OPERATIONAL & MAINTENANCE MANUAL
SEM Model 0201 OMD
REV: 1
Security Engineered Machinery Co., Inc
NATIONWIDE SERVICE
Phone Toll Free 1(800)225-9293
Email:
Service@SEMSHRED.COM
Fax: 1(508)836-4154
Website:
WWW.SEMSHRED.com

Advertisement

Table of Contents
loading

Related Manuals for SEM 0201 OMD

Summary of Contents for SEM 0201 OMD

  • Page 1 Security Engineered Machinery Co., Inc OPERATIONAL & MAINTENANCE MANUAL SEM Model 0201 OMD REV: 1 Security Engineered Machinery Co., Inc NATIONWIDE SERVICE Phone Toll Free 1(800)225-9293 Email: Service@SEMSHRED.COM Fax: 1(508)836-4154 Website: WWW.SEMSHRED.com...

  • Page 2: Safety Procedures

    https://www.supplychimp.com ***IMPORTANT SAFETY PROCEDURES*** Your new CD/DVD shredder incorporates powerful, heavy duty cutting mechanisms, serious and permanent injury may result if proper precautions are not followed. 1. This equipment should never be operated by children or individuals that are untrained or incapable of understanding these safety precautions! 2. Do not reach into the feed opening for any reason! Never insert fingers, hands, other extremities, or objects not meant to be shredded into the feed opening!

  • Page 3: Table Of Contents

    Website: www.semshred.com E-mail: info@semshred.com Order On-line: GSA Customers: www.fedshred.com Commercial Customers: www.semshred.com IMPORTANT Two to three preventive maintenance calls per year are recommended Only authorized SEM service personnel should be allowed to service the shredder. For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 4: Safety Precautions

    https://www.supplychimp.com SAFETY PRECAUTIONS The door must be closed when operating the shredder. Ensure free access to mains. Automatic standby that switches off after 1 hour; green LED control light is off. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 5 https://www.supplychimp.com SAFETY PRECATIONS Cont… Remove plug before cleaning the machine. Do not operate the machine without the safety flap (A). ON/OFF! Quick stop’! Open the door! For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 6 https://www.supplychimp.com SAFETY PRECATIONS Cont… Destroyed CD/DVD material must not be emptied onto the floor. Danger of slipping! For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 7: Installation And Set-Up

    • Put the oil tube into the oil bottle and screw on (C) • Click the tube into the connection (D) Insert the plastic bag in the container. Note: Must use SEM proprietary Anti Static Bag #638ASB0201. If not used static will affect machines performance and may void warranty.

  • Page 8: Operation And Feeding

    https://www.supplychimp.com OPERATION When Using for the first time the oil pump starts automatically: •Press after approximately 30 seconds red blinking (A) disappears. When the oil bottle (B) is changed: •Press the rocker switch “R” until the red LED (A) no longer blinks red. Flashing LED (A): •Cutting shafts are automatically oiled.
  • Page 9 https://www.supplychimp.com OPERATION Cont…. •Press the rocker switch (1.): green light is on, The machine is now ready for operation. •Machine starts automatically when CD/DVD is inserted. (Note: The machine will automatically switch off after one hour and the green LED control light will turn off.) •When the machine is switched off continuous operation can be switched on.
  • Page 10 https://www.supplychimp.com OPERATION Cont…. Stops automatically when door is opened symbols flash alternatively. Stops automatically when plastic bag is full. Enough (half full, because of weight, otherwise it is too heavy to be transported) The “bag full” indicator lights. Stops automatically if too many CD/DVDs are inserted. Automatic reverse if CD/DVDs jam.
  • Page 11 https://www.supplychimp.com OPERATION Cont…. If required: (Jam) Open the safety flap (1.) Remove CD/DVD (2.) Reset by pressing the rocker switch . Re-feed the CD/DVD. For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 12: Troubleshooting

    https://www.supplychimp.com TROUBLESHOOTING Machine will not start. Is the machine plugged in? Is the rocker switch pressed? Is the green light rocker switch ON? (1) Feed only one CD/DVD at a time into the opening (2). For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 13 https://www.supplychimp.com TROUBLESHOOTING Cont…. Feed the CD/DVD into the center of the feed opening. (photo cell) (A) Is the door open? Is the container half full? Note: Container will not fill all the way this is a factory setting. If filled completely then container would be to heavy.
  • Page 14 https://www.supplychimp.com TROUBLESHOOTING Cont…. Machine will not stop. Unplug from the main. Clean the photo cell (A) with a small brush or Q-tip with isopropyl (rubbing alcohol) By continuous operation press or “R” switch off. Machine stops. Symbols and “R” flash alternatively. •...
  • Page 15 https://www.supplychimp.com TROUBLESHOOTING Cont…. None of the above mentioned methods helped To solve the problem: Contact our Customer Service at 1(800)225-9293 For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 16: Accessories

    https://www.supplychimp.com ACCESSSORIES Environmentally friendly oil (4 gallons) Part # 647OILHV Proprietary Anti-Static Plastic Bags (50 pieces) Part # 638ASB0201 For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 17: Technical Information

    https://www.supplychimp.com TECHNICAL INFORMATION Do not shred paper clips. Do not destroy Paper. This machine is approved by independent safety laboratories and is in compliance with the EC-regulations 98/37/EG, 2006/95/EG and 2004/108/EG. Since 1/29/09 will be replaced by 2006/42/EG from12/29/2009 Sound Level Information: The sound level at the work place is less than the ISO 7779 standard’...

  • Page 18: Spare Parts List

    https://www.supplychimp.com Parts List For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 19 https://www.supplychimp.com Parts List Cont…. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 20 https://www.supplychimp.com Parts List Cont…. Parts List Cont…. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 21 https://www.supplychimp.com Parts List Cont…. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 22 https://www.supplychimp.com Parts List Cont…. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 23 https://www.supplychimp.com Parts List Cont…. For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 24: Wiring Diagram

    https://www.supplychimp.com Wiring Diagram For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 25 https://www.supplychimp.com Wiring Diagram Cont….. For NATIONWIDE SERVICE Call 1(800)225-9293...
  • Page 26 https://www.supplychimp.com Wiring Diagram Cont….. For NATIONWIDE SERVICE Call 1(800)225-9293...

  • Page 27: Warranty Information

    SEM PRODUCT WARRANTY SEM warrants, for a period of time listed below from date of shipment, that product will be free from defects in material and workmanship when used under normal operating conditions. Excluded from warranty coverage are normal wear items and electrical components.
