to the rear. 2.
  • Page 14 1. Pull the battery out of the product to the rear. 2. Clean the mounting flange and the clamping flange. 3. Fit the mounting flange onto the drive spindle the right way round. 4. Open the pivoting guard. 5. Fit the new saw blade. 6.
  • Page 15 5.5 Setting the cutting angle 1. Pull the battery out of the product to the rear. 2. Release the cutting angle adjustment clamping lever. 3. Pivot the product into the desired position. 4. Tighten the cutting angle adjustment clamping lever. 5.6 Inserting the battery WARNING Risk of injury! Inadvertent starting of the circular saw.
  • Page 16 5.7 Sawing along a line Note Secure the workpiece to prevent movement. Position the workpiece so that the saw blade is free to rotate beneath it. Check to ensure that the on/off switch on the product is in the “off” position. Position the forward section of the saw’s base plate on the workpiece but do not bring the blade into contact with the workpiece.
  • Page 17 1. Remove the battery. 2. Remove the rip fence, if one is fitted. 3. Fit the base plate into the side retaining channels of the guide rail adapter. 4. Fully insert the base plate into the guide rail adapter. 5. Lock the guide rail adapter by pressing in the two sliders as far as they will go. 5.9.1 Longitudinal cuts at 0°...
  • Page 18 To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Center or online at: www.hilti.com 6.2 Transport and storage of cordless tools...

  • Page 19: Troubleshooting

    ◁ The pivoting guard must close quickly and completely when the guard operating lever is released. 7 Troubleshooting ▶ If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by yourself, please contact Hilti Service. 7.1 The circular saw is not in working order. Malfunction...
  • Page 20 Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, your old tools, machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative for further information.
  • Page 21 Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
  • Page 22 Hilti = registered trademark of Hilti Corp., Schaan 20160714 Printed: 27.07.2016 | Doc-Nr: PUB / 5292954 / 000 / 00...
