3 SNZ button (snooze function)
5 ALARM button (Alarm setting)
7 UP button (Value setting upwards)
9 Battery compartment cover (Base station)
11 Display (Remote sensor)
13 Battery compartment (Remote sensor)
15 °C/°F button (temperature format setting)
17 Stand, fold-out
Scope of delivery
Base station (A), remote sensor (B)
Recommended batteries (not included)
4 pcs. Micro batteries (1.5V, AAA type)

6 Screen display

1
19
18
17
16
Illustration 2: Screen display for base station (left) and remote sensor (right)
1 AM/PM information in 12-hour time mode
3 Symbol for active alarm
5 Symbol for active daylight saving time (DST)
7 Graphical weather trend display
9 Battery level indicator (Base station)
11 Indoor humidity value
13 Indoor temperature value
15 Outdoor temperature value
17 Selected channel for remote sensor
19 Symbol when snooze function is activated
6 / 10
3 4
2
14
15 13
4 CH button (channel control)
6 DOWN button (Value setting downwards)
8 Set button (Basic settings)
10 Battery compartment (Base station)
12 Battery compartment cover (Remote
sensor)
14 CH button (Channel setting)
16 Wall mount
5 6 7 8
12 11
2 Standard: Current time; Alarm: Alarm time
4 Symbol for active time zone
6 Current date
8 Symbol for radio signal
10 Indoor humidity information
12 Indoor temperature information
14 Battery level indicator (Remote sensor)
16 Symbol for temperature alarm (highest or low-
est value)
18 Outdoor temperature information
20 Battery level indicator (Remote sensor)
