2.4 Processor STM32F103RB from STMicroelectronics

2 Electrocardiogram (Ecg) Signals

2.4.1 Features

The STM32F103RB from STMicroelectronics is a processor with a ARM 32-bit Cortex-M3 CPU
The Electrocardiogram (Ecg)
and peripherals. STMicroelectronics is reshaping the 16/32-bit MCU market with they'r STM32
family.
• Ecg: electrical manifestation of heart activity recorded
The key benefits of the STM32F103RB are:
from the body surface
Leading performance, real time behavior
• monitoring of heart rate
A lot of peripherals
Outstanding power efficiency
In production since 2007
The Ecg signal can be recorded fairly easily with surface
70 part numbers across 4 product lines
electrodes placed on the limbs and/or the chest, see pages
below.
SW Libraries are free available from
Core: CPU clock internal up to 72Mhz, single-cycle multiplication and hardware division
Memory: 128KBytes flash, 20KByte ram and memory controller
LCD parallel interface
Low power states (sleep, stop and standby)
7 DMA channels
RTC
WDT
PWM
3x Timers and SysTick
Communication interface:
– 2x SPI
– 2x I2C
– 3x I2S
– 3x USART
– USB 2.0
Josef Goette
– CAN
Up to 51 GPIO (multiplexed with peripherals, 5V tolerable [but not for analog inputs!])
2x ADC 12 bit
Operating voltage 2.0-3.6V
Temperature: -40C +85C
Debugging: JTAG and serial wire interface
A lot of information, data sheets and examples can be found at
http://www.st.com/mcu/familiesdocs-110.html.
