Key
Sets the current gross weight to zero.
ZERO
Also used to navigate to different menu levels or used to increment a number when editing a value.
Sends "on-demand" print format out a communications port, provided the conditions for standstill are met. PRINT
PRINT
may be displayed while the unit prints.
Also used to navigate to different menus or to toggle to another digit when editing a value.
Toggles between gross and net. If a tare value has been entered or acquired, the net value is the gross weight minus
GROSS
the tare.
NET
B/N
Gross mode is shown by the Gross/Brutto annunciator; net mode is shown by the Net annunciator.
Also used to navigate to different menu levels or to decrement a number when editing a value.
The MENU key is used to access the user setup menu.
MENU
Acts as the cancel key when editing parameter values.
Acts as an exit when in the setup or user detup menus
Switches the weight display to an alternate unit, defined in the Format menu, see Figure 3-9.
UNITS Units Available: lb, kg, oz, metric ton, ton, gram.
Also used to navigate to different menus or to toggle to another digit when editing a value.
Performs one of several predetermined Tare functions dependent on the mode of operation selected in the TAREFN
TARE
parameter.
Also acts as enter for numeric or parameter entry.
Key
Gross/Brutto LED
Gross
Brutto Gross weight mode (or Brutto in OIML mode)
Net
Net LED
Net weight mode.
0
Indicates that the current gross weight reading is within +/- 0.25 display divisions of the acquired zero, or
is within the center of zero band.
A display division is the resolution of the displayed weight value, or the smallest incremental increase or
decrease that can be displayed or printed.
Scale is at standstill or within the specified motion band. Some operations, including Zero, Tare and
Printing, can only be done when the standstill LED is on.
lb LED
Primary units, pound by default
lb
kg LED
kg
Secondary units, kilograms by default
PT
T LED
Indicates that a tare has been acquired and stored by the system.
T
PT LED
Indicates that a preset tare weight has been keyed in or entered via the EDP serial port.
R1 R2 R3
Not available at time of publication
R1, R2 and R3
Range settings for multi interval or multi range
4 880 Installation Manual
Table 1-1. Key Functions
Center of Zero LED
Standstill LED
Bluetooth
Table 1-2. Annunciator Functions
Function
Function
