SONOST 3000
User's Manual
Model: SONOST 3000
Council Directive 93/42/EEC Concerning Medical Device
http://www.osteosys.com
OsteoSys Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SONOST 3000 and is the answer not in the manual?

Questions and answers

Related Manuals for OsteoSys SONOST 3000

Summary of Contents for OsteoSys SONOST 3000

  • Page 1 SONOST 3000 User’s Manual Model: SONOST 3000 Council Directive 93/42/EEC Concerning Medical Device http://www.osteosys.com OsteoSys Co., Ltd.

  • Page 2: Model Designation: Sonost

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL SONOST 3000 User’s Manual Manufacturer and EC Authorized Representative Information ♣ Manufacturer: OsteoSys Co., Ltd. 901-914, 9F, JnK Digitaltower, 111 Digital-ro 26, Guro-gu, Seoul 152-848, Republic of Korea info@osteosys.com...
  • Page 3 OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Thank you for purchasing SONOST 3000 Ultrasound Bone Densitometer. To ensure safe operation and long-term performance stability, it is essential that you fully understand the functions and operating, maintenance instructions by reading this manual before operating the equipment.
  • Page 4 OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL The symbols which are shown in this manual or SONOST 3000 The noticed information which should be concerned with explanation in this manual The noticed information when the device is operated...
  • Page 5 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL The protecting device from external electromagnetic wave. This device can be affect from external electromagnetic wave which is related to precision and operation. When you using this device, we strongly recommend you, avoid from other device from protect electromagnetic wave.
  • Page 6 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL (3) Cautions for Storage - Do not apply excessive force when connecting or disconnecting cables. - Auxiliary devices should be maintained clean, in working conditions. - Devices should be positioned in their proper positions, so as not to interfere with worker or patient movement.
  • Page 7 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Guidance and manufacturer’s declaration – electromagnetic immunity The model SONOST-3000 is intended for use in the electromagnetic environment specified below. The customer or the user of the model SONOST-3000 should assure that it is used in such an environment.
  • Page 8 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Guidance and manufacturer’s declaration – electromagnetic immunity The model SONOST-3000 is intended for use in the electromagnetic environment specified below. The customer or the user of model SONOST-3000 should assure that it is used in such an environment.
  • Page 9 For use safely, you must use part of device which supplied or approved from Osteosys. NOTE ! If you use part of device which is not approved from Osteosys, we do not guarantee safety to user. Moreover, it become dangerous and errors and wrong results to users or patients. In this case, user has responsibility.
  • Page 10 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL The exchange and using period of expandable goods The period for The method of exchange Name Part number exchange expandable products FOOT SUPPORTER 0 : 10years...

  • Page 11: Table Of Contents

    2.1.1 Shape and Components of Device ..............15 2.1.2 Accessories List ....................1 6 2.1.3 Articles List ...................... 17 Chapter 3. Using SONOST 3000 ....................20 3.1. Daily Test ........................20 3.1.1 Preparation ......................20 3.1.2 Daily Test Procedure .................... 21 3.2 Shutting down processing ....................
  • Page 12 3.5.5 Patient search and delete ................. 7 5 3.5.6 Searching, erasing and printing the result about patients' disease history ..7 8 Chapter 4. Maintenance and Repair of SONOST 3000 .............. 80 4.1 Resolution to Problems ....................80 4.2 Maintenance and Repair ....................81 4.2.1 Cleaning, Disinfection, Sterilization.

  • Page 13: Chapter 1. Introduction

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Chapter 1. Introduction Osteoporosis is one of the serious diseases. This device is a bone densitometer which estimates a bone mineral density of the calcaneus by ultrasound.
  • Page 14 - When you give the appropriate commands in SONOST 3000 software, ultrasonic waves are generated. The generated ultrasonic waves pass through the Patient’s calcaneus and the electric signal is treated by SONOST 3000 algorithm. - All operators must understand the potential hazards in the use of medical electronic devices.

  • Page 15: Chapter 2. Configuration Of Device

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Chapter 2. Configuration of Device 2.1 Composition of Device 2.1.1 Shape and Components of Device Name Function TOP COVER Protection for internal circuit CALF SUPPORTER Leg fixation for diagnosing...

  • Page 16: Accessories List

    NOTE ! Use Accessory which defined at user‘s manual. 2.1.2 Accessories List Check the following accessories before installing the system. If they are not in good condition, contact to OsteoSys or its authorized dealer for this service. Names of Number...

  • Page 17: Articles List

    DOC. No. : OT06-2R0423-06-MUL 2.1.3 Articles List Check the following accessories before installing the system. If they are not in good condition, contact to OsteoSys or its authorized dealer for this service 4.2.3 Stockpiles and Replacement of Articles Names of Products...

  • Page 18: A4(210

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 2.2 Installation of SONOST 3000 NOTE ! Since SONOST3000is made up of precise components, you should install the product according to instructions below. Do not install and keep SONOST3000 at Do not install or keep SONOST3000 in the excessively high or low temperatures.
  • Page 19 - If you find any damage or any sign of it, immediately contact an agency. - Put the Power cord into only oneplug. - Make sure not to share the power outlet to prevent SONOST 3000 from being affected. １９ A4(210 × 297)

  • Page 20: Chapter 3. Using Sonost 3000

    DOC. No. : OT06-2R0423-06-MUL Chapter 3. Using SONOST 3000 3.1. Daily Test The SONOST 3000 system is checkedusing the daily test. The daily test should be performed at least once a day, before patient’s measurements. 3.1.1. Preparation SONOST 3000 device, Phantomand ultrasound transmission gel Dailytest Recommendation ...

  • Page 21: Daily Test Procedure

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.1.2. Daily Test Procedure  Phantom’s value checking Switch on the device and the main screen appears after booting up. Select “setup” button to check the value of phantom.
  • Page 22 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL  Phantom’s setting Apply the ultrasound transmission to the phantom to the area which will be in contact with both probes when the phantom is on the foot rest. The amount of the gel should be same as the area of the phantom in contact with the probe.
  • Page 23 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL  Perform the dailytest Press the DailyTest button The Daily test should be done if the color of button is red. When the daily test is finished, red colored character will be disappear.

  • Page 24: Shutting Down Processing

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL The following images are the execution screen of the daily test. “Complete Daily Test” appears when the daily test is done. Complete the process of <the daily test> by pushing the “OK” button.

  • Page 25: Position Of Shutdown Button

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.2.1 Position of Shutdown button The shutdown button is located as below 4 screens. ① Main screen ② Patient screen ③ History screen ④ History detail screen ２５...

  • Page 26: Shutting Down Processing

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.2.2 Shutting down processing Click shutdown button Click [OK] Waiting until the black or blue screen appear Turning off the main switch of the system ２６...

  • Page 27: The Analysis Of How To Rotate The Screen

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3 The analysis of how to rotate the screen The procedure of rotate the screen is as below NOTE ! This function is applicated some devices. The adopted device’s serial number is start from AC1TA.

  • Page 28: The Method And Sequence Order Of The Screen Rotation Button

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3.2 The method and sequence order of the screen rotation button Press the screen rotation button on the top right side of the screen Press the confirm button.

  • Page 29: Using H/W

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3 Using H/W 3.3.1 Patient Measurement Procedure Clean the surface of the Coupling Pad with an alcohol pad and apply sufficient gel to probes. Clean the both side of patient’s heelwith an alcohol pad and apply gel.

  • Page 30: Selection Of The Foot Supporter

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3.2Selection of the foot supporter Put the foot supporter according to the below guide. The section is arranged for each size of the foot. If the foot of patient is belong to * Section 1 : use only foot supporter 1.

  • Page 31: Where And How Much Apply To The Patient's Heel

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3.3 Where and How Much Apply to the Patient’s Heel Before measuring, use alcohol to rub patient’s heel : this provides protection for removing air bubbles surface of patient’s skin and other infections.

  • Page 32: Correct Position For Patient's Foot & Body

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3.4 Correct position for Patient’s foot & body Place heel in the unit as shown in the 3 points below. Make sure measuring device and body should be one line as shown below.

  • Page 33: Osd (Auto Screen Alignment)

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.3.5OSD (Auto screen alignment) The size and position of LCD screen is adjusted automatically by pushing the button on the LCD cover. 3.3.6 Setting of Internal Printer - Paper type : Thermal paper width 58mm.
  • Page 34 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 2) Paper inserting : Insert the paper as shown below.Outer surface ofpaper shouldface to the inside of the device. Paper isscrolled in automatically. 3) Cover shutting : Put the paper to the gap in the cover, then shut thecoverup.

  • Page 35: Using S/W

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4 Using S/W 3.4.1 Progress Table of Program ３５ A4(210 × 297) OT06-2R0423-06...

  • Page 36: Execution Of Program

    DOC. No. : OT06-2R0423-06-MUL 3.4.2 Execution of Program CAUTION ! If you hear any strange noise from the screen, switch it off and contact to OsteoSys or its Authorized dealer. Turn on the power switch. 10 seconds after calibration that checks functions of the system and memory device, the program is automatically activated and you should configure the incipientenvi- onment.

  • Page 37: Setting Of The Incipient Environment

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.3 Setting of the Incipient Environment Click the <Setup>button on the Home Screen, then environment window is appeared. 'Setup' Window - <Settings> : Fundamental settings related Software.
  • Page 38 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL System It makes settings related Operating System. Setup>System Window - System Date/ Time: Present time setting. It becomes standard for patient’s registered date, measured date and printed date.
  • Page 39 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL - Query :You should input some conditions which are get information about patients from the worklist server.When you input modality in Query should be the same as the modality in worklist server.
  • Page 40 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Backup It controls the measured data. ※ If a USB memory has many files and folders , the speed of recognition of the USB memory could be lower. Connect a USB memory after empty.
  • Page 41 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL - Clear : If you click this button, you can clear data. Setup>Backup>Clear Window ∙All : Clear all data. ∙By period : Clear data within a selected period of time.
  • Page 42 : setup.exe) to USB removable disk. Insert USB removable disk into SONOST 3000 device’s USB port. Select [Setup>Patch>Exit to Windows] for close the program. Execute the setup.exe in the setup folder of USB memory stick.

  • Page 43: Measurement Of Bone Mineral Density

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.4 Measurement of Bone Mineral Density Selection of BMD and GDP - Pediatry mode : when you want to get the result and graph of Pediatry BMD and GDP (growth rate factor) for under 20 years old.
  • Page 44 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Patient Registration If you click the <patient>button on the top line at the incipient screen, you can move to “Patient List” which display and control the registered patient Left list mean registered patient’s birth year.
  • Page 45 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL - Height : Input the height of patient. - Weight : Input the weight of patient. - Father’s H. : Input the height of patient’s father. (it is disabled on BMD mode) - Mother’s H.
  • Page 46 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Measurement of Patients If you want to measure the patient’s Bone Density, select a desired patient in the Patient List screen and click the <Measure>button. Then the “Measure” screen appears as shown below.
  • Page 47 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Select Site Window When ultrasound waves are generated, the <Start>button is changed into <Stop>button. In case of emergency, click this button, and you can stop measuring. In the normal condition, ultrasound waves generation is finished about 15 seconds after, then the “Measure Complete”...
  • Page 48 DOC. No. : OT06-2R0423-06-MUL Pediatricfunction Accessory is arranged for more convenience of pediatric measurement. If you want to purchase below item, contact to Osteosys. - Top cover for Pediatry - Foot supporter for Pediatry If you want to view the graph of pediatry for children, select Activate Pediatry button in setup window.
  • Page 49 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL ※Current Height and Predicted adult height [History View] [Detailed Result View] ※Weight [History View] [Detailed Result View] ※BMI [History View] [Detailed Result View] ４９ A4(210 × 297)

  • Page 50: Revision And Deletion Of Patient's Information

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL ※When [Activate BMD] is selected. [History View] [Detailed Result View] 3.4.5 Revision and Deletion of Patient’s Information Revision of Patient’s Information If you want to revise the registered patients’ information, select a desired patient and click the <Modify>button on the bottom.
  • Page 51 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Deletion of Patient’s Information If you want to delete the registered patients’ information, select a desired patient in the “Patient List” screen and click the <Delete>button on the bottom.
  • Page 52 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Worklist - Giving a test to someone who is already registered on the system. After selection of patient from the list, you can take a test or see the disease history from <Disease history>...

  • Page 53: Inquiry And Deletion Of Clinical History Of Existing Patients

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.6 Inquiry and Deletion of Clinical History of Existing Patients Inquiry of Clinical History of Existing Patients If you want to retrieve the clinical history of existing patients, select a desired patient and click the <History>button on the top of the “Patient List”...
  • Page 54 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Detailed Representation of Clinical History of Existing Patients If you click the <Detail>button on the “History List” screen, the detailed result of the selected patient appears in the full screen.

  • Page 55: Dailytest Of Sonost 3000

    OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.7 DailyTest of SONOST 3000 DailyTest Make sure to calibrate the system to reduce a margin of error and to get accurate value in times of examining bone density. It is to raise credibility of examination results through checking of system reliability on a daily basis.
  • Page 56 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL NOTE ! In case of the screen shows the calibration has failed, do not use the system and execute “DailyTest” once again. If calibration fails continually, contact to OsteoSys or its authorized dealer.

  • Page 57: Printing Of Clinical History And Result

    Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.8 Printing of clinical history and Result SONOST 3000 support inner printer(thermal printer) and external printer(normal USB printer). (If the selected model is exclusive use of external printer. Inner printer will not be provided.) Inner Printer (Thermal Printer) Inner printer is affixed on the device back inside.
  • Page 58 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL External Printer (Normal Printer) Available printer : All USB printer supporting Windows XP driver. For the installation of printer driver, exit program (Setup > Patch > Exit to Windows) Copy the printer driver to USB memory stick.
  • Page 59 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL You can find the installed printer above and check it default printer (default printer : printer with checked mark) If you want to change the default printer, select the printer and then choose [File] –...

  • Page 60: Customize The Logo In Printing

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.9 Customize the logo in printing Make the bitmap filesfor the color printing and gray printing as 272 px X 70 px X 24 bit. 70px 272px Give the name and extension name to bmp (ex: NHIC_C.bmp, NHIC_G.bmp)

  • Page 61: The Function Of Shot Count

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.10 The function of Shot Count Connect USB keyboard or PS/2 keyboardto the device. At Home screen push the button “Ctrl + Alt + C” simultaneously.

  • Page 62: Setup The Worklist

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.11 Setup the worklist Connect to worklist In terms of Worklist, it makes database from people who checked through this device. This database saved in the hospital server. Later, you can get this information from the PC which is connecting to server.

  • Page 63: Setup And Sending Function Of Pacs

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.4.12 Setup and sending function of PACS PACS requirements ∙ USB Ethernet Adapter ∙ You should get specification IP, Serve net mask, basic gateway from hospital network.
  • Page 64 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL When you connect to PACS network in hospital, you should choice Local area. Next, click the right side of mouse on ‘properties’. If you see message, you should choice Internet Protocol(TCP/IP) and click the ‘properties’...
  • Page 65 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL You should press the start and command button for connect to PACS server in hospital. When Command board appeared, you should input CMD. Next, you can see DOS mode.
  • Page 66 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL This pictures figure the same as Worklist server control, when you input IP, Port, Atitle which are bring from server manager in hospital. - Sending PACS After move on to ‘list of patients’, you can see ‘disease history’...
  • Page 67 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL The alarming message whether when sending disease history to server success or not. Sending successfulSending failure When it comes to sending failure message, you should check below parts.

  • Page 68: The Method Of Data Manager S

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.5 The Method of Data manager S/W 3.5.1Program operation process Configuration Start Export Clear Backup Home Import Patient Information Patient List Print Result Delete Patient Search Patient...

  • Page 69: Start To Program

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.5.2 Start to program You can operate the program, when you click "SONOSTO 3000 DM" on the screen or on the srart button. Home screen Screen is consist of 4 buttons and <Information> button which is you can show software information.

  • Page 70: Program Setup

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.5.3 Program Setup You can setup this program - Hospital name : you can input name. This information, when you printer you port, you can see it.

  • Page 71: Backup

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.5.4 Backup This function is if you send data to others such as USB memory stick, Printer and MS Excel file or get from USB memory stick, or delete the data.
  • Page 72 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Export This function is data saved in PC and export to other device. You can export to USB memory stick, it can be send data to other PC and device.
  • Page 73 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL * When you export data to USB memory stick, you should choice the version correctly. If it is transfer data between data manager, it will be no problem. However, if it is transfer data between device, you must check and make the same version.
  • Page 74 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Clear This is delete data in PC Clear window Clear window are divided by two which are range set up and delete the patients’ information set up.

  • Page 75: Patient Search And Delete

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Import This function is get data from USB memory stick to PC. Import window You can choice the data from SELECT and then click <OK> button. The contents in list of SELECT are when it exported on time and range.
  • Page 76 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Search the Patient If you click <Patient Search> on “Patient List” window, you can see “Search Patient” window Search Patient window You should input information correctly, and click <OK> button. It can show you Search Result window and then find the patient Doing search, if you find the result, you can stop search through click <Stop Search>...
  • Page 77 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL After, select the patient, click <OK> button, you can choice the patient on the “Patient List” window Delete the patient's info If you want to delete patient, you should click <Patient Delete> button on “Patient List”...

  • Page 78: Searching, Erasing And Printing The Result About Patients' Disease History

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 3.5.6 Searching, erasing and printing the result about patients' Disease history Searching Patients’ disease history When you search about patients’ disease history, you should choice patient on the 'Patient List' screen.
  • Page 79 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Print out the result sheet There are two type of result sheet. One of them is disease history result sheet. The other one is normal result sheet. If you click <Print> button in the left side, you will get disease history result.

  • Page 80: Resolution To Problems

    Is the desired part of the body properly placed? Despite measurement according to the instructions, its result turns 4.2.1. Cleaning, Disinfection, out to be abnormal Sterilization CAUTION ! If you cannot resolve the problem, contact to OsteoSys or its authorized dealer. ８０ A4(210 × 297) OT06-2R0423-06...

  • Page 81: Maintenance And Repair

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 4.2 Maintenance and Repair 4.2.1 Cleaning, Disinfection, Sterilization. CAUTION ! Turn off the power before cleaning the device. Product Instructions After using the device, wash with Alcohol swap.

  • Page 82: Product's Life

    - Unplug the power cord. - Put cover on the product to avoid dust. Storage - Keep the product according to instructions described in “2.2 for a Installation of SONOST 3000” long time period 2.2 Installation of SONOST 3000 ８２ A4(210 × 297) OT06-2R0423-06...

  • Page 83: Safe Use Of Sonost 3000

    OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 4.3 Safe Use of SONOST 3000 4.3.1 Safety Rules The followings are instructions for safe use of the product Make sure to comply with the instructions when you activate the system.

  • Page 84: Cautions Related To Use Electronic Medical Equipment

    １ Nobody can handle SONOST 3000 except for doctors and authorized personnel ２ Comply with followings in times of installation of SONOST 3000. Do not install it in following places. A) Places where the product is exposed to water vapor B) Places where the product is exposed to spray or splashing water.
  • Page 85 OsteoSys or its authorized dealer for assistance. G) Before electrically or mechanically connection any other manufactures’ devices to SONOST 3000, contact OsteoSys or its authorized dealer for instructions H) Do not operate the product improperly when you use it with other products.
  • Page 86 Otherwise, abnormal images may result. An independent circuit and a safely grounded outlets are strongly recommended for SONOST 3000. Poor or abnormal images may occur if the system shares a power source with other electrical or electronic equipment.
  • Page 87 E) Make sure to clean the product so that users can use it immediately ６ If the product is out of order, do not try to repair it for yourself. ７ Do not modify use the product. If any modification is desired, ask OsteoSys or its authorized dealer for this service.

  • Page 88: Chapter 5. Specifications & Software Updates

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Chapter 5. Specifications & Software Updates 5.1 Specifications *General Classification Class Ⅰ , Type BF Applied part *Device Dimensions 615mm× 293mm× 310mm Weight 15Kg AC 100V ~ 240V,...
  • Page 89 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL *Environmental 15 ~ 30℃ Operating Temperature Transport / Storage Temperature -10 ~ 70℃ 30 ~ 75% relative humidity Operating Humidity Transport / Storage Humidity 0 ~ 90% relative humidity, non-condensing...

  • Page 90: Software Updates

    Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 5.2 Software Updates 1. Updates to SONOST 3000 software are irregular, we will inform you through your email whenever SONOST 3000 software needs to be updated. 2. For details, call the OsteoSys Co., Ltd customer service department or your OsteoSys Co., Ltd distributor.

  • Page 91: Chapter 6. Reference

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL Chapter 6. Reference 6.1 Definition of Parameter Terminology  BUA(Broadband Ultrasound Attenuation) Parameter which reflect bone density and structure by reduction analysis of ultrasound pulse intensity which through the bone.
  • Page 92 User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL For example, Person in T<-3 exist 1.35 ratio of 1,000 persons in whole population.  Z-Score Average BQI in the same age, that is BQI standard deviation in the same age.

  • Page 93: Reference Data

    User’s Manual (Confidential) OsteoSys Co., Ltd. Model Designation: SONOST 3000 DOC. No. : OT06-2R0423-06-MUL 6.2 Reference Data  Reference Data We achieved reference data from several group with different environment in Korea. And the data is analyzed by statistical method.

  • Page 94: Chapter 7. Product Warranty

    (4) Cosmetic defects or deterioration will not be refinished or replaced. The costs of replacement of fuses are not covered. (5) OsteoSys Co., Ltd. will not be responsible for any loss, damage, or injury resulting from delay in rendering service under this warranty.
  • Page 95 OsteoSys Co., Ltd. will replace the defective product at no cost to you. OsteoSys Co., Ltd. will pay the shipping and insurance costs of product sent to you.
