- Page 1 H E AT S T R I P E l e c t r i c P o r t a b l e H e a t e r Model No. THH1800AP Scan here for HEATSTRIP Installation video www.heatstrip.com.au...
-
Page 2: Table Of Contents
Manual # Rev A - Date:2017/02/09 Contents Product Overview Specifications Product Features & Benefits Installation Requirements Hardware Pack Hardware Tools Required Parts Diagram Product Part List Assembly Instructions Electric Heater Assembly Instructions Maintenance and Safety Replacement Parts Warranty For repairs or replacement parts, please contact: Thermofilm Australia Pty Ltd 17 Johnston Court, Dandenong South, Victoria 3175, Australia Telephone: (03) 9562 3455... -
Page 3: Specifications
WEIGHT LEAD PLUG (WATTS) (AMPS) (Kg) LENGTH (mm) THH1800AP 1800 1104 (w) x 670 (d) x 2150 (h) 3000 HEATER TYPE High intensity electric radiant overhead heater with high surface area profiled alloy POWER 230-240 Volts Nominal at 50—60 Hertz, Single Phase CONNECTION 3 Core Cable 2.5mm... -
Page 4: Hardware Pack
PART # PART DESCRIPTION PURPOSE OF PART P06033001A Hardware Pack For use in assembly of THH1800AP S112M06102 Pan Head Screw M6 x 10mm Install Base Brackets to Base S112M06102 Pan Head Screw M6 x 10mm Install Lower Post to Base S112M06102 Pan Head Screw M6 x 10mm Install Side Panels to Lower Post &... - Page 5 Parts List of THH1800AP Description Part No Wheel P03351004D Skid Pad P05518114I Base P03351001D Kick Plate P03351002D Fixed Bracket P03351003D Post - Rear, Lower P03351005D Post - Rear, Upper P03351006D Post - Front, Lower P03351007D Post - Front, Upper P03351008D...
-
Page 6: Parts Diagram
Parts Diagram Description Wheel Skid Pad Base Kick Plate Fixed Bracket Post—Rear, Lower Post—Rear, Upper Post—Front, Lower Post—Front, Upper Side Panel / Left Side Panel / Right Rear Panel Heater Bracket Base Bracket Electric Heater Model THH1800A... -
Page 7: Assembly Instructions
Assembly Instructions CAUTION: To assemble this heater, you should obtain assistance from another person when handling the larger, heavier pieces. Install Base Brackets (Optional for fixed installation) Remove all the packing materials and place on a non- abrasive surface. ... - Page 8 Assembly Instructions Install Rear Panel Install the Rear Panel to the Lower Post using 2 Pan Head screws. (M6x10mm) Install the Rear Panel to the Side Panels using 4 Pan Head Screws (M5x10mm) then tighten all the screws securely. Pan Head Screw M6x 10mm Pan Head Screw M5x10mm QTY: 2...
- Page 9 Assembly Instructions Install the Upper post Assembly With the help of an assistant, insert and slide top post over front assembly slip joint to the lower post. Before sliding the top post to the lower post an assistant is required to hold the upper post while you lower the cord though the centre of the lower post concealing the 3 pin cord.
- Page 10 Carrying out the cleaning process at least every three months will reduce the amount of build up and keep the Heatstrip in good condition. If the heater is in a corrosive environment eg. salt spray, we recommend that you clean your heater with a light spray of fresh water every week.
-
Page 11: Warranty
Thermofilm warrants to the original owner that HEATSTRIP Electric Portable Heater products will be free from defects in materials and workmanship for a period of 24 months from the date of purchase for residential applications and 12 months for commercial applications in accordance with the following warranty terms and conditions.
