Command
SP.TRIP#n TRIP
SP.VALUE#n VALUE
BATCHNG BATCHG
Different setpoint parameters are available and accepted depending on KIND, TRIP, and PREACT. These
Note
restrictions are listed below by the EDP command name but the same applies to access by menu.
GROSS, NET, -GROSS, -NET, and %REL type setpoints
SP.KIND#n=GROSS, NET, -GROSS, -NET, or %REL
SP.ACCESS#n
SP.BNDVAL#n (if TRIP INBAND or OUTBAND only)
SP.BRANCH#n (if BATSEQ is ON)
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.HYSTER#n (if TRIP HIGHER or LOWER only)
SP.BATSEQ#n
SP.NAME#n
SP.PCOUNT#n (if PREACT is LEARN only)
SP.PREACT#n (if TRIP HIGHER or LOWER only)
SP.PREADJ#n (if PREACT is LEARN only)
SP.PRESTAB#n (if PREACT is LEARN only)
SP.PREVAL#n (if PREACT is ON or LEARN only)
SP.PSHACM#n
SP.PSHPRT#n
SP.PSHTAR#n
SP.RELNUM#n (for %REL setpoints only)
SP.SENSE#n
SP.SLOT#n
SP.TRIP#n
SP.VALUE#n
WAITSS type setpoints
SP.KIND#n=WAITSS
SP.ACCESS#n
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.NAME#n
SP.PSHACCM#n
SP.PSHPRINT#n
SP.PSHTARE#n
SP.SENSE#n
SP.SLOT#n
Menu
Specifies when the setpoint is satisfied when
compared to value
Setpoint value
Batching enable
Table 6-15. Setpoints EDP Commands (Continued)
Description
PAUSE type setpoints
SP.KIND#n=PAUSE
SP.ACCESS#n
SP.DIGOUT#n
SP.NAME#n
SP.SENSE#n
SP.SLOT#n
DELAY type setpoints
SP.KIND#n=DELAY and AUTJOG
SP.ACCESS#n
SP.CLRACCM#n
SP.CLRTARE#n
SP.DIGOUT#n
SP.NAME#n
SP.PSHACM#n
SP.PSHPRT#n
SP.PSHTAR#n
SP.SENSE#n
SP.SLOT#n
SP.VALUE#n
COUNTR type setpoints:
SP.KIND#n=COUNTR
SP.ACCESS#n
SP.BRANCH#n
SP.DIGOUT#n
SP.NAME#n
SP.SENSE#n
SP.SLOT#n
SP.VALUE#n
SP.KIND#n=TIMER and CONCUR
SP.ACCESS#n
SP.DIGOUT#n
SP.END#n
SP.NAME#n
SP.SLOT#n
SP.START#n
SP.SENSE#n
SP.VALUE#n
Choices / Range
HIGHER, LOWER, INBAND,
OUTBAND
Range:
0 - 65535 (for the COUNTR
and DELAY setpoints)
0 - 999999 (for the GROSS,
NET, and %REL setpoints)
OFF, AUTO, MANUAL
EDP Commands 65
