COM Menu
Parameter Choices
TRIGGE COMAND
STRLFT
STRIND
REMOTE
BAUD 9600
19200
28800
38400
57600
115200
1200
2400
4800
BITS 8NONE
7EVEN
7ODD
STOP B 1
2
TERMIN CR/LF
CR
ECHO ON
OFF
RESPNS ON
OFF
EOLDLY 000000
TYPE 232
485
ADDRES 0-255
PRNMSG OFF
ON
SFMT format
Menu Structure if TRIGGE is set to REMOTE
TRIGGE REMOTE
BAUD 9600
19200
28800
38400
57600
115200
1200
2400
4800
BITS 8NONE
7EVEN
7ODD
40 880 Installation Manual
Allows opration of EDP commands and can print.
Stream Legal for Trade data – data is updated at the configured display update rate.
Stream Industrial scale data – data is updated at the configured sample rate.
Configures the port to operate as a serial scale input. See "Menu Structure if
TRIGGE is set to REMOTE" below. (Not available in USBCOM)
Port baud rate. (Not available in USBCOM)
Port data bits and parity. (Not available in USBCOM)
Stop Bits – selects the number of stop bits transmitted and the number of stop bits
expected to be received by the port. (Not available in USBCOM)
Termination – selects the termination character(s) for data sent from the port.
Specifies whether characters received by the port are echoed back to the sending
unit.
Response – specifies whether the port transmits replies to serial commands
End of Line – port end-of-line delay, 0.1 second intervals.
Specifies the protocal for the COM port. (Not available in USBCOM)
If TYPE is 485, specifies the RS-485 address. (Not available in USBCOM)
Print message – display a message when a print is transmitted on this port.
Stream format – specifies the stream format used for streaming output of scale data
(TRIGGE=STRLFT or STRIND) or specifies the expected input for a serial scale
(TRIGGE=REMOTE).
Configures the port to operate as a serial scale input.
Port baud rate.
Port data bits and parity.
Table 3-11. COM Menu Parameters
Description
