- Page 1 Home Automatic Washers Refer to Page 6 for Model Numbers W001C Part No. 201143R4 www.comlaundry.com June 2009...
-
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 4 Timer No. 38881 Cycle Sequence......44 Timer No. 39445 and 201013 Cycle Sequence ............. 46 Timer No. 200604 Cycle Sequence...... 47 Timer No. 200927 Cycle Sequence...... 48 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143...
-
Page 5: Section 1 - Safety Information
• Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the product is properly grounded and to reduce the risk of fire, electric shock, serious injury or death. W006R2 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 6 The manufacturer will not be responsible for any injury or property damage arising from improper service and/or service procedures. W008 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143...
-
Page 7: Locating An Authorized Servicer
Alliance Laundry Systems also recommends contacting an authorized technician and using authorized factory parts. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 8: Section 2 - Introduction
LWS01A*-1000 LWS01A*-1088 LWS01A*-3088 LWS01A*-3300 LWS01M*-1000 LWS01M*-3088 LWS01M*-3300 LWS01N*-3088 LWS01N*-3300 LWS11A*-3062 LWS11N*-3062 LWS16A*K * Add Letter To Designate Color. L – Almond W – White Q – Bisque © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... - Page 9 LWS17M*-1000 LWS17M*-1127 LWS17M*-3000 LWS17M*-3022 LWS17M*-3050 LWS17M*-3300 LWS17M*-3322 LWS17M*B3020 LWS17M*B3069 LWS17N*-1000 LWS17N*-1127 LWS17N*-3000 * Add Letter To Designate Color. L – Almond W – White Q – Bisque 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
- Page 10 LWZ17A*-3000 LWZ17A*B3020 LWZ17A*B3069 LWZ17M*-3000 LWZ17M*B3020 LWZ17M*B3069 LWZ17N*-3022 LWZ17N*B3020 LWZ17N*B3069 LWZ20M*-3300 LWZ20N*-3300 LWZ22M*-1102 * Add Letter To Designate Color. L – Almond W – White Q – Bisque © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143...
- Page 11 Washtub (cu. ft.) LWZ22N*-1102 LWZ42M*-1102 LWZ42N*-1102 LWZ52M*-1102 LWZ52N*-1102 LWZ77M*-1102 LWZ77N*-1102 ZWN311SP111CW01 ZWN412SP111CW01 ZWN432SP111CW01 * Add Letter To Designate Color. L – Almond W – White Q – Bisque 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 12: How Your Washer Works
Introduction How Your Washer Works Pressure Switch Temperature Switch Timer Mixing Valve Agitator Washtub Outer Transmission Motor Pump W407SE3A © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... - Page 13 After the wash agitation is completed, the timer advances into the first spin. During spin, the motor reverses turning in the clockwise direction to spin the water out of the washtub. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 14: Customer Service
Alliance Laundry Systems at (920) 748-3950 numbers are located on nameplate(s) as shown. for the name and address of the nearest authorized parts distributor. For technical assistance, call (920) 748-3121. W429S Nameplate © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 15: Section 3 - Troubleshooting
• Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the washer is properly grounded. W003 IMPORTANT: Refer to Wiring Diagram for aid in testing washer components. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 16: No Hot Water
Is there Refer to replace screen. faucet clogged? broken, loose appropriate or incorrect wiring wiring? diagram. TLW371S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 17: No Cold Water
Is there Refer to broken, loose appropriate Is temperature Test switch or incorrect wiring switch and replace if wiring? diagram. inoperative? inoperative. TLW372S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 18: No Warm Water
There is no warm water. Is there no Refer to No Hot hot water? Water paragraph . Is there no Refer to No Cold cold water? Water paragraph . TLW362S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 19: Water Fill Does Not Stop At Proper Level
Blow air through water in hose to remove pressure water or replace hose? hose. Is there broken, Refer to loose, appropriate shorted or wiring diagram. incorrect wiring? TLW348S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 20: Timer Does Not Advance
Allow completion wiring diagram. operation? wiring? of those steps. Some cycles (delicate) have additional pauses. Refer to diagram for information on time required. TLW363S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 21: Motor Does Not Run
Is timer circuits (refer inoperative? to wiring diagram) and Is there replace if Refer to broken, inoperative. appropriate loose or wiring diagram. incorrect wiring? TLW364S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 22: No Agitation
1 to Close lid or test inoperative? 3. Replace if Is lid open switch and inoperative. or lid switch replace if inoperative? inoperative. TLW358S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 23: Constant Agitation
Is there shorted or Refer to appropriate incorrect wiring diagram. wiring? Repair or Does washer replace agitate during transmission spin cycle? assembly. TLW365S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 24: Washer Overheats, Cycles On Motor Thermal Protector, Switch Actuator Kicks In And Out
Check for foreign objects between inner and outer tubs. Is there a bind Replace pump. in water pump? TLW366S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 25: Slow Spin
(through Serial and any other No. 001113645)? damaged parts. Is there no clearance Replace pads between and brake brake pads assembly. and discs? TLW359S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 26: No Spin
Remove drive motor and Is motor pulley roll pin sheared replace roll pin and any other (through Serial No. damaged 001113645)? parts. TLW367S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 27: Constant Spin
Is there shorted or Refer to appropriate incorrect wiring diagram. wiring? Is lid switch Replace lid inoperative? switch. TLW368S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 28: Washer Stops In Cycle; Quits After A Couple Loads; Is Intermittent
Is there move freely. will not turn? Refer to broken, loose appropriate wiring or incorrect diagram. wiring? TLW356S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 29: Washer Is Locked Up Or Binding
Is there a bind in water Replace pump. pump? Is there a bind in transmission Repair or replace during transmission. agitation only? TLW369S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 30: Outer Tub Does Not Empty
Outer tub does not empty. Is drain hose Straighten hose. kinked? Is water pump Replace pump. inoperative? Is there an obstruction Remove obstruction. in outer tub outlet hose? TLW370S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 31: Excessive Vibration
"spongy" condition. built-up floor? Is friction Replace ring friction ring. broken? Are cabinet Replace with screws correct screws incorrect or or tighten. loose? TLW357S 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 32: Water Leaking From Outer Tub
Tighten clamp. Is pressure Replace leaking at hose or pressure hose clamp? accumulator and/or leaking? accumulator. Is outer tub cover Replace gasket. gasket leaking? TLW341S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 33: Section 4 - Adjustments
If these locknuts are not tight, washer will not remain stationary during operation. Level Washer Base Locknut Leveling Rubber Foot W456SE3A Figure 1 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 34: Pressure Switch
When testing, pressure switch has continuity from terminal 1 to 2 when empty and 1 to 3 when full. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 35: Section 5 - Test Procedures
“P” to Blue (2-speed motor) Refer to Blue to White and Violet to White. (approximate) Closed “P” to Blue (2-speed motor) Open low (6 pole) winding run switch. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 36: Mixing Valve Solenoid Test Procedure
L1 - 2, L2 - 2 Warm Cold L1 - 1, L1 - 2 Warm Warm L1 - 1, L1 - 2, L2 - 2 Cold Cold L1 - 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 37: Section 6 - Cycle Sequence Charts
Section 6 Cycle Sequence Charts CYCLE SEQUENCE CHARTS FOUND ON THE FOLLOWING PAGES ARE FOR TIMERS COVERED IN THIS MANUAL. 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 38: Timer No. 37004 Cycle Sequence
FAST 4:07 PAUSE (:40) & DRAIN 3:00 INTERVAL DRAIN & SPIN FAST 1:51 DRAIN/SPIN/SPRAY COLD FAST DRAIN & SPIN FAST 4:31 (continued) TIMER NO. 37004 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... - Page 39 DRAIN & SPIN 2:30 2:30 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37004 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 40: Timer No. 37922 Cycle Sequence
SPIN MEDIUM 2:40 RINSE FILL & AGITATE MEDIUM 3:00 SPIN MEDIUM 3:00 OFF/PAUSE CYCLE END OR PAUSE FOR EXTRA RINSE 3:00 (continued) TIMER NO. 37922 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... - Page 41 MEDIUM 3:00 3:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37922 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 42: Timer No. 37925 Cycle Sequence
SLOW 4:05 3:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37925 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 43: Timer No. 37927 Cycle Sequence
SLOW 4:00 4:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37927 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 44: Timer No. 37928, 37929, 37930 And 200885 Cycle Sequence
*On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37928, 37929, 37930 AND 200885 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 45: Timer No. 37995 Cycle Sequence
FAST 4:45 3:36 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 37995 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 46: Timer No. 38881 Cycle Sequence
H,W,C 2:35 SPIN SLOW 3:00 SPIN & SPRAY SLOW SPIN SLOW 2:35 RINSE FILL & AGITATE SLOW 3:00 SPIN SLOW 3:00 (continued) TIMER NO. 38881 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... - Page 47 SLOW 3:00 3:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 38881 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 48: Timer No. 39445 And 201013 Cycle Sequence
7:30 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 39445 AND 201013 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143... -
Page 49: Timer No. 200604 Cycle Sequence
FAST 6:00 3:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 200604 CYCLE SEQUENCE 201143 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 50: Timer No. 200927 Cycle Sequence
FAST 3:00 3:00 *On Single Speed Model Washers, All Speeds are Fast. KEY: H = HOT W = WARM C = COLD TIMER NO. 200927 CYCLE SEQUENCE © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 201143...
