Rice Lake 880 Technical And Service Manual page 66

Scales Menu
Command
SC.ACCUM#1 ACCUM
SC.DFTHRH#1 DFTHRH
SC.DSPRATE#1 DSPRAT
SC.DFSENS#1 DFSENS
SC.GRADS#1 GRADS
SC.MOTBAND#1 MOTBAN
SC.OVRLOAD#1 OVRLOA
SC.PWRUPMD#1 PWRUPM
SC.RANGE1.MAX#1 MAX1
SC.RANGE2.MAX#1 MAX2
SC.RANGE3.MAX#1 MAX3
SC.SMPRAT#1 SMPRAT
SC.SPLIT#1 SPLIT
SC.SSTIME#1 SSTIME
SC.TAREFN#1 TAREFN
SC.THRESH#1 THRESH
SC.ZRANGE#1 ZRANGE
SC.ZTRKBND#1 ZTRKBN
Format Menu
Command
If SPLIT = 2RNG, 3RNG, 2INTVL, 3INTVL
SC.PRI.DECPNT#1 DECPNT1
SC.SEC.DECPNT#1 DECPNT2
SC.TER.DECPNT#1 DECPNT3
SC.PRI.DSPDIV#1 DDIV1
SC.SEC.DSPDIV#1 DDIV2
SC.TER.DSPDIV#1 DDIV3
If SPLIT = OFF
SC.PRI.DECPNT#1 DECPNT
SC.PRI.DSPDIV#1 DSPDIV
SC.PRI.UNITS#1 UNITS
SC.SEC.DECPNT#1 DECPNT
SC.SEC.DSPDIV#1 DSPDIV
SC.SEC.UNITS#1 UNITS
60 880 Installation Manual
Menu
Accumulator
Digital filter cutout threshold
Display Update Rate (in 0.1 sec intervals)
Digital filter cutout sensitivity
Graduations
Motion Band (in divisions)
Overload
Power Up Mode
Maximum weight for first range or interval.
Maximum weight for second range or interval.
Maximum weight for third range or interval.
Sample Rate
Specifies full range, multi-range, or
multi-interval
Stand still time (in 0.1 sec intervals)
Tare Function
Accumulator Zero Threshold
Zero range (in %)
Zero track band (in divisions)
Table 6-3. Scales EDP Commands
Menu
Decimal point location for first range or interval. 888888, 888880, 8.88888, 88.8888,
Decimal point location for second range or
interval.
Decimal point location for third range or
interval. Only available in 3RNG or 3INTVL
Range/Interval (1 division size)
Range/Interval (2 division size)
Range/Interval (3 division size)
Only available in 3RNG or 3INTVL
Decimal point location (for primary units)
Display divisions
Specifies primary units for displayed and
printed weight.
Decimal point location (for secondary units)
Display divisions. (for secondary units)
Specifies secondary units for displayed and
printed weight.
Table 6-4. FORMAT EDP Commands
Description
Description
Choices / Range
OFF, ON
0-99999
1-80
LIGHT,MEDIUM,HEAVY
1 - 100000
0-100
FS+2% FS+1D FS+9D FS
, , ,
GO, DELAY
0.0 - 999999.0
0.0 - 999999.0
0.0 - 999999.0
7.5HZ, 15HZ, 30HZ 60HZ,
,
120HZ, 240HZ, 480HZ, 960HZ
OFF, 2RNG, 3RNG, 2INTVL, 3INTVL
1 - 65535
BOTH, NOTARE, PBTARE, KEYED
0-999999
0.0 - 100.0
0.0 - 100.0
Choices / Range
888.888, 8888.88, 88888.8
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
1D, 2D, 5D
1D, 2D, 5D
1D, 2D, 5D
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
1D, 2D, 5D
LB, KG, OZ, TN, T, G, NONE
888888, 888880, 8.88888, 88.8888,
888.888, 8888.88, 88888.8
1D, 2D, 5D
LB, KG, OZ, TN, T, G, NONE
