Format Identifier
B15
B16
B17
B18
B19
B20
<wspec [–] [0] digit[[.]digit]>
<CR>
Defined By
Configuration =00 (not used)
=01 if secondary DSPDIV=1
=10 if secondary DSPDIV=2
=11 if secondary DSPDIV=5
Configuration =00 (not used)
=01 if tertiary* DSPDIV=1
=10 if tertiary* DSPDIV=2
=11 if tertiary* DSPDIV=5
Configuration =000 (not used)
=001 if current DECPNT=888880
=010 if current DECPNT=888888
=011 if current DECPNT=88888.8
=100 if current DECPNT=8888.88
=101 if current DECPNT=888.888
=110 if current DECPNT=88.8888
=111 if current DECPNT=8.88888
Configuration =000 (not used)
=001 if primary DECPNT=888880
=010 if primary DECPNT=888888
=011 if primary DECPNT=88888.8
=100 if primary DECPNT=8888.88
=101 if primary DECPNT=888.888
=110 if primary DECPNT=88.8888
=111 if primary DECPNT=8.88888
Configuration =000 (not used)
=001 if secondary DECPNT=888880
=010 if secondary DECPNT=888888
=011 if secondary DECPNT=88888.8
=100 if secondary DECPNT=8888.88
=101 if secondary DECPNT=888.888
=110 if secondary DECPNT=88.8888
=111 if secondary DECPNT=8.88888
Configuration =000 (not used)
=001 if tertiary* DECPNT=888880
=010 if tertiary* DECPNT=888888
=011 if tertiary* DECPNT=88888.8
=100 if tertiary* DECPNT=8888.88
=101 if tertiary* DECPNT=888.888
=110 if tertiary* DECPNT=88.8888
=111 if tertiary* DECPNT=8.88888
Scale weight Weight for the source scale. wspec is defined as follows:
wspec Indicates whether the weight is the current displayed weight
(W, w), gross (G, g), net (N, n), or tare (T, t) weight. Upper-case
letters specify right-justified weights; lower-case are left-justified.
Optional /P, /S, or /T suffixes can be added before the ending
delimiter (>) to specify weight display in primary (/P), secondary
(/S), or tertiary* (/T) units.
[–] Enter a minus sign (–) to include sign for negative values.
[0] Enter a zero (0) to display leading zeroes.
digit[[.][.]digit]
The first digit indicates the field width in characters – range is 1-7. Decimal point
only indicates floating decimal; decimal point with following digit (range is 1-5)
indicates fixed decimal with n digits to the right of the decimal. Two consecutive
decimals send the decimal point even if it falls at the end of the transmitted
weight field.
- Carriage return, hex 0x0D, ASCII decimal 13
Table 9-5. Custom Stream Format Identifiers (Continued)
Description
Appendix 85
