Rice Lake 880 Technical And Service Manual page 70

Keypad Lock Menu
Command
KEYLCK.GROSSNET GRSNET
KEYLCK.MENU MENU
KEYLCK.PRINT PRINT
KEYLCK.TARE TARE
KEYLCK.UNITS UNITS
KEYLCK.ZERO ZERO
Setpoints Menu
Note
For setpoint commands the "n" symbolizes the setpoint number, 1-20.
Command
SP.ACCESS#n ACCESS
SP.BANDVAL#n BNDVAL
SP.BRANCH#n BRANCH
SP.CLRACCM#n CLRACM
SP.CLRTAR#n CLRTAR
SP.DIGOUT#n DIGOUT
SP.END#n END
SP.HYSTER#n HYSTER
SP.KIND#n Selection made
directly after
dropping down
from SETPT x
SP.BATSEQ#n BATSEQ
SP.NAME#n NAME
SP.PCOUNT#n PCOUNT
SP.PREACT#n PREACT
SP.PREADJ#n PREADJ
SP.PRESTAB#n PRESTB
SP.PREVAL#n PREVAL
SP.PSHACCM#n PSHACM
SP.PSHPRINT#n PSHPRT
SP.PSHTARE#n PSHTAR
SP.RELNUM#n RELNUM
SP.SENSE#n SENSE
SP.DSLOT#n SLOT
SP.START#n START
64 880 Installation Manual
Menu
Locks or unlocks the
Locks or unlocks the
Locks or unlocks the
Locks or unlocks the
Locks or unlocks the
Locks or unlocks the
Table 6-14. Keypad Lock EDP Commands
Menu
Setpoint access in top level menu (user)
Band value
Branch destination
Clear accumulator
Clear tare
Lists all digital output bits available for the
specified SLOT
Ending setpoint number for TIMER and CONCUR
Hysteresis
Supported setpoint kinds
Specifies whether the setpoint is a batch step
Setpoint name string
Preact learn interval (number of cycles before it
learns)
Preact type
Preact adjustment percentage
Preact learn stability
Preact value
Push accumulate
Push print
Push tare
Relative setpoint number
Digital output sense
Digital output slot
Starting setpoint number for TIMER and CONCUR 1- 20
Table 6-15. Setpoints EDP Commands
Description
Gross/Net Key
Menu Key
Print Key
Tare Key
Units Key
Zero Key
Description
Choices / Range
LOCK, UNLOCK
LOCK, UNLOCK
LOCK, UNLOCK
LOCK, UNLOCK
LOCK, UNLOCK
LOCK, UNLOCK
Choices / Range
OFF, ON, HIDE
0 - 999999
0,1-20
OFF, ON
OFF, ON
NONE, BIT 1-4
1- 20
Range:
0 - 65535 (for the COUNTR and
DELAY setpoints)
0 - 999999 (for the GROSS,
NET, and %REL setpoints)
OFF, GROSS, NET, -GROSS,
-NET, %REL, PAUSE, DELAY,
WAITSS, COUNTR, AUTJOG,
TIMER, CONCUR
OFF, ON
Alphanumeric, Max Length: 6
Range: 0 - 65535
OFF, ON, LEARN
Range: 0 – 999999
Range: 0 - 65535
Range: 0 - 999999
OFF, ON, ONQUIET
OFF, ON, WAITSS
OFF, ON
1- 20
NORMAL, INVERT
NONE, SLOT0, SLOT1
