Page 1: Hedge Trimmer
Hedge Trimmer model number 060-3014-6 | contact us: 1.866.523.5218 IMPORTANT: Instruction Read and follow all safety rules and operating Manual instructions before using this product. - Page 2 060-3014-6 | contact us: 1.866.523.5218 SPeCifiCAtioNS KNoW YoUR MoWeR SYMBolS SAfetY RUleS exPloded VieW PARtS liSt eleCtRiCAl ASSeMBlY oPeRAtioN MAiNteNANCe WARRANtY Motor: 3.5 A Blade length: 18” (45.7 cm) Cut capacity: 2/3” (1.7 cm) No load speed: 3000 (±10%) SPM Weight: 6 lb (2.7 kg)
-
Page 3: Cord Retainer
060-3014-6 | contact us: 1.866.523.5218 1. lock-off button 2. Auxiliary handle 3. Guard 4. Blade support rod 5. Blade 6. trigger switch 7. Cord retainer 1. Cord 2. extension cord KNOW YOUR MOWeR the safe use of this product requires an understanding of the information in this operator’s manual as well as a knowledge of the project you are attempting. - Page 4 060-3014-6 | contact us: 1.866.523.5218 Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
- Page 5 060-3014-6 | contact us: 1.866.523.5218 the following signal words and meanings are intended to explain the levels of risk associated with this product. Symbol Signal Meaning indicates an imminently hazardous situation, which, if not avoided, dANGeR could result in death or serious injury.
- Page 6 060-3014-6 | contact us: 1.866.523.5218 Save all warnings and instructions for future reference. the term “power tool” in all of the warnings listed below refers to your corded or cordless power tool. 1. Work area safety Cluttered or dark areas invite accidents.
- Page 7 060-3014-6 | contact us: 1.866.523.5218 Keep proper footing and balance at all times. this enables better e. Do not overreach. control of the power tool in unexpected situations. do not wear loose clothing or jewellery. Keep your hair, clothing and f.
-
Page 8: Hedge Trimmer Safety Warnings
060-3014-6 | contact us: 1.866.523.5218 HeDGe TRIMMeR SAFeTY WARNINGS • Use both hands when operating the hedge trimmer. Using one hand could cause loss of control and result in serious personal injury. do not remove cut material or •... - Page 9 060-3014-6 | contact us: 1.866.523.5218...
- Page 10 060-3014-6 | contact us: 1.866.523.5218 item description drawing Motor cover housing 31301652-2 Board 34118441-1 Screw St3.5*10-C 32201441 trigger 34106456-2 Spring 33402161-1 lock-off spring 32201647 lock-off button 34109453-11 4.8 Sheath 34901161 terminal 4.8*0.8 36503161 Micro swtich 36303152 Screw 3220313...
-
Page 11: Double Insulation
060-3014-6 | contact us: 1.866.523.5218 DOUBLe INSULATION double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. double-insulated tools do not need to be grounded. -
Page 12: Extension Cords
060-3014-6 | contact us: 1.866.523.5218 eXTeNSION CORDS When using a power tool at a considerable distance from a power source, be sure to use an extension cord that has the capacity to handle the current the product will draw. An undersized cord will cause a drop in line voltage, resulting in overheating and loss of power. -
Page 13: Packing List
060-3014-6 | contact us: 1.866.523.5218 UNPACKING • this product requires no assembly. • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • inspect the product carefully to make sure no breakage or damage occurred during shipping. -
Page 14: Connecting To Power Supply
060-3014-6 | contact us: 1.866.523.5218 CONNeCTING TO POWeR SUPPLY this product is designed with a cord retainer that prevents the extension cord from being pulled loose while using. • form a loop with the end of the extension cord. -
Page 15: Starting The Hedge Trimmer
060-3014-6 | contact us: 1.866.523.5218 STARTING THe HeDGe TRIMMeR Attach an extension cord to your hedge trimmer. Place one hand on the trigger handle (1). Place the other hand on the auxiliary handle (2). Slide the lock switch (4) toward you then squeeze the trigger switch (3) to turn oN the hedge trimmer. -
Page 16: Cutting Tips
060-3014-6 | contact us: 1.866.523.5218 CUTTING TIPS • When operating the hedge trimmer, keep the extension cord behind the trimmer. Never drape it over the hedge being trimmed. • do not force the hedge trimmer through heavy shrubbery. this can cause the blades to bind and slow down. -
Page 17: General Maintenance
060-3014-6 | contact us: 1.866.523.5218 GeNeRAL MAINTeNANCe Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, grease, etc. -
Page 18: Cleaning The Hedge Trimmer
060-3014-6 | contact us: 1.866.523.5218 CLeANING THe HeDGe TRIMMeR • Stop the motor and disconnect from power supply. • Clean dirt and debris from the body of the hedge trimmer, using a damp cloth with a mild detergent. -
Page 19: Year Limited Warranty
Made in China and workmanship for a period of one hundred imported by twenty (120) days from the date of retail Yardworks Canada toronto, Canada M4S 2B8 purchase. Yardworks CANADA will not be liable for incidental or consequential loss or damage.
