Summary of Contents for BLAUBERG VENTO inHOME Wi-Fi

  • Page 1 Single-room reverSible energy recovery ventilator vento inHome Wi-Fi vento inHome Wi-Fi m vento inHome Wi-Fi mini vento inHome Wi-Fi mini m USER’S MANUAL...
  • Page 2: Table Of Contents

    The manual contains information about purpose, technical details, operating principle, design, and installation of the VENTO inHOME Wi-Fi (mini) (M) unit and all its modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
  • Page 3 Wi-Fi (mini) (m) www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
  • Page 4: Purpose

    L07 – 700 mm Ventilator series VENTO inHOME Wi-Fi – a series of reversible ventilators controlled via Wi-Fi with a duct diameter of 160 mm and a nominal capacity of 50 m VENTO inHOME Wi-Fi mini – a series of reversible ventilators controlled via Wi-Fi with a duct diameter...
  • Page 5: Technical Data

    Wi-Fi (mini) (m) www.blaubergventilatoren.de TECHNICAL DATA The temperature in the room where the indoor unit of the ventilator is installed must be in the range from +1 ˚C to +40 ˚C with relative humidity up to 65 % (no condensation build-up).
  • Page 6: Unit Design And Operating Principle

    The ventilator consists of an indoor unit with a decorative front panel, a fan unit, a heat exchanger unit, located inside the air duct and the outer ventilation hood. In the VENTO inHOME Wi-Fi mini and VENTO inHOME Wi-Fi mini M models, the fan and heat exchanger units are combined in a single cartridge.
  • Page 7 The shutter opening/closing mechanism operates with a delay of 1 to 5 minutes after the unit is switched on or off. The indoor unit of the VENTO inHOME Wi-Fi M ventilators does not have shutters. The air duct in these models can only be blocked by pushing the front panel of the ventilator as far as it will go, as shown in the figure below.
  • Page 8 If necessary, you can set different ventilator speeds for different time intervals by day of the week in the «Weekly Schedule» section of the Blauberg Home mobile app. For the week schedule to work correctly, you need to set the current date and time correctly in the «Date and Time»...
  • Page 9: Installation And Set-Up

    Wi-Fi (mini) (m) www.blaubergventilatoren.de MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. DO NOT BLOCK THE AIR DUCT OF THE INSTALLED VENTILATOR WITH DUST ACCUMULATING MATERIALS, SUCH AS CURTAINS, CLOTH SHUTTERS, ETC. AS IT PREVENTS AIR CIRCULATION IN THE ROOM.
  • Page 10 Wi-Fi (mini) (m) www.blaubergventilatoren.de 1. Prepare a round core hole in the outer wall. The figure below shows the minimum distance from the hole to the surrounding objects. The hole diameter depends on the specific ventilator model. The corresponding values are given in the table.
  • Page 11 Wi-Fi (mini) (m) www.blaubergventilatoren.de 5. Separate the front panel of the indoor unit from its back part. To do this, press the round buttons on the top and bottom of the indoor unit simultaneously, as shown on the left in the figure below.
  • Page 12 Wi-Fi (mini) (m) www.blaubergventilatoren.de 8. Route the power cable as figured below and connect the ventilator to power mains in compliance with the external wiring diagram, see section Connection to power mains. Secure the power cable with the clamp.
  • Page 13 Wi-Fi (mini) (m) www.blaubergventilatoren.de Insert the sound-absorbing layer in the air duct. Roll the layer of the sound absorbing material to match the air duct diameter. The protecting paper layer must be outside. Insert the sound absorbing roll into the cartridge against stop. Make a mark at the end of the air duct, remove the material and cut the roll as marked.
  • Page 14: Connection To Power Mains

    Wi-Fi (mini) (m) www.blaubergventilatoren.de CONNECTION TO POWER MAINS The ventilator is rated for connection to single-phase AC 100-240 V/50 (60) Hz power mains. For electric installations use insulated, flexible conductors (cables, wires) with the minimum cross section of 0.5 up to 0.75 mm power cables and 0.25 mm...
  • Page 15 Wi-Fi (mini) (m) www.blaubergventilatoren.de PRE-SETTING OF THE VENTILATOR Prior to operating the ventilator set it up using the DIP switch. It is located on the controller circuit board. To access the DIP switch, take off the front panel of the indoor unit and uplift the rubber plug that covers the switch.
  • Page 16 Wi-Fi (mini) (m) www.blaubergventilatoren.de The figure below shows the control buttons on the indoor unit and the remote control with a brief description of their function. Turning the ventilator on/o Speed/Standby The speed selection sequence is as follows: I-II-III-Standby.
  • Page 17 Wi-Fi (mini) (m) www.blaubergventilatoren.de VENTILATOR CONTROL WITH THE BUTTONS ON THE INDOOR UNIT The table below shows the buttons and indicators on the indoor ventilator unit with a detailed description of their purpose and functionality. The speed selection sequence is follows: I-II-III-Standby. All ventilators combined into one network run at the speed set by the master ventilator.
  • Page 18 Press any speed setting key to deactivate the timer or press the timer control button once again. VENTILATION UNIT OPERATION WITH THE MOBILE APPLICATION BLAUBERG HOME Download the Blauberg Home application and install it on the mobile device. Blauberg Home – App Store Blauberg Home –...
  • Page 19 Wi-Fi (mini) (m) www.blaubergventilatoren.de WIRELESS CONNECTION OF SEVERAL VENTILATORS Ventilators can be combined into a group in which one ventilator shall act as the master and the others shall be connected to it as slaves. If the ventilator is a master ventilator, the slave ventilators and mobile devices connect to it via Wi-Fi. The master ventilator is controlled using a mobile device, remote control or touch buttons on the ventilator casing.
  • Page 20 Wi-Fi (mini) (m) www.blaubergventilatoren.de VENTILATOR WIRELESS CONNECTION DIAGRAMS Wiring diagram 1 Connection of up to 8 Slave units or mobile devices to the Master unit with its own wireless Master with a Wi-Fi access point access point. In case of connection of 8 Slave units to the Master unit with its own wireless access point a mobile device may not be connected.
  • Page 21 Set the DIP switches on each ventilator to the position that corresponds to its role in the group (see «Position of the DIP switch»). • Next, configure the Wi-Fi settings of the master ventilator by following the instructions in the Blauberg Home mobile app. •...
  • Page 22: Technical Maintenance

    Wi-Fi (mini) (m) www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION Maintenance of the ventilator means regular cleaning of the ventilator surfaces of dust and cleaning and replacement of the filters. To enable access to the main units, follow the procedure described below.
  • Page 23 Wi-Fi (mini) (m) www.blaubergventilatoren.de 4. Clean filters once they become dirty. Upon elapse of the set number of days the filter replacement indicator (Filter) starts glowing. Depending on the dustiness of the air, the duration of the ventilator operation until the next filter cleaning may be different. The duration of the period when the filter replacement indicator is turned on can be set using the mobile application in the range from 70 to 365 days of continuous operation (by default, the Manufacturer’s recommended value is set to 90 days).
  • Page 24: Storage And Transportation Regulations

    Wi-Fi (mini) (m) www.blaubergventilatoren.de POSSIBLE FAULTS AND TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line is connected No power supply. correctly, otherwise troubleshoot the connection When switching on the error. ventilator, the fan does not Turn the ventilator off.
  • Page 25: Manufacturer's Warranty

    Wi-Fi (mini) (m) www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 26 Wi-Fi (mini) (m) www.blaubergventilatoren.de...
  • Page 27: Certificate Of Acceptance

    Wi-Fi (mini) (m) www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Single-room reversible energy recovery ventilator Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
