3.8 Configuring the Target
After the simulation on the computer we know that our program works and in case of errors
we have corrected them. Now there is need of configuring the linker and the debug utilities.
Therefore quit the debug mode first. Klick first on the icon 1 according to Figure 3.11. You already
know the appearing window. Now click on New Project Target, name it STM32H103 and click OK.
Select now the created target on the left side of the icon 1. Klick now on the icon 2 according to
Figure 3.11.
The processor won't run if is not configured as shown in the Figures
Go to the tab Debug and select Use: Your JTAG Adapter. In the tab Utilities select Use Target Driver
for Flash Programming: Your JTAG Adapter. Click on Settings and there on Add. Select STM32F10x
2
Med-density Flash
and click Add and twice OK.
Figure 3.8: Options for Output
2
In Vision before version 3.7 select STM32F10x 128kB Flash
Lukas Kohler
Figure 3.10: Options for Linker
2
The Electrocardiogram
3.11
- 3.15!
electrodes placed on the l
below.
Figure 3.9: Options for Listing
Josef Goette
Electrocardio
• Ecg: electrical ma
from the body surfa
• monitoring of heart
The Ecg signal can b
19
