Introduction

Equipment information to install the GTX 3X5 and optional accessories is in this section. Cabling is made
by the installing agency to fit each particular aircraft. Always follow permitted avionics installation
procedures as outlined in AC 43.13-1B and AC 43.13-2B or later FAA approved revisions.
3.2

Unit Configurations

The GTX 3X5 is available in different configurations.
Model Mount
GTX 335 Panel
GTX 335 NV Panel
GTX 335, GPS Panel
GTX 335R Remote
GTX 335R Remote
GTX 335R, GPS Remote
GTX 335R, GPS Remote
GTX 345 Panel
GTX 345, GPS Panel
GTX 345R Remote
GTX 345R Remote
GTX 345R, GPS Remote
GTX 345R, GPS Remote
190-01499-02
Rev. 4
Table 3-1 GTX 3X5 Configurations
ADS-B
GPS Unit P/N
In
011-03300-00
011-03300-20
X 011-03300-40
011-03301-00
011-03301-00
X 011-03301-40
X 011-03301-40
X 011-03302-00
X X 011-03302-40
X 011-03303-00
X 011-03303-00
X X 011-03303-40
X X 011-03303-40
GTX 3X5 Transponder TSO Installation Manual
Unit Only Kit Standard Kit
010-01214-00 010-01214-01
010-01214-20 010-01214-21
010-01214-40 010-01214-41
010-01215-00 010-01215-01
010-01215-00 010-01215-02
010-01215-40 010-01215-41
010-01215-40 010-01215-42
010-01216-00 010-01216-01
010-01216-40 010-01216-41
010-01217-00 010-01217-01
010-01217-00 010-01217-02
010-01217-40 010-01217-41
010-01217-40 010-01217-42
Mount
Type
Standard
Vertical
Standard
Vertical
Standard
Vertical
Standard
Vertical
Page 3-2
