7.3.3

Using Revolution

The Revolution configuration utility provides a print formatting grid with a tool bar. The grid allows you to
construct the print format without the formatting commands (<NL> and <SP>) required by the front panel or EDP
command methods. Using Revolution, you can type text directly into the grid, then select weight value fields from
the tool bar and place them where you want them to appear on the printed ticket.
Figure 7-2 shows an example of the Revolution print formatting grid.
Need New
72 880 Installation Manual
®
Figure 7-2. Revolution Print Format Grid
