  • Page 1 P670RE...
  • Page 3 Preface Notebook Computer P670RE Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P670RE se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 MB ....................A-5 HDD ....................A-6 Overview ..................1-1 LCD ....................A-7 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &...
  • Page 12 P650RE USB Board 2/3 ...............B-73 USB3.0 ..................B-42 P650RE USB Board 3/3 ...............B-74 USB Charger ................B-43 P670RE USB Board 1/3 ...............B-75 M.2 3G + M.2 SATA ..............B-44 P670RE USB Board 2/3 ...............B-76 M.2 WLAN+BT, PCIE4X SSD ........... B-45 P670RE USB Board 3/3 ...............B-77...

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P670RE series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Security i7-6820HK (2.70GHz) Security (Kensington® Type) Lock Slot  8MB Smart Cache, 14nm, DDR4-2133MHz, TDP 45W BIOS Password Support Intel® XTU over-clocking technology on i7-6820HK Intel PTT for Systems Without TPM Hardware Latest Specification Information (Factory Option) TPM 2.0 i7-6700HQ (2.60GHz) The specifications listed in this section are (Factory Option) Fingerprint Reader Module...
  • Page 15 Introduction Pointing Device Interface Power Built-in Touchpad (scrolling key functionality integrated) Four USB 3.0 Ports (Including one AC/DC Powered USB Embedded 4-Cell Polymer Battery Pack, 60WH port) Full Range AC/DC Adapter Keyboard One HDMI-Out Port AC Input: 100 - 240V, 50 - 60Hz Two Mini DisplayPorts (1.2) Full-size Winkey Illuminated White-LED Keyboard (with DC Output: 19.5V, 9.23A (180W)

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Array Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View RIGHT SIDE VIEW 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. USB 3.0 Ports 5. Multi-in-1 Card Reader 6.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent 2. HDMI-Out Port 3. Powered USB 3.0 LEFT SIDE VIEW Port 4. Mini DisplayPorts Figure 5 REAR VIEW Rear View 1. Vent 2. DC-In Jack 3.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Sub Woofer  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Memory Slots DDR4 SO-DIMM 2. KBC-ITE IT8587 3. CMOS Battery 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (WLAN Module) 2. Mini-Card Connector (M.2 3G/SATA Module) 3. Mini-Card Connector (M.2 PCIE/SATA SSD Module) 4. GPU-GTX970M 5. Memory Slots DDR4 SO-DIMM 6. CPU Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. Powered USB Port 3.0 Connector 3. Mini Display Port 4. USB Port 3.0 Connector 5. DC-In Jack 6. Keyboard Cable Connector 7. TP Connector 8. Speaker Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Multi-in-1 Card Reader 2. Battery Connector 3. Fan Connector 4. LCD Cable Connector 5. CCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P670RE series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: 1. Remove the keyboard page 2 - 5 To remove the Battery: 1.

  • Page 29: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove screws from the 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- bottom of the computer cial eject stick...

  • Page 30: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove the SD card cover and screws (Figure 2a). a. Remove the SD cover 3. Carefully lift the bottom case up in the direction of the arrow and remove it (Figure 2b and screws.
  • Page 31 Disassembly 5. Carefully disconnect the cable , then remove screws (Figure 3d Figure 3 6. Lift the battery off the computer (Figure 3e Battery Removal 7. Reinsert the bottom case starting from point as shown (Figure 3f) to avoid damaging the rear eSATA/USB 3.0 (cont’d.) port.

  • Page 32: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 33 Disassembly 4. Carefully pull the hard disk assembly in the direction of arrow (Figure 5c Figure 5 5. Lift the hard disk assembly out of the bay (Figure 5d HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 5e Removal (cont’d.) 7.

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM-1 Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR4 2133 MHz. The main memory can be expanded up to 64GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 35 Disassembly 4. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 8c). The RAM module will pop-up Figure 8d , and you can then remove it RAM-1 Module 5.
  • Page 36 Disassembly Memory-2 Upgrade Process Figure 8 RAM-2 Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The RAM-2 modules will be visible at point on the mainboard (Figure 8a 3. Gently pull the two release latches ( &...

  • Page 37: Removing And Installing The The M.2 Ssd Module

    Disassembly Removing and Installing the the M.2 SSD Module Figure 9 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The SSD module will be visible at point on the mainboard (Figure 9a).
  • Page 38 Disassembly M.2 SSD-2 Removal Procedure Figure 10 M.2 SSD-2 Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the module, it is visible at point Figure 10a 3. Remove the screw from the module Figure 10b a.
  • Page 39 Disassembly M.2 SSD-2 Installation Procedure Figure 11 1. Place the thermal pad on the module as shown (Figure 11a). M.2 SSD-2 Module 2. Insert the module in the computer Figure 11b Installation 3. Tighten the screw to secure it in place (Figure 11c).
  • Page 40 Disassembly 4. Press down the mylar and thermal pad into place at point as shown (Figure 12d). Figure 12 5. Make sure that the mylar is secure in place and the thermal pad is in place along the contour (no glue is M.2 SSD-2 Module required).

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 13a).

  • Page 42: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 43: Removing The 3G / M.2 Sata Module

    Disassembly Removing the 3G / M.2 SATA Module Figure 14 3G Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 14a b.
  • Page 44 Disassembly M.2 SATA Removal Procedure Figure 15 M.2 SATA Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the module, it is visible at point Figure 15a 3. Remove the screw from the module Figure 15b a.

  • Page 45: Part Lists

    Appendix A:Part Lists This appendix breaks down the P670RE series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 A - 2...

  • Page 47: Top

    Figure A - 1 Top A - 3...

  • Page 48: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...
  • Page 49 Figure A - 3 MB A - 5...

  • Page 50: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 51: Lcd

    Figure A - 5 LCD A - 7...
  • Page 52 A - 8...

  • Page 53: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P670RE notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 54: System Block Diagram

    Schematic Diagrams System Block Diagram 1.35V(VDDQ),1.5VS P650RE Skylake System Block Diagram P650 AUDIO BOARD SHEET 52 6-71-P65R8-D02 SHEET 65 VDD3,VDD5 P650 POWER SW BOARD SHEET 53 6-7P-P65RC-004 6-71-P65RC-D01 SHEET 66 5V,3.3V,5VS,3VS, 6-71-P65R0-D03 <=4.5" PCIE*16 SHEET 54 P650 HDD BOARD 6-71-P65RN-D01 SHEET 67 DDR4/1.2V/1866, 2133MHz 27 MHz...

  • Page 55: Processor 1/7

    Schematic Diagrams Processor 1/7 U113C SKYLAKE_HALO BGA1440 PEG_TX_0 C784 0.22u_10V_X5R_04 PEG_RX0 PEG_RXP[0] PEG_TXP[0] PEG_TX0 18 PEG_TX#_0 C782 0.22u_10V_X5R_04 PEG_RX#0 PEG_RXN[0] PEG_TXN[0] PEG_TX#0 18 PEG_TX_1 C788 0.22u_10V_X5R_04 PEG_RX1 PEG_RXP[1] PEG_TXP[1] PEG_TX1 18 PEG_TX#_1 C785 0.22u_10V_X5R_04 PEG_RX#1 PEG_RXN[1] PEG_TXN[1] PEG_TX#1 18 PEG_TX_2 C779 0.22u_10V_X5R_04 PEG_RX2...

  • Page 56: Processor 2/7

    Schematic Diagrams Processor 2/7 SKYLAKE_HALO U113D BGA1440 IEDP_TXP_0 DDI1_TXP[0] EDP_TXP[0] IEDP_TXN_0 DDI1_TXN[0] EDP_TXN[0] IEDP_TXP_1 DDI1_TXP[1] EDP_TXP[1] IEDP_TXN_1 DDI1_TXN[1] EDP_TXN[1] IEDP_TXN_2 DDI1_TXP[2] EDP_TXN[2] IEDP_TXP_2 DDI1_TXN[2] EDP_TXP[2] IEDP_TXN_3 DDI1_TXP[3] EDP_TXN[3] IEDP_TXP_3 DDI1_TXN[3] EDP_TXP[3] IEDP_AUXP DDI1_AUXP EDP_AUXP IEDP_AUXN DDI1_AUXN EDP_AUXN DDI2_TXP[0] DDI2_TXN[0] EDP_DISP_UTIL VCCIO DDI2_TXP[1] EDP_DISP_UTIL...

  • Page 57: Processor 3/7

    Schematic Diagrams Processor 3/7 M_A_DQ[63:0] 9,10 SKYLAKE_HALO U113B 11,12 M_B_DQ[63:0] SKYLAKE_HALO BGA1440 U113A M_B_DQ0 BT11 BGA1440 DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_B_CLK_DDR0 M_B_DQ1 BR11 M_A_DQ0 M_B_CLK_DDR#0 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] DDR0_DQ[0] DDR0_CKP[0] M_A_CLK_DDR0 M_B_DQ2 M_A_DQ1 DDR1_DQ[2]/DDR0_DQ[18] DDR1_CKN[1] M_B_CLK_DDR#1 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR#0 M_B_DQ3 M_A_DQ2 DDR1_DQ[3]/DDR0_DQ[19] DDR1_CKP[1] M_B_CLK_DDR1 M_B_DQ4 DDR0_DQ[2]...

  • Page 58: Processor 4/7

    Schematic Diagrams Processor 4/7 NEAR CPU CFG[0]: Stall reset sequence after PCU PLL lock until de-asserted: — 1 = (Default) Normal Operation; 1.0V_VCCST No stall. VCCIO — 0 = Stall. R781 CFG[1]: Reserved configuration lane. SKYLAKE_HALO U113E CFG9 *1K_04 CFG[2]: PCI Express* Static x16 Lane BGA1440 Numbering Reversal.

  • Page 59: Processor 5/7

    Schematic Diagrams Processor 5/7 VCORE VCORE +VCCEDRAM PLACE CAPS AT BOARD EDGE VCORE CPU_TOP_VCCCORE SKYLAKE_HALO U113G C545 C544 SKYLAKE_HALO U113J BGA1440 BGA1440 AA13 C466 C960 C465 C460 AA31 BJ17 VCCOPC C426 C383 AA32 BJ19 VCCOPC AA33 BJ20 VCCOPC AA34 BK17 VCCOPC AA35 BK19...

  • Page 60: Processor 6/7

    Schematic Diagrams Processor 6/7 PLACE CAP BACKSIDE VCCSA VDDQ VCCVDDQ_CLK 1.0V_VCCSFR 1.0V_VCCST SKYLAKE_HALO U113I C408 C385 C387 BGA1440 VCCSA VDDQ AE12 SKYLAKE_HALO U113K VCCSA VDDQ VCCSA VDDQ BGA1440 VCCSA VDDQ BM33 VCCSA VDDQ RSVD_TP RSVD_TP BL33 VCCSA VDDQ RSVD_TP RSVD_TP AJ12 VCCSA VDDQ...

  • Page 61: Processor 7/7

    Schematic Diagrams Processor 7/7 VCCGT +VCCGTU U113M SKYLAKE_HALO VCCGT VCCGT SKYLAKE_HALO U113N BGA1440 SKYLAKE_HALO AK30 U113L BGA1440 SKYLAKE_HALO SKYLAKE_HALO U113F AK29 U113H AJ29 BGA1440 VCCGT BGA1440 AJ30 AJ38 BG34 BGA1440 AF29 VCCGT VCCGT AV29 AJ31 VCCGTX BA38 AJ37 BG35 AF30 VCCGT VCCGT VCCGT...

  • Page 62: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] VTT_MEM STD TYPE DDR4 VDDQ J_DIMMA_1B H=4mm 2.5V J_DIMMA_1A VDD19 VDD18 VDD17 M_A_CLK_DDR0 CK0_T M_A_DQ5 4,10 VDD16 VPP2 M_A_CLK_DDR#0 CK0_C M_A_DQ0 4,10 VDD15 VPP1 M_A_CLK_DDR1 M_A_DQ2 4,10 CK1_T VDD14 M_A_CLK_DDR#1 CK1_C M_A_DQ3 4,10 VDD13...

  • Page 63: Ddr4 Cha So-Dimm_1

    Schematic Diagrams DDR4 CHA SO-DIMM_1 Channel A SO-DIMM 1[RAM3] REV TYPE DDR4 H=5.2mm J_DIMMA_2A M_A_CLK_DDR2 M_A_DQ5 CK0_T M_A_CLK_DDR#2 CK0_C M_A_DQ0 VTT_MEM M_A_CLK_DDR3 CK1_T M_A_DQ2 M_A_CLK_DDR#3 CK1_C M_A_DQ3 J_DIMMA_2B M_A_DQ1 VDDQ M_A_CKE2 CKE0 M_A_DQ4 2.5V PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM M_A_CKE3 CKE1 M_A_DQ6...

  • Page 64: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 VTT_MEM Channel B SO-DIMM 0[RAM2] RSV TYPE J_DIMMB_1B DDR4 VDDQ H=4mm 2.5V VDD19 VDD18 J_DIMMB_1A VDD17 M_B_DQ[63:0] 4,12 VDD16 VPP2 M_B_DQ0 M_B_CLK_DDR0 CK0_T VDD15 VPP1 M_B_DQ5 M_B_CLK_DDR#0 CK0_C VDD14 M_B_DQ7 M_B_CLK_DDR1 3.3VS CK1_T VDD13 M_B_DQ3 M_B_CLK_DDR#1 CK1_C VDD12...

  • Page 65: Ddr4 Chb So-Dimm_1

    Schematic Diagrams DDR4 CHB SO-DIMM_1 Channel B SO-DIMM 1[RAM4] STD TYPE DDR4 H=5.2mm J_DIMMB_2A M_B_DQ[63:0] 4,11 M_B_DQ0 VTT_MEM M_B_CLK_DDR2 CK0_T M_B_DQ5 M_B_CLK_DDR#2 J_DIMMB_2B CK0_C M_B_DQ7 VDDQ M_B_CLK_DDR3 CK1_T M_B_DQ3 2.5V M_B_CLK_DDR#3 CK1_C M_B_DQ4 VDD19 M_B_DQ2 M_B_CKE2 CKE0 VDD18 M_B_DQ1 M_B_CKE3 CKE1 VDD17 M_B_DQ6...

  • Page 66: Panel, Inverter, Crt

    Schematic Diagrams Panel, Inverter, CRT PANEL CONNECTOR (For coaxial cable) DEFAULT SHORT PANEL POWER PLVDD *MTS3572G6 VLED C151 C204 C212 J_LCD1 C227 1u_6.3V_X5R_04 FRAME_LOCK#_R *0.22u_50V_Y5V_06 FRAME_LOCK# CABLE *2SK3018S3 3.3VS D01A *4.7K_06 3.3V R1872 VGA_ENAVDD 0_04 *150K_1%_04 D01A *100K_04 PANEL G sync, GND5 3.3V GND5...

  • Page 67: Redriver

    Schematic Diagrams Redriver NV_DP_F PARADA 61'366 36% 6-03-08330-030 6-02-75130-BQ0 MDP_F_AUX#_RE MDP_F_AUX_RE R814 *100K_1%_04 X) *1' X) *1' PS8330B R829 *100K_1%_04 MDP_F_AUX_SCL 3.3VS SLQ SN75DP130SSRGZR MDP_F_AUX#_SDA 2.2u_6.3V_X5R_04 MDP_F_AUX pin2 C826 1u_6.3V_X5R_04 MDP_F_AUX# . 9&& . *1' D01A SLQ R619 10K_04 A_AUTO_EQ 0_04 3.3VS pin3...

  • Page 68: Mini Dp Port E

    Schematic Diagrams Mini DP Port E mini-Display Port E R343 *0_04 D01A R344 *0_04 Close to Display PORT MDP_E#3 3.3VS 3.3VS_MDP C572 0.1u_10V_X7R_04 D_MDP_E#3 D_MDP_E3 C567 0.1u_10V_X7R_04 MDP_E3 *DVI2012F2SF-900T05_08-SHORT VOUT C553 C613 R339 *0_04 SY6288DAAC R341 *0_04 *10u_6.3V_X5R_06 10u_6.3V_X5R_06 MDP_E#2 D_MDP_E#2 C564 0.1u_10V_X7R_04...

  • Page 69: Mini Dp Port F

    Schematic Diagrams Mini DP Port F mini-Display Port F PLEASE CLOSE TO CONNECTOR 3.3VS_MDP D01A Close to Display PORT R393 *0_04 C550 MDP_F#3 C637 0.1u_10V_X7R_04 D_MDP_F#3 D_MDP_F3 C635 0.1u_10V_X7R_04 10u_6.3V_X5R_06 MDP_F3 *DVI2012F2SF-900T05_08-SHORT R387 *0_04 R380 *0_04 MDP_F#2 C628 0.1u_10V_X7R_04 D_MDP_F#2 D_MDP_F2 C616 0.1u_10V_X7R_04...

  • Page 70: Hdmi Connector

    Schematic Diagrams HDMI Connector HDMI_5VS HDMI CONNECTOR HDMI_5VS HDMI_5VS D01A For ESD HDMI_5VS EMC2 EMC3 BY platform J_HDMI1 16-A0171-2003-0 R146 R163 *100p_50V_NPO_04 *0.1u_16V_Y5V_04 VOUT P/N = 6-21-14A80-019 C348 C352 2.2K_04 2.2K_04 SY6288DAAC 22u_6.3V_X5R_08 22u_6.3V_X5R_08 *BAV99 RECTIFIER *BAV99 RECTIFIER *BAV99 RECTIFIER PCB Footprint = C12881-100C 15,52,54 SUSB...

  • Page 71: Vga Pci Express

    Schematic Diagrams VGA PCI Express 3V3_AON 36,60 DGPU_PWRGD NV PCI EXPRESS R521 10K_04 2SK3018S3 PEX_CLKREQ# PEG_CLKREQ# R522 *100K_04 BGA1745 PLACE AT PLACE OUTSIDE COMMON PEX_VDD 1/21 PCI_EXPRESS BALLS OF BGA D01A SNN_PEXWAKE BJ21 PEX_WAKE AW33 PEX_IOVDD BE20 AY32 R520 0_04 C108 C106 C109...

  • Page 72: [19] Vga Frame Buffer Partition

    Schematic Diagrams VGA Frame Buffer Partition PAGE3: GPU FRAME BUFFER PARTITION A/B BGA1745 COMMON BGA1745 COMMON 3/21 FBB 2/21 FBA FBB_D0 FBB_CMD0 FBB_D0 FBB_CMD0 FBA_DBI[7..0] FBB_DBI[7..0] FBA_D0 FBA_CMD0 FBB_D1 FBB_CMD1 FBA_D0 FBA_CMD0 FBB_D1 FBB_CMD1 FBA_DBI[7..0] FBB_DBI[7..0] FBA_D1 FBA_CMD1 FBB_D2 FBB_CMD2 FBA_D1 FBA_CMD1 FBB_D2...

  • Page 73: [20] Frame Buffer Partition A

    Schematic Diagrams Frame Buffer Partition A FBA_WCK01 FBA_CMD[31..0] FBA_W CK01 FBA_CMD[31..0] FBA_WCK01* FBA_W CK01* FRAME BUFFER PARTITION A FBA_WCK23 FBA_D[63..0] FBA_W CK23 FBA_D[63..0] FBA_WCK23* FBA_W CK23* FBA_WCK45 FBA_DBI[7..0] FBA_W CK45 FBA_DBI[7..0] FBA_WCK45* FBA_W CK45* FBA_WCK67 FBA_EDC[7..0] FBA_W CK67 FBA_EDC[7..0] FBA_WCK67* FBA_W CK67* INS115241755 BGA170...

  • Page 74: [21] Frame Buffer Partition B

    Schematic Diagrams Frame Buffer Partition B FBB_WCK01 FBB_CMD[31..0] FBB_W CK01 FBB_CMD[31..0] FBB_WCK01* FRAME BUFFER PARTITION B FBB_W CK01* FBB_WCK23 FBB_D[63..0] FBB_W CK23 FBB_D[63..0] FBB_WCK23* FBB_W CK23* FBB_WCK45 FBB_DBI[7..0] FBB_W CK45 FBB_DBI[7..0] FBB_WCK45* FBB_W CK45* FBB_WCK67 FBB_EDC[7..0] FBB_W CK67 FBB_EDC[7..0] FBB_WCK67* FBB_W CK67* INS115243542 BGA170...

  • Page 75: Frame Buffer Partition A_B

    Schematic Diagrams Frame Buffer Partition A_B FRAME BUFFER PARTITION A/B DECOUPLING FBVDDQ DECOUPLING AROUND FBA MEMORIES (DQ0-DQ31) PLACE Under MEM FBVDDQ PLACE Under MEM DECOUPLING AROUND FBA MEMORIES (DQ32-DQ63) SPARE SPARE C708 C709 C711 FBVDDQ P6xxRA Frame A,B Sheet 22 of 79 FBVDDQ Frame Buffer 1K_1%_04...

  • Page 76: [23] Gpu Frame Buffer Partition

    Schematic Diagrams GPU Frame Buffer Partition FBD_DBI[7..0] FBD_CMD[31..0] GPU FRAME BUFFER PARTITION C/D FBD_DBI[7..0] FBD_CMD[31..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_DBI[7..0] FBD_EDC[7..0] FBD_D[63..0] FBC_EDC[7..0] FBC_EDC[7..0] P6xxRE Frame D FBC_CMD[31..0] BGA1745 BGA1745 FBC_CMD[31..0] COMMON COMMON FBVDDQ FBC_D[63..0] 4/21 FBC 5/21 FBD FBC_D[63..0] FBC_D0 FBC_CMD0 FBD_D0 FBD_CMD0...

  • Page 77: [24] Frame Buffer Partition C

    Schematic Diagrams Frame Buffer Partition C FRAME BUFFER PARTITION C FBC_CMD[31..0] FBC_CMD[31..0] FBC_WCK01 FBC_W CK01 FBC_WCK01* FBC_D[63..0] FBC_D[63..0] FBC_W CK01* FBC_WCK23 FBC_W CK23 FBC_DBI[7..0] FBC_WCK23* FBC_DBI[7..0] FBC_W CK23* FBC_WCK45 FBC_W CK45 FBC_EDC[7..0] FBC_WCK45* FBC_EDC[7..0] FBC_W CK45* FBC_WCK67 FBC_W CK67 FBC_WCK67* INS115249753 FBC_W CK67* BGA170...

  • Page 78: [25] Frame Buffer Partition D

    Schematic Diagrams Frame Buffer Partition D FRAME BUFFER PARTITION D FBD_CMD[31..0] FBD_CMD[31..0] FBD_WCK01 FBD_W CK01 FBD_D[63..0] FBD_WCK01* FBD_D[63..0] FBD_W CK01* FBD_WCK23 FBD_W CK23 FBD_DBI[7..0] FBD_WCK23* FBD_DBI[7..0] FBD_W CK23* FBD_WCK45 FBD_W CK45 FBD_WCK45* INS115251069 FBDEDC[7..0] BGA170 FBD_EDC[7..0] FBD_W CK45* FBD_WCK67 COMMON FBD_W CK67 FBD_WCK67* FBD_W CK67*...

  • Page 79: Frame Buffer Partition C_D

    Schematic Diagrams Frame Buffer Partition C_D FRAME BUFFER PARTITION C/D DECOUPLING FBVDDQ FBVDDQ PLACE Under MEM DECOUPLING AROUND FBC MEMORIES (DQ0-DQ31) DECOUPLING AROUND FBC MEMORIES (DQ32-DQ63) PLACE Under MEM SPARE SPARE C717 C116 C168 C721 C147 C146 C197 C729 C113 C213 C121 C728...

  • Page 80: Gpu Decoupling

    Schematic Diagrams GPU Decoupling Sheet 27 of 79 GPU Decoupling B - 28 GPU Decoupling...

  • Page 81: Daca Interface & Xtal

    Schematic Diagrams DACA Interface & XTAL DACA INTERFACE and XTAL N15E-GT GC6 1.0 IO PORT PCH BGA1745 COMMON 6/21 DACA AW18 DACA_VDD I2CA_SCL 3V3_RUN I2CA_SCL I2CA_SDA I2CA_SDA AW20 DACA_VREF AY20 BA20 DACA_RSET DACA_HSYNC AY18 DACA_VSYNC AY21 DACA_RED BA21 DACA_GREEN AW21 DACA_BLUE N16E-GT Sheet 28 of 79...

  • Page 82: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface BGA1745 BGA1745 IFP I/O INTERFACE COMMON COMMON 12/21 MIOB 11/21 MIOA BGA1745 AM11 AJ10 COMMON VDD33 MIOBD0 VDD33 MIOAD0 AN11 AJ11 VDD33 MIOBD1 VDD33 MIOAD1 7/21 IFPAB AR11 AK11 VDD33 MIOBD2 VDD33 MIOAD2 MIOBD3 MIOAD3 GK104 GM204 MIOBD4...

  • Page 83: Misc - Gpio, I2C And Rom

    Schematic Diagrams Misc - GPIO, I2C and ROM MISC: GPIO, I2C, and ROM BGA1745 MULTI-LEVEL STRAPS COMMON 15/21 MISC_2 3V3_RUN 3V3_RUN U118 VGA_ROM_CS# ROM_CS 0.1u_16V_Y5V_04 C1732 IVGA_ROM_CS# 3V3_AON DVGA_ROM_CS# VGA_ROM_SI Setting RAM type ROM_SI VGA_ROM_CS# VGA_ROM_SO ROM_SO STRAP0 VGA_ROM_SCLK PS8331_SW 3,13,36,51 STRAP0 ROM_SCLK...

  • Page 84: Gpu Nvvdd, Fbvddq, And Gnd

    Schematic Diagrams GPU NVVDD, FBVDDQ, and GND BGA1745 BGA1745 GPU NVVDD, FBVDDQ, AND GND COMMON COMMON 16/21 GND_1/2 17/21 GND_2/2 AJ25 BB32 AJ27 BB34 AJ29 BB35 AJ31 BB36 AA15 AK14 NVVDD AA17 AK16 BGA1745 BGA1745 NVVDD NVVDD NVVDD COMMON COMMON AA19 AK18 AA21...

  • Page 85: Pch 1/9

    Schematic Diagrams PCH 1/9 BOOT HALT JTAG ODT ESPI FLASH SHARING MODE MASTER ATTACHED FLASH SHARING:LOW ENABLE:LOW DISABLE:LOW SLAVE ATTACEHD FLASH SHARING:HIGH (INTERNAL WEAK PD) (INTERNAL WEAK PU) (INTERNAL WEAK PD) SPI_3.3V SPI_3.3V 3.3VA R664 R689 R669 *20K_04 *20K_04 *4.7K_04 SPI_SI_R SPI_SO_R GPP_H_12...

  • Page 86: Pch 3/9

    Schematic Diagrams PCH 2/9 SPT-H_PCH U114B DMI_MT_IR_0_DN DMI_RXN0 USB2N_1 USB_PN1 DMI_MT_IR_0_DP DMI_RXP0 USB3 PORT1, , C h a r g e r USB2P_1 USB_PP1 DMI_IT_MR_0_DN DMI_TXN0 USB2N_2 Del test point D01A DMI_IT_MR_0_DP DMI_TXP0 USB2P_2 DMI_MT_IR_1_DN DMI_RXN1 USB_PN3 USB2N_3 DMI_MT_IR_1_DP DMI_RXP1 AG10 USB3 PORT3, USB2P_3...

  • Page 87: Pch 6/9

    1.0V_VCCST PCB Footprint = 193705-1 PN = 6-20-437E0-022 P650RE, P655RE, P650RA, P655RA 6-20-437E0-022 Size Size Size Document Number Document Number Document Number P650RG, P670RE, P670RG, P670RA 6-21-43710-022 6-71-P65R0-D03 6-71-P65R0-D03 6-71-P65R0-D03 P650RE P650RE P650RE Date: Date: Date: W ednesday, July 08, 2015...

  • Page 88: Pch 8/9

    Schematic Diagrams PCH 4/9 U114D SPT-H_PCH VDD3 D01A ISH_GP_6_R BB17 HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# AW22 PM_CLKRUN# *RB751V-40(lision) 45,46 HDA_RST# PM_CLKRUN# HDA_RST# GPP_A8/CLKRUN# HDA_SDIN0 HDA_SDI0 AR15 HDA_SDI1 GPD11/LANPHYPC R1862 1.5K_1%_04 R1863 45.3K_1%_04 Del test point D01A HDA_SDOUT AV13 35,45 HDA_SDOUT HDA_SDO GPD9/SLP_WLAN# HDA_SYNC HDA_SYNC BC14...
  • Page 89 Schematic Diagrams PCH 5/9 U114E R632 100K_04 SPT-H_PCH 3.3VS FROM DP REDRIVER GPP_I7/DDPC_CTRLCLK 14,30 MDP_F_HPD_RE GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA 17,30 HDMI_HPD GPP_I1/DDPC_HPD1 GPP_I5/DDPB_CTRLCLK FROM DP REDRIVER 14,30 MDP_E_HPD_RE GPP_I2/DDPD_HPD2 GPP_I6/DDPB_CTRLDATA DGPU_RST#_PCH GPP_I3/DDPE_HPD3 R253 *10K_04 R729 100K_04 GPP_I9/DDPD_CTRLCLK DGPU_SELECT# GPP_I10/DDPD_CTRLDATA R699 10K_04 GPP_F14 H_SKTOCC_N DGPU_PRSNT# R683...
  • Page 90 Schematic Diagrams PCH 6/9 D01A W 76-147_24MHZ C787 24MHZ 12p_50V_NPO_04 fsx3m 6-22-24R00-1B9 6-22-24R00-1BA R565 1M_04 C790 12p_50V_NPO_04 SPT-H_PCH U114G RTC (10 MOHM RES): DO NOT CHANGE TO 0402 AR17 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN CLKOUT_ITPXDP PCH_XDP_CLK_DP CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P C795 CLKOUT_ITPXDP_P CPU_24MHZ_R_DN CLKOUT_CPUNSSC D01A 15p_50V_NPO_04 CLKOUT_CPUPCIBCLK PCH_CPU_PCIBCLK_R_DN...
  • Page 91 Schematic Diagrams PCH 7/9 D01A R166 *20mil_Short-p VDD1.0 R238 *28mil short-p VDD3 VDD1.0 +VCCPRIM_1P0 SPT-H_PCH DEFAULT SHORT U114H D01A R264 *20mil_Short-p eSPI:1.8V +VCCPRIM_1P0 2.899A AA23 3.3VA LPC:3.3V VCCPRIM_1P0 AA26 VCCPRIM_1P0 R297 *28mil short-p PJ10 AA28 AL22 0.0908A +VCCFHV_2P8 3.3VA D01A VCCPRIM_1P0 VCCPRIM_1P0 AC23...
  • Page 92 Schematic Diagrams PCH 8/9 U114I SPT-H_PCH U114L SPT-H_PCH AC18 AB11 AN10 BE14 AB14 BE18 AE29 AB31 BE23 AB32 BE28 AE42 AB38 BE32 AF18 BE37 AF20 BE40 AF21 AF23 AC20 AF25 AC21 AF26 AC25 AF28 AC29 AF29 AC45 AG11 AG13 AD11 AG31 AD14 AG32...
  • Page 93 Schematic Diagrams PCH 9/9 NO REBOOT STARP ENABLE: HIGH SPT-H_PCH U114J (INTERNAL WEAK PD) DFX TEST MODE QUALIFIER FOR OTHER 3.3VS DFX STRAP WHEN SAMPLED LOW (WEAK INTERNAL PU) AR22 R213 *1K_04 RSVD BD45 R638 RSVD BD44 RSVD BE44 *4.7K_04 RSVD LPSS_GSPI0_MOSI RSVD...

  • Page 94: Usb3.0

    Schematic Diagrams USB3.0 USB3.0 re-driver USB3.0 PORT5 (MB ) 3.3V USBVCC3.0_5 *0_04 100 mil *4.7K_04 VOUT *4.7K_04 C714 *2K_1%_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 R497 *0402_short uP7549UMA5-20 51,52,54 DD_ON# PCB Footprint = M-SOT23-5 *4.7K_04 I2C_SDA_P5 I2C_SCK_P5 *4.7K_04 SMB_DATA SMB_SCK USB3_TXN5 TXN5 *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 USB3_TXN5 TX1-...

  • Page 95: Usb Charger

    Schematic Diagrams USB Charger USB3.0 re-driver 3.3V R695 *0_04 R687 *4.7K_04 R667 *4.7K_04 R661 2K_1%_04 R724 *4.7K_04 I2C_SDA_P1 I2C_SCK_P1 R647 *4.7K_04 SMB_DATA SMB_SCK USB3_TXN1 TXN1 0.1u_10V_X7R_04 C908 C860 0.1u_10V_X7R_04 TX1- RX1- USB3_TXN1 VDD5 VDD5 D01A TXP1 0.1u_10V_X7R_04 C907 C859 0.1u_10V_X7R_04 USB3_TXP1 TX1+ USB3_TXP1...

  • Page 96: M.2 3G + M.2 Sata

    Schematic Diagrams M.2 3G + M.2 SATA 3G 4G CARD USB3.0 / M.2 SATA CURRENT2A ,DON'T DROP BELOW 3.135V 3G_3.3V 80 mils P670 MSATA Only, J_3G1 C984 220u_6.3V_6.3*6.3*4.2 C596 0.1u_16V_Y5V_04 3G_CONFIG2 CONFIG_2 3.3V4 GND10 3.3V3 C598 0.1u_16V_Y5V_04 3G_CONFIG1 GND9 3.3V2 3G_CONFIG1 CONFIG_1 SUSCLK(32Khz)(O)

  • Page 97: M.2 Wlan+Bt, Pcie4X Ssd

    Schematic Diagrams M.2 WLAN+BT, PCIE4X SSD J_W LAN1 40 mil WLAN+BT W LAN_3.3V GND10 3.3V3 C295 Reserved/REFCLKN1 3.3V2 C305 Reserved/REFCLKP1 UIM_Power_In/Gpio1/PEWake1# GND9 UIM_Power_Out/CLKREQ1# 22u_6.3V_X5R_08 0.1u_16V_Y5V_04 Reserved/PERn1 UIM_SWP/PERST1# Reserved/PERp1 Reserved1 GND8 ALERT#(I) R200 10K_04 *2mm Reserved/PETn1 I2C CLK(O) W LAN_3.3V 3.3V R194 10K_04 Reserved/PETp1...

  • Page 98: Realtek Alc892

    Schematic Diagrams Realtek ALC892 3.3V 2,13,30,41,42,43,44,49,51,52,54,55,58,59,60 Layout Note: 3.3VS 3,9,10,11,12,13,14,15,16,17,32,34,35,36,37,38,40,43,44,46,48,49,50,51,54,59,61,63 41,51,52,54,57,58,59,60,61,62,63,64 U43 pin 1 ~ pin 11 and pin 47 and pin 48 C600 0.1u_16V_Y5V_04 13,17,34,46,47,49,50,51,54 are Digital signals. 13,48,52,53,54,55,56,57,58,61,62,63,64 C599 0.1u_16V_Y5V_04 The others are Analog signals. C603 0.1u_16V_Y5V_04 3.3VS 3.3VS_AUD 5VS_AUD C602...

  • Page 99: Tpa2008D2

    Schematic Diagrams TPA2008D2 AMP_5VS TPA2008D2 HCB1608KF-121T30 The volume control.the gain range is from -80db(Vvolume=5V) to +20db(Vvolume=0V) with P2P BA20550 D01A 64 steps precise control. C611 C612 C605 (TSSOP24) 0.1u_10V_X7R_04 0.1u_10V_X7R_04 22u_6.3V_X5R_08 Front Speaker R / L AUDG AUDG AUDG 4 Ohm 2W Speaker AMP_EN ROUTP FCM1005KF-121T03...

  • Page 100: Subwoofer

    Schematic Diagrams Subwoofer P670SE ONLY 2.2_04 2200p_50V_X7R_04 SAMP_PW R SAMP_PW R SC36 EMC18 SC21 SC40 SC10 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 1000p_50V_X7R_04 2.2uH_4*4*2.0 SAMPPW R_SW 10K_04 AUDG_2 AUDG_2 AUDG_2 AUDG_2 AUDG_2 FMS3004-AS-H SOSCIN *10K_04 45,46 AMP_EN OSCIN 10u_6.3V_X5R_06 SR13 0_04 MUTE OSOC...

  • Page 101: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 P670RE IT8587(Follow IT8991 PIN Define) MODEL_ID RB (PL) RA (PH) Voltage J_KB2 KBC_AVDD 85208-24051 VDD3 DEFAULE HCB1005KF-121T20 KB-SI0 MODEL_ID R798 *10K_04 VDD3 VDD3 KB-SI1 C610 C646 C690 C691 C688 C689 KB-SI2 R799 10K_04 15.4K KB-SI3 10u_6.3V_X5R_06 0.1u_16V_Y5V_04...

  • Page 102: Tpm, Ccd, Tp

    Schematic Diagrams TPM, CCD, TP TPM_PW R FOR TP TP_VCC R477 SLB9665TT GPIO 100K_04 TP_VCC H: W / TPM ( R477 ) R451 R419 C686 L: W/O TPM ( R474 ) TPM_PW R R420 0_04 3.3VS TPM_DET 10K_04 10K_04 *10u_6.3V_X5R_06 D01A R478 *0_04...

  • Page 103: Fan, Lid, Kb, Led

    Schematic Diagrams Fan, LID, KB, LED VGA FAN CONTROL-Selector CPU FAN CONTROL LID SWITCH IC FON1# VDD3 VOUT C265 C261 100K_04 VSET 1u_6.3V_X5R_04 *4.7u_6.3V_X5R_06 NCT3940S-A C458 0.1u_16V_Y5V_04 CPU_FAN CPU_FAN LID_SW # 13,48 5VS_CPU_FAN J_FAN1 AH9249NTR-G1 VGA_FAN2SEN *1u_10V_Y5V_06 0.1u_16V_Y5V_04 *100p_50V_NPO_04 VGA_FAN1SEN C733 VGA_FANSEN VGASEN_SEL...

  • Page 104: Connector

    Schematic Diagrams Connector 3.3VS LED BOARD LAN BOARD C403 ( USB3.0x2, PHONE JACK) *0.01u_16V_X7R_04 J_LED1 J_LAN1 LED_ACIN LED_PW R USB_PN4 LED_BAT_CHG USB_PP4 C469 C463 LED_BAT_FULL LED_NUM# USB3_TXN4 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 LED_CAP# USB3_TXP4 R1914 0_04 LED_SCROLL# PS8331_SW 3,13,30,36 USB3_RXN4 AIRPLAN_LED# USB3_RXP4 R1915 *0_04 DGPU_PW R_EN 58,59...

  • Page 105: Ddr 1.2V / 0.6Vs

    Schematic Diagrams DDR 1.2V / 0.6VS DDR4: 1.2V/0.6VS PQ27 MDU1516 EMC17 PC240 PC252 DDR4 UP6163 ULTRASO-8 6-02-05616-CQ0 2ND RB0540S2 UP6163 VDDQ_R VTT_MEM(0.6V) 1.2V PC225 PC86 0.1u_10V_X7R_04 VLDOIN VBST DEFAULT SHORT 10u_6.3V_X5R_06 EMR2 VDDQ_R VTT_MEM DRVH DEFAULT SHORT PL12 0_06 PJ18 BCIHP0730-1R0M PJ26 PC84...

  • Page 106: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR219 *0_04 PR220 0_04 PC93 1u_10V_Y5V_06 PR85 PR94 EN_3V EN_5V PC220 D01A D01A 130K_1%_04 130K_1%_04 PC235 1000p_50V_X7R_04 1000p_50V_X7R_04 PU17 VREG3 PC251 PC250 PC246 PC111 PC110 PC103 PC239 Sheet 53 of 79 VDD3_5_POK PC219 PR323 10K_04 0.1u_50V_Y5V_06 SYS5V VDD3...

  • Page 107: 5V, 5Vs, 3.3V, 3.3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA VIN1 VIN1 R384 10K_04 R398 100K_04 DD_ON VIN1 D01A R392 1_1%_06 R400 *100K_04 DD_ON_LATCH USB_CHARGE_EN 42,48,53 C618 C631 C638 R401 10K_04 R406 10K_04 M_BTN# VDD3 M_BTN# PWR_SW# 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 R412 *100K_04 R411 1K_1%_04 INSTANT-ON PW R_SW #...

  • Page 108: Power 1.0V, Vccio

    Schematic Diagrams Power 1.0V, VCCIO For CV test VDD1.0 PR328 100K_04 PR65 820K_1%_06 VDD3 PJ13 *CV-40mil D02_BCN PC205 15u_25V_SMD-B2 PC73 PC72 VDD1.0_EN 6-11-15612-8B0 PC71 VDD3_5_POK 6-11-15612-8B1 PJ14 *1mm PC285 D01A PR61 PC204 0_06 0.1u_10V_X7R_04 *0.01u_16V_X7R_04 EN_PSV 35,48,53,54 EC_SLP_SUS# VTT_SELECT VTT VR Output Voltages PJ47 V1.0A VDD1.0...

  • Page 109: Ac_In, Charger

    Schematic Diagrams AC_In, Charger PC126 SMART CHARGER V_BAT PR149 EMB20P03V PQ30 PC271 20K_04 PC128 EMB20P03V EML1 HCB2012KF-800T80 EMB20P03V D01A PQ31 PRS5 PRS6 J_DC_JACK1 EML2 EMB20P03V HCB2012KF-800T80 D01A 6-19-41001-739 *0.01_1%_32 *0.01_1%_32 PL16 PD20 FMS3004-AS-H BCIHP0730-4R7M PRS3 PRS4 PC33 PC165 PC164 PR45 0.01_1%_32 0.01_1%_32 2DC3003-002211...

  • Page 110: 1.0Dx_Vccstg/Vccsfr_Oc/2.5V

    Schematic Diagrams 1.0DX_VCCSTG/VCCSFR_OC/2.5V NOTE: 1.0DX_VCCSTG TURN-ON need <65us VCCSFR_OC DEFAULT SHORT DEFAULT SHORT 1.0DX_VCCSTG M5938 TURN-ON TIME=60us 1.0DX_VCCSTG VCCSFR_OC VDD1.0 VDDQ PJ35 PJ34 VOUT VOUT C783 C331 C786 C805 C794 C791 VOUT VOUT VOUT VOUT R576 VDD3 R571 VDD3 *100_04 VOUT VOUT D01A...

  • Page 111: Pex_Vdd, 3V3_Aon, 3V3_Run

    Schematic Diagrams PEX_VDD, 3V3_AON, 3V3_RUN Open VREG Type 0 PEX_VDD 2.6Amps @ 1.0V PR14 22u_6.3V_X5R_08 10_06 0.1u_10V_X7R_04 10K_1%_04 INS102335846 APW8805 DFN10 COMMON PS6_BOOT_PEXVDD PEX_VDD PR182 10K_04 0.200 *160K_04 3V3_RUN PEXVDD_PWRGD PGOOD PEXVDD_PWRGD 1.1V OpenVReg PR181 15K_04 PS3_1V05_EN *0.01u_16V_X7R_04 2.4A EN/FS 3V3_RUN 0.400 BOOT/NC...

  • Page 112: Nvvdd Phase 1 & 2

    Schematic Diagrams NVVDD Phase 1 & 2 PR198 2.2_1%_06 PWR_SRC_NV PAGE 21: NVVDD PHASE 1 and 2 Optional Place Close to DrMOS PS1_NVVDD_VCC PR46 100K_04 PS1_NVVDD_PVCC PC32 PC166 PC167 PC63 PC52 PC203 PC55 PC65 PC64 PC48 PC61 PC60 0.1u_10V_X7R_04 0.1u_10V_X7R_04 22u_6.3V_X5R_08 FREQ SELECTION PR24...

  • Page 113: Fbvddq

    Schematic Diagrams FBVDDQ PAGE22: NVVDD PHASE 3, FBVDDQ, and MXM Mounting Holes ~6A at 15A/1.5V Output with 7V Input PWR_SRC_NV_FB Optional Place Close to DrMOS FBVDDQ PC162 PC163 PC11 PC17 PC158 PC14 PC297 INS102340263 TPS51211 DFN10 COMMON LFPAK 3.3V PQ16 PC161 INS102340183 V5IN...

  • Page 114: Vcc_Core & Vccsa

    Schematic Diagrams VCC_Core & VCCSA VCORE_PROG ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS CONFIGURATION 3.3VS 1.0V_VCCST PR263 PR272 13K_1%_04 PR108 1K_1%_04 D01A PR116 PR262 PR110 2.2_06 PR268 PR270 PR269 PC259 100K_04 *1K_1%_04 100K_04 1u_6.3V_X5R_04 PC255 PC113 0.01u_50V_X7R_04 *CV-40mil 100_04 45.3_1%_04 *45.3_1%_04...

  • Page 115: Vcore & Vccsa Output Stage

    Schematic Diagrams VCore & VCCSA Output Stage DEFAULT SHORT VCCVIN D01A VCORE & VCCSA OUTPUT STAGE PJ36 PC234 PC98 PC241 PC106 PR221 PC223 2.2_06 PR223 2.2_06 0.22u_16V_X7R_06 PU16 NCP81151MNTBG PR225 1_1%_06 INS118403478 INS118404489 MLP08 MLP08 PR229 10K_06 6-19-41001-043 PW M11 COMMON COMMON PL13...

  • Page 116: Vccgt

    Schematic Diagrams VCCGT ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS 3.3VS 1.0V_VCCST PR125 D01A PR127 1K_1%_04 PR145 PR132 PR148 2.2_06 PR144 PR137 PR140 PC130 100K_04 *1K_1%_04 100K_04 1u_6.3V_X5R_04 PC266 PC125 VCCGT_PROG *CV-40mil *100_04 *45.3_1%_04 *45.3_1%_04 PUT CLOSE 0.01u_50V_X7R_04 PC268 PC273 4.7u_6.3V_X5R_06...

  • Page 117: Vccgt Output Stage

    Schematic Diagrams VCCGT Output Stage DEFAULT SHORT VGTVIN PJ43 D01A PC272 PC132 PC133 PR117 PC119 PR134 2.2_06 0.22u_16V_X7R_06 2.2_06 PU63 NCP81151MNTBG PR115 INS118517944 1_1%_06 MLP08 COMMON PL14 6-19-41001-043 PR277 CMME063T-R15MS0R907 PW M12 10K_1%_04 VCCGT PCB Footprint = BCIHP0735A DRVON2 PC116 PC115 PR267 470u_2V_SMD-V...

  • Page 118: P650Re Audio Board A

    Schematic Diagrams P650RE Audio Board A AJ_SPDIF1 ASIDE_L FCM1005KF-121T03 A_5VS ASIDE_R FCM1005KF-121T03 AJ_MB1 ASIDE_SENSE AC10 A_AUDG A_5VS 680p_50V_X7R_04 680p_50V_X7R_04 ASPDIFO A_AUDG DRIVE AJD_SENSEA AJD_SENSEB ASPDIFO FCM1005KF-121T03 AMIC1-R AMIC1-L TOJ-0015STR2-2-H4-PA9T-J P/N = 6-20-B2820-005 AGND ASIDE_R AR10 0.1u_16V_Y5V_04 PCB Footprint = TOJ-001ST-2-H4 ASIDE_L 220_04 180p_50V_NPO_04...

  • Page 119: P650Re Power Board

    Schematic Diagrams P650RE Power Board B3.3VS BJ_BTN1 B3.3VS BM_BTN# 20mil FP226H-004S10M PCB Footprint = fp226h-004xxxm_r 220_1%_04 BGND 20mil 20mil B_SW1 POWER BUTTON P650RE D01 *0.1u_16V_Y5V_04 B_SW1 Sheet 66 of 79 TJE-532-Q-T/R BGND P650RE Power BM_BTN# Board PCB Footprint = tje-53x-q P650RE D01 BGND 0.1u_50V_Y5V_06...

  • Page 120: P650Re Hdd Board

    Schematic Diagrams P650RE HDD Board HJ_MB1 SATA PORT1 HGND HGND HSATA_TXP1 P650RE HDD D01 HJ_SATA1 HSMB_SDA HSATA_TXN1 H_SATA_TXP1 HSMB_SCK H_SATA_TXN1 HSATA_RXN1 H_SATA_RXN1 H_5V HSATA_RXP1 H_SATA_RXP1 H_5VS H_3.3VS HP670RG-M_TPLED P650RE HDD D01 H_3.3VS HC13 HC11 50009-03041-001 *0.01u_16V_X7R_04 *10u_6.3V_X5R_06 P/N = 6-21-C2430-215 PCB Footprint = 50009-0304x H_5VS HGND...

  • Page 121: P650Re Led Board

    Schematic Diagrams P650RE LED Board LJ_LED1 LLED_ACIN LD11 LLED_PWR LLED_BAT_CHG LLED_PWR LLED_BAT_FULL 330_04 LR13 330_04 LLED_BAT_FULL Green Green LLED_NUM# RY-SP260UYG24-5M RY-SP260UYG24-5M LLED_CAP# LD10 LD12 LLED_SCROLL# L_WLAN_AIRPLANE# LLED_ACIN 330_04 LLED_BAT_CHG LR11 330_04 L_dGPU_LED Amber Amber LSATA_LED# RY-SP260USO24-5M RY-SP260USO24-5M LED_GND AC IN/POWER ON LED BAT CHARGE/FULL LED L_3.3VS FP225H-012S10M...

  • Page 122: Finger Sensor Board

    Schematic Diagrams Finger Sensor Board NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND MODE FUSB_PP F3.3V AVDD FUSB_PN F2.5V F2.5V DVDD FMOSI F3.3V F3.3V VDDIO UVDD FMCLK FLED1 FLED1 FMCS FMCS FLED2 LED1 SPI_CS FMISO FDISCON FMOSI FMISO SPI_MOSI...

  • Page 123: P650Re Click Board

    Schematic Diagrams P650RE Click Board T_TP_VCC T3.3V W/O FP TJ_CLICK TJ_TP1 T_TP_BTN_L T_TP_CLK T_TP_DATA TO BOTTOM/B FCM1005KF-121T03 T_TP_BTN_R T_TP_BTN_L TO T/P T_TP_BTN_R FP226H-004S10M 8 PIN JXT_FP226H-004XXAM T_TP_SMB_CLK T_TP_VCC TJ_FP1 T_TP_SMB_DAT TGND TJ_MB FP225H-008S10M 27.4_1%_04 TUSB_PN10 fp225h-008gxxxm_r TGND 27.4_1%_04 TUSB_PP10 T_TP_DATA 6-20-94K30-108 T_TP_CLK TO M/B...

  • Page 124: P650Re Usb Board 1/3

    Schematic Diagrams P650RE USB Board 1/3 LAN (RTL8411B) Switching Regulator close to PIN48 2 IN 1 SOCKET KR80 0_06 Standard PUSH PUSH CARD READER KVDD10 (>20mil) KJ_CARD1 KRSET KR71 2.49K_1%_04 KREGOUT KVDD10 KGND (>20mil) KSD_D2/MS_CLK_R SD_DATA2 KR70 *1K_04 *SW F2520CF-4R7M-M KSD_D3/MS_D3_R KXTAL2 KGND...
  • Page 125 Schematic Diagrams P650RE USB Board 2/3 USB3.0 re-driver USB3.0 PORT4 K3.3V KR68 *0_04 KUSBVCC3.0_6 KR62 *4.7K_04 KR58 *4.7K_04 100 MIL KR53 2K_1%_04 VOUT KC45 KC46 KC28 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 KGND KGND KGND uP7549UMA5-20 K_SDA_P4 K_SCK_P4 KR79 *4.7K_04 KR37 *4.7K_04 KGND KGND KGND PCB Footprint = M-SOT23-5...
  • Page 126 Schematic Diagrams P650RE USB Board 3/3 USB3.0 PORT3 USB3.0 re-driver K3.3V KUSBVCC3.0_2 KR32 *0_04 KR33 *4.7K_04 100 mil VOUT KR24 *4.7K_04 KC38 10u_6.3V_X5R_06 KC48 KC40 KR15 2K_1%_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 KGND KR42 *0402_short KDD_ON# uP7549UMA5-20 KGND PCB Footprint = M-SOT23-5 2A/90mohm KGND KGND KR44...

  • Page 127: P670Re Usb Board 1/3

    Size Document Number Document Number Document Number 6-71-P67R3-D02A 6-71-P67R3-D02A 6-71-P67R3-D02A ZGND ZGND D02A D02A D02A Date: Date: Date: Friday, July 03, 2015 Friday, July 03, 2015 Friday, July 03, 2015 Sheet Sheet Sheet P670RE USB Board 1/3 B - 75...
  • Page 128 ZGND PCB Footprint = 51049-0804X ZGND D02A D02A D02A P650RE P650RE P650RE P67 USB D03 Date: Date: Date: Monday, July 06, 2015 Monday, July 06, 2015 Monday, July 06, 2015 Sheet Sheet Sheet B - 76 P670RE USB Board 2/3...
  • Page 129 Document Number Document Number Document Number 6-71-P67R3-D02A 6-71-P67R3-D02A 6-71-P67R3-D02A D02A D02A D02A P650RE P650RE P650RE Date: Date: Date: Monday, July 06, 2015 Monday, July 06, 2015 Monday, July 06, 2015 Sheet Sheet Sheet P670RE USB Board 3/3 B - 77...

  • Page 130: P670Re Led Board

    [77] P670RE LED BOARD Size Size Size Document Number Document Number Document Number 6-71-P67R4-D01 6-71-P67R4-D01 6-71-P67R4-D01 P650RE P650RE P650RE Date: Date: Date: Friday, July 03, 2015 Friday, July 03, 2015 Friday, July 03, 2015 Sheet Sheet Sheet B - 78 P670RE LED Board...

  • Page 131: P655Re Power Board

    Schematic Diagrams P655RE Power Board I3.3VS IJ_BTN1 IM_BTN# FP226H-004S10M PCB Footprint = fp226h-004xxxm_r IGND P655RE D01 I3.3VS POWER BUTTON Sheet 78 of 79 POWER I_SW1 *0_04 *0_04 SWITCH TJE-532-Q-T/R P655RE Power *0_04 *0_04 IM_BTN# 20mil Board *0_04 *0_04 1K_04 PCB Footprint = tje-53x-q 20mil IGND 0.1u_50V_Y5V_06...

  • Page 132: P655Re Led Board

    Schematic Diagrams P655RE LED Board OJ_LED1 OLED_ACIN OD11 OLED_PWR OLED_BAT_CHG OLED_PWR OLED_BAT_FULL 330_04 OR13 330_04 OLED_BAT_FULL Green Green OLED_NUM# RY-SP260UYG24-5M RY-SP260UYG24-5M OLED_CAP# OD10 OD12 OLED_SCROLL# LOT3 O_WLAN_AIRPLANE# OLED_ACIN OLED_BAT_CHG 330_04 OR11 330_04 O_dGPU_LED Amber Amber OSATA_LED# RY-SP260USO24-5M RY-SP260USO24-5M O_GND AC IN/POWER ON LED BAT CHARGE/FULL LED O_3.3VS FP225H-012S10M...

  • Page 133: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 134: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.

Table of Contents
