Excell ZSME300000240 User Manual

Weighing scale 4key & 5key
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Weighing Scale
4key & 5key

User manual

© EXCELL PRECISION CO., LTD. 2014. All rights reserved worldwide.
The information contained herein is the property of EXCELL PRECISION CO., LTD. and is
supplied without liability for errors or omissions. No part may be reproduced or used except
as authorized by contract or other written permission. The copyright and the foregoing
restriction on reproduction and use extend to all media in which the information may be
embodied.

Advertisement

Table of Contents
loading

Related Manuals for Excell ZSME300000240

Summary of Contents for Excell ZSME300000240

  • Page 1: User Manual

    User manual © EXCELL PRECISION CO., LTD. 2014. All rights reserved worldwide. The information contained herein is the property of EXCELL PRECISION CO., LTD. and is supplied without liability for errors or omissions. No part may be reproduced or used except as authorized by contract or other written permission.

  • Page 3: Table Of Contents

    EXCELL PRECISION CO., LTD. Table of Contents INSTRUCTIONS FOR USE ....................2 PREPARING TO USE THE SCALE ..................2 CHAPTER 1 INTRODUCTION ....................4 1-1 P ..................4 RODUCTION NTRODUCTION 1-2 D ....................4 ISPLAY ESCRIPTION 1-3 K .................5 EYPAD UNCTIONS ESCRIPTION 1-4 P ....................5...

  • Page 4: Instructions For Use

    EXCELL PRECISION CO., LTD. Thank for your purchasing of our EXCELL Weighing Scale. To guide you to use our product correctly, please read this User Manual carefully to extend the life of machine and to avoid error. Instructions for Use 1.
  • Page 5 EXCELL PRECISION CO., LTD. Due to the storage battery adopt the advanced free-maintaining technique, customers need not to replenish electrolyte. The scale should be recharged every 3 months to prevent failure of the internal rechargeable battery. 1. The battery should be charged for 8~10 hours.

  • Page 6: Chapter 1 Introduction

    EXCELL PRECISION CO., LTD. Chapter 1 Introduction 1-1 Production Introduction 1. High performance A/D converter • 0.3 uv/D high sensitivity • zero point adjustable range -2mV~ +5mV • Sampling speed 15 times/second • use range -4mV ~ +30mV • non-linear scale 0.01% full scale •...

  • Page 7: Keypad Functions Description

    EXCELL PRECISION CO., LTD. 1-3 Keypad Functions Description 4-key model has no key. Press this key to zero the scale. Press this key to tare (deduct the container weight) Net/Gross key Press this key to print Press this key to select the required unit from the preset units...

  • Page 8: Error Messages

    EXCELL PRECISION CO., LTD. Low Power Alarm Please note when the ( ) symbol keeps flashing on the left down corner of the display, the batteries should be recharged. The scale will turn off automatically after a few hours when the low battery warning symbol shows up.

  • Page 9: Chapter 2 General Operation Description

    EXCELL PRECISION CO., LTD. Chapter 2 General Operation Description 2-1 Units Selection ( ) (only for the model “5key”) Press key to select the units “kg” and “lb”. The selected unit will be memorized when you turn the scale off. And the memorized unit will appear after you turn on the scale next time.

  • Page 10: Backlight Function

    EXCELL PRECISION CO., LTD. 2-5 Backlight Function ＜Method 1＞ Press key, the display shows “CEntr”. At this time, press key to select backlight mode. There are auto backlight mode(The display shows “BL.Auto” ), backlight on mode( The display shows “BL. on” ) and backlight off mode ( The display shows “BL.

  • Page 11: Chapter 3 General Function Setting

    EXCELL PRECISION CO., LTD. Chapter 3 General Function Setting ♦ Switch on the scale. While the scale is counting down to zero, press and hold until the display shows the software program version number Release the key, the scale enters into the configuration setting mode and is showed on the display.

  • Page 12: Check Weighing Configurations

    EXCELL PRECISION CO., LTD. ⇒ Check Weighing Configurations ♦ If hold mode is set, accessing to is denied. key to select F4 function ⇒ the display shows Press key for 5 Press times to clear HI, OK, Press LO values Preset “LO value”...

  • Page 13: Rs-232 Interface Output Setting (Option)

    EXCELL PRECISION CO., LTD. ⇒ RS-232 Interface Output Setting (option) key to select F5 function ⇒ the display shows key = Increase the flash value by one (from 0 to 10) or Press selecting baud rate from 1 200, 2 400,4 800 and...
  • Page 14 EXCELL PRECISION CO., LTD. RS-232 Interface Format I . Mode: UART Signal of EIA-RS0232 C II . Format : 1. Baud rate : 1 200, 2 400, 4 800, 9 600 bits/second 2. Data bits : 8 bits 3. Parity bit : None 4.
  • Page 15 EXCELL PRECISION CO., LTD. HEAD1 ( 2 BYTES ) HEAD2 ( 2 BYTES ) OL - Overload , Under load TR - TARE Mode ST - Display is Stable NT - NET Mode US - Display is Unstable GS -...
  • Page 16 EXCELL PRECISION CO., LTD. Press key to transmit (simple mode) WT/UNIT ( kg / lb ) - - - - - - - - - - - - - - 0001 1.0000 Press 0002 1.0000 Press 0003 1.0000 Press 0004 1.0000...
  • Page 17 EXCELL PRECISION CO., LTD. Stable Transmission (totalizing mode) WT/UNIT ( kg / lb ) - - - - - - - - - - - - - - 0001 1.0000 The scale is stable 0002 1.0000 The scale is stable 0003 1.0000...
  • Page 18 EXCELL PRECISION CO., LTD. Then the printing form is: FR”WT3N ” 1,200 0,700 0,300 0,200 000020001000000020 P1,1 key twice to clear the format Then, form of clearing the printing “ “ <LF> ? <LF> TN TN TN <LF> TW TW TW TW TW TW <LF>...

  • Page 19: Exit Setting Mode

    EXCELL PRECISION CO., LTD. ⇒ Exit Setting Mode key to select F6 function ⇒ the display shows Press Counting down to zero and exit setting mode ⇒ Internal Value Display Mode key to select F7 function ⇒ the display shows...

  • Page 20: Gvalue Calibration

    EXCELL PRECISION CO., LTD. ⇒ G value Calibration key to select F10 function. ⇒ The display shows key or You can input at most 9 sets of G value’s data. The historic data can be found out and not to be revised.

  • Page 21: Id Code Setting

    EXCELL PRECISION CO., LTD. ⇒ ID Code Setting ， ， (Use must be in coordination with key to select F11 function ⇒ the display shows key or Press Machine ID code setting: Press to set 01 ~ 99 Default setting: 00 (1) “00”: RS-232 does not transmit Machine ID...

  • Page 22: Print Key ( ) Function Setting

    EXCELL PRECISION CO., LTD. ⇒ Print Key ( ) Function Setting key to select F12 function ⇒ the display shows key or Press to set 0 ~ 2 Default setting: 0 Press ⇒ Press key to print current weight if weight variation is within ±1d ~ ±10d, or to print accumulated weight if weight variation is over ±10d.

  • Page 23: Printing Orders When Is Set As

    EXCELL PRECISION CO., LTD. ⇒ Printing orders when is set as No.0 No print. No.1 TICKET NO. No.2 No.3 No.4 No.5 No.6 No.7 No.8 No print No.9 No print Contains a 9-digit code is set as The format of is as following...
  • Page 24 EXCELL PRECISION CO., LTD. is set as The format of is as following P/N 012345678901 TICKET NO. 0001 75.01kg 0.00kg 0.00kg 75.01kg WT/UNIT ( kg / lb ) - - - - - - - - - - - - - - 0001 1.0000...

  • Page 25: Appendix 1 7-Segment Display Characters

    EXCELL PRECISION CO., LTD. Appendix 1 7-Segment Display Characters Number Display Letter Display Letter Display ℃ 02018058 ZSME300000240...
