- Page 1 14” (36 CM) BRUSHLESS GRASS TRIMMER model number 060-1984-8 | contact us: 1.866.523.5218 3026035 IMPORTANT: Instruction Read and follow all safety rules and operating Manual instructions before using this product.
- Page 2 model no. model no. | contact us: 1.866.523.5218 | contact us: 1.866.523.5218 060-1984-8 060-1984-8...
- Page 3 model no. | contact us: 1.866.523.5218 060-1984-8 Introduction Safety Instructions & Symbols Product Specifications Product Diagram Assembly Operating Instructions Maintenance Storage Troubleshooting Exploded View Parts List Warranty...
-
Page 4: Safety First
It has been designed, engineered ® and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please contact our Yardworks ® customer service line at 1.866.523.5218. PLEASE READ AND RETAIN THIS INSTRUCTION MANUAL. These instructions will enable you to assemble and maintain your appliance properly. - Page 5 model no. | contact us: 1.866.523.5218 060-1984-8 FOR ALL APPLIANCES safety guard. Check the alignment of the moving parts, the binding of the moving • Avoid dangerous environments — do not parts. Check for broken or defective use appliances in damp or wet locations. parts that can affect the safe operation •...
-
Page 6: Safety Warnings For Battery Pack
model no. | contact us: 1.866.523.5218 060-1984-8 ejected from the battery; avoid contact. battery pack. If contact accidentally occurs, flush with b) Do not expose battery pack to heat or water. If liquid contacts eyes, additionally fire. Avoid storage in direct sunlight. seek medical help. - Page 7 Recharge only with the charger turning the equipment off and on, the user is specified by Yardworks . Do not ® encouraged to try to correct the interference...
- Page 8 Yardworks Inc. has established a partnership with the RBRC Corporation ® to recycle any Yardworks batteries with the RBRC-call2recycle seal. For ® environmental protection, please do not discard batteries in the trash. After the battery’s life cycle is ended, please call 1-800-822-8837 for a free service that will properly dispose of the battery.
-
Page 9: Technical Data
model no. | contact us: 1.866.523.5218 060-1984-8 TECHNICAL DATA Voltage Speed high: 6000/min low: 4500/min Cutting Diameter 14" (36 cm) Line Diameter 0.080" (2.0 mm) Line length 2x8 ft (4.9 m) Battery capacity (060-1987-2) 2.0 Ah Charger Input(060-1990-2) 120 V~, 60 Hz, 110 W Charger Output(060-1990-2) 48 V , 2 A... - Page 10 model no. | contact us: 1.866.523.5218 060-1984-8 Battery pack (060-1987-2) Battery pack release button On/Off switch Lock-off button Two-speed gear control Auxiliary handle Couplings Safety guard Line cutter 10. Trimmer head 11. Spool 12. Bump knob 13. Charger (060-1990-2) 14. Hex key (Fig. A2) 15.
- Page 11 model no. | contact us: 1.866.523.5218 060-1984-8 To reduce the risk of injury, user must read instruction manual. Intended Use The machine is intended for the cutting of grass and weeds under bushes, as well as on slopes and edges that cannot be reached with a lawn mower. 1.
- Page 12 model no. model no. | contact us: 1.866.523.5218 | contact us: 1.866.523.5218 060-1984-8 060-1984-8 3. Assembling the safety guard Attach the safety guard to the trimmer head. Align the guard so it slides into the slots located on the trimmer head (see Fig. C1.). Secure the safety guard onto the trimmer head with the screw provided (see Fig.
-
Page 13: Charging Indicator
model no. | contact us: 1.866.523.5218 060-1984-8 CHARGING INDICATOR This charger is designed to detect some problems that can arise with battery packs. Indicator lights indicate problems (see table below). Light ON/ Flash Status Defective battery. Red on Battery Temperature Protection. The temperature of battery pack is less than 0 C (32... -
Page 14: Switch On/Off
model no. model no. | contact us: 1.866.523.5218 | contact us: 1.866.523.5218 060-1984-8 060-1984-8 1. SWITCH ON/OFF To switch on, press the lock-off button first, then the On/Off switch (see Fig. F). To switch off, release the On/Off switch. 2. TWO-SPEED GEAR CONTROL The trimmer has a two-speed gear control designed for working at Low (mark is 1) or High (mark is 2) speeds (see Fig. - Page 15 High model no. | contact us: 1.866.523.5218 060-1984-8 High 4. Adjusting cutting line length The trimmer head allows the operator to release more cutting line without stopping the motor. As line becomes frayed or worn, additional line can be released by lightly tapping the bump knob on the ground while operating the trimmer (see Fig.
- Page 16 model no. | contact us: 1.866.523.5218 060-1984-8 5. To replace the spool and line For your convenience it is recommended you buy a replacement spool with line. Press and hold in the two cap release latches. Loosen the cap by rotating it counter- clockwise.
- Page 17 model no. | contact us: 1.866.523.5218 060-1984-8 6. To replace the line only Take a line of approximately 16’ (5 m). Insert the centre point of line into the notch in the middle section of the spool and wind the line in a clockwise direction (see Fig.
-
Page 18: Maintenance
model no. | contact us: 1.866.523.5218 060-1984-8 MAINTENANCE Always check the product prior to being used for any damage. After use, disconnect the battery from the tool and check for damage. Your power tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. - Page 19 Corrective Action Battery discharged. Recharge battery; also see the content in charger manual. Battery too hot/cold. Allow to cool/warm. Trimmer fails to operate. Motor is broken. Contact Yardworks at 1.866.523.5218. ® Internal wiring of machine Contact Yardworks at 1.866.523.5218. ® damaged.
- Page 20 model no. | contact us: 1.866.523.5218 060-1984-8...
- Page 21 model no. | contact us: 1.866.523.5218 060-1984-8 Lock Knob Part Description Quantity Switch Self Tapping Screw Compression Spring Rear Cover Self Tapping Screw Motor Compression Spring Housing Trigger Gear Right_handle Flange Self Tapping Screw Gear Box Body Internal Wire Needle Bearing Self Tapping Screw Self Tapping Screw Right Side Cover...
- Page 22 (365) days from the date of retail purchase. Made in China. Imported by Yardworks Canada Toronto, Canada M4S 2B8 Always remove or disconnect the battery pack before adjusting, cleaning,...
- Page 23 FCC Part 15 Supplier’s Declaration of Conformity Product Description: 48V 2.0 A Charger Model Number: 060-1990-2 Trade Name: Yardworks ® This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and...
-
Page 25: Assembling The Safety Guard
14” (36 CM) BRUSHLESS GRASS TRIMMER model no. 060-1984-8 | contact us: 1.866.523.5218 1. ASSEMBLING THE UPPER SHAFT AND LOWER SHAFT Connect the couplings together. (See Fig. A1) Align the holes and fasten the couplings by tightening the bolt with hex key. (See Fig. A2) 2. -
Page 26: Operation
14” (36 CM) BRUSHLESS GRASS TRIMMER model no. 060-1984-8 | contact us: 1.866.523.5218 OPERATION 1. CHARGING THE BATTERY (SEE FIG. D ) 2. INSTALLING AND REMOVING THE BATTERY PACK Slide the battery pack into tool’s battery port. A simple push and slight pressure will be sufficient.
