  • Page 1 P650HS(-G) / P651HS(-G)
  • Page 3 Preface Notebook Computer P650HS(-G) / P651HS(-G) Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P650HS(-G) / P651HS(-G) series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Main Board ................... A-5 HDD ....................A-6 Overview ..................1-1 LCD ....................A-7 Specifications ..................1-2 LCD (Sharp) .................. A-8 External Locator - Top View with LCD Panel Open ......1-4 Schematic Diagrams......... B-1 External Locator - Front & Right Side Views .........1-5 External Locator - Left Side &...
  • Page 12 Preface GPU Decoupling 1 ............... B-27 TPM, CCD, TP ................B-59 GPU Decoupling 2 ............... B-28 Fan, LID, KB LED ...............B-60 Straps & XTAL ................B-29 Connector ..................B-61 IFP I/O Interface ................B-30 DDR 1.2V / 0.6VS ................B-62 Misc - GPIO, I2C and ROM ............B-31 VDD3, VDD5 ................B-63 NVIDIA Power Sequence ............
  • Page 13 Preface P670RS USB Board 1/2 ............... B-91 P670RS USB Board 2/2 ............... B-92 Updating the FLASH ROM BIOS..C-1 Download the BIOS ............... C-1 Unzip the downloaded files to a bootable CD/DVD/ or USB Flash drive ................C-1 Set the computer to boot from the external drive ......C-1 Use the flash tools to update the BIOS ..........
  • Page 14 Preface...

  • Page 15: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P650HS(-G) / P651HS(-G) series notebook com- puter. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. In- formation about dri-vers (e.g.

  • Page 16: Specifications

    Introduction Specifications Processor Options Security i7-7820HK (2.90GHz) Security (Kensington® Type) Lock Slot  8MB Smart Cache, 14nm, DDR4-2400MHz, TDP 45W BIOS Password i7-7700HQ (2.80GHz) Intel PTT for Systems Without TPM Hardware Latest Specification Information 6MB Smart Cache, 14nm, DDR4-2400MHz, TDP 45W (Factory Option) TPM 2.0 The specifications listed in this section are Supports Intel®...
  • Page 17 Introduction Storage Communication Features (Factory Option) Two SATA M.2 2280 SSDs supporting Built-In 10/100/1000Mb Base-TX Ethernet LAN Supports NVIDIA G-SYNC Technolgy in dGPU Mode RAID level 0/1 2.0M FHD PC Camera Module (G-SYNC is only supported if you have a G-SYNC capable display and a GTX series video adapter) (Factory Option) M.2 3G/4G Module (Factory Option) One PCIe Gen3 x4 M.2 2280 SSD...

  • Page 18: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Speakers 6.

  • Page 19: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. Headphone & S/ PDIF Combo Jack 2. Microphone-In RIGHT SIDE VIEW Jack 3. Line-Out Jack 4. USIM Card Reader (for 3G/ 4G USIM Cards) 5.

  • Page 20: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent 2. Mini Display Port 3. USB 3.1 Gen 2 LEFT SIDE VIEW Type C Ports 4. USB 3.0/3.1 Port 5. Powered USB 3.0/ 3.1 Port Figure 5 REAR VIEW Rear View...

  • Page 21: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 22: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Memory Slots DDR4 SO-DIMM 2. CMOS Battery 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 23: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (WLAN Module) 2. Mini-Card Connector (M.2 3G/4G Module) 3. Mini-Card Connector (M.2 PCIE/SATA SSD Module) 4. GPU-GTX1070M 5. Memory Slots DDR4 SO-DIMM 6. CPU Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 24: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. Mini Display Port 2. USB Ports 3.1 Gen 2 Type C Connector 3. USB Ports 3.0/3.1 Connector 4. Keyboard Cable Connector 5. TP Connector 6. Speaker Connector 7. HDD Connector 8.

  • Page 25: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Multi-in-1 Card Reader 2. Battery Connector 3. LCD Cable Connector 4. CCD Connector 5. Mini Display Port 6. HDMI-Out Port 7. DC-In Jack Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 26 Introduction 1 - 12...
  • Page 27 Introduction Mainboard Overview - Bottom (Connectors) 1 - 13...
  • Page 28 Introduction 1 - 14 Mainboard Overview - Bottom (Connectors)

  • Page 29: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P650HS(-G) / P651HS(-G) series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 30: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 31: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 32: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: 1. Remove the keyboard page 2 - 5 To remove the Battery: 1.

  • Page 33: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 34: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove the SD card cover and screws (Figure 2a). a. Remove the SD cover 3. Carefully lift the bottom case up in the direction of the arrow and remove it (Figure 2b and screws.
  • Page 35 Disassembly 5. Carefully disconnect the cable , then remove screws (Figure 3b Figure 3 6. Lift the battery off the computer (Figure 3e Battery Removal 7. Reinsert the bottom case starting from point as shown (Figure 3f) to avoid damaging the rear eSATA/USB 3.0 (cont’d.) port.

  • Page 36: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 37 Disassembly 4. Slightly lift and pull the hard disk in the direction of arrow (Figure 5c Figure 5 5. Lift the hard disk assembly out of the bay (Figure 5d HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 5e Removal (cont’d.) 7.

  • Page 38: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM-1 Module The computer has four memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) support- Removal ing DDR4 2133/2400 MHz. The main memory can be expanded up to 64GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 39 Disassembly 4. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 7c). The RAM module will pop-up Figure 7d , and you can then remove it RAM-1 Module 5.
  • Page 40 Disassembly Memory-2 Upgrade Process Figure 8 RAM-2 Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The RAM-2 modules will be visible at point on the mainboard (Figure 8a 3. Gently pull the two release latches ( &...

  • Page 41: Removing And Installing The M.2 Ssd Module

    Disassembly Removing and Installing the M.2 SSD Module Figure 9 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a).
  • Page 42 Disassembly M.2 SSD-2 Removal Procedure Figure 10 M.2 SSD-2 Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the module, it is visible at point Figure 10a 3. Remove the screw from the module Figure 10b a.
  • Page 43 Disassembly M.2 SSD Installation Procedure Figure 11 1. Place the thermal pad on the module as shown (Figure 11a). M.2 SSD Module 2. Insert the module in the computer Figure 11b Installation 3. Tighten the screw to secure it in place (Figure 11c).

  • Page 44: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 12 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 12a).

  • Page 45: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 46: Removing The 3G/4G Module

    Disassembly Removing the 3G/4G Module Figure 13 3G/4G Removal Procedure 3G/4G Module Removal 1. Turn off the computer, remove the battery (page 2 - 2. Locate the module, it is visible at point Figure 13a a. Locate the module. 3. Carefully disconnect the cables &...

  • Page 47: Part Lists

    Appendix A:Part Lists This appendix breaks down the P650HS(-G) / P651HS(-G) series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 48: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 page A - 8...

  • Page 49: Top

    Figure A - 1 Top A - 3...

  • Page 50: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 51: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 52: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 53: Lcd

    Figure A - 5 LCD A - 7...

  • Page 54: Lcd (Sharp

    LCD (Sharp) Figure A - 6 LCD (Sharp) A - 8 LCD (Sharp)

  • Page 55: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P650HS(-G) / P651HS(-G) notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Diagram - Page...

  • Page 56: System Block Diagram

    Schematic Diagrams System Block Diagram 1.2V(VDDQ),0.6VS SHEET 61 P650RS Skylake System Block Diagram P650 ESS AUDIO BOARD 6-71-P65S8-D02C SHEET 77,78,79 SHEET 62 VDD3,VDD5 EM370(D) 5V,3.3V,5VS,3VS P670 3DAMP AUDIO BOARD SHEET 63 6-7P-P65SB-008 6-71-P67P8-D02B SHEET 80 VDD1.0,VCCIO SHEET 64 6-71-P65S0-D02C PCIE*16 P650 POWER SW BOARD <=4.5"...

  • Page 57: Processor 1/7

    Schematic Diagrams Processor 1/7 U59C SKYLAKE_HALO BGA1440 PEG_TX_0 C863 0.22u_10V_X5R_04 PEG_RX0 PEG_RXP[0] PEG_TXP[0] PEG_TX0 17 PEG_TX#_0 C855 0.22u_10V_X5R_04 PEG_RX#0 PEG_RXN[0] PEG_TXN[0] PEG_TX#0 17 PEG_TX_1 C854 0.22u_10V_X5R_04 PEG_RX1 PEG_RXP[1] PEG_TXP[1] PEG_TX1 17 PEG_TX#_1 C849 0.22u_10V_X5R_04 PEG_RX#1 PEG_RXN[1] PEG_TXN[1] PEG_TX#1 17 PEG_TX_2 C846 0.22u_10V_X5R_04 PEG_RX2...

  • Page 58: Processor 2/7

    Schematic Diagrams Processor 2/7 SKYLAKE_HALO U59D BGA1440 IEDP_TXP_0 DDI1_TXP[0] EDP_TXP[0] IEDP_TXN_0 DDI1_TXN[0] EDP_TXN[0] IEDP_TXP_1 DDI1_TXP[1] EDP_TXP[1] IEDP_TXN_1 DDI1_TXN[1] EDP_TXN[1] IEDP_TXN_2 DDI1_TXP[2] EDP_TXN[2] IEDP_TXP_2 DDI1_TXN[2] EDP_TXP[2] IEDP_TXN_3 DDI1_TXP[3] EDP_TXN[3] IEDP_TXP_3 DDI1_TXN[3] EDP_TXP[3] IEDP_AUX DDI1_AUXP EDP_AUXP IEDP_AUX# DDI1_AUXN EDP_AUXN DDI2_TXP[0] DDI2_TXN[0] EDP_DISP_UTIL VCCIO DDI2_TXP[1] EDP_DISP_UTIL...

  • Page 59: Processor 3/7

    Schematic Diagrams Processor 3/7 M_A_DQ[63:0] 9,10 SKYLAKE_HALO U59B 11,12 M_B_DQ[63:0] SKYLAKE_HALO BGA1440 U59A M_B_DQ0 BT11 BGA1440 DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_B_CLK_DDR0 M_B_DQ1 BR11 M_A_DQ0 M_B_CLK_DDR#0 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] DDR0_DQ[0] DDR0_CKP[0] M_A_CLK_DDR0 M_B_DQ2 M_A_DQ1 DDR1_DQ[2]/DDR0_DQ[18] DDR1_CKN[1] M_B_CLK_DDR#1 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR#0 M_B_DQ3 M_A_DQ2 DDR1_DQ[3]/DDR0_DQ[19] DDR1_CKP[1] M_B_CLK_DDR1 M_B_DQ4 DDR0_DQ[2]...

  • Page 60: Processor 4/7

    Schematic Diagrams Processor 4/7 NEAR CPU CFG[0]: Stall reset sequence after PCU PLL lock until de-asserted: — 1 = (Default) Normal Operation; 1.0V_VCCST No stall. — 0 = Stall. CFG[1]: Reserved configuration lane. SKYLAKE_HALO U59E CFG[2]: PCI Express* Static x16 Lane BGA1440 Numbering Reversal.

  • Page 61: Processor 5/7

    Schematic Diagrams Processor 5/7 PLACE CAPS AT BOARD EDGE VCORE CPU_TOP_VCCCORE VCORE SKYLAKE_HALO VCORE U59G SKYLAKE_HALO U59J BGA1440 BGA1440 AA13 C522 C523 AA31 BJ17 VCCOPC C562 C536 AA32 BJ19 VCCOPC AA33 BJ20 VCCOPC AA34 BK17 VCCOPC AA35 BK19 VCCOPC AA36 BK20 VCORE VCCOPC...

  • Page 62: Processor 6/7

    Schematic Diagrams Processor 6/7 PLACE CAP BACKSIDE VCCVDDQ_CLK 1.0V_VCCSFR 1.0V_VCCST VCCSA VDDQ SKYLAKE_HALO U59I C481 C475 C473 BGA1440 VCCSA VDDQ AE12 SKYLAKE_HALO U59K VCCSA VDDQ VCCSA VDDQ BGA1440 VCCSA VDDQ D02A BCN BM33 VCCSA VDDQ D02A BCN RSVD_TP RSVD_TP BL33 VCCSA VDDQ RSVD_TP...

  • Page 63: Processor 7/7

    Schematic Diagrams Processor 7/7 VCCGT U59M SKYLAKE_HALO VCCGT VCCGT SKYLAKE_HALO U59N BGA1440 SKYLAKE_HALO AK30 SKYLAKE_HALO U59L SKYLAKE_HALO BGA1440 U59F AK29 U59H AJ29 BGA1440 VCCGT AJ30 BGA1440 BGA1440 AJ38 BG34 VCCGT AF29 AV29 AJ31 VCCGT VCCGTX BA38 AJ37 BG35 VCCGT VCCGT AF30 AV30 AJ32...

  • Page 64: Ddr Cha So-Dimm_0

    Schematic Diagrams DDR CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] VTT_MEM RVS TYPE BOT Short VDDQ J_DIMMA_2B H=4mm 2.5V J_DIMMA_2A VDD19 VDD18 VDD17 M_A_CLK_DDR0 CK0_T M_A_DQ5 4,10 VDD16 VPP2 M_A_CLK_DDR#0 CK0_C M_A_DQ1 4,10 VDD15 VPP1 M_A_CLK_DDR1 M_A_DQ3 4,10 CK1_T VDD14 M_A_CLK_DDR#1 CK1_C M_A_DQ6 4,10...

  • Page 65: Ddr Cha So-Dimm_1

    Schematic Diagrams DDR CHA SO-DIMM_1 Channel A SO-DIMM 1[RAM3] STD TYPE TOP Close to CPU H=4mm J_DIMMA_1A M_A_CLK_DDR2 M_A_DQ5 CK0_T M_A_CLK_DDR#2 CK0_C M_A_DQ1 VTT_MEM M_A_CLK_DDR3 CK1_T M_A_DQ3 M_A_CLK_DDR#3 CK1_C M_A_DQ6 J_DIMMA_1B M_A_DQ4 VDDQ M_A_CKE2 CKE0 M_A_DQ0 2.5V PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM M_A_CKE3 CKE1 M_A_DQ2...

  • Page 66: Ddr Chb So-Dimm_0

    Schematic Diagrams DDR CHB SO-DIMM_0 VTT_MEM Channel B SO-DIMM 0[RAM2] RSV TYPE J_DIMMB_2B BOT High VDDQ H=8mm 2.5V VDD19 VDD18 J_DIMMB_2A VDD17 M_B_DQ[63:0] 4,12 VDD16 VPP2 M_B_DQ4 M_B_CLK_DDR0 CK0_T VDD15 VPP1 M_B_DQ0 M_B_CLK_DDR#0 CK0_C VDD14 M_B_DQ7 M_B_CLK_DDR1 3.3VS CK1_T VDD13 M_B_DQ3 M_B_CLK_DDR#1 CK1_C...

  • Page 67: Ddr Chb So-Dimm_1

    Schematic Diagrams DDR CHB SO-DIMM_1 Channel B SO-DIMM 1[RAM4] RVS TYPE TOP Distant H=4mm J_DIMMB_1A M_B_DQ[63:0] 4,11 M_B_DQ4 VTT_MEM M_B_CLK_DDR2 CK0_T M_B_DQ0 M_B_CLK_DDR#2 J_DIMMB_1B CK0_C M_B_DQ7 VDDQ M_B_CLK_DDR3 CK1_T M_B_DQ3 2.5V M_B_CLK_DDR#3 CK1_C JY SWAP DDR NET M_B_DQ1 VDD19 M_B_DQ5 M_B_CKE2 CKE0 VDD18...

  • Page 68: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL CONNECTOR (For coaxial cable) DEFAULT SHORT PANEL POWER PJ31 PLVDD Q35A *MTS3572G6 VLED C697 1/28 NV CHECK , connect to J_LCD1_Pin1 R787 1u_6.3V_X5R_04 GSYNC D02B C733 C729 10K_04 C1141 D02B NV recommend J_LCD1 C734 D02B NV recommend *0.22u_50V_Y5V_06 FRAME_LOCK#_R...

  • Page 69: Mini Dp Port E

    Schematic Diagrams Mini DP Port E mini-Display Port E (back) R380 *0_04 R379 *0_04 Close to Display PORT MDP_PW R MDP_E#3 C677 0.1u_10V_X7R_04 D_MDP_E#3 R376 0_04 NV3V3 C678 0.1u_10V_X7R_04 D_MDP_E3 MDP_E3 R383 *0_04 3.3VS *DVI2012F2SF-900T05_08-SHORT VOUT C673 R382 *0_04 SY6288DAAC R381 *0_04 *10u_6.3V_X5R_06...

  • Page 70: Mini Dp Port F + Ps8330B

    Schematic Diagrams Mini DP Port F + PS8330B mini-Display Port F (LEFT) PLEASE CLOSE TO CONNECTOR AUX interception disable for Port y (y = 1, 2). Internal pull down at ~150K , 3.3V I/O; L: AUX interception enable, driver configuration is set by link training (default) H: AUX interception disable, driver output with fixed 800mV and 0dB M: AUX interception disable, driver output with fixed 400mV and 0dB Close to Display PORT...

  • Page 71: Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR HDMI_5VS For ESD HDMI_5VS 3/21 J_HDMI1 HDMI Logo 116E-1C001-20Y D02A BCN VOUT P/N = 6-21-13K20-019 C681 PCB Footprint = c-116e-xx001-x0x RB751V-40(lision) RB751V-40(lision) C671 SY6288DAAC D02A BCN *10u_6.3V_X5R_06 22u_6.3V_X5R_08 22u_6.3V_X5R_08 HDMI Logo 15,37,59,61,63 SUSB HDMI_HPD-C HOT PLUG DETECT uP7549UMA5-20 PCB Footprint = M-SOT23-5 2K_04...

  • Page 72: Vga Pci Express

    Schematic Diagrams VGA PCI Express NV3V3 D02A DG P.252 recommend CLKREQ , is OD pin , must have a 10k pull up to 1V8_AON D02A R394 31,68 NVVDD_PWRGD 10K_04 NV PCI EXPRESS MTN2002ZS3 PEG_CLKREQ# U39A 1/28 Cap follow reference board design , x6s INS130817227 R396 BGA2152...

  • Page 73: Vga Frame Buffer Partition

    Schematic Diagrams VGA Frame Buffer Partition U39C U39B PAGE3: GPU FRAME BUFFER PARTITION A/B INS127422923 BGA2152 INS127421140 COMMON BGA2152 COMMON 3/23 FBB 2/23 FBA FBB_D0 FBB_CMD0 FBB_D0 FBB_CMD0 FBA_D0 FBA_CMD0 FBA_DBI[7..0] FBB_DBI[7..0] FBB_D1 FBB_CMD1 FBA_D0 FBA_CMD0 FBB_D1 FBB_CMD1 FBA_DBI[7..0] FBB_DBI[7..0] FBA_D1 FBA_CMD1 FBB_D2...

  • Page 74: Frame Buffer Partition A

    Schematic Diagrams Frame Buffer Partition A FBA_WCK01 FBA_CMD[31..0] FBA_W CK01 FBA_CMD[31..0] FBA_WCK01* FBA_W CK01* FRAME BUFFER PARTITION A FBA_WCK23 FBA_D[63..0] FBA_W CK23 FBA_D[63..0] FBA_WCK23* FBA_W CK23* FBA_WCK45 FBA_DBI[7..0] FBA_W CK45 FBA_DBI[7..0] FBA_WCK45* FBA_W CK45* FBA_WCK67 FBA_EDC[7..0] FBA_W CK67 FBA_EDC[7..0] FBA_WCK67* FBA_W CK67* INS115241755 BGA170...

  • Page 75: Frame Buffer Partition B

    Schematic Diagrams Frame Buffer Partition B FBB_WCK01 FBB_CMD[31..0] FBB_W CK01 FBB_CMD[31..0] FBB_WCK01* FBB_W CK01* FRAME BUFFER PARTITION B FBB_WCK23 FBB_D[63..0] FBB_W CK23 FBB_D[63..0] FBB_WCK23* FBB_W CK23* FBB_WCK45 FBB_DBI[7..0] FBB_W CK45 FBB_DBI[7..0] FBB_WCK45* FBB_W CK45* FBB_WCK67 FBB_EDC[7..0] FBB_W CK67 FBB_EDC[7..0] FBB_WCK67* FBB_W CK67* M10B INS115243542...

  • Page 76: Frame Buffer Partition A_B

    Schematic Diagrams Frame Buffer Partition A_B FRAME BUFFER PARTITION A/B DECOUPLING FBVDDQ FBVDDQ DECOUPLING AROUND FBA MEMORIES (DQ0-DQ31) PLACE Under MEM DECOUPLING AROUND FBA MEMORIES (DQ32-DQ63) PLACE Under MEM SPARE SPARE C666 C663 C665 FBVDDQ FBVDDQ C658 C662 1u x 10 1u x 10 10u x 6 10u x 6...

  • Page 77: Gpu Frame Buffer Partition

    Schematic Diagrams GPU Frame Buffer Partition FBD_DBI[7..0] FBD_CMD[31..0] GPU FRAME BUFFER PARTITION C/D FBD_DBI[7..0] FBD_CMD[31..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_EDC[7..0] U39D FBC_EDC[7..0] U39E P67RP Frame D INS127538168 INS127540031 FBC_CMD[31..0] BGA2152 BGA2152 FBC_CMD[31..0] COMMON COMMON FBVDDQ FBC_D[63..0] 4/23 FBC 5/23 FBD FBC_D[63..0] FBC_D0...

  • Page 78: Frame Buffer Partition C

    Schematic Diagrams Frame Buffer Partition C FRAME BUFFER PARTITION C FBC_CMD[31..0] FBC_CMD[31..0] FBC_WCK01 FBC_W CK01 FBC_D[63..0] FBC_WCK01* FBC_D[63..0] FBC_W CK01* FBC_WCK23 FBC_W CK23 FBC_DBI[7..0] FBC_WCK23* FBC_DBI[7..0] FBC_W CK23* FBC_WCK45 FBC_W CK45 FBC_EDC[7..0] FBC_WCK45* FBC_EDC[7..0] FBC_W CK45* M11D FBC_WCK67 FBC_W CK67 M11B FBC_WCK67* INS115249753...

  • Page 79: Frame Buffer Partition D

    Schematic Diagrams Frame Buffer Partition D P67RP Frame D FRAME BUFFER PARTITION D FBD_CMD[31..0] FBD_CMD[31..0] FBD_WCK01 FBD_W CK01 FBD_D[63..0] FBD_WCK01* FBD_D[63..0] FBD_W CK01* FBD_WCK23 FBD_W CK23 FBD_DBI[7..0] FBD_WCK23* FBD_DBI[7..0] FBD_W CK23* FBD_WCK45 M14D FBD_W CK45 FBD_WCK45* INS115251069 FBDEDC[7..0] FBD_EDC[7..0] FBD_W CK45* BGA170 FBD_WCK67 COMMON...

  • Page 80: Frame Buffer Partition C_D

    Schematic Diagrams Frame Buffer Partition C_D FRAME BUFFER PARTITION C/D DECOUPLING P670RP Frame D FBVDDQ PLACE Under MEM DECOUPLING AROUND FBC MEMORIES (DQ32-DQ63) FBVDDQ PLACE Under MEM DECOUPLING AROUND FBC MEMORIES (DQ0-DQ31) C768 C342 C337 C810 C762 C759 C769 C811 C783 C781 C147...

  • Page 81: Gpu Decoupling1

    Schematic Diagrams GPU Decoupling 1 GPU DECOUPLING1 VGA Support inside NVVDD PLACE Near GPU NVVDD D01A x9 4.7uF 0603 X6S x2 330uF x4 22uF X5R 0805 NVVDD NVVDD NVVDD x11 10uF X6S 0603 x2 47uF X5R 0805 C131 C187 C159 C141 C134 C133...

  • Page 82: Gpu Decoupling2

    Schematic Diagrams GPU Decoupling 2 GPU DECOUPLING FBVDDQ PLACE Under GPU FBVDDQ 1V8_RUN Partition A x2 10uF, x6 1uF 1V8_AON C191 C143 C149 C233 C726 C731 C728 C256 C237 C257 C238 C236 C247 C239 C252 C259 C223 C241 Partition B x2 10uF, x6 1uF C112 C122...

  • Page 83: Straps & Xtal

    Schematic Diagrams Straps & XTAL XTAL U39S DG P.114 Note: PLL power rails INS130841599 trace rounting to GPU BGA ball BGA2152 must be 12~16 mil wide. COMMON 30ohm ESR 10mohm bead GPU_PLLVDD 14/23 XTAL/PLL 40mil HCB1608KF-300T60 GPU_PLLVDD BD12 1V8_RUN SP_PLLVDD Near to GPU 20mil 0_06...

  • Page 84: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface U39V U39U IFP I/O INTERFACE INS133234907 INS133234980 BGA2152 BGA2152 COMMON COMMON U39N 11/23 MIOA 12/23 MIOB INS127648990 BGA2152 MIOAD0 MIOBD0 COMMON MIOAD1 MIOBD1 MIOAD2 MIOBD2 MIOAD3 MIOBD3 7/23 IFPAB MIOAD4 MIOBD4 MIOAD5 MIOBD5 DL-DVI DVI/HDMI MIOAD6 MIOBD6 MIOAD7...

  • Page 85: Misc - Gpio, I2C And Rom

    Schematic Diagrams Misc - GPIO, I2C and ROM U39T INS136854842 DG P.78 recommend ROM_CS Pull up 10K VBIOS ROM 4M VBIOS ROM 8M BGA2152 MISC: GPIO, I2C, and ROM COMMON 1V8_AON 1V8_AON (OPTIMUS) (DGPU) 15/23 MISC 2 1V8_AON VGA_ROM_CS# ROM_CS 1V8_AON VGA_ROM_SI R416...

  • Page 86: Nvidia Power Sequence

    Schematic Diagrams NVIDIA Power Sequence 3.3VS D02A 4/29 reserve timing 1V8_RUN_EN 3.3VS C1121 *0.1u_10V_X7R_04 C340 0.1u_10V_X7R_04 3.3VS NVVDD POWER GOOD LOOPBACK R776 SN74LV1T32DCKR NV3V3 1V8_AON_PW RGD NV_1V8RUN_EN R753 0_04 NV_1V8RUN_EN 1V8_AON_PW RGD 10K_04 1.8V 3.3VS 30,32 GPIO4_1V8_MAIN_EN 3.3V GFX_ON 74AHC1G08GW R103 10K_04 17,30...

  • Page 87: Gpio Level Shift

    Schematic Diagrams GPIO Level Shift NVIDIA GPIO LEVEL SHIFT 3.3VS 3.3VS R744 D02A D02A 100K_04 3.3VS R745 3.3VS Q55A 100K_04 DGPU_PW RGD_R MTDK3S6R C744 0.1u_10V_X7R_04 C286 0.1u_10V_X7R_04 1V8 in 3V3 out 1V8 in 3V3 out Q55B 30,32 GC6_FB_EN MTDK3S6R GC6_FB_EN_R 31,39 VGA_BKLPW M GPIO7_BL_PW M_GPU...

  • Page 88: Gpu Nvvdd, Fbvddq

    Schematic Diagrams GPU NVVDD, FBVDDQ U39F U39G U39H GPU NVVDD, FBVDDQ NVVDD INS127547041 NVVDD INS127550888 NVVDD INS127611495 BGA2152 BGA2152 BGA2152 NVVDD FBVDDQ FBVDDQ COMMON COMMON COMMON 18/21 VDD_1/2 19/23 VDD_2/2 20/23 FBVDDQ AA14 AG22 AP21 BB45 AA10 AT43 FBVDDQ FBVDDQ U39J AA15 AG23...

  • Page 89: Gpu Gnd

    Schematic Diagrams GPU GND U39K U39L U39M INS127621373 INS127622592 INS127623759 BGA2152 BGA2152 BGA2152 COMMON COMMON COMMON 16/23 GND_1/3 17/23 GND_2/3 22/23 GND_3/3 GPU GND AR20 BL43 AR21 AJ14 AR22 BA48 AJ15 AR23 BB49 AJ16 AR24 BC13 AJ17 AR25 BC16 AJ18 AR26 BC19 AA49...

  • Page 90: Pch 1/9

    Schematic Diagrams PCH 1/9 BOOT HALT JTAG ODT ESPI FLASH SHARING MODE MASTER ATTACHED FLASH SHARING:LOW ENABLE:LOW DISABLE:LOW SLAVE ATTACEHD FLASH SHARING:HIGH (INTERNAL WEAK PD) (INTERNAL WEAK PU) (INTERNAL WEAK PD) 3.3VA R592 *4.7K_04 SPI_SI_R SPI_SO_R GPP_H_12 GPP_G_14_GSXDIN: DMI AC COUPLING FULL VOLTAGE MODE 3.3VS WHEN SAMPLED LOW R573...

  • Page 91: Pch 2/9

    Schematic Diagrams PCH 2/9 SPT-H_PCH U52B DMI_MT_IR_0_DN DMI_RXN0 USB_PN1 USB2N_1 DMI_MT_IR_0_DP DMI_RXP0 USB3 PORT1, , C h a r g e r USB2P_1 USB_PP1 DMI_IT_MR_0_DN DMI_TXN0 USB2N_2 DMI_IT_MR_0_DP DMI_TXP0 USB2P_2 DMI_MT_IR_1_DN DMI_RXN1 USB2N_3 DMI_MT_IR_1_DP AG10 DMI_RXP1 USB2P_3 DMI_IT_MR_1_DN DMI_TXN1 USB2N_4 USB_PN4 USB3 PORT4, DMI_IT_MR_1_DP...

  • Page 92: Pch 6/9

    Schematic Diagrams PCH 3/9 BIOS RECOVERY PCH_RSVD SPT-H_PCH ENABLE :LOW U52C BIOS SET GPIO pin 3.3VS 3.3VS NV power on/off timing CL_CLK1 CL_CLK CL_DATA1 PCIE9_RXN/SATA0A_RXN PCIE_RXN9_SATA0A_RXN_SSD CL_DATA CL_RST#1 CLINK PCIE_RXP9_SATA0A_RXP_SSD PCIE9_RXP/SATA0A_RXP SSD_1 CL_RST# R257 R244 PCIE_TXN9_SATA0A_TXN_SSD PCIE9_TXN/SATA0A_TXN PCIE9_TXP/SATA0A_TXP PCIE_TXP9_SATA0A_TXP_SSD 48 GPPG8_PCH_1V8AON_EN GPP_G8/FAN_PWM_0 10K_04...

  • Page 93: Pch 9/9

    Schematic Diagrams PCH 4/9 SPT-H_PCH U52D VDD3 ISH_GP_6_R BB17 HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# AW22 PM_CLKRUN# HDA_RST# PM_CLKRUN# HDA_RST# GPP_A8/CLKRUN# VCCRTC 3.2V HDA_SDIN0 HDA_SDI0 (Skarkbay 3.3V) (1.5K,45.3K) AR15 HDA_SDI1 GPD11/LANPHYPC R263 1.5K_1%_04 R262 45.3K_1%_04 HDA_SDOUT AV13 38,50 HDA_SDOUT HDA_SDO GPD9/SLP_WLAN# HDA_SYNC HDA_SYNC BIOS DDR4_DRAMRST# BC14...
  • Page 94 Schematic Diagrams PCH 5/9 U52E R157 100K_04 SPT-H_PCH FROM DP REDRIVER GPP_I7/DDPC_CTRLCLK 15,32 MDP_F_HPD GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA 3.3VS 16,32 HDMI_HPD GPP_I1/DDPC_HPD1 FROM DP GPP_I5/DDPB_CTRLCLK 14,32 G_DP_DHPD_E GPP_I2/DDPD_HPD2 GPP_I6/DDPB_CTRLDATA GPP_I3/DDPE_HPD3 R164 100K_04 GPP_I9/DDPD_CTRLCLK DGPU_SELECT# R593 10K_04 GPP_I10/DDPD_CTRLDATA GPP_F14 H_SKTOCC_N DGPU_PRSNT# R623 10K_04 GPP_F23 DGPU_PW R_EN 31,44,60,67...
  • Page 95 Schematic Diagrams PCH 6/9 W 76-147_24MHZ C784 24MHZ 12p_50V_NPO_04 fsx3m 6-22-24R00-1B9 6-22-24R00-1BA R495 1M_04 C793 12p_50V_NPO_04 SPT-H_PCH U52G AR17 RTC (10 MOHM RES): DO NOT CHANGE TO 0402 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN CLKOUT_ITPXDP PCH_XDP_CLK_DP CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P C787 CLKOUT_ITPXDP_P CPU_24MHZ_R_DN CLKOUT_CPUNSSC 32.768Khz SOC or PCH 15p_50V_NPO_04 PCH_CPU_PCIBCLK_R_DN CLKOUT_CPUPCIBCLK...
  • Page 96 Schematic Diagrams PCH 7/9 VDD1.0 VDD3 VDD1.0 U52H SPT-H_PCH eSPI:1.8V 2.899A AA23 3.3VA LPC:3.3V VCCPRIM_1P0 AA26 VCCPRIM_1P0 AA28 AL22 3.3VA 0.0908A VCCPRIM_1P0 VCCPRIM_1P0 AC23 C393 VCCPRIM_1P0 AC26 BA24 0.403A 3.3VA VCCPRIM_1P0 VCCDSW_3P3 AC28 0.1u_10V_X7R_04 C414 R216 *0_04 VCCPRIM_1P0 BA31 0.082A 3.3VA AE23 VCCPGPPA...
  • Page 97 Schematic Diagrams PCH 8/9 U52I SPT-H_PCH U52L SPT-H_PCH AC18 AB11 AN10 BE14 AB14 BE18 AE29 AB31 BE23 AB32 BE28 AE42 AB38 BE32 AF18 BE37 AF20 BE40 AF21 AF23 AC20 AF25 AC21 AF26 AC25 AF28 AC29 AF29 AC45 AG11 AG13 AD11 AG31 AD14 AG32...
  • Page 98 Schematic Diagrams PCH 9/9 NO REBOOT STARP ENABLE: HIGH SPT-H_PCH U52J (INTERNAL WEAK PD) 3.3VS AR22 RSVD22 RSVD BD45 R562 RSVD BD44 RSVD BE44 *4.7K_04 RSVD LPSS_GSPI0_MOSI RSVD P65x: 00 P67x: 10 RSVD RSVD RSVD RSVD R239 R628 R239 R628 AN29 RSVD 10K_04...

  • Page 99: Kbc It8587

    Schematic Diagrams KBC IT8587 VDD3 IT8587(Follow IT8991 PIN Define) VGA Chipset RB (PL) RA (PH) P670RS_RP J_KB2 R294 R293 MODEL_ID 85208-24051 R293 10K_04 KBC_AVDD N17E-G1 N17EG2 HCB1005KF-121T20 KB-SI0 N17E-G2 VDD3 VDD3 KB-SI1 R294 10K_04 C956 C625 C976 C963 C962 KB-SI2 N17E-G3 KB-SI3 10u_6.3V_X5R_06...

  • Page 100: Rgb Kb Only

    Schematic Diagrams RGB KB Only RGB KB Only P650RS PJ33 layout trace J_KBLED1 3.3VS KB_5VS 3/31 R654 ,R655 C591 KBZONE1_R R654 *0_06 KB_VDD KBZONE1_B KBZONE1_G KB_5VS LED0 4.7u_25V_X5R_08 KBZONE1_R KBZONE1_B R655 0_06 LED1 3.3VS KBZONE1_G KBZONE2_R LED2 KBZONE2_G C952 KBZONE2_B KBZONE2_B 0.1u_10V_X5R_04 LED3...

  • Page 101: Usb Charger

    Schematic Diagrams USB Charger USB3.0 re-driver 3.3V R327 *0_04 R326 *4.7K_04 R325 *4.7K_04 R324 2K_1%_04 R322 *4.7K_04 I2C_SDA_P1 I2C_SCK_P1 R323 *4.7K_04 SMB_DATA SMB_SCK USB3_TXN1 TXN1 0.1u_10V_X7R_04 C634 C633 0.1u_10V_X7R_04 TX1- RX1- USB3_TXN1 VDD5 VDD5 TXP1 0.1u_10V_X7R_04 C632 C631 0.1u_10V_X7R_04 USB3_TXP1 TX1+ USB3_TXP1 To Conn.

  • Page 102: Wigig/Wlan +Bt

    Schematic Diagrams M.2 WiGig/WLAN + BT J_W LAN1 40 mil GND14 3.3V3 W IGIG_3.3V 4/29 follow common, change net CLK_PCIE_W IGIG# WLAN+BT/WIGIG Reserved/REFCLKN1 3.3V2 R590 *0_04 C895 CLK_PCIE_W IGIG Reserved/REFCLKP1 PEWake1#(IO)(0/3.3V) LAN_W AKEUP# 35,44,47,60 GND13 CLKREQ1#(IO)(0/3.3V) W IGIG_CLKREQ# CAP CLOSE TO M.2 CONN 0.1u_16V_Y5V_04 PCIE_RXN8_W IGIG Reserved/PERn1...

  • Page 103: Pcie4X Ssd

    Schematic Diagrams M.2 PCIE4X SSD 3.3VS NGFF_M (M2) SSD_1 (PCIE 4X) >120 mil 3.3VS J_SSD1 SATAGP0 R687 C1029 C1034 C1038 SATAGP0 GND13 10K_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 10u_6.3V_X5R_06 GND12 3.3V8 L: PCIe GND11 3.3V7 H: SATA PCIE_SATA_0 PEDET(NC-PCIe/GND-SATA) 3.3V6 NC18 SUSCLK(32Khz)(O) 2SK3018S3 M KEY GND10 NC17...

  • Page 104: Lte

    Schematic Diagrams M.2 3G/LTE 3G /LTE CARD USB3.0 Only P670RS 3G CURRENT2A ,DON'T DROP BELOW 3.135V 3G_3.3V 80 mils D02A GJ_3G1 GC14 220u_6.3V_6.3*6.3*4.2 GC12 0.1u_16V_Y5V_04 CONFIG_2 3.3V4 GND10 3.3V3 4/8 follow common del GC13 0.1u_16V_Y5V_04 GND9 3.3V2 CONFIG_1 SUSCLK(32Khz)(O) *0_04 3G_RST# Reset#(O)1.8V SIM Detect(O)

  • Page 105: Realtek Alc898

    Schematic Diagrams Realtek ALC898 C1026 0.1u_16V_Y5V_04 Layout Note: C596 0.1u_16V_Y5V_04 BOM Note: C565 0.1u_16V_Y5V_04 U43 pin 1 ~ pin 11 and pin 47 and pin 48 are Digital signals. C555 0.1u_16V_Y5V_04 1. P650RS,P670RS= ALC898+ESS The others are Analog signals. C590 0.1u_16V_Y5V_04 2.

  • Page 106: Tpa2008D2

    Schematic Diagrams TPA2008D2 AMP_5VS TPA2008D2 HCB1608KF-121T30 The volume control.the gain range is from -80db(Vvolume=5V) to +20db(Vvolume=0V) with P2P BA20550 64 steps precise control. C994 C996 C1006 (TSSOP24) 0.1u_10V_X7R_04 0.1u_10V_X7R_04 22u_6.3V_X5R_08 AUDG AUDG AUDG AMP_EN ROUTP FCM1005KF-121T03 ROUT+ SHUTDOWN ROUTP C992 2.2u_6.3V_X5R_04 20 Mil J_SPK1...

  • Page 107: Subwoofer

    Schematic Diagrams Subwoofer P670Sx ONLY SR15 2.2_04 SC15 2200p_50V_X7R_04 Subwoofer Subwoofer SAMP_PW R SAMP_PW R SEMC2 SC12 SC11 SC26 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *1000p_50V_X7R_04 SR13 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 Subwoofer Subwoofer Subwoofer Subwoofer Subwoofer 2.2uH_4*4*2.0 SAMPPW R_SW 10K_04 Subwoofer Subwoofer Subwoofer Subwoofer FMS3004-AS-H AUDG_2 AUDG_2...

  • Page 108: Ar_Tbt

    Schematic Diagrams AR_TBT XTAL NOTE: SNK0_DDC_data/clk ?connect to 2k PU only if SRC0 is connected and support HDMI (a.i HDMI or DP++ connector). Otherwise can be 100k PD. TBT_XTAL_25_IN SNK1_DDC_data ?connect to 100k PD. If SRC0 support HDMI, connect as SNK0_CFG1 to GPU and/or appropriate AUX/DDC demux control SNK1_DDC_clk ?connect to 100k PD.

  • Page 109: Ar_Power

    Schematic Diagrams AR_Power VCC0V9_DP VCC3V3_LC VCC3V3_SX_SYS VCC3V3_S0_SYS VCC3V3_S0 C428 C870 C862 C859 C861 C860 C435 1u_6.3V_X5R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 10u_6.3V_X5R_06 10u_6.3V_X5R_06 10u_6.3V_X5R_06 VCC0V9_DP VCC0P9_DP VCC3P3_SVR VCC0P9_DP VCC3P3_SVR VCC0P9_DP VCC3P3_SVR C448 C444 C445 C443 C446 C447 C440 VCC0P9_DP VCC0P9_DP VCC0V9_SVR 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04...

  • Page 110: Tps65982

    Schematic Diagrams TPS65982 TBTA_VBUS VCC5V0_SYS 80Ohm, 0.01Ohm DCR, 8A Idc HCB2012KF-800T80 C370 C369 C387 C386 C388 22u_6.3V_X5R_08 TBTA_LDO_BMC 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 VCC1V8D_TBTA_LDO 1u_25V_X5R_06 VCC1V8A_TBTA_LDO 2/4 Tim C882 C872 C884 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 close to pin,1/14 C402 0.1u_10V_X7R_04 VCC3V3_SX_SYS NOTE: C396 PAY ATTENTION SYMBOL 10u_6.3V_X5R_06 D02A...
  • Page 111 Schematic Diagrams TPS65982-1 TBTB_VBUS VCC5V0_SYS 80Ohm, 0.01Ohm DCR, 8A Idc HCB2012KF-800T80 C1068 C1069 C1070 C1071 C1073 22u_6.3V_X5R_08 TBTB_LDO_BMC 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 VCC1V8D_TBTB_LDO 1u_25V_X5R_06 VCC1V8A_TBTB_LDO 2/4 Tim C1065 C1066 C1067 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 close to pin,1/14 C1076 0.1u_10V_X7R_04 VCC3V3_SX_SYS VCC3V3_SX_SYS NOTE: C1077 PAY ATTENTION SYMBOL Q58A...

  • Page 112: Ar_Conn Type A/C

    Schematic Diagrams AR_Conn Type A/C AR_TYPE_C, MB , Port A TBTA_CA2HD_1_P TBTA_VBUS TBTA_CA2HD_1_P TBTA_CA2HD_1_N TBTA_CA2HD_1_N 150 mil TBTA_HD2CA_0_N CSOD140SH TBTA_HD2CA_0_N TBTA_HD2CA_0_P TBTA_HD2CA_0_P J_TYPEC1 UCF3T-21S01-0P11 TBTA_HD2CA_0_P TBTA_CA2HD_0_P TX0_P RX0_P TBTA_HD2CA_0_N TBTA_CA2HD_0_N TX0_N RX0_N C851 1u_25V_X5R_06 C864 1u_25V_X5R_06 VBUS VBUS TBTA_CC1_J TBTA_SBU2_J SBU2 TBTA_USB2_TP_J TBTA_USB2_BN_J...

  • Page 113: Tpm, Ccd, Tp

    Schematic Diagrams TPM, CCD, TP TPM_PW R FOR TP SLB9665TT(SLB9660 )& NPCT650 COLAY TP_VCC R707 GPIO 100K_04 TP_VCC H: W / TPM ( R707 ) R333 R332 C648 L: W/O TPM ( R704 ) TPM_PW R R335 0_04 3.3VS TPM_DET 10K_04 10K_04 *10u_6.3V_X5R_06...

  • Page 114: Fan, Lid, Kb Led

    Schematic Diagrams Fan, LID, KB LED VGA FAN CONTROL-Selector CPU FAN CONTROL LID SWITCH IC FON1# VDD3 VOUT C326 C325 100K_04 VSET 1u_6.3V_X5R_04 *4.7u_6.3V_X5R_06 NCT3940S-A C513 0.1u_16V_Y5V_04 CPU_FAN CPU_FAN LID_SW # 13,44 D01A 5VS_CPU_FAN J_FAN1 AH9249NTR-G1 VGA_FAN2SEN 0.1u_16V_Y5V_04 *100p_50V_NPO_04 VGA_FAN1SEN *V15AVLC0402 C741 VGA_FANSEN...

  • Page 115: Connector

    Schematic Diagrams Connector 3.3VS LED BOARD LAN BOARD J_LAN1 USB_PN4 C936 USB_PP4 J_LED1 C500 C518 ( USB3.0x2, PHONE JACK) LED_ACIN *0.01u_16V_X7R_04 USB3_TXN4 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 LED_PW R USB3_TXP4 LED_BAT_CHG USB3_RXN4 LED_BAT_FULL USB3_RXP4 LED_NUM# LED_CAP# 3.3VS 3.3V VDD3 R247 0_04 LED_SCROLL# PS8331_SW 3,13,30,39 AIRPLAN_LED# C567...

  • Page 116: Ddr 1.2V/0.6Vs

    Schematic Diagrams DDR 1.2V / 0.6VS DDR4: 1.2V/0.6VS PD24 PQ68 MDU1516 PC393 PC389 DDR4 UP6163 ULTRASO-8 100u_25v_SMD PU23 6-02-05616-CQ0 2ND RB0540S2 UP6163 VDDQ_R VTT_MEM(0.6V) 1.2V PC368 PC371 0.1u_10V_X7R_04 VLDOIN VBST DEFAULT SHORT 10u_6.3V_X5R_06 EMR13 VDDQ_R VTT_MEM DRVH DEFAULT SHORT PL21 0_06 PJ56 BCIHP0730-1R0M...

  • Page 117: Vdd3,Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR293 *0_04 PR297 0_04 PC249 1u_10V_Y5V_06 PR291 PR308 4/7 power change value EN_3V EN_5V PC126 130K_1%_04 80.6K_1%_04 PC135 2/19 power change 1000p_50V_X7R_04 1000p_50V_X7R_04 100u_25v_SMD PU15 3/1 power Add VREG3 PC289 PC290 D01A PC412 PC241 PC246 PC245 PC247 100u_25v_SMD...

  • Page 118: 5Vs,3.3V,3.3Vs,3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA VIN1 VIN1 DD_ON R339 10K_04 R344 100K_04 VIN1 R343 1_1%_06 R342 *100K_04 USB_CHARGE_EN 44,46,62 DD_ON_LATCH C654 C651 C650 R346 10K_04 R350 10K_04 M_BTN# M_BTN# PWR_SW# VDD3 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 R349 *100K_04 R347 1K_1%_04 INSTANT-ON PW R_SW # USB_CHARGE_EN...

  • Page 119: Power 1.0V,Vccio

    Schematic Diagrams Power 1.0V, VCCIO For CV test VDD1.0 PR285 100K_04 PR132 820K_1%_06 VDD3 PJ34 *CV-40mil PC112 15u_25V_SMD-B2 PC115 PC113 VDD1.0_EN 6-11-15612-8B0 PC114 VDD3_5_POK 6-11-15612-8B1 PJ37 *1mm PC229 PR133 PC116 0_06 0.1u_10V_X7R_04 *0.01u_16V_X7R_04 EN_PSV 38,44,62,63 EC_SLP_SUS# VTT_SELECT VTT VR Output Voltages PJ36 VDD1.0 G5602_5V...

  • Page 120: Ac_In, Charger

    Schematic Diagrams AC_In, Charger PC182 SMART CHARGER V_BAT PR223 PQ57 EMB20P03V PQ19 PC190 20K_04 D01A 3/2 change PC191 EMB20P03V 3/2 change EML1 2/19 power change HCB2012KF-800T80 3/3 del dc-jack EML3 PQ56 HCB2012KF-800T80 EMB20P03V 4/1 power modify 0.02_1% PQ18 PRS7 4/25 power modify PD25 PRS2 EML2 EMB20P03V...

  • Page 121: Dx_Vccstg/Vccsfr_Oc/2.5V

    Schematic Diagrams 1.0DX_VCCSTG/VCCSFR_OC/2.5V NOTE: 1.0DX_VCCSTG TURN-ON need <65us DEFAULT SHORT VCCSFR_OC DEFAULT SHORT 1.0DX_VCCSTG M5938 TURN-ON TIME=60us 1.0DX_VCCSTG VCCSFR_OC VDD1.0 VDDQ PJ15 PJ22 VOUT VOUT C398 C380 C412 C610 C609 C597 VOUT VOUT R291 VOUT VOUT VDD3 R548 VDD3 VOUT VOUT *100_04 *100_04...

  • Page 122: V8_Run/Aon, Nv3V3

    Schematic Diagrams 1V8_RUN/AON, NV3V3 1V8_AON PC211 PC215 4/7 power change value PR266 PR280 22u_6.3V_X5R_08 10_06 0.1u_10V_X7R_04 10K_1%_04 PU12 3Amps @ 1.8V EM5841BVT PR107 10K_04 DFN10 3.3V PR282 0.200 COMMON PR283 *160K_04 D01A *0.003_12 1V8_AON_PW RGD PGOOD 1V8_AON Default OpenVReg PR278 *0_04 DGPU_PW R_EN_R PC222 *0.01u_16V_X7R_04...

  • Page 123: Nvvdd Phase 1 & 2

    Schematic Diagrams NVVDD Phase 1 & 2 PW R_SRC_NV_FB PW R_SRC_NV 0.400 PRS3 4/20 NV/power change PR90 PW R_SRC_NV_VINN_R PW R_SRC_NV_VINP_R RL1632T4F-B-R005-FNH COMMON PR91 10K_1%_04 1V8_AON 1206 PR90 0_04 30,70 GPIO6_NVVDD_PSI# 6-13-R0051-15C PW R_SRC_NV PR79 *10K_1%_04 layout 1pcs B2 2PCS 0805 size *CV-40mil PR96 100K_04...

  • Page 124: Nvvdd Phase 3~4

    Schematic Diagrams NVVDD Phase 3~4 PW R_SRC_NV layout 1pcs B2 2PCS 0805 size PR46 PC205 PC204 2.2_06 GPU DECOUPLING NVVDD N17EG2 1u_25V_X7R_06 1u_25V_X7R_06 N17EG2 N17EG2 MDL914S2 120A 6/8 ME PC61 NVVDD PC58 N17EG2 D02A 2.2u_16V_X5R_06 N17EG2 0.1u_25V_X7R_06 RESERVE N17EG2 PH3_UPI_9509 PC23 2/11 Stanley PR27...

  • Page 125: Nvvdds

    Schematic Diagrams NVVDDS NVVDDS PHASE NVVDDS FOR N17_VGA PJ48 *CV-40mil 1V8_AON PR353 100K_04 VDD3 4/25 modify timing close change to open PJ47 *CV-40mil NVVDDS ENABLE PR339 Default 2/25 power check PR354 4.7K_04 1V8_AON *0_04 D01A PR161 0_04 1666_DGPU_ON PR358 10K_04 NV_NVVDDS_EN PW R_SRC_NVVDDS PW R_SRC_NV_FB...

  • Page 126: Pex_Vdd

    Schematic Diagrams PEX_VDD Open VREG Type 0 PEX_VDD 2.6Amps @ 1.0V PC201 PC200 PR25 4/7 power change value = EM5841BVT PR16 22u_6.3V_X5R_08 10_06 0.1u_10V_X7R_04 10K_1%_04 EM5841BVT DFN10 PR19 10K_04 0.200 COMMON PR18 *160K_04 D01A 3.3V PGOOD PEX_VDD PEX_VDD_PWRGD OpenVReg PEXVDD_EN PC52 *0.01u_16V_X7R_04 EN/FS 4.5A...

  • Page 127: Fbvddq

    Schematic Diagrams FBVDDQ PAGE72: 1V8_AON PJ51 *CV-40mil FBVDDQ FOR N17_VGA FBVDDQ, and MXM Mounting Holes PR411 100K_04 VDD3 PR430 *0_04 3/16 del PR403 (power check) NV_FBVDDQ_EN PR431 *0_04 PR390 20K_1%_04 NV_FBVDDQ_EN Default FB_ON PR435 PC326 4/25 modify timing 10k change to 20k , *1500p change to 0.1u FBVDDQ RC, delay FBVDDQ_EN *10K_04 0.1u_10V_X7R_04...

  • Page 128: Vcc_Core & Vccsa

    Schematic Diagrams VCC_Core & VCCSA VCORE_PROG ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS CONFIGURATION 3.3VS 1.0V_VCCST PR342 PR349 PR158 1K_1%_04 13K_1%_04 4/13 footprint PR422 PR362 PR409 2.2_06 D02A PR387 PR366 PR380 PC293 100K_04 *1K_1%_04 100K_04 1u_6.3V_X5R_04 PC283 PC138 0.01u_50V_X7R_04 4.7u_6.3V_X5R_06 *CV-40mil...

  • Page 129: Vcore Output Stage

    Schematic Diagrams VCore Output Stage DEFAULT SHORT VCCVIN VCORE & VCCSA OUTPUT STAGE PJ19 PC265 PC148 PC144 PC165 PC263 PR188 *0.003_12 PR317 PC274 2.2_06 PR318 2.2_06 0.22u_16V_X7R_06 PU16 NCP81151MNTBG PR352 1_1%_06 INS118403478 INS118404489 MLP08 MLP08 PR351 10K_06 6-19-41001-043 PW M11 COMMON COMMON PL18...

  • Page 130: Vccgt

    Schematic Diagrams VCCGT ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS 3.3VS 1.0V_VCCST PR213 PR480 1K_1%_04 PR470 PR204 PR461 2.2_06 PR474 PR492 PR481 PC375 100K_04 *1K_1%_04 100K_04 1u_6.3V_X5R_04 PC374 PC169 *CV-40mil *100_04 *45.3_1%_04 *45.3_1%_04 PUT CLOSE VCCGT_PROG 0.01u_50V_X7R_04 PC167 PC369 4.7u_6.3V_X5R_06 PU10...

  • Page 131: Vccgt Output Stage

    Schematic Diagrams VCCGT Output Stage PR222 *0.003_12 DEFAULT SHORT VGTVIN PJ23 PC173 PC171 PC383 PR498 PC378 PR469 2.2_06 0.22u_16V_X7R_06 2.2_06 PU24 NCP81151MNTBG PR508 INS136512057 1_1%_06 MLP08 COMMON PL22 6-19-41001-043 PR507 CMME063T-R15MS0R907 PWM12 10K_1%_04 2/22 power change value to 330u ( 470u) VCCGT PCB Footprint = BCIHP0735A...

  • Page 132: Audio Board P65_Ess_A 1/3

    Schematic Diagrams Audio Board P65_ESS_A 1/3 ESS DAC (ES9018-2M) 3/2 change 3.3V SUPPLY 3.3V DAC SUPPLY 3.3V DAC SUPPLY A_5V A_ESS_VCCA A_5V A_ESS_AVCC_L A_5V A_ESS_AVCC_R D01A AU11 VOUT VOUT ES9018K2M Pin15 VOUT ES9018K2M Pin16 HCB1005KF-121T20 A_3.3V A_ESS_DVCC ES9016K2M Pin16 Thermal Pad Thermal Pad Thermal Pad AC51...
  • Page 133 Schematic Diagrams Audio Board P65_ESS_A 2/3 5/26 AR15, AR32, AR38, AR8 Change to 825_1%_04 for SNR= -122dB Amplifier (LM49720+OPA1622) AC16 2200p_50V_NPO_06 D02B BCN AR15 806_0.1%_04 AAUDG AC26 2200p_50V_NPO_06 D02B AR32 806_0.1%_04 1/30 ESS WeiKeng check AR140 100_06 A_A-15V A_-15V D02B BCN AR27 AC23 A_+15V...
  • Page 134 Schematic Diagrams Audio Board P65_ESS_A 3/3 5/16 Follow 6-24-30003-009 D02B AGND AVLC5S02100 3/21 ADD ESS board AHP_DET 3/18 Add (follow P870DM2) AAL898_GPIO33 BAT54CS3 AJ_SPDIF1 A_5V A_3.3V 0_04 FCM1005KF-121T03 AHP-LC AHEADPHONE-LC AJ_AUDIO1 0_04 FCM1005KF-121T03 AHP-RC AHEADPHONE-RC AHP_SENSE A_5VS A_AUDG A_5VS D02B DRIVE 4/28 ESS bo sound...

  • Page 135: Audio Board P67_3Damp_E

    Schematic Diagrams Audio Board P67_3DAMP_E 3D HeadPhone AMP D02A E3D_HP_L E_5V Del 615 co-lay E3D_HP_L ER16 54.9_1%_04 EHEADPHONE-LC EC11 EC23 EC28 EC25 E3D_HP_R ER13 54.9_1%_04 EHEADPHONE-RC EHP_JSGND 0.01u_16V_X7R_04 E_HP_L E_HP_INL EHEADPHONE-L ER18 470_04 0.01u_16V_X7R_04 C2_3DL EC20 E_AUDG VREF C1_3DL 1u_16V_X7R_06 15_1%_04 EHP_JSGND REXT...

  • Page 136: P650Rs Power Board

    Schematic Diagrams P650RS Power Board B3.3VS BJ_BTN1 B3.3VS BM_BTN# FP226H-004S10M 20mil PCB Footprint = fp226h-004xxxm_r 220_1%_04 BGND 20mil B_SW1 20mil Sheet 81 of 91 POWER BUTTON *0.1u_16V_Y5V_04 B_SW1 P650RS Power TJE-532-Q-T/R P670RG-M BGND BM_BTN# POWER SWITCH LED Board PCB Footprint = tje-53x-q NON-Medion BGND 0.1u_50V_Y5V_06...

  • Page 137: P650Rs Hdd Board

    Schematic Diagrams P650RS HDD Board HJ_MB1 SATA PORT1 HGND HGND HSATA_TXP1 HJ_SATA1 HSATA_TXN1 H_SATA_TXP1 H_SATA_TXN1 HSATA_RXN1 H_SATA_RXN1 H_5V HSATA_RXP1 H_SATA_RXP1 H_5VS H_3.3VS HP670RG-M_TPLED H_3.3VS HC14 HC11 51049-03041-001 *0.01u_16V_X7R_04 *10u_6.3V_X5R_06 P/N = 6-21-C2420-215 PCB Footprint = 50008-0304X-A H_5VS HGND HGND HDD D02A 3/28 footprint, HC10...

  • Page 138: P650Rs Led Board

    Schematic Diagrams P650RS LED Board D01A LJ_LED1 3/3 follow P670RP D01A 3/3 follow P670RP LLED_ACIN D02A D02A LLED_PWR LLED_BAT_CHG LD10 LLED_BAT_FULL LLED_ACIN 680_04 LLED_BAT_CHG 680_04 LLED_NUM# Oragne Oragne LLED_CAP# LLED_SCROLL# L_WLAN_AIRPLANE# LLED_PWR LLED_BAT_FULL 330_04 330_04 L_dGPU_LED Green Green LSATA_LED# RY-SP195UHYUYG4 RY-SP195UHYUYG4 LED_GND AC IN/POWER ON LED...

  • Page 139: P650Rs Fp Board

    Schematic Diagrams P650RS FP Board NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND MODE FUSB_PP F3.3V AVDD FUSB_PN F2.5V F2.5V DVDD FMOSI F3.3V F3.3V VDDIO UVDD FMCLK FLED1 FLED1 FMCS FMCS FLED2 LED1 SPI_CS FMISO FDISCON FMOSI FMISO SPI_MOSI...

  • Page 140: P650Rs Click Board

    Schematic Diagrams P650RS Click Board T_TP_VCC T3.3V W/O FP TJ_CLICK TJ_TP1 T_TP_BTN_L T_TP_CLK T_TP_DATA TO BOTTOM/B FCM1005KF-121T03 T_TP_BTN_R T_TP_BTN_L TO T/P T_TP_BTN_R FP226H-004S10M 8 PIN T_TP_SMB_CLK JXT_FP226H-004XXAM TGND M:6-20-94A40-004 T_TP_VCC T_TP_SMB_DAT TJ_FP1 S:6-20-94A60-004 TJ_MB FP225H-008S11M TUSB_PN10 27.4_1%_04 fp225h-008gxxxm_r TGND H3_7B7_0D3_7 H3_7B7_0D3_7 TUSB_PP10 T_TP_DATA...

  • Page 141: P650Rs Usb Board 1/3

    Schematic Diagrams P650RS USB Board 1/3 LAN (RTL8411B) Switching Regulator close to PIN48 2 IN 1 SOCKET Standard PUSH PUSH CARD READER KVDD10 (>20mil) KJ_CARD1 KRSET KR30 2.49K_1%_04 KREGOUT KR33 0_06 KVDD10 KGND (>20mil) KSD_D2/MS_CLK_R SD_DATA2 KR31 *1K_04 KSD_D3/MS_D3_R KXTAL2 KGND SD_DATA3 KR24...
  • Page 142 Schematic Diagrams P650RS USB Board 2/3 USB3.0 re-driver USB3.0 PORT4 K3.3V KR18 *0_04 KR16 *4.7K_04 KUSBVCC3.0_6 KR14 *4.7K_04 100 MIL KR12 2K_1%_04 VOUT KC50 KC34 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 KGND KGND KGND From PCH uP7549UMA5-20 K_SDA_P4 K_SCK_P4 KR20 *4.7K_04 KR10 *4.7K_04 KGND KGND KGND PCB Footprint = M-SOT23-5...
  • Page 143 Schematic Diagrams P650RS USB Board 3/3 LAN BOARD KVDD3 ( USB3.0x2, PHONE JACK, SIM) KJ_MB1 0.1u_16V_Y5V_04 KUSB_PN4 KUSB_PP4 KUSB3_TXN4 2.2u_6.3V_X5R_04 0.1u_16V_Y5V_04 KGND KUSB3_TXP4 87 KUSB3_RXN4 KUSB3_RXP4 KGND KGND K3.3V K3.3VS 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 KCLK_PCIE_GLAN# Sheet 88 of 91 KVDD3 KCLK_PCIE_GLAN KGND KGND KPCIE_TXN5_GLAN P650RS USB Board...

  • Page 144: P670Rs Led Board

    Schematic Diagrams P670RS LED Board YLED_ACIN YD1_1 330_04 Oragne YJ_MB YLED_ACIN 2016/7/22 YLED_PWR YLED_PWR YD1_3 330_04 YLED_BAT_CHG D02A Green YLED_BAT_FULL RY-SP195UHYUYG4 YLED_NUM# YLED_PWR trace AC IN/POWER ON LED YLED_CAP# YLED_SCROLL# Y_GND Y_WLAN_AIRPLANE# Y_dGPU_LED YSATA_LED# Y_GND YLED_BAT_CHG YD8_1 330_04 Y_3.3VS Oragne FP225H-012S10M PCB Footprint = fp225-012g YLED_BAT_FULL...

  • Page 145: P670Rs Usb Board 1/2

    Schematic Diagrams P670RS USB Board 1/2 LAN (RTL8411B) Switching Regulator close to PIN48 2 IN 1 SOCKET Crystal 5032 SIZE ZVDD10 ZRSET ZR26 2.49K_1%_04 (>20mil) (>20mil) Standard PUSH PUSH CARD READER meet realtek Freq tolerance 50ppm ZGND ZR24 *1K_04 ZREGOUT 0_06 ZVDD10 ZJ_CARD1...
  • Page 146 Schematic Diagrams P670RS USB Board 2/2 USB3.0 re-driver USB3.0 PORT4 Z3.3V ZR30 *0_04 ZR35 *4.7K_04 ZUSBVCC3.0_6 ZR38 *4.7K_04 100 MIL ZR40 2K_1%_04 VOUT ZC15 ZC13 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 ZGND ZGND ZGND uP7549UMA5-20 Z_SDA_P4 Z_SCK_P4 ZR21 *4.7K_04 ZR41 *4.7K_04 *0402_short PCB Footprint = M-SOT23-5 ZGND ZGND ZGND...

  • Page 147: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 148: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.

This manual is also suitable for:

P650hs-gP651hsP651hs-g

Table of Contents

Save PDF
