Rice Lake 880 Technical And Service Manual page 27

Item No. Part No.
151674
1 131740
2 151663
3 151667
4 131598
5 14822
6 156439
7 14621
8 151668
151672
9 14838
10 65685
11 151664
151665
12 131745
13 153856
14 151661
15 131599
151675
16 152666
152373
156668
156669
17 14822
18 69291
19 131597
20 154762
152235
153647
NS 152334
15888
NS 153873
NS 153883
NS 94422
* Additional parts included in parts kit. See Section 2.1.1 on page 5 for additional parts information.
CAUTION
There is a risk of explosion if battery is replaced by an incorrect type.
Description (Quantity)
Display Assembly, 880 Panel Mount (Includes items 1-7)
Overlay, Membrane Switch
Faceplate, Display 880
Gasket, Faceplate 880
Board Assy, 880 LED Disp.
Screw, Mach 4-40NC x 1/4
Backer, Plate With DIN
Nut, Kep 6-32NC HEX
Cable Assy, Controller to Display
Controller, 880 Panel (Includes items 9-20)
Screw, Mach 6-32NC x 1/4
Washer, Flat .375OD .156ID
Hook, Left DIN Rail Clip
Hook, Right DIN Rail Clip
Bracket, DIN Rail Clip 880
Screw, Mach 6-32NCx1/4
Enclosure, CPU 880
Board Assy, 880 Power, AC
Board Assy, 880 Power, DC
BackPlate, CPU Relay
BackPlate, Relay Option
BackPlate, Analog Option
BackPlate, CompactCom Options
Screw, Mach 4-40NC x 1/4
Battery, 3v Coin Lithium
Board Assy, CPU 880 PNL
Cable Assy, CPU Board To
Parts Kit, AC Power 880 (Includes items below)
Parts Kit, DC Power 880 (Includes items below)
Conn, 3 Pos Screw Terminal (AC Option)
Terminal Block, 3 position (DC Option)
Conn, 3 Pos Screw Terminal
Conn, 6 Pos Screw Terminal
Label, Capacity .40 x 4.63
Table 2-6. Panel Mount Replacement Parts
Qty
Ref
1
1
1
1
4
1
4
1
Ref
2
2
1
1
1
8
1
1
1
1
1
1
1
8
1
1
1
1
1
1
2
1
Installation 21
