Introduction

See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.

Radio Overview

Item Key Description
DISTRESS Lift the door and press to send a DSC distress
call with a programmed MMSI number
(Entering Your MMSI Number, page
VOL/SQ Press the dial to switch between volume or
squelch.
Rotate the dial to adjust the volume or squelch
level.
Select the key that corresponds to the on-
screen item to select the item.
SELECT On the home screen, rotate the dial to change
the channel.
On the home screen, press the dial to toggle
weather channels
and Alerts, page
Rotate the dial to highlight an item in a list.
Press the dial to select an item.
PWR Hold to turn the radio on and off.
North America: Press to toggle between preset channels.
16/9
International:
16+
DSC Select to view a menu of DSC options.
HI/LO Select to change the transmission mode and
power settings.
CLEAR Select to return to the previous menu option.
Select to cancel or mute an incoming DSC call.
MENU From the home screen, select to view
configuration options.
From a menu, select to return to the home
screen.
Introduction
WARNING
VHF 110
VHF 210 AIS
(NOAA Weather Broadcasts
®
4).

Handset Overview

PTT
or
North America: 16/9
International: 16+

Home Screen

Current radio system status, settings, and alerts.
Current International, Canadian, or USA frequency band
4).
*Current latitude
*Current longitude
*Current time
**Current speed over ground (SOG) or course over ground (COG)
Soft-key functions change depending on your current activity
Current working channel
*The current latitude, longitude, and time appear when the
transceiver is connected to a GPS device. You can enter data
manually when the transceiver is not connected to a GPS
device.
** The current SOG and COG appear when the transceiver is
connected to a GPS device, and the option is enabled in the
menu (Number Settings, page

System Status Icons

Icon Status
Receiving an incoming signal
Transmitting
Transmitting at 25 W
Transmitting at 1 W
Saved channel
Local receiver mode, often used in areas with radio frequency
interference (harbors)
ATIS enabled
Position tracking enabled
Auto channel changing disabled
Incoming or missed DSC call
Hold to broadcast.
Select to change the channel on the radio.
Select to toggle between preset channels.
9).
1
