PORT Menu
Parameter Choices
ETHNET Sublevel
DHCP ON
OFF
IPADRS 000.000.000.000
Valid IP Address
NETMSK 000.000.000.000
Valid Net Mast
DFTGWY 000.000.000.000
Valid IP Address
DNSPRI 000.000.000.000
Valid IP Address
DNSSEC 000.000.000.000
Valid IP Address
PORT 1-65535
10001
RMOTIP 000.000.000.000
Valid IP Address
RMOTPT 1
1-65535
MAC 00.00.00.00.00.00
ECHO OFF
ON
FLDBUS Sublevel
SWAP NONE
BYTE
BOTH
DVCNET 63
1-64
PRFBUS 126
1-126
38 880 Installation Manual
Enables (ON) or disables (OFF) Dynamic Host Configuration Protocal.
Configures the IP address for this device.
Specifies the subnet mask.
Default Gateway.
IP address for the primary DNS server.
IP address for the secondary DNS server.
Port to use for communications on the 880.
Remote IP address – IP address of the remote unit the 880 will connect to.
Remote port – port number on the remote unit the 880 will connect to.
The MAC address for this device, read only.
Specifies whether characters received by the port are echoed back to the sending
unit. Applies to EDP command operation.
Specifies byte-swapping used for the fieldbus card. For DeviceNet cards, this
parameter defaults to BYTE; for all other cards the default value is NONE.
DeviceNet option address
Profibus option address
Table 3-10. PORT Menu Parameters
Description
