Calibration Menu
Command
SC.WZERO#1 WZERO
SC.WSPAN#1 WSPAN
SC.LC.CD#1 n/a
SC.LC.CW#1 n/a
SC.LC.CZ#1 n/a
SC.REZERO#1 REZERO
SC.WLIN.C1#1 n/a
SC.WLIN.C2#1 n/a
SC.WLIN.C3#1 n/a
SC.WLIN.C4#1 n/a
SC.WLIN.C5#1 n/a
SC.WLIN.F1#1 CAL 1
SC.WLIN.F2#1 CAL 2
SC.WLIN.F3#1 CAL 3
SC.WLIN.F4#1 CAL 4
SC.WLIN.F5#1 CAL 5
SC.WLIN.V1#1 WGT 1
SC.WLIN.V2#1 WGT 2
SC.WLIN.V3#1 WGT 3
SC.WLIN.V4#1 WGT 4
SC.WLIN.V5#1 WGT 5
SC.WVAL#1 WVAL
The menu items, CAL1 – CAL5 are used to do the calibration. A value cannot be keyed in.
Note
The SC.WLIN.Fx#1 EDP commands can be used to view and edit the value but they do not perform the
calibration. Use the SC.WLIN.Cx#1 commands to perform the calibration.
Ports COM Menu
Command
EDP.BAUD#1
EDP.BITS#1
EDP.ECHO#1
EDP.EOLDLY#1
EDP.TYPE#1
EDP.ADDRESS#1
EDP.PRNMSG#1
EDP.RESPONSE#1
EDP.SFMT#1
EDP.STOPBITS#1
EDP.TERMIN#1
EDP.TRIGGER#1
FB.BYTESWAP#1
FB.DEVICENETADDRESS#1 DVCNET
FB.PROFIBUSADDRESS#1
Menu
Perform zero calibration
Perform span calibration
Raw count at zero
Raw count at span
Perform zero caibration
Calibrate linearization point 1
Calibrate linearization point 2
Calibrate linearization point 3
Calibrate linearization point 4
Calibrate linearization point 5
Raw count value for linearization point 1
Raw count value for linearization point 2
Raw count value for linearization point 3
Raw count value for linearization point 4
Raw count value for linearization point 5
Test weight value for linearization point 1
Test weight value for linearization point 2
Test weight value for linearization point 3
Test weight value for linearization point 4
Test weight value for linearization point 5
Test weight value
Table 6-5. CALIBR EDP Commands
Menu
BAUD Port baud rate
BITS Port data bits and parity
ECHO Specifies whether characters received by the
port are echoed back to the sending unit
EOLDLY Port end-of-line delay in 0.1 sec intervals
TYPE Specifies RS-232 or RS-485 communication
ADDRES RS-485 address
PRNMSG Print message
RESPNS Response
SFMT Stream format
STOP B Stop Bits
TERMIN Termination character
TRIGGE Selects the operation of the port.
SWAP Specify byte swap for FB card
Address for DeviceNet option
PRFBUS Address for Profibus option
Table 6-6. PORTS (COM) EDP Commands
Description
Description
Choices / Range
n/a
n/a
-2147483646 to 2147483647
-2147483646 to 2147483647
-2147483646 to 2147483647
n/a
n/a
n/a
n/a
n/a
n/a
-2147483646 to 2147483647
-2147483646 to 2147483647
-2147483646 to 2147483647
-2147483646 to 2147483647
-2147483646 to 2147483647
0.0 - 999999.0
0.0 - 999999.0
0.0 - 999999.0
0.0 - 999999.0
0.0 - 999999.0
0.00001 - 999999.0
Choices / Range
1200, 2400, 4800, 9600, 19200,
28800, 38400, 57600, 115200
8NONE, 7EVEN, 7ODD
OFF, ON
Range: 0 - 255
232, 485
Range: 0 - 255
OFF, ON
OFF, ON
Alphanumeric, max Length: 200
1, 2
CR/LF, CR
COMAND, STRLFT, STRIND,
REMOTE
NONE, BYTE, BOTH
1-64
1-126
EDP Commands 61
