Washer-Extractors
Cabinet Hardmount
Design 2 and 3 Models
Refer to Page 8 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CHM1786C_SVG
(If this machine changes ownership, this manual must accompany machine.)
Part No. F8429301ENR18
www.alliancelaundry.com
April 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCN020HNF and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems CCN020HNF

Summary of Contents for Alliance Laundry Systems CCN020HNF

  • Page 1 Washer-Extractors Cabinet Hardmount Design 2 and 3 Models Refer to Page 8 for Model Identification Original Instructions Keep These Instructions for Future Reference. CHM1786C_SVG (If this machine changes ownership, this manual must accompany machine.) Part No. F8429301ENR18 www.alliancelaundry.com April 2017...

  • Page 3: Table Of Contents

    Input Voltage Requirements................49 © Copyright 2017, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 4 Beginning of Day..................71 End of Day....................71 Monthly....................... 71 Yearly......................72 Care of Stainless Steel................... 74 Disposal of Unit..................76 China Restriction of hazardous substances (RoHS)....... 77 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 5: Safety Information

    To reduce the risk of poisoning or • Install the washer according the INSTALLATION instruc- tions. Refer to the EARTH/GROUND instructions in the IN- © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 6: Safety Decals

    Any problems or conditions not understood should be reported to the dealer, distributor, service agent or the manufacturer. The following maintenance checks must be performed daily: © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 7 Do not bypass any safety devices in the machine. WARNING Operating the machine with severe out-of-balance loads could result in personal injury and serious equipment damage. W728 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 8: Introduction

    Information in this manual is applicable to Design 2 models or later. Refer to the 12th position of the model number (e.g. *CN040*YVXU 2 001): © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 9 UCY020KNV HCL020ZEV HCU020ZXV SCH020WEV SCN020JCF SCU020LLV UCZ020GNF HCL020ZXV HCU020ZYF SCH020WLF SCN020JCV SCU020LXV UCZ020HNF HCN020GNF HCZ020GNF SCH020WLV SCN020JDF SCU020LYV HCN020GNV ICN020GNF SCH020WXF SCN020JEF SCU020WCF Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 10 HCL030KYF HCU030ZCF SCH030LXV SCN030GNV SCU030LCV UCY030KNV HCL030ZCF HCU030ZCV SCH030LYF SCN030HNF SCU030LDV UCZ030GNF HCL030ZCV HCU030ZEV SCH030LYV SCN030HNV SCU030LEF UCZ030HNF HCL030ZDF HCU030ZLV SCH030WCF SCN030JCF SCU030LEV Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 11 UCU040KNV HCL040ZDF HCU040ZCF SCH040LXF SCL040WYV SCU040KNF UCY040KNF HCL040ZDV HCU040ZCV SCH040LXV SCN040GNF SCU040KNV UCY040KNV HCL040ZEF HCU040ZEV SCH040LYF SCN040GNV SCU040LCV HCL040ZEV HCU040ZLF SCH040LYV SCN040HNF SCU040LDV Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 12 SCU060KNV UCY060KNF HCL060ZCV HCU060ZCF SCH060LYV SCN060JCF SCU060LCV UCY060KNV HCL060ZDF HCU060ZCV SCH060WCV SCN060JCV SCU060LDV HCL060ZDV HCU060ZEV SCH060WEF SCN060JDF SCU060LEV HCL060ZEF HCU060ZLF SCH060WEV SCN060JEF SCU060LLF Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 13: Delivery Inspection

    Refer to Fig- pers before the shipping receipt is signed, or advise the carrier of ure 1 . the condition as soon as it is discovered. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 14: Replacement Parts

    For technical assistance, contact your local distributor or contact: Alliance Laundry Systems Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A. www.alliancelaundry.com Phone: +1 (920) 748-3121 Ripon, Wisconsin © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 15: Specifications And Dimensions

    20.3 [515] 22 [559] 21.9 [556] 25.9 [657] Cylinder volume, ft 2.8 [79.3] 4.2 [119] 6.3 [178] 9.00 [255] 12.9 [365] 15.2 [430] Table 1  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 16 1.28 [0.58] 2.40 [1.09] 4.65 [2.11] 4.65 [2.11] 5.49 [2.49] 10°F/lbs. [10°C/kg] HIGH 1.44 [0.65] 1.74 [0.79] 2.84 [1.29] 5.79 [2.63] 5.79 [2.63] 6.84 [3.10] Table 1  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 17 * For B, Q and X-voltage models = 1 hp [.75 kW] and for N and P-voltage models = 2 hp [1.7 kW] ** 20 and 30 models can be prep for steam and a kit is available for conversion. N/A = Not Applicable Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 18: Machine Dimensions

    CHM2618N_SVG 1. Supply Dispenser 2. Input Power Block Compartment 3. Hot Water Inlet 4. Cold Water Inlet 5. Vacuum Breaker 6. Drain Outlet Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 19 1.5 [3] 1.5 [3] 1.5 [38] 1.5 [38] 1.5 [38] 16.75 [426] 16.75 [426] 19.38 [429] 21.75 [552] 21.75 [552] N/A = Not Applicable Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 20: 80 And 100 Models

    3. Auxiliary Hot Water Inlet 4. Auxiliary Cold Water Inlet 5. Cold Water Inlet 6. Hot Water Inlet 7. Vacuum Breaker 8. Drain Outlet Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 21 16.66 [423] 41.5 [1054] 18.18 [462] 26.15 [664] 21.65 [550] 3.57 [91] 26.15 [664] 56.16 [1426] 30.35 [771] 1.5 [38] 53.57 [1361] 25.25 [641] Table 3 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 22: Mounting Bolt Hole Locations - 20 And 30 Models

    Mounting Bolt Hole Locations – 20 and 30 Models, in. [mm] Specification 2 [51] 2 [51] 26.37 [670] 29.38 [746] 20.88 [530] 23.89 [607] Table 4  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 23 27.92 [709] 32.59 [828] 20.65 [524] 23.5 [597] 26.37 [670] 29.38 [746] 26 [660] 29.02 [737] 22.2 [564] 26.1 [663] 31.19 [792] 37.53 [953] Table 4 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 24: Mounting Bolt Hole Locations - 40 And 60 Models

    2. Front of Mounting Bolt Template 3. Machine Width Figure 5 Mounting Bolt Hole Locations - 40 and 60 Models, in. [mm] Specification 2 [51] 2 [51] Table 5  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 25 37.25 [946] 40.5 [1029] 23.63 [600] 27.5 [699] 30.88 [784] 34.44 [875] 30.63 [778] 34.19 [868] 28.85 [733] 32.29 [820] 41.62 [1057] 46.86 [1190] Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 26: Mounting Bolt Hole Locations - 80 And 100 Models

    Mounting Bolt Hole Locations – 80 and 100 Models, in. [mm] Specification 41.5 [1054] 41.5 [1054] 39.62 [1006] 39.62 [1006] 31.62 [803] 31.62 [803] Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 27 42.72 [1085] 42.72 [1085] Inside 35.43 [900] 35.43 [900] Outside 52.86 [1342] 52.86 [1342] Inside 47.16 [1197] 47.16 [1197] N/A = Not Applicable Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 28: Floor Mounting Layout - 20-60 Models

    5.99 [152] edge of pad (minimum) Distance of machine base to 2.52 [64] 2.51 [64] 2.81 [71] 5.18 [131] edge of pad (minimum) Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 29 Mounted without bases (min- 5.14 [131] 5.12 [130] 4.63 [118] 4.06 [103] imum) Mounted with bases (mini- 5.5 [139] 5.5 [139] 4.88 [124] 4.44 [112] mum) Table 8 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 30 27.6 [702] 28.0 [710] 27.5 [699] (minimum) Distance from front bolt to 5.26 [134] 5.26 [134] 6.19 [157] 8.9 [226] edge of pad (minimum) Table 9 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 31: Floor Mounting Layout - 80 And 100 Models

    24 [610] Distance of machine base to edge of pad (minimum) 4.98 [126] Distance of machine base to edge of pad (minimum) 8 [203] Table 10 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 32 Standard Mount Side-by-Side - 80 and 100 Models, in. [mm] Description 80-100 Distance to wall (minimum) 24 [610] Adjacent unit bolt spacing (minimum) 6 [152] Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 33 Distance to wall (minimum) 24 [610] Adjacent unit bolt spacing (minimum) 10.38 [264] IMPORTANT: When close mounting, bolt machine using inside bolt holes. Table 12 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 34 Back-to-Back Mount (refer to Table 13 ) PHM810N_SVG 1. Front of Machine 2. Machine 2 3. Rear of Machine 4. Machine 1 5. Edge of Concrete Pad Figure 13 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 35 Back-to-Back Mount - 80 and 100 Models, in. [mm] Description 80-100 Adjacent rear bolt spacing (minimum) 33.3 [846] Distance from front bolt to edge of pad (minimum) 8 [203] Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 36: Installation

    Thoroughness of detail must be stressed with all foundation work to ensure a stable unit installation, eliminating possibilities of ex- cessive vibration during extract. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 37: New Foundation

    IMPORTANT: The above instructions and recommenda- tions are conservative specifications for a typical in- stallation based on consultations with a structural en- gineer. Alliance Laundry Systems stands behind all in- stallations meeting these specifications. For alternate installation specifications based on your soil type, lo-...

  • Page 38: Machine Foundation And Pad Installation

    [64 mm] into the existing floor. The reinforcing should be 12 ure 20 and Table 18 . inches [305 mm] on center each way around entire perimeter. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 39: Machine Installation

    1. Existing Floor 2. 3500 PSI (minimum) Concrete 3. Reinforcing Bar 4. Perimeter Reinforcing Bar 5. Compacted Fill (minimum 6 in. [152 mm]) Figure 17 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 40 Tie-in to Existing Floor, in. [mm] 40-60 40-60 (F-speed) (V-speed) Description 20-30 80-100 Required thickness of existing floor 4 [102] 4 [102] 6 [152] 6 [152] (minimum) Table 17  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 41: Machine Mounting And Grouting

    15. Align the mounting holes on the machine with the corre- sponding holes on the elevated base frame. 16. Install a bolt, flat washer and locknut in each mounting hole. 17. Hand tighten each nut. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 42 3. Acrylic Adhesive 4. Anchor Bolt (minimum Grade 5 SAE rating) 5. Concrete 6. Drill Hole Size per Manufacturer Requirements 7. Edge of Pad Figure 19 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 43 1670 [7.51] Static pressure, lbs.-ft [kN-m ] 96 [4.60] 99 [4.74] 100 [4.79] 106 [5.08] 137 [6.56] 147 [7.04] Table 19 2. Floor Load Data continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 44: Drain Connection

    All drain systems must be vented to prevent an air lock or siphon- ing. Use the supplied black rubber adapter and clamps to transition from the machine drain outlet to the 2 inches [51 mm] schedule © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 45 * Drain line must be vented to meet local plumbing codes. 1. Drain Hose 2. Drain Valve 3. Drain Tee 4. Overflow Hose 5. Vent Pipe* 6. Trap (as required by local codes) Figure 22 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 46: Water Connection Requirements

    (2) minutes. 2. Check filters in the machine’s inlet hoses for proper fit and cleanliness before connecting. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 47 Table 22 Suitable air cushions (risers) should be installed in supply lines to prevent “hammering.” Refer to Figure 23 . Alliance Laundry Systems, LLC ranges of front loading commer- Figure 24 cial clothes washing machines have solenoid valves at the inlets.

  • Page 48: Electrical Installation Requirements

    Installation IMPORTANT: Alliance Laundry Systems warranty does not cover components that fail as a result of improper input voltage. Make sure the correct transformer jumper (208 Volt or 240 Volt) is in place. Refer to the “optional” Electrical Service Conversion label located on the back of the machine near the serial plate.

  • Page 49: Input Power Conditioning

    Refer to North American Approval section for mod- el-specific circuit breaker requirements. W810 IMPORTANT: All quick disconnects should comply with the specifications. DO NOT use fuses instead of circuit breakers. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 50: Connection Specifications

    3. Ground Figure 29 Single-Phase Connections (220V) For single-phase input, connect L1, L2 and ground and cap neu- tral as shown in Figure 30 . © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 51: Three-Phase Connections

    National Elec- tric Code, article 250 (current edition). The ground connection must be made to a proven earth ground, not to conduit or water pipes. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 52: Phase Adder

    IMPORTANT: Do not use a phase adder on any ma- chine. Thermal Overload Protector For V-speed machines, the inverter drive provides overload pro- tection for the drive motor. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 53: North American Approval

    Voltage Cycle Phase Wire Amps F and V-Speed Models (unless otherwise noted) X (F-speed) 200–208 50/60 220-240 X (V-speed) 200-208 50/60 220-240 Table 25  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 54 X (F-speed) 200–208 50/60 220-240 X (V-speed) 200–208 50/60 220-240 Standard 200-208 50/60 Electric 220-240 10.0 Heat Standard 440-480 50/60 Electric Heat Table 26  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 55 440-480 50/60 Electric Heat Standard 380-415 50/60 Electric Heat NOTE: Wire sizes shown are for copper, THHN, 90°C conductor per NEC article 310. Table 27 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 56 Electric 10.0 Heat Standard 380-415 50/60 Electric 10.0 Heat NOTE: Wire sizes shown are for copper, THHN, 90°C conductor per NEC article 310. Table 28 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 57 Electric 10.0 Heat Standard 380-415 50/60 Electric 10.0 Heat NOTE: Wire sizes shown are for copper, THHN, 90°C conductor per NEC article 310. Table 29 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 58: Ce Approval

    X (F-speed) 200–208 50/60 220-240 X (V-speed) 200–208 50/60 10/6 220-240 Standard 200-208 50/60 Electric Heat 220-240 Standard 380–415 50/60 Electric Heat Table 31  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 59 Electric Heat P (V-Speed) Standard 380-415 50/60 Electric Heat NOTE: Wire sizes shown are for copper, THHN, 90°C conductor per NEC article 310. Table 32 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 60 Phase Wire Amps F-Speed Models Standard 440-480 50/60 Electric Heat 200–208 50/60 12/8 16/10 220-240 Standard 200–208 50/60 Electric Heat 220-240 16.0 Table 34  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 61 Amps F and V-Speed Models Standard 440-480 50/60 Electric Heat 200–208 50/60 17/11 20/16 220-240 Standard 200–208 50/60 Electric Heat 220-240 16.0 Table 35  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 62: Specifications

    Cycle Phase Wire Amps Standard 380-415 50/60 Electric Heat NOTE: Wire sizes shown are for copper, THHN, 90°C conductor per NEC article 310. Table 35 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 63: Steam Requirements (Steam Heat Option Only)

    Number of liquid chemical supply signals W699 (OPL only) IMPORTANT: DO NOT remove the red jumper wire from Number of supply compartments the terminal strip. Table 37  continues... © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 64 2. Internal Control Transformer 3. RELAY COM Terminal 4. External Dispenser Input Signal Common 5. Red Jumper Wire 6. 24VAC Terminal 7. 24VAC COM Terminal Figure 35 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 65: Chemical Injection Using External Ac Power Source

    Refer to Figure 37 for Internal Supply Connection or Figure 38 for Ex- W699 ternal AC Connection. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 66 2. K1 Contact 3. Supply 1 Signal Figure 37 = Neutral = Power PHM824N_SVG 1. ES1 Power supply 2. K1 Contact 3. Supply 1 Signal Figure 38 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 67: Connection Of External Liquid Supplies

    NOTE: Do not attempt to make chemical injection sup- ply pump electrical connections to points other than those provided specifically for that purpose by the fac- tory. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 68: Start Up

    1. If rotation is not counterclockwise, disconnect power to ma- chine. 2. Have a qualified electrician reverse any two motor leads at the inverter terminal block. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 69: Operation

    11. When cycle is complete, display shows “00”. CHM2244N_SVG Figure 43 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 70 CHM2228N_SVG 1. Liquid Detergent 2. Powder Detergent b. BLEACH CHM2229N_SVG CHM2230N_SVG 3. Liquid Bleach 4. Powder Bleach c. SOFTENER CHM2231N_SVG 5. Liquid Softener Table 38 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 71: Maintenance

    NOTE: Disconnect power to the machine at its source b. Verify that door and door gasket do not leak. before performing the monthly maintenance proce- dures. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 72: Yearly

    5. Use compressed air to ensure that all electrical components including coin acceptors (if applicable) are free of moisture and dust. 6. Tighten door hinges and fasteners, if necessary. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 73 (refer to Figure 46 ) when mod- erate pressure of is applied to the point midway be- tween pulleys. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
  • Page 74 Grouting section, if necessary. Inspect grout for cracking. IMPORTANT: All torque joints must remain dry (non-lu- .09 [2] bricated). .09 [2] .38 [10] Table 41 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 75: Care Of Stainless Steel

    Locate the pump and tubing below the machine’s injection point to prevent siphoning of chemicals into the machine. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 76: Disposal Of Unit

    MIX1N_SVG Figure 47 © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...

  • Page 77: China Restriction Of Hazardous Substances (Rohs)

    NOTE: The referenced Environmental Protection Use Period Marking was determined according to normal oper- ating use conditions of the product such as temperature and humidity. This product under normal use, durable years of environmental protection is 15 years. © Copyright, Alliance Laundry Systems LLC - Part No. F8429301ENR18 DO NOT COPY or TRANSMIT...
