Summary of Contents for BLAUBERG Sileo V2
- Page 1 Sileo V2 OPERATION MANUAL...
- Page 2 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Disconnect the fan from power supply prior to any connection, servicing and repair operations. Only duly qualified electricians with valid electrical permit for electric operations at the units with operating voltage up to 1000 V are allowed for mounting and maintenance after careful study of the present user's manual.
- Page 3 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING While mounting the fan do not compress the casing! Deformation of the casing may result in the motor jam and noisy operation. Misuse of the fan and any unauthorised modifications are not allowed.
- Page 4 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Do not use the fan in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the fan intake or extract vents in order to ensure the efficient stream.
- Page 5 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING The product is allowed to be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge provided that they have been given supervision or instruction regarding a safe use of the product and understand the risks involved.
-
Page 6: Delivery Set
Read the user's manual carefully before proceeding with installation works. Compliance with the manual requirements ensures reliable operation and long service life of the product. Keep the user's manual available as long as you use the product. You may need to re-read the information on the product servicing. DELIVERY SET 1. -
Page 7: Operation Indication
Fan mounting steps are shown in Fig. 4-12. Wiring options are shown in Fig. 13-18. Adjustment of the turn-off delay timer, interval timer of humidity sensor settings is shown in Fig. 19. OPERATION INDICATION Basic model and model with a switch: The light indicator glows orange during the fan operation. -
Page 8: Manufacturer's Warranty
MANUFACTURER'S WARRANTY We hereby declare that the product complies with the essential protection requirements of Electromagnetic Council Directive 2004/108/EC, 89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. This certificate is issued following test carried out on samples of the product referred to above. - Page 9 Redesign or engineering changes to the fan. Replacement and use of any assemblies, parts and components not approved by the manufacturer. Fan misuse. User's violation of the fan control regulations. Fan connection to the power mains with a voltage different from the one stated in the user's manual. Fan breakdown due to voltage surges in the power mains.
- Page 10 Sileo V2 100 Sileo V2 125 D, mm B, mm H, mm L, mm L1, mm...
- Page 12 Sileo V2 100/125, Sileo V2 100/125 S Low speed Sileo V2 100/125 (low speed) Fan does not run Switch S is ON Fan runs with low speed Sileo V2 100/125 S (low speed) Switch S is OFF High speed Sileo V2 100/125 (high speed)
- Page 13 Sileo V2 100/125 (low and high speed) speed Fan does not run Switch S is speed Sspeed in position L or LT Fan runs with Fan runs with Sileo V2 100/125 S (low and high speed) high speed ow speed speed Switch S is...
- Page 14 Sileo V2 100/125 T 6/12/24 hours Interval timer Fan runs with Fan does not run low speed Activation of the interval Switch S is Switch S is timer (6/12/24 hours) Fan runs with Activation of turn-on delay Activation of turn-on delay...
- Page 15 Sileo V2 100/125 H Fan runs with low speed Switch S is Humidity is above set point Activation of turn-on delay timer 60 seconds Activation of turn-on delay timer 60 seconds Switch S is OFF during countdown of turn-on delay...
- Page 16 Sileo V2 100/125 T/H Turning of the interval timer on and its adjustment is performed with the potentiometer Ti. To turn the interval timer і off set the potentiometer Ti into the leftmost position. Rotation of the potentiometer for 1/3 clockwise sets the interval timer operation for 6 hours, rotation of the potentiometer for 2/3 clockwise sets the interval timer operation for 12 hours, rotation of the potentiometer clockwise in the rightmost position sets the interval timer operation for 24 hours.
- Page 17 Latches...
- Page 18 notes...
- Page 19 Sileo V2 ACCEPTANCE CERTIFICATE The fan is recognized as serviceable. Stamp of the acceptance inspector Manufacturing date Sold by (name of the vendor, stamp of the shop) Date of sale WARRANTY CARD...
- Page 20 Sileo V2 Sileo V2 v1(1) EN...
