Aircraft Diagram

7
6
3
4
1. FPV Camera
2. Forward Vision System
3. DJI Gimbal Connector V2.0 (DGC2.0)
4. Gimbal and Camera Detachment Button
5. Frame Arms
6. Motors
7. Propellers
8. ESC LEDs
9. Landing Gear
10. Upward Infrared Sensor
5
1
2
20
Folded
10
11
8
9
11. Aircraft Status Indicator
12. Linking Button/Linking Indicator
13. USB Port
14. USB Mode Switch
15. Battery Removal Button
16. Intelligent Flight Batteries
17. Battery Level Indicators
18. Power Button
19. Downward Vision System
20. Micro SD Card Slot
MATRICE 200 User Manual
12 13 14
15
16
17
18
19
©
2017 DJI All Rights Reserved.
