Print Format Menu
The Menu items (except for HDRFMT) are listed by the format and the subparameters.
Command
ACC.FMT ACCFMT | FMT
ACC.PORT ACCFMT | PORT
GFMT.FMT GFMT | FMT
GFMT.PORT GFMT | PORT
HDRFMT1 HDRFMT
NFMT.FMT NFMT | FMT
NFMT.PORT NFMT | PORT
SPFMT.FMT SPFMT | FMT
SPFMT.PORT SPFMT | PORT
Note
See Section 7.2 on page 70 for detailed information.
Digital I/O Configuration Menu
Command Menu
DIO.b#s BIT x
Note
Digital inputs and outputs are specified by bit number (b = 1, 2, 3 or 4) and slot number (s = 0 or 1).
Analog Out Menu
Command
ALG.MODE#1 MODE
ALG.OUTPUT#1 OUTPUT
ALG.ERRACT#1 ERRACT
ALG.MIN#1 MIN
ALG.MINNEG#1 MINNEG
ALG.MAX#1 MAX
ALG.MAXNEG#1 MAXNEG
66 880 Installation Manual
Menu
Accumulator enabled and displayed, or setpoint
print operation with PSHACCM=ON
Accumulator print port
Normal mode, no tare in system
Normal mode, no tare in system, print port
Must be inserted into other print format
Normal mode, tare in system
Normal mode, tare in system, print port
Setpoint print operation with PSHPRT=ON
Setpoint print port
Table 6-16. Print Format EDP Commands
OFF, PRINT, ZERO, TARE, UNITS, CLEAR, DSPACC, DSPTAR, NT/GRS, CLRCN,
BATRUN, BATSTR, BATPAS, BATRST, BATSTP, OUTPUT
Table 6-17. Digital I/O Configuration EDP Commands
Menu
Specifies the weight data, gross or net, tracked by the
analog output.
Specifies the output type.
Error action
Minimum value tracked
Specify ON if the minimum weight is a negative value.
Maximum value tracked
Specify ON if the maximum weight is a negative value.
Table 6-18. ALGOUT EDP Commands
Description
Choices / Range
Description
Choices / Range
Alphanumeric, Max Length: 1000
COM, USBCOM, OFF
Alphanumeric, Max Length: 1000
COM, USBCOM, OFF
Alphanumeric, Max Length: 300
Alphanumeric, Max Length: 1000
COM, USBCOM, OFF
Alphanumeric, Max Length: 1000
COM, USBCOM, OFF
Choices / Range
GROSS, NET
0-10V, 0-20MA, 4-20MA
FULLSC, HOLD, ZEROSC
Range: 0 - 999999
OFF, ON
Range: 0 - 999999
OFF, ON
