Kind
WAITSS Wait for standstill. Suspends the batch sequence until the scale is at standstill.
COUNTR Specifies the number of consecutive batch sequences to perform. Counter
setpoints should be placed at the beginning of a batch routine.
AUTJOG Automatically checks the previous weight-based setpoint to verify the setpoint
weight value is satisfied in a standstill condition. If the previous setpoint is not
satisfied when at standstill, the AUTJOG setpoint activates the digital output of
the previous weight-based setpoint for a period of time, specified by the VALUE
parameter. The autjog process repeats until the previous weight-based setpoint
is satisfied when the scale is at standstill.
Note
TIMER Tracks the progress of a batch sequence based on a timer.
The timer value, specified in tenths of a second on the VALUE parameter,
determines the length of time allowed between start and end setpoints. The
indicator START and END parameters are used to specify the start and end
setpoints. If the END setpoint is not reached before the timer expires, the digital
output associated with this setpoint is activated.
CONCUR Allows a digital output to remain active over a specified portion of the batch
sequence. Two types of concur setpoints can be configured:
Type 1 (VALUE=0):
active when the START setpoint becomes the current batch step and remains
active until the END setpoint becomes the current batch step.
Type 2 (VALUE > 0):
value represents the timer, in tenths of a second, for this setpoint. The digital
output associated with this setpoint becomes active when the START setpoint
becomes the current batch step and remains active until the timer expires.
74 880 Installation Manual
Description
The AUTJOG digital output is typically used to signify that an
autjog operation is being performed. AUTJOG should not be
assigned to the same digital output as the related
weight-based setpoint.
The digital output associated with this setpoint becomes
If a non-zero value is specified for the VALUE parameter, that
Table 8-1. Setpoint Kinds (Continued)
Batch Continuous
X
X
X
X
X
