REGION Menu, REGULA / INDUST Submenu
Parameter Choices
AUDAG NTEP
CANADA
NONE
OIML

3.2.8 Ports Menu

....
....
PORT Menu
Parameter Choices
COM
USBCOM
ETHNET
FLDBUS
Description
Selects the agency having jurisdiction over the scale site.
• OIML, NTEP, and CANADA modes allow a tare to be acquired at any weight greater
than zero. NONE allows tares to be acquired at any weight value. A tare can be
cleared only if the gross weight is at no load. NONE allows tares to be cleared at any
weight value.
• NTEP and OIML modes allow a new tare to be acquired even if a tare is already
present. In OIML mode, printing is not allowed if the scale is more than -20dd.
In CANADA mode, the previous tare must be cleared before a new tare can be
acquired.
• NONE, NTEP and CANADA modes allow the scale to be zeroed in either gross or net
mode as long as the current weight is within the specified ZRANGE. In OIML mode,
the scale must be in gross mode before it can be zeroed; pressing ZERO in net mode
clears the tare.
The value specified for this parameter affects the function of the front panel TARE and ZERO
keys. See Section 9.5 on page 81
Table 3-9. Region Menu Parameters
....
SETUP
....
PORTS
USBCOM ETHNET
COM
DHCP
See
IPADRS
Figure 3-14
NETMSK
DFTGWY
DNSPRI
DNSSEC
PORT
RMOTIP
RMOTPT
MAC
ECHO
Figure 3-13. Ports Menu Structure
See Figure 3-14
See Figure 3-14
See ETHNET Sublevel below.
See FLDBUS Sublevel below.
for more information.
FLDBUS
SWAP DVCNET
PRFBUS
NONE Address Address
BYTE
number number
BOTH
Description
Configuration 37
