Carimali F10 Quick Start Manual

STARTING UP
After checking that the machine
door is closed and the ground bin
is inserted, press the key No.1
(ON/OFF) to turn ON the machine.
DISPENSING
COFFEE/CAPPUCCINO
DISPENSING
Place a cup under the coffee
dispenser, and press the desired
dose key. For Shift doses, press
the Key No3 (Shift) fi rst and then
the desired dose key.
The display shows:
XXXXXXXX
Where "XXXXXXXX" indicates the
selected dose key name.
DECAFFEINATED DISPENSING
(NOT AVAILABLE FOR SELF
CONFIGURATION)
Place a cup under the coffee
dispenser and open the
decaffeinated coffee door, the
display shows :
❐ Pour in the powdered coffee
❐ Close the decaffeinated door
❐ Press the desired dose key, the
display shows:
XXXXXX
When the set-up temperature is
reached, the display shows:
For machine confi guration Standard
or Self
SELECT DRINK
Warning: during this stage
remove any jug with milk or any
other kind of liquid from the
steam wand!
1
PLEASE NOTE:
❐ Pressing the same dose key
during dispensing can stop the
selected dose (not available for
Self confi guration).
❐ In case of a milk-based
dose, press once to stop milk
dispensing, and once again
to stop coffee dispensing; the
sequence depends on the type of
dispensing (not available for Self
confi guration).
3
Where indicates that the
selected dose will be dispensed
without the activation of the
grinders.
PLEASE NOTE:
If the decaffeinated door is not
closed, or if the dose button is
not selected, the machine will
automatically cancel this function
after 20 seconds. The coffee group
will carry out a cleaning cycle of
the brewing chamber. The display
shows:
PLEASE WAIT
Q U I C K S T A R T G U I D E
F10 - F20
C O F F E E M A C H I N E S
FILL IN BEAN HOPPER
Fill in the required amount for
daily consumption in order to
keep coffee always fresh.
HOT WATER DISPENSING
Place a cup under the hot water
outlet, and press the hot water
key dose. Dispensing will be
automatically stopped once the
programmed dose is over. The
display shows:
HOT WATER
PLEASE NOTE:
❐ Pressing the same dose key
during dispensing may stop the
selected dose (not available for
Self confi guration).
EXTRAMILK DISPENSING (ONLY
LM MACHINE, NOT AVAILABLE
FOR SELF CONFIGURATION)
Press any milk-based key and
keep it pressed, after 2 seconds
foamed milk will start being
dispensed, the display shows:
EXTRA MILK
By releasing the pressed key,
dispensing will be stopped.
2
WARNING:
❐ Handle the hot water spout with
caution because it might cause
burns due to high temperature.
❐ Hot water cannot be dispensed
simultaneously with steam.
4
