3 INSTALLATION OVERVIEW

3.1 Introduction

Equipment information for installing the GTX 3x5 and related optional accessories is provided in this
section. Installation of the GTX 3x5 should follow the information detailed in this manual and
airworthiness approved data. Cabling is fabricated by the installing agency to fit each particular aircraft.
Always follow acceptable avionics installation practices as outlined in AC 43.13-1B and AC 43.13-2B or
later FAA approved revisions.

3.2 Unit Configurations

The GTX 3x5 is available in the following configuration part numbers.
Model Mount
GTX 325 Panel
GTX 335 Panel
GTX 335 NV Panel
GTX 335, GPS Panel
GTX 335R Remote
GTX 335R,
Remote
GPS
GTX 345 Panel
GTX 345, GPS Panel
GTX 345R Remote
GTX 345R,
Remote
GPS
190-01499-02
Rev. 1
ADS-B
GPS Unit P/N
In
011-02974-00
011-03300-00
011-03300-20
X 011-03300-40
011-03301-00
X 011-03301-40
X 011-03302-00
X X 011-03302-40
X 011-03303-00
X X 011-03303-40
Unit Only Standard
Kit Kit
010-01083-00 010-01083-01
010-01214-00 010-01214-01
010-01214-20 010-01214-21
010-01214-40 010-01214-41
010-01215-01
010-01215-00
010-01215-02
010-01215-41
010-01215-40
010-01215-42
010-01216-00 010-01216-01
010-01216-40 010-01216-41
010-01217-01
010-01217-00
010-01217-02
010-01217-41
010-01217-40
010-01217-42
GTX 3x5 TSO Installation Manual
Mount
Type
Horizontal
Vertical
Horizontal
Vertical
Horizontal
Vertical
Horizontal
Vertical
Page 3-1
