FORMAT Menu
Parameter Choices
If SPLIT = ON
PRI DECPNT
DSPDIV
UNITS
SEC DECPNT
DSPDIV
UNITS
If SPLIT = OFF submenu
DECPNT 888888
888880
8.88888
88.8888
888.888
8888.88
88888.8
DSPDIV 1D
2D
5D
UNITS LB
KG
OZ
TN
T
G
NONE
If SPLIT = 2RNG, 3RNG, 2INTVL, or 3INTVL
DECPT1 888888
DECPT2 888880
DECPT3 8.88888
88.8888
888.888
8888.88
88888.8
DDIV1 1D
DDIV2 2D
DDIV3 5D
MAX1 2000
MAX2 5000
MAX3 10000
UNITS LB
KG
OZ
TN
T
G
NONE
Primary Units
Secondary Units
Decimal Point Location – Specifies the location of the decimal point or dummy zeroes in the
unit display.
Display Divisions – Selects the minimum division for the units.
Units – Specifies units for displayed and printed weight.
LB = pound
KG = kilogram
OZ = ounces
TN = short ton
T = metric ton
G = gram
Decimal Point Location – Specifies the location of the decimal point or dummy zeroes in the
unit display.
Display Divisions – Selects the minimum division for the units.
Maximum weight for first range or interval.
Maximum weight for second range or interval.
Maximum weight for third range or interval.
Units – Specifies units for displayed and printed weight.
LB = pound
KG = kilogram
OZ = ounces
TN = short ton
T = metric ton
G = gram
Table 3-6. Format Menu Parameters
Description
Configuration 31
