SETPTS Menu
Parameter Choices
PCOUNT 1
0–65535
%REL 1–20
BATSEQ OFF
ON
CLRACM OFF
ON
CLRTAR OFF
ON
PSHACM OFF
ON
ONQUIE
PSHPRT OFF
ON
WAITSS
PSHTAR OFF
ON
If two or more of the CLRxxx and PSHxxx parameters are set on, the actions specified by those parameters
Note
are performed in the following order when the setpoint is satisfied: 1) clear accumulator; 2) clear tare; 3)
accumulate; 4) print; 5) acquire tare.
START 1–20
END 1–20
ACCESS ON
OFF
NAME 6ALPHA
SLOT NONE
SLOT 0
SLOT 1
DIGOUT BIT 1-4
BRANCH 0
1-20
SENSE NORMAL
INVERT
46 880 Installation Manual
Preact learn interval. For setpoints with PREACT set to LEARN, specifies the number
of batches after which the preact value is recalculated. The default value, 1,
recalculates the preact value after every batch cycle.
For %REL setpoints, specifies the number of the relative setpoint. The target weight for
this setpoint is the percentage (specified on the VALUE parameter of the %REL
setpoint) of the target value of the relative setpoint
Specifies whether the setpoint is used as a batch (ON) or continuous (OFF) setpoint.
Specify ON to clear the accumulator when the setpoint is satisfied
Specify ON to clear the tare when the setpoint is satisfied
Specify ON to update the accumulator and perform a print operation when the setpoint
is satisfied (uses the accumulator print format). Specify ONQUIE to update the
accumulator without printing.
Specify ON to perform a print operation when the setpoint is satisfied; specify WAITSS
to wait for standstill after setpoint is satisfied before printing.
For AUTJOG setpoints, it will print only once the previous setpoint is
Note
satisfied. Instead of printing the setpoint print format, it will print the
GROSS or NET print format (depends on the type of the previous
setpoint).
Specify ON to perform an acquire tare operation when the setpoint is satisfied.
PSHTAR acquires the tare regardless of the value specified for the
Note
REGULA parameter on the FEATUR menu, and regardless of the
stability.
Specifies the starting setpoint number. Do not specify the number of the TIMER or
CONCUR setpoint itself. The TIMER or CONCUR setpoint begins when the starting
setpoint begins.
Specifies the ending setpoint number. Do not specify the number of the TIMER or
CONCUR setpoint itself. The TIMER or CONCUR setpoint stops when the ending
setpoint begins.
Specifies the access allowed to setpoint parameters shown in the new user menu.
ON: Values can be displayed and changed
OFF: Values can be displayed but not changed
A six character alphanumeric name for the setpoint.
Lists all available digital I/O slots.
SLOT 0 – onboard DIO
SLOT 1 – Option card (if installed)
A slot will only appear if one or more of its indiviual bits are
Note
configured as an output.
Lists all digital output bits available for the specified SLOT. This parameter is used to
specify the digital output bit associated with this setpoint. Use the DIG I/O menu to
assign bit function to OUTPUT.
For continuous setpoints, the digital output becomes active (low) when the condition is
met; for batch setpoints, the digital output is active until the setpoint condition is met.
Specifies the setpoint number to which the batch sequence is to branch if the current
setpoint is not satisfied upon initial evaluation.
The special value zero indicates that no branch is taken.
Specifies whether the state of the digital output associated with this setpoint is inverted
when the setpoint is satisfied.
